This workflow follows the Google Drive → HTTP Request recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "App Screenshot Generator - Multi-Device App Store",
"nodes": [
{
"parameters": {
"content": "## \ud83d\udcf1 App Screenshot Generator\n\n**What this workflow does:**\nAuto-generates App Store screenshots for iPhone, iPad, MacBook mockups from CI/CD pipeline\n\n**Requirements:**\n- SudoMock API key ([Free tier](https://sudomock.com))\n- Device mockup PSDs uploaded (iPhone 15, iPad Pro, MacBook)\n- Webhook endpoint configured\n- Screenshot URLs (from app build)\n\n**Perfect for:**\n- App Store submission automation\n- Product launch assets\n- Multi-language app screenshots",
"height": 388,
"width": 412,
"color": 4
},
"id": "d2981bd3-8406-4fd0-bc37-07433afe1890",
"name": "Sticky Note",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
8736,
3776
]
},
{
"parameters": {
"httpMethod": "POST",
"path": "app-screenshots",
"responseMode": "lastNode",
"options": {}
},
"id": "ed5f62f7-2f03-4e08-8020-86c85b540201",
"name": "Webhook Trigger",
"type": "n8n-nodes-base.webhook",
"typeVersion": 1.1,
"position": [
8736,
4176
],
"notes": "Trigger from CI/CD or manual with screenshot URLs"
},
{
"parameters": {
"jsCode": "// Expected webhook payload:\n// {\n// \"screenshots\": [\n// {\"name\": \"home\", \"url\": \"https://...\"},\n// {\"name\": \"profile\", \"url\": \"https://...\"}\n// ],\n// \"appName\": \"MyApp\",\n// \"version\": \"1.2.0\"\n// }\n\nconst payload = $input.item.json.body;\n\nreturn [{\n json: {\n screenshots: payload.screenshots || [],\n appName: payload.appName || 'App',\n version: payload.version || '1.0.0'\n }\n}];"
},
"id": "818e2d50-2c65-4f25-9226-d82e23b32cdd",
"name": "Parse Webhook Data",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
8960,
4176
]
},
{
"parameters": {
"operation": "listMockups",
"additionalOptions": {}
},
"id": "3e80de43-2fb3-485a-81f1-7ae458438751",
"name": "Get Device Templates",
"type": "n8n-nodes-sudomock.sudoMock",
"typeVersion": 1,
"position": [
9184,
4176
],
"notes": "Get uploaded device mockups: iPhone-15-Pro, iPad-Pro, MacBook-Pro"
},
{
"parameters": {
"jsCode": "const screenshots = $('Parse Webhook Data').item.json.screenshots;\nconst devices = $input.item.json.data.mockups;\nconst appInfo = $('Parse Webhook Data').item.json;\n\nconst combinations = [];\n\nfor (const screenshot of screenshots) {\n for (const device of devices) {\n const smartObject = device.smart_objects.find(so => so.name === 'Screen');\n \n if (!smartObject) continue;\n \n combinations.push({\n screenshotName: screenshot.name,\n screenshotUrl: screenshot.url,\n deviceName: device.name,\n deviceUuid: device.uuid,\n smartObjectUuid: smartObject.uuid,\n appName: appInfo.appName,\n version: appInfo.version,\n fileName: `${device.name}_${screenshot.name}`\n });\n }\n}\n\nreturn combinations.map(c => ({ json: c }));"
},
"id": "2a9ec235-c27f-413e-8ec6-a3d16f9d0ba5",
"name": "Create Screenshot\u00d7Device Matrix",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
9408,
4176
],
"notes": "Create: home\u00d7iPhone, home\u00d7iPad, profile\u00d7iPhone, etc."
