Compare Shipping Rates with Fedex, Dhl, Bluedart, Delhivery and Claude AI

The workflow JSON

Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →

{
  "id": "6HuVv5w13YcvIEzu",
  "meta": {
    "templateCredsSetupCompleted": true
  },
  "name": "Compare shipping rates with FedEx, DHL, BlueDart, Delhivery and Claude AI",
  "tags": [],
  "nodes": [
    {
      "id": "48452fd5-01e3-4211-86d6-cdaf40ab0c6a",
      "name": "Receive shipment request",
      "type": "n8n-nodes-base.webhook",
      "position": [
        3424,
        5872
      ],
      "parameters": {
        "path": "shipment-quote",
        "options": {},
        "httpMethod": "POST",
        "responseMode": "responseNode"
      },
      "typeVersion": 2
    },
    {
      "id": "dc940eba-a7fd-48f6-aeaa-39de558d8490",
      "name": "Validate input and calculate weights",
      "type": "n8n-nodes-base.code",
      "position": [
        3648,
        5872
      ],
      "parameters": {
        "mode": "runOnceForEachItem",
        "jsCode": "// Extract shipment data from request body\nconst shipment = $input.item.json.body || $input.item.json;\n\n// Define required fields\nconst required = ['origin', 'destination', 'weight', 'length', 'width', 'height'];\n\n// Check for missing fields\nconst missing = required.filter(field => !shipment[field]);\nif (missing.length > 0) {\n  throw new Error(`Missing required fields: ${missing.join(', ')}`);\n}\n\n// Validate numeric values\nconst numericFields = ['weight', 'length', 'width', 'height'];\nfor (const field of numericFields) {\n  const value = parseFloat(shipment[field]);\n  if (isNaN(value) || value <= 0) {\n    throw new Error(`Invalid ${field}: must be a positive number`);\n  }\n}\n\n// Structure the data\nconst structured = {\n  origin: {\n    postalCode: shipment.origin.postalCode || shipment.origin,\n    country: shipment.origin.country || 'IN'\n  },\n  destination: {\n    postalCode: shipment.destination.postalCode || shipment.destination,\n    country: shipment.destination.country || 'IN'\n  },\n  package: {\n    weight: parseFloat(shipment.weight),\n    length: parseFloat(shipment.length),\n    width: parseFloat(shipment.width),\n    height: parseFloat(shipment.height)\n  },\n  preferences: {\n    deliverySpeed: shipment.deliverySpeed || 'standard',\n    insurance: Boolean(shipment.insurance),\n    cod: Boolean(shipment.cod),\n    autoBook: Boolean(shipment.autoBook)\n  },\n  metadata: {\n    requestId: `REQ-${Date.now()}-${Math.random().toString(36).substr(2, 9)}`,\n    requestedAt: new Date().toISOString()\n  }\n};\n\n// Calculate volumetric weight (standard divisor: 5000 for cm\u00b3 to kg)\nstructured.package.volumetricWeight = \n  (structured.package.length * structured.package.width * structured.package.height) / 5000;\n\n// Calculate chargeable weight (higher of actual or volumetric)\nstructured.package.chargeableWeight = Math.max(\n  structured.package.weight,\n  structured.package.volumetricWeight\n);\n\nreturn { json: structured };"
      },
      "typeVersion": 2
    },
    {
      "id": "49ff4abf-ce3b-4033-88a7-3e542f31f4fd",
      "name": "Get FedEx rates",
      "type": "n8n-nodes-base.httpRequest",
      "position": [
        3872,
        5584
      ],
      "parameters": {
        "url": "https://api.fedex.com/rate/v1/rates/quotes",
        "options": {
          "timeout": 10000
        },
