This workflow follows the HTTP Request → Postgres recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "Central Knowledge Management Orchestrator",
"nodes": [
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyMinute"
}
]
},
"triggerOn": "everyMinute",
"options": {}
},
"id": "orchestrator-cron-trigger",
"name": "Orchestrator Cron Trigger",
"type": "n8n-nodes-base.cron",
"typeVersion": 1,
"position": [
200,
400
]
},
{
"parameters": {
"httpMethod": "POST",
"path": "knowledge-orchestrator",
"responseMode": "responseNode",
"options": {}
},
"id": "orchestrator-webhook",
"name": "Orchestrator Webhook",
"type": "n8n-nodes-base.webhook",
"typeVersion": 2,
"position": [
200,
600
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "orchestration-mode",
"name": "mode",
"value": "={{ $json.body?.mode || 'auto' }}",
"type": "string"
},
{
"id": "target-systems",
"name": "targetSystems",
"value": "={{ $json.body?.targetSystems || ['appflowy', 'affine', 'google_drive'] }}",
"type": "array"
},
{
"id": "orchestration-timestamp",
"name": "timestamp",
"value": "={{ $now }}",
"type": "string"
},
{
"id": "force-full-sync",
"name": "forceFullSync",
"value": "={{ $json.body?.forceFullSync || false }}",
"type": "boolean"
},
{
"id": "enable-ai-analysis",
"name": "enableAIAnalysis",
"value": "={{ $json.body?.enableAIAnalysis || true }}",
"type": "boolean"
}
]
},
"options": {}
},
"id": "process-orchestration-request",
"name": "Process Orchestration Request",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
450,
500
]
},
{
"parameters": {
"operation": "executeQuery",
"query": "SELECT \n source_system,\n COUNT(*) as total_documents,\n MAX(sync_timestamp) as last_sync,\n COUNT(CASE WHEN status = 'error' THEN 1 END) as error_count\nFROM knowledge_sync_log \nWHERE sync_timestamp > NOW() - INTERVAL '24 hours'\nGROUP BY source_system",
"options": {}
},
"id": "analyze-system-health",
"name": "Analyze System Health",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
700,
300
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "SELECT \n document_id,\n source_system,\n content_hash,\n sync_timestamp,\n metadata\nFROM knowledge_sync_log \nWHERE status = 'synced' \n AND sync_timestamp > NOW() - INTERVAL '1 hour'\nORDER BY sync_timestamp DESC",
"options": {}
},
"id": "get-recent-activity",
"name": "Get Recent Activity",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
700,
400
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "SELECT \n sm.source_system,\n sm.target_system,\n sm.mapping_type,\n COUNT(*) as mapping_count,\n COUNT(CASE WHEN sm.status = 'active' THEN 1 END) as active_mappings,\n COUNT(CASE WHEN sm.status = 'error' THEN 1 END) as error_mappings\nFROM knowledge_sync_mapping sm\nGROUP BY sm.source_system, sm.target_system, sm.mapping_type",
"options": {}
},
"id": "check-sync-mappings",
"name": "Check Sync Mappings",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
700,
500
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "system-health-summary",
"name": "systemHealth",
"value": "={{ $('Analyze System Health').all().reduce((acc, item) => { acc[item.source_system] = { totalDocs: item.total_documents, lastSync: item.last_sync, errorCount: item.error_count, status: item.error_count > 0 ? 'warning' : 'healthy' }; return acc; }, {}) }}",
"type": "object"
},
{
"id": "recent-activity-count",
"name": "recentActivityCount",
"value": "={{ $('Get Recent Activity').all().length }}",
"type": "number"
},
{
"id": "sync-mappings-summary",
"name": "syncMappings",
"value": "={{ $('Check Sync Mappings').all() }}",
"type": "array"
},
{
"id": "needs-maintenance",
"name": "needsMaintenance",
"value": "={{ Object.values($json.systemHealth).some(system => system.status === 'warning') }}",
"type": "boolean"
},
{
"id": "needs-sync",
"name": "needsSync",
"value": "={{ $json.recentActivityCount > 0 || $('Process Orchestration Request').item.json.forceFullSync }}",
"type": "boolean"
}
]
},
"options": {}
},
"id": "evaluate-orchestration-needs",