},
{
"parameters": {
"content": "## \u26a1 Parallel Processing\n\n**Speed optimization:**\nProcesses 2 renders at a time (batchSize: 2)\n\n**Example:** 4 screenshots \u00d7 3 devices = 12 renders\n- Sequential (1 at a time): ~12 seconds\n- Parallel (2): ~6 seconds\n- Parallel (10 with Pro): ~2 seconds\n\n**Each render: ~1 second**\n\n**Webhook payload:**\n```json\n{\n \"screenshots\": [{\"name\": \"home\", \"url\": \"...\"}],\n \"appName\": \"MyApp\",\n \"version\": \"1.2.0\"\n}\n```",
"height": 440,
"width": 556,
"color": 5
},
"id": "4de8e653-b921-44c3-8cd5-7c7af5c8fa91",
"name": "Sticky Note1",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
9616,
3680
]
},
{
"parameters": {
"batchSize": 2,
"options": {}
},
"id": "472535f0-cf7b-4c65-9f34-1fb14d72a5cf",
"name": "Loop (2 at a time)",
"type": "n8n-nodes-base.splitInBatches",
"typeVersion": 3,
"position": [
9616,
4176
],
"notes": "Process 2 renders in parallel - faster than sequential"
},
{
"parameters": {
"mockupUuid": "={{ $json.deviceUuid }}",
"smartObjects": {
"items": [
{
"uuid": "={{ $json.smartObjectUuid }}",
"assetUrl": "={{ $json.screenshotUrl }}",
"fit": "fill",
"additionalOptions": {}
}
]
},
"exportOptions": {
"imageFormat": "png",
"imageSize": 2732,
"quality": 100,
"exportLabel": "={{ $json.fileName }}"
}
},
"id": "d64ac94e-751a-4fd3-9cb5-495521107339",
"name": "Render Device Screenshot",
"type": "n8n-nodes-sudomock.sudoMock",
"typeVersion": 1,
"position": [
9840,
4176
],
"continueOnFail": true,
"notes": "High quality PNG for App Store submission"
},
{
"parameters": {
"jsCode": "const loopData = $('Loop (2 at a time)').item.json;\nconst renderResult = $input.item.json;\n\nreturn [{\n json: {\n fileName: loopData.fileName,\n deviceName: loopData.deviceName,\n screenshotName: loopData.screenshotName,\n appName: loopData.appName,\n version: loopData.version,\n renderedUrl: renderResult.renderedImageUrl || null,\n success: !!renderResult.renderedImageUrl\n }\n}];"
},
"id": "363c0ed5-1139-4a17-ae95-f91829d14ce2",
"name": "Collect Result",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
10064,
4176
]
},
{
"parameters": {
"jsCode": "const allResults = $input.all();\nconst appInfo = allResults[0]?.json;\n\n// Group by device for App Store format\nconst byDevice = {};\nallResults.forEach(r => {\n const device = r.json.deviceName;\n if (!byDevice[device]) byDevice[device] = [];\n byDevice[device].push(r.json);\n});\n\nreturn [{\n json: {\n appName: appInfo.appName,\n version: appInfo.version,\n totalScreenshots: allResults.length,\n successCount: allResults.filter(r => r.json.success).length,\n byDevice: byDevice,\n allUrls: allResults.filter(r => r.json.renderedUrl).map(r => r.json.renderedUrl)\n }\n}];"
},
"id": "ab78d1b1-bc91-4609-98eb-94ed2d76f708",
"name": "Group by Device",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
10064,
4384
],
"notes": "Organize screenshots by device type for easy App Store upload"
},
{
"parameters": {
"content": "## \ud83d\udce6 Output & Delivery\n\n**What you get:**\n- ZIP file with all screenshots\n- Organized by device (iPhone/, iPad/, MacBook/)\n- High-quality PNG format (2732px max)\n- Uploaded to Google Drive\n- Team notified via Slack\n\n**File structure:**\n```\nMyApp-v1.2.0-screenshots.zip\n\u251c\u2500\u2500 iPhone-15-Pro/\n\u2502 \u251c\u2500\u2500 home.png\n\u2502 \u2514\u2500\u2500 profile.png\n\u251c\u2500\u2500 iPad-Pro/\n\u2514\u2500\u2500 MacBook-Pro/\n```",