        "jsonBody": "={\n  \"accountNumber\": {\n    \"value\": \"{{$credentials.accountNumber}}\"\n  },\n  \"requestedShipment\": {\n    \"shipper\": {\n      \"address\": {\n        \"postalCode\": \"{{$json.origin.postalCode}}\",\n        \"countryCode\": \"{{$json.origin.country}}\"\n      }\n    },\n    \"recipient\": {\n      \"address\": {\n        \"postalCode\": \"{{$json.destination.postalCode}}\",\n        \"countryCode\": \"{{$json.destination.country}}\"\n      }\n    },\n    \"pickupType\": \"DROPOFF_AT_FEDEX_LOCATION\",\n    \"serviceType\": \"FEDEX_GROUND\",\n    \"rateRequestType\": [\"ACCOUNT\"],\n    \"requestedPackageLineItems\": [\n      {\n        \"weight\": {\n          \"value\": {{$json.package.chargeableWeight}},\n          \"units\": \"KG\"\n        },\n        \"dimensions\": {\n          \"length\": {{$json.package.length}},\n          \"width\": {{$json.package.width}},\n          \"height\": {{$json.package.height}},\n          \"units\": \"CM\"\n        }\n      }\n    ]\n  }\n}",
        "sendBody": true,
        "sendHeaders": true,
        "specifyBody": "json",
        "authentication": "predefinedCredentialType",
        "headerParameters": {
          "parameters": [
            {
              "name": "Content-Type",
              "value": "application/json"
            }
          ]
        },
        "nodeCredentialType": "fedExApi"
      },
      "typeVersion": 4.2,
      "continueOnFail": true
    },
    {
      "id": "25831822-8f70-4818-b9cd-e75dc86d0f5f",
      "name": "Get DHL rates",
      "type": "n8n-nodes-base.httpRequest",
      "position": [
        3872,
        5776
      ],
      "parameters": {
        "url": "https://api-eu.dhl.com/mydhlapi/v1/rates",
        "options": {
          "timeout": 10000
        },
        "jsonBody": "={\n  \"customerDetails\": {\n    \"shipperDetails\": {\n      \"postalCode\": \"{{$json.origin.postalCode}}\",\n      \"countryCode\": \"{{$json.origin.country}}\"\n    },\n    \"receiverDetails\": {\n      \"postalCode\": \"{{$json.destination.postalCode}}\",\n      \"countryCode\": \"{{$json.destination.country}}\"\n    }\n  },\n  \"accounts\": [\n    {\n      \"typeCode\": \"shipper\",\n      \"number\": \"{{$credentials.accountNumber}}\"\n    }\n  ],\n  \"plannedShippingDateAndTime\": \"{{new Date().toISOString()}}\",\n  \"unitOfMeasurement\": \"metric\",\n  \"isCustomsDeclarable\": false,\n  \"monetaryAmount\": [\n    {\n      \"typeCode\": \"declaredValue\",\n      \"value\": 100,\n      \"currency\": \"INR\"\n    }\n  ],\n  \"packages\": [\n    {\n      \"weight\": {{$json.package.chargeableWeight}},\n      \"dimensions\": {\n        \"length\": {{$json.package.length}},\n        \"width\": {{$json.package.width}},\n        \"height\": {{$json.package.height}}\n      }\n    }\n  ]\n}",
        "sendBody": true,
        "sendHeaders": true,
        "specifyBody": "json",
        "authentication": "predefinedCredentialType",
        "headerParameters": {
          "parameters": [
            {
              "name": "Content-Type",
              "value": "application/json"
            }
          ]
        },
        "nodeCredentialType": "dhlApi"
      },
      "credentials": {
        "dhlApi": {
          "name": "<your credential>"
        }
      },
      "typeVersion": 4.2,
      "continueOnFail": true
    },
    {
      "id": "1722bca0-bbc4-48a6-98cd-2599907fa4a5",
      "name": "Get BlueDart rates",
      "type": "n8n-nodes-base.httpRequest",
      "position": [
        3872,
        5968
      ],
      "parameters": {
        "url": "https://api.bluedart.com/servlet/RoutingServlet",
        "options": {
          "timeout": 10000
        },