"name": "Evaluate Orchestration Needs",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
950,
400
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "maintenance-needed",
"leftValue": "={{ $json.needsMaintenance }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-maintenance-needed",
"name": "Check Maintenance Needed",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
1200,
300
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "sync-needed",
"leftValue": "={{ $json.needsSync }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-sync-needed",
"name": "Check Sync Needed",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
1200,
500
]
},
{
"parameters": {
"url": "https://n8n.{{ $vars.domain_name }}/webhook/trigger-knowledge-sync",
"options": {
"timeout": 120000
},
"sendBody": true,
"contentType": "json",
"body": {
"source": "all",
"direction": "bidirectional",
"forceSync": "={{ $('Process Orchestration Request').item.json.forceFullSync }}",
"orchestrationSession": "={{ $('Process Orchestration Request').item.json.timestamp }}"
}
},
"id": "trigger-bidirectional-sync",
"name": "Trigger Bidirectional Sync",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1450,
400
]
},
{
"parameters": {
"url": "https://n8n.{{ $vars.domain_name }}/webhook/enhanced-rag-agent",
"options": {
"timeout": 60000
},
"sendBody": true,
"contentType": "json",
"body": {
"chatInput": "Please analyze the recent knowledge management activity and provide insights about content patterns, frequently updated topics, and potential knowledge gaps.",
"sessionId": "orchestrator-analysis-{{ $('Process Orchestration Request').item.json.timestamp }}",
"enableAnalysis": "={{ $('Process Orchestration Request').item.json.enableAIAnalysis }}"
}
},
"id": "trigger-ai-analysis",
"name": "Trigger AI Analysis",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1450,
600
]
},
{
"parameters": {
"operation": "executeQuery",
"query": "UPDATE knowledge_sync_log \nSET status = 'resolved'\nWHERE status = 'error' \n AND sync_timestamp < NOW() - INTERVAL '1 hour'",
"options": {}
},
"id": "cleanup-old-errors",
"name": "Cleanup Old Errors",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1450,
200
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"url": "http://qdrant:6333/collections/knowledge_base/cluster/status",
"options": {
"timeout": 10000
},
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "api-key",
"value": "{{ $vars.qdrant_api_key }}"
}
]
}
},
"id": "check-vector-db-health",
"name": "Check Vector DB Health",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1450,
100
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "orchestration-summary",
"name": "orchestrationSummary",
"value": "={{ { timestamp: $('Process Orchestration Request').item.json.timestamp, systemHealth: $('Evaluate Orchestration Needs').item.json.systemHealth, maintenancePerformed: $('Evaluate Orchestration Needs').item.json.needsMaintenance, syncTriggered: $('Evaluate Orchestration Needs').item.json.needsSync, recentActivity: $('Evaluate Orchestration Needs').item.json.recentActivityCount, vectorDbStatus: $('Check Vector DB Health').item.json.status || 'unknown', aiAnalysisEnabled: $('Process Orchestration Request').item.json.enableAIAnalysis } }}",
"type": "object"
}
]
},
"options": {}
},
"id": "compile-orchestration-report",
"name": "Compile Orchestration Report",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
1700,
400
]
},
{
"parameters": {
"operation": "insert",
"table": {
"__rl": true,
"value": "orchestration_log",
"mode": "list"
},
"data": {
"insert": [
{
"column": "session_id",
"value": "={{ $('Process Orchestration Request').item.json.timestamp }}"
},
{
"column": "mode",
"value": "={{ $('Process Orchestration Request').item.json.mode }}"
},
{
"column": "target_systems",
"value": "={{ $('Process Orchestration Request').item.json.targetSystems }}"
},
{
"column": "maintenance_performed",
"value": "={{ $('Evaluate Orchestration Needs').item.json.needsMaintenance }}"