"height": 380,
"width": 416,
"color": 6
},
"id": "5d170e73-9c45-4427-be05-6632cbbd437a",
"name": "Sticky Note2",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
10288,
4528
]
},
{
"parameters": {
"options": {}
},
"id": "67be4ec4-15bf-4a27-bcf0-b209362ffb99",
"name": "Download All Screenshots",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.1,
"position": [
10288,
4384
]
},
{
"parameters": {
"operation": "compress"
},
"id": "05e1c7d3-2f44-4157-bebd-c8de998e1467",
"name": "Create ZIP Archive",
"type": "n8n-nodes-base.compression",
"typeVersion": 1,
"position": [
10496,
4384
],
"notes": "ZIP all screenshots for easy download"
},
{
"parameters": {
"driveId": {
"__rl": true,
"mode": "list",
"value": "My Drive"
},
"folderId": {
"__rl": true,
"mode": "list",
"value": "root",
"cachedResultName": "/ (Root folder)"
},
"options": {}
},
"id": "9b56381e-9bdc-4125-8058-4adb67632212",
"name": "Upload to Drive",
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
10720,
4384
]
},
{
"parameters": {
"text": "={{ '\ud83d\udcf1 App Store Screenshots Ready!\\n\\n*App:* ' + $('Group by Device').item.json.appName + '\\n*Version:* ' + $('Group by Device').item.json.version + '\\n*Screenshots:* ' + $('Group by Device').item.json.successCount + '/' + $('Group by Device').item.json.totalScreenshots + '\\n\\nDownload: [Google Drive Link]' }}",
"otherOptions": {}
},
"id": "f764ac9b-d971-4a01-87ac-7d25c64e937d",
"name": "Notify Team",
"type": "n8n-nodes-base.slack",
"typeVersion": 2.1,
"position": [
10944,
4384
]
}
],
"connections": {
"Webhook Trigger": {
"main": [
[
{
"node": "Parse Webhook Data",
"type": "main",
"index": 0
}
]
]
},
"Parse Webhook Data": {
"main": [
[
{
"node": "Get Device Templates",
"type": "main",
"index": 0
}
]
]
},
"Get Device Templates": {
"main": [
[
{
"node": "Create Screenshot\u00d7Device Matrix",
"type": "main",
"index": 0
}
]
]
},
"Create Screenshot\u00d7Device Matrix": {
"main": [
[
{
"node": "Loop (2 at a time)",
"type": "main",
"index": 0
}
]
]
},
"Loop (2 at a time)": {
"main": [
[
{
"node": "Group by Device",
"type": "main",
"index": 0
}
],
[
{
"node": "Render Device Screenshot",
"type": "main",
"index": 0
}
]
]
},
"Render Device Screenshot": {
"main": [
[
{
"node": "Collect Result",
"type": "main",
"index": 0
}
]
]
},
"Collect Result": {
"main": [
[
{
"node": "Loop (2 at a time)",
"type": "main",
"index": 0
}
]
]
},
"Group by Device": {
"main": [
[
{
"node": "Download All Screenshots",
"type": "main",
"index": 0
}
]
]
},
"Download All Screenshots": {
"main": [
[
{
"node": "Create ZIP Archive",
"type": "main",
"index": 0
}
]
]
},
"Create ZIP Archive": {
"main": [
[
{
"node": "Upload to Drive",
"type": "main",
"index": 0
}
]
]
},
"Upload to Drive": {
"main": [
[
{
"node": "Notify Team",
"type": "main",
"index": 0
}
]
]
}
},
"active": false,
"settings": {
"executionOrder": "v1",
"availableInMCP": false
},
"versionId": "4e524d43-8b6c-4be5-b8da-689770d953ff",
"meta": {
"templateCredsSetupCompleted": true
},
"id": "hJ48C57K9kadS90L",
"tags": []
}
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
App Screenshot Generator - Multi-Device App Store. Uses n8n-nodes-sudomock, httpRequest, compression, googleDrive. Webhook trigger; 15 nodes.
Source: https://github.com/sudomock/n8n-nodes-sudomock/blob/main/demos/app-screenshot-generator-workflow.json — original creator credit. Request a take-down →