        "jsonBody": "={\n  \"Request\": {\n    \"ServiceType\": \"{{$json.preferences.deliverySpeed === 'express' ? 'P' : 'S'}}\",\n    \"OriginPincode\": \"{{$json.origin.postalCode}}\",\n    \"DestinationPincode\": \"{{$json.destination.postalCode}}\",\n    \"Weight\": \"{{$json.package.chargeableWeight}}\",\n    \"Dimensions\": {\n      \"Length\": {{$json.package.length}},\n      \"Width\": {{$json.package.width}},\n      \"Height\": {{$json.package.height}}\n    },\n    \"IsCOD\": \"{{$json.preferences.cod ? 'Y' : 'N'}}\",\n    \"CustomerCode\": \"{{$credentials.customerCode}}\",\n    \"LoginID\": \"{{$credentials.loginId}}\"\n  }\n}",
        "sendBody": true,
        "sendHeaders": true,
        "specifyBody": "json",
        "authentication": "predefinedCredentialType",
        "headerParameters": {
          "parameters": [
            {
              "name": "Content-Type",
              "value": "application/json"
            }
          ]
        },
        "nodeCredentialType": "blueDartApi"
      },
      "typeVersion": 4.2,
      "continueOnFail": true
    },
    {
      "id": "58beb078-f224-4077-b4c9-24ff36ca46d7",
      "name": "Get Delhivery rates",
      "type": "n8n-nodes-base.httpRequest",
      "position": [
        3872,
        6160
      ],
      "parameters": {
        "url": "https://track.delhivery.com/api/kinko/v1/invoice/charges/.json",
        "options": {
          "timeout": 10000
        },
        "sendQuery": true,
        "authentication": "predefinedCredentialType",
        "queryParameters": {
          "parameters": [
            {
              "name": "ss",
              "value": "Delivered"
            },
            {
              "name": "md",
              "value": "={{ $json.preferences.deliverySpeed === 'express' ? 'E' : 'S' }}"
            },
            {
              "name": "cgm",
              "value": "={{ $json.package.chargeableWeight }}"
            },
            {
              "name": "o_pin",
              "value": "={{ $json.origin.postalCode }}"
            },
            {
              "name": "d_pin",
              "value": "={{ $json.destination.postalCode }}"
            }
          ]
        },
        "nodeCredentialType": "delhiveryApi"
      },
      "typeVersion": 4.2,
      "continueOnFail": true
    },
    {
      "id": "67140ee6-bba6-4482-a3b0-38eb6d10af27",
      "name": "Combine all carrier responses",
      "type": "n8n-nodes-base.merge",
      "position": [
        4096,
        5872
      ],
      "parameters": {
        "mode": "mergeByPosition"
      },
      "typeVersion": 3
    },
    {
      "id": "4971d1ba-2f6e-4f67-8c90-d4443917cb83",
      "name": "Parse and normalize carrier rates",
      "type": "n8n-nodes-base.code",
      "position": [
        4320,
        5872
      ],
      "parameters": {
        "mode": "runOnceForEachItem",
        "jsCode": "// Get shipment details and carrier responses\nconst shipment = $('Validate input and calculate weights').item.json;\nconst fedex = $('Get FedEx rates').item.json;\nconst dhl = $('Get DHL rates').item.json;\nconst bluedart = $('Get BlueDart rates').item.json;\nconst delhivery = $('Get Delhivery rates').item.json;\n\nconst rates = [];\n\n// Parse FedEx response\ntry {\n  if (fedex && !fedex.error && fedex.output?.rateReplyDetails) {\n    const fedexRate = fedex.output.rateReplyDetails[0];\n    rates.push({\n      carrier: 'FedEx',\n      cost: parseFloat(fedexRate.ratedShipmentDetails?.[0]?.totalNetCharge || 0),\n      currency: fedexRate.ratedShipmentDetails?.[0]?.currency || 'INR',\n      transitDays: parseInt(fedexRate.commit?.transitTime || 999),\n      service: fedexRate.serviceName || 'Standard',\n      available: true\n    });\n  }\n} catch (error) {\n  console.log('FedEx parsing error:', error.message);\n}\n\n// Parse DHL response\ntry {\n  if (dhl && !dhl.error && dhl.products && dhl.products.length > 0) {\n    const dhlRate = dhl.products[0];\n    rates.push({\n      carrier: 'DHL',\n      cost: parseFloat(dhlRate.totalPrice?.