},
{
"column": "sync_triggered",
"value": "={{ $('Evaluate Orchestration Needs').item.json.needsSync }}"
},
{
"column": "system_health",
"value": "={{ $('Evaluate Orchestration Needs').item.json.systemHealth }}"
},
{
"column": "orchestration_summary",
"value": "={{ $json.orchestrationSummary }}"
},
{
"column": "created_at",
"value": "={{ $now }}"
}
]
},
"options": {}
},
"id": "log-orchestration-session",
"name": "Log Orchestration Session",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1950,
400
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "webhook-trigger-check",
"leftValue": "={{ $('Orchestrator Webhook').item }}",
"rightValue": "",
"operator": {
"type": "object",
"operation": "notEmpty"
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-webhook-response-needed",
"name": "Check Webhook Response Needed",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
2200,
400
]
},
{
"parameters": {
"options": {}
},
"id": "respond-to-orchestrator-webhook",
"name": "Respond to Orchestrator Webhook",
"type": "n8n-nodes-base.respondToWebhook",
"typeVersion": 1.1,
"position": [
2450,
300
]
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyHour"
}
]
},
"triggerOn": "everyHour",
"options": {}
},
"id": "deep-analysis-trigger",
"name": "Deep Analysis Trigger",
"type": "n8n-nodes-base.cron",
"typeVersion": 1,
"position": [
200,
800
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "deep-analysis-mode",
"name": "mode",
"value": "deep_analysis",
"type": "string"
},
{
"id": "analysis-timestamp",
"name": "timestamp",
"value": "={{ $now }}",
"type": "string"
},
{
"id": "enable-full-ai",
"name": "enableAIAnalysis",
"value": true,
"type": "boolean"
}
]
},
"options": {}
},
"id": "prepare-deep-analysis",
"name": "Prepare Deep Analysis",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
450,
800
]
},
{
"parameters": {
"url": "https://n8n.{{ $vars.domain_name }}/webhook/enhanced-rag-agent",
"options": {
"timeout": 180000
},
"sendBody": true,
"contentType": "json",
"body": {
"chatInput": "Perform a comprehensive analysis of the knowledge management system: 1) Identify content clusters and themes across all platforms, 2) Detect knowledge gaps and outdated information, 3) Suggest content consolidation opportunities, 4) Analyze user interaction patterns, 5) Recommend system optimizations.",
"sessionId": "deep-analysis-{{ $json.timestamp }}",
"enableAnalysis": true
}
},
"id": "perform-deep-analysis",
"name": "Perform Deep Analysis",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
700,
800
]
},
{
"parameters": {
"operation": "insert",
"table": {
"__rl": true,
"value": "deep_analysis_reports",
"mode": "list"
},
"data": {
"insert": [
{
"column": "analysis_timestamp",
"value": "={{ $('Prepare Deep Analysis').item.json.timestamp }}"
},
{
"column": "analysis_type",
"value": "comprehensive_knowledge_audit"
},
{
"column": "findings",
"value": "={{ $json.output || $json.response || 'Analysis completed' }}"
},
{
"column": "recommendations",
"value": "{{ [] }}"
},
{
"column": "created_at",
"value": "={{ $now }}"
}
]
},
"options": {}
},
"id": "store-deep-analysis-report",
"name": "Store Deep Analysis Report",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
950,
800
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"content": "## Central Knowledge Management Orchestrator\n\n**Purpose:** Master controller for the entire knowledge management ecosystem, coordinating all sync processes, health monitoring, and AI-driven insights.\n\n**Core Functions:**\n- **Health Monitoring**: Continuous system health checks across all platforms\n- **Sync Orchestration**: Coordinates bidirectional sync processes\n- **AI Analysis**: Triggers intelligent content analysis and recommendations \n- **Maintenance**: Automated cleanup and optimization tasks\n- **Reporting**: Comprehensive logging and analytics\n- **Deep Analysis**: Periodic comprehensive knowledge audits\n\n**Triggers:**\n- Cron: Every minute for routine checks\n- Webhook: On-demand orchestration\n- Hourly: Deep analysis and comprehensive audits\n\n**Integrations:**\n- AppFlowy Content Sync\n- Affine Content Sync \n- Bidirectional Knowledge Sync\n- Enhanced RAG AI Agent\n- Vector Database Health Checks\n- PostgreSQL Analytics\n\n**API Endpoints:**\n- POST /webhook/knowledge-orchestrator\n- Supports: mode, targetSystems, forceFullSync, enableAIAnalysis parameters",