[0]?.price || 0),\n      currency: dhlRate.totalPrice?.[0]?.priceCurrency || 'INR',\n      transitDays: parseInt(dhlRate.deliveryCapabilities?.estimatedDeliveryDateAndTime ? \n        Math.ceil((new Date(dhlRate.deliveryCapabilities.estimatedDeliveryDateAndTime) - new Date()) / (1000 * 60 * 60 * 24)) : 999),\n      service: dhlRate.productName || 'Standard',\n      available: true\n    });\n  }\n} catch (error) {\n  console.log('DHL parsing error:', error.message);\n}\n\n// Parse BlueDart response\ntry {\n  if (bluedart && !bluedart.error && bluedart.Response) {\n    rates.push({\n      carrier: 'BlueDart',\n      cost: parseFloat(bluedart.Response.Charges?.TotalAmount || 0),\n      currency: 'INR',\n      transitDays: parseInt(bluedart.Response.TransitDays || 999),\n      service: bluedart.Response.ServiceType || 'Standard',\n      available: bluedart.Response.Status === 'Success'\n    });\n  }\n} catch (error) {\n  console.log('BlueDart parsing error:', error.message);\n}\n\n// Parse Delhivery response\ntry {\n  if (delhivery && !delhivery.error && Array.isArray(delhivery) && delhivery.length > 0) {\n    const delhiveryRate = delhivery[0];\n    rates.push({\n      carrier: 'Delhivery',\n      cost: parseFloat(delhiveryRate.total_amount || 0),\n      currency: 'INR',\n      transitDays: parseInt(delhiveryRate.transit_time || 999),\n      service: delhiveryRate.mode || 'Standard',\n      available: true\n    });\n  }\n} catch (error) {\n  console.log('Delhivery parsing error:', error.message);\n}\n\n// Filter out invalid rates and sort by cost\nconst validRates = rates.filter(r => r.cost > 0 && r.available);\n\nif (validRates.length === 0) {\n  throw new Error('No valid rates received from any carrier. Please check API credentials and service availability.');\n}\n\n// Sort rates by cost (lowest first)\nvalidRates.sort((a, b) => a.cost - b.cost);\n\nreturn {\n  json: {\n    shipmentDetails: shipment,\n    rates: validRates,\n    ratesCount: validRates.length,\n    carriersQueried: 4,\n    carriersResponded: validRates.length\n  }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "3353c46c-c50f-4cee-a8bd-d3628f105ea5",
      "name": "Analyze with Claude AI",
      "type": "@n8n/n8n-nodes-langchain.agent",
      "position": [
        4544,
        5872
      ],
      "parameters": {
        "text": "=You are a shipping logistics expert. Analyze these shipping rates and recommend the best carrier based on the customer's preferences.\n\n**Available Rates:**\n{{ JSON.stringify($json.rates, null, 2) }}\n\n**Customer Preferences:**\n- Delivery Speed: {{ $json.shipmentDetails.preferences.deliverySpeed }}\n- Insurance Required: {{ $json.shipmentDetails.preferences.insurance }}\n- Cash on Delivery (COD): {{ $json.shipmentDetails.preferences.cod }}\n\n**Analysis Guidelines:**\n1. If deliverySpeed is \"express\", prioritize carriers with fewer transit days\n2. If deliverySpeed is \"standard\", balance cost and transit time\n3. Consider insurance and COD requirements\n4. Provide a value score from 1-100 based on overall value\n\n**Response Format (JSON only):**\n{\n  \"recommendedCarrier\": \"carrier name\",\n  \"reasoning\": \"brief explanation of why this carrier is best\",\n  \"valueScore\": 85\n}",
        "options": {
          "systemMessage": "You are a shipping logistics expert that provides carrier recommendations in JSON format only. Never include markdown code blocks or additional text."
        },
        "promptType": "define"
      },
      "typeVersion": 1.6
    },
    {
      "id": "cd07d172-2e69-48d5-9701-8283e895dd26",
      "name": "Claude AI model",
      "type": "@n8n/n8n-nodes-langchain.lmChatAnthropic",
      "position": [
        4616,
        6096
      ],
      "parameters": {
        "model": "claude-sonnet-4-20250514",
        "options": {
          "temperature": 0.3
        }
      },
      "credentials": {
        "anthropicApi": {
          "name": "<your credential>"
        }
      },
      "typeVersion": 1
    },
    {
      "id": "6d8c057a-efd9-4c53-b5b8-4d343da94a7d",
      "name": "Build final response",
      "type": "n8n-nodes-base.code",
      "position": [
        4896,
        5872
      ],
      "parameters": {
        "mode": "runOnceForEachItem",
        "jsCode": "// Extract AI response\nconst aiResponse = $input.item.json;\nlet aiText = aiResponse.response || aiResponse.output || aiResponse.text || '';\n\n// Handle content array format\nif (aiResponse.content && Array.isArray(aiResponse.content)) {\n  aiText = aiResponse.content[0]?.text || '';\n}\n\n// Clean JSON from markdown code blocks\nconst cleanText = aiText\n  .replace(/```json\\s*/g, '')\n  .replace(/```\\s*/g, '')\n  .trim();\n\nlet aiRecommendation;\ntry {\n  aiRecommendation = JSON.parse(cleanText);\n} catch (error) {\n  throw new Error(`Failed to parse AI response: ${error.message}. Response was: ${cleanText}`);\n}\n\n// Get normalized rates data\nconst ratesData = $('Parse and normalize carrier rates').item.json;\n\n// Find the recommended carrier in rates\nconst recommended = ratesData.rates.find(\n  r => r.carrier.toLowerCase() === aiRecommendation.recommendedCarrier.toLowerCase()\n);\n\nif (!recommended) {\n  throw new Error(`Recommended carrier \"${aiRecommendation.recommendedCarrier}\" not found in available rates`);\n}\n\n// Calculate comparison metrics\nconst sorted = [...ratesData.rates].sort((a, b) => a.cost - b.cost);\nconst cheapest = sorted[0];\nconst fastest = [...ratesData.rates].sort((a, b) => a.transitDays - b.transitDays)[0];\nconst mostExpensive = sorted[sorted.length - 1];\n\nconst savingsVsMostExpensive = mostExpensive.cost - recommended.cost;\nconst extraCostVsCheapest = recommended.cost - cheapest.cost;\n\nreturn {\n  json: {\n    requestId: ratesData.shipmentDetails.metadata.requestId,\n    recommended: {\n      ...recommended,\n      reasoning: aiRecommendation.reasoning,\n      valueScore: aiRecommendation.valueScore\n    },\n    comparison: {\n      cheapestCarrier: cheapest.carrier,\n      cheapestCost: cheapest.cost.toFixed(2),\n      fastestCarrier: fastest.carrier,\n      fastestTransitDays: fastest.transitDays,\n      savingsVsMostExpensive: savingsVsMostExpensive.toFixed(2),\n      extraCostVsCheapest: extraCostVsCheapest.toFixed(2),\n      totalOptionsCompared: ratesData.rates.length\n    },\n    allRates: sorted,\n    shipmentDetails: ratesData.shipmentDetails\n  }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "86b26897-d45d-4305-bf3e-0b51bfba2090",
      "name": "Check if auto-booking enabled",
      "type": "n8n-nodes-base.if",
      "position": [
        5120,
        5872
      ],
      "parameters": {
        "options": {},
        "conditions": {
          "options": {
            "leftValue": "",
            "caseSensitive": false,
            "typeValidation": "strict"
          },
          "combinator": "and",
          "conditions": [
            {
              "operator": {
                "type": "boolean",
                "operation": "true"
              },
              "leftValue": "={{ $json.shipmentDetails.preferences.autoBook }}",
              "rightValue": true
            }
          ]
        }
      },
      "typeVersion": 2
    },
    {
      "id": "ce8a11a8-6b61-4a78-8397-e8988835f20d",
      "name": "Prepare booking request",
      "type": "n8n-nodes-base.code",
      "position": [
        5344,
        5776
      ],
      "parameters": {
        "mode": "runOnceForEachItem",