"height": 700,
"width": 900,
"color": 1
},
"id": "orchestrator-documentation",
"name": "Orchestrator Documentation",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
2600,
50
]
}
],
"connections": {
"Orchestrator Cron Trigger": {
"main": [
[
{
"node": "Process Orchestration Request",
"type": "main",
"index": 0
}
]
]
},
"Orchestrator Webhook": {
"main": [
[
{
"node": "Process Orchestration Request",
"type": "main",
"index": 0
}
]
]
},
"Process Orchestration Request": {
"main": [
[
{
"node": "Analyze System Health",
"type": "main",
"index": 0
},
{
"node": "Get Recent Activity",
"type": "main",
"index": 0
},
{
"node": "Check Sync Mappings",
"type": "main",
"index": 0
}
]
]
},
"Get Recent Activity": {
"main": [
[
{
"node": "Evaluate Orchestration Needs",
"type": "main",
"index": 0
}
]
]
},
"Evaluate Orchestration Needs": {
"main": [
[
{
"node": "Check Maintenance Needed",
"type": "main",
"index": 0
},
{
"node": "Check Sync Needed",
"type": "main",
"index": 0
}
]
]
},
"Check Maintenance Needed": {
"main": [
[
{
"node": "Cleanup Old Errors",
"type": "main",
"index": 0
},
{
"node": "Check Vector DB Health",
"type": "main",
"index": 0
}
]
]
},
"Check Sync Needed": {
"main": [
[
{
"node": "Trigger Bidirectional Sync",
"type": "main",
"index": 0
},
{
"node": "Trigger AI Analysis",
"type": "main",
"index": 0
}
]
]
},
"Trigger Bidirectional Sync": {
"main": [
[
{
"node": "Compile Orchestration Report",
"type": "main",
"index": 0
}
]
]
},
"Check Vector DB Health": {
"main": [
[
{
"node": "Compile Orchestration Report",
"type": "main",
"index": 0
}
]
]
},
"Compile Orchestration Report": {
"main": [
[
{
"node": "Log Orchestration Session",
"type": "main",
"index": 0
}
]
]
},
"Log Orchestration Session": {
"main": [
[
{
"node": "Check Webhook Response Needed",
"type": "main",
"index": 0
}
]
]
},
"Check Webhook Response Needed": {
"main": [
[
{
"node": "Respond to Orchestrator Webhook",
"type": "main",
"index": 0
}
]
]
},
"Deep Analysis Trigger": {
"main": [
[
{
"node": "Prepare Deep Analysis",
"type": "main",
"index": 0
}
]
]
},
"Prepare Deep Analysis": {
"main": [
[
{
"node": "Perform Deep Analysis",
"type": "main",
"index": 0
}
]
]
},
"Perform Deep Analysis": {
"main": [
[
{
"node": "Store Deep Analysis Report",
"type": "main",
"index": 0
}
]
]
}
},
"active": true,
"settings": {
"executionOrder": "v1"
},
"versionId": "orchestrator-v1",
"meta": {
"templateCredsSetupCompleted": true
},
"id": "KnowledgeOrchestrator",
"tags": [
"orchestrator",
"knowledge-management",
"automation",
"monitoring",
"ai-analysis"
]
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
postgres
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
Central Knowledge Management Orchestrator. Uses postgres, httpRequest. Scheduled trigger; 22 nodes.
Source: https://github.com/161sam/n8n-installer/blob/main/modularium/ai-workspace/Knowledge-Orchestrator.json — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
Disparador 1.8. Uses itemLists, postgres, emailSend, httpRequest. Scheduled trigger; 85 nodes.
Item Lists, Postgres, Email Send +1
공유회_알림톡_크론. Uses postgres, httpRequest, n8n-nodes-solapi. Scheduled trigger; 39 nodes.
Postgres, HTTP Request, N8N Nodes Solapi
QuepasaAutomatic. Uses postgres, postgresTrigger, httpRequest. Scheduled trigger; 39 nodes.
Postgres, Postgres Trigger, HTTP Request
QuepasaAutomatic. Uses postgres, postgresTrigger, httpRequest. Scheduled trigger; 39 nodes.
Postgres, Postgres Trigger, HTTP Request
QuepasaAutomatic. Uses postgres, postgresTrigger, httpRequest. Scheduled trigger; 39 nodes.
Postgres, Postgres Trigger, HTTP Request