        "jsCode": "const response = $input.item.json;\nconst carrier = response.recommended.carrier;\n\n// Map carriers to their booking endpoints\nconst carrierEndpoints = {\n  'FedEx': 'https://api.fedex.com/ship/v1/shipments',\n  'DHL': 'https://api-eu.dhl.com/mydhlapi/v1/shipments',\n  'BlueDart': 'https://api.bluedart.com/servlet/RoutingServlet',\n  'Delhivery': 'https://track.delhivery.com/api/cmu/create.json'\n};\n\nconst endpoint = carrierEndpoints[carrier];\n\nif (!endpoint) {\n  throw new Error(`No booking endpoint configured for carrier: ${carrier}`);\n}\n\n// Generate unique booking reference\nconst bookingRef = `BK-${Date.now()}-${Math.random().toString(36).substr(2, 9)}`;\n\nreturn {\n  json: {\n    carrier,\n    endpoint,\n    shipmentData: response.shipmentDetails,\n    recommendedService: response.recommended.service,\n    estimatedCost: response.recommended.cost,\n    bookingRef\n  }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "b9272e4f-0012-4475-9260-03c051c5896c",
      "name": "Book shipment with carrier",
      "type": "n8n-nodes-base.httpRequest",
      "position": [
        5568,
        5776
      ],
      "parameters": {
        "url": "={{ $json.endpoint }}",
        "options": {
          "timeout": 15000
        },
        "jsonBody": "={\n  \"shipment\": {{ JSON.stringify($json.shipmentData) }},\n  \"service\": \"{{ $json.recommendedService }}\",\n  \"reference\": \"{{ $json.bookingRef }}\"\n}",
        "sendBody": true,
        "sendHeaders": true,
        "specifyBody": "json",
        "headerParameters": {
          "parameters": [
            {
              "name": "Content-Type",
              "value": "application/json"
            }
          ]
        }
      },
      "typeVersion": 4.2,
      "continueOnFail": true
    },
    {
      "id": "06218eee-b8f1-4a42-a153-fa0d96f50884",
      "name": "Format booking confirmation",
      "type": "n8n-nodes-base.code",
      "position": [
        5792,
        5776
      ],
      "parameters": {
        "mode": "runOnceForEachItem",
        "jsCode": "const bookingResponse = $input.item.json;\nconst preparedData = $('Prepare booking request').item.json;\nconst recommendation = $('Build final response').item.json;\n\n// Extract tracking number from various carrier response formats\nlet trackingNumber = 'PENDING';\n\nif (bookingResponse.tracking_number) {\n  trackingNumber = bookingResponse.tracking_number;\n} else if (bookingResponse.trackingNumber) {\n  trackingNumber = bookingResponse.trackingNumber;\n} else if (bookingResponse.trackingId) {\n  trackingNumber = bookingResponse.trackingId;\n} else if (bookingResponse.shipmentIdentificationNumber) {\n  trackingNumber = bookingResponse.shipmentIdentificationNumber;\n}\n\nreturn {\n  json: {\n    success: true,\n    booked: true,\n    status: 'Shipment booked successfully',\n    carrier: recommendation.recommended.carrier,\n    trackingNumber,\n    estimatedCost: recommendation.recommended.cost,\n    currency: recommendation.recommended.currency,\n    estimatedTransitDays: recommendation.recommended.transitDays,\n    service: recommendation.recommended.service,\n    savings: recommendation.comparison.savingsVsMostExpensive,\n    bookingRef: preparedData.bookingRef,\n    requestId: recommendation.requestId\n  }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "1c155c2d-46e2-4926-a1b5-3eb1715f2635",
      "name": "Format quote response",
      "type": "n8n-nodes-base.code",
      "position": [
        5792,
        5968
      ],
      "parameters": {
        "mode": "runOnceForEachItem",
        "jsCode": "const response = $input.item.json;\n\nreturn {\n  json: {\n    success: true,\n    booked: false,\n    status: 'Quote generated - manual booking required',\n    message: 'Rate comparison completed. Enable autoBook in request to book automatically.',\n    recommended: {\n      carrier: response.recommended.carrier,\n      cost: response.recommended.cost,\n      currency: response.recommended.currency,\n      transitDays: response.recommended.transitDays,\n      service: response.recommended.service,\n      reasoning: response.recommended.reasoning,\n      valueScore: response.recommended.valueScore\n    },\n    comparison: response.comparison,\n    allRates: response.allRates.map(rate => ({\n      carrier: rate.carrier,\n      cost: rate.cost,\n      currency: rate.currency,\n      transitDays: rate.transitDays,\n      service: rate.service\n    })),\n    requestId: response.requestId\n  }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "75d57ff1-41b6-4f26-959e-9745cbec5e55",
      "name": "Send response to client",
      "type": "n8n-nodes-base.respondToWebhook",
      "position": [
        6016,
        5872
      ],
      "parameters": {
        "options": {
          "responseHeaders": {
            "entries": [
              {
                "name": "Content-Type",
                "value": "application/json"
              }
            ]
          }
        },
        "respondWith": "json",
        "responseBody": "={{ JSON.stringify($json, null, 2) }}"
      },
      "typeVersion": 1
    },
    {
      "id": "67db4ae5-ac95-4285-b69c-9cf11b29d36d",
      "name": "Sticky Note",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        2432,
        5200
      ],
      "parameters": {
        "width": 760,
        "height": 1084,
        "content": "## Compare shipping rates with FedEx, DHL, BlueDart, Delhivery and Claude AI\n\nThis AI-powered workflow automatically compares shipping rates across four major carriers, uses Claude AI to recommend the best option based on cost and delivery time, and optionally books shipments instantly.\n\n### How it works\n\n1. **Receive request** - Webhook accepts shipment details (origin, destination, weight, dimensions)\n2. **Validate data** - Checks required fields and calculates volumetric weight\n3. **Query carriers** - Simultaneously fetches rates from FedEx, DHL, BlueDart, and Delhivery\n4. **Normalize responses** - Parses different carrier formats into standardized structure\n5. **AI analysis** - Claude AI evaluates options considering cost, speed, and preferences\n6. **Return results** - Provides recommendation with savings analysis, or books shipment if enabled\n\n### Setup steps\n\n1. Import this workflow into your n8n instance\n2. Configure carrier API credentials:\n   - **FedEx API** - Get credentials from FedEx Developer Portal\n   - **DHL API** - Register at DHL Developer Portal\n   - **BlueDart API** - Contact BlueDart for API access\n   - **Delhivery API** - Get token from Delhivery partner portal\n3. Add **Anthropic API** credentials for Claude AI\n4. Activate workflow to generate webhook URL\n5. Test with sample request:\n   ```json\n   {\n     \"origin\": \"400001\",\n     \"destination\": \"110001\",\n     \"weight\": 2,\n     \"length\": 30,\n     \"width\": 20,\n     \"height\": 15,\n     \"deliverySpeed\": \"standard\",\n     \"autoBook\": false\n   }\n   ```\n\n### Features\n\n- **Real-time rates** from 4 carriers\n- **AI-powered recommendations** considering cost, speed, and preferences  \n- **Automatic booking** when enabled\n- **Comprehensive error handling**\n- **Detailed cost comparison** and savings analysis"
      },
      "typeVersion": 1
    },
    {
      "id": "52fd0104-1bbc-46ac-9d41-1783efe02dff",
      "name": "Sticky Note1",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        3340,
        5704
      ],
      "parameters": {
        "color": 4,
        "width": 424,
        "height": 328,
        "content": "## 1. Input validation"
      },
      "typeVersion": 1
    },
    {
      "id": "8dc75b93-73ba-4e3a-aebd-f37f276ea69c",
      "name": "Sticky Note2",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        3788,
        5444
      ],
      "parameters": {
        "color": 4,
        "width": 456,
        "height": 684,
        "content": "## 2. Fetch carrier rates"
      },
      "typeVersion": 1
    },
    {
      "id": "1ea2ac82-f318-40d6-a862-9926a8ea0f10",
      "name": "Sticky Note3",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        4292,
        5748
      ],
      "parameters": {
        "color": 4,
        "width": 712,
        "height": 284,
        "content": "## 3. AI recommendation"
      },
      "typeVersion": 1
    },
    {
      "id": "b99daf49-429a-4c56-a660-23d11a0d982d",
      "name": "Sticky Note4",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        5052,
        5636
      ],
      "parameters": {
        "color": 4,
        "width": 1176,
        "height": 492,
        "content": "## 4. Book or quote"
      },
      "typeVersion": 1
    }
  ],
  "active": false,
  "settings": {
    "executionOrder": "v1"
  },
  "versionId": "21367db6-abe9-433d-acaf-c68d2cbbdef3",
  "connections": {
    "Get DHL rates": {
      "main": [
        [
          {
            "node": "Combine all carrier responses",
            "type": "main",
            "index": 1
          }
        ]
      ]
    },
    "Claude AI model": {
      "ai_languageModel": [
        [
          {
            "node": "Analyze with Claude AI",
            "type": "ai_languageModel",
            "index": 0
          }
        ]
      ]
    },
    "Get FedEx rates": {
      "main": [
        [
          {
            "node": "Combine all carrier responses",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Get BlueDart rates": {
      "main": [
        [
          {
            "node": "Combine all carrier responses",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Get Delhivery rates": {
      "main": [
        [
          {
            "node": "Combine all carrier responses",
            "type": "main",
            "index": 1
          }
        ]
      ]
    },
    "Build final response": {
      "main": [
        [
          {
            "node": "Check if auto-booking enabled",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Format quote response": {
      "main": [
        [
          {
            "node": "Send response to client",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Analyze with Claude AI": {
      "main": [
        [
          {
            "node": "Build final response",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Prepare booking request": {
      "main": [
        [
          {
            "node": "Book shipment with carrier",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Receive shipment request": {
      "main": [
        [
          {
            "node": "Validate input and calculate weights",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Book shipment with carrier": {
      "main": [
        [
          {
            "node": "Format booking confirmation",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Format booking confirmation": {
      "main": [
        [
          {
            "node": "Send response to client",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Check if auto-booking enabled": {
      "main": [
        [
          {
            "node": "Prepare booking request",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Format quote response",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Combine all carrier responses": {
      "main": [
        [
          {
            "node": "Parse and normalize carrier rates",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Parse and normalize carrier rates": {
      "main": [
        [
          {
            "node": "Analyze with Claude AI",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Validate input and calculate weights": {
      "main": [
        [
          {
            "node": "Get FedEx rates",
            "type": "main",
            "index": 0
          },
          {
            "node": "Get DHL rates",
            "type": "main",
            "index": 0
          },
          {
            "node": "Get BlueDart rates",
            "type": "main",
            "index": 0
          },
          {
            "node": "Get Delhivery rates",
            "type": "main",
            "index": 0
          }
        ]
      ]
    }
  }
}

Credentials you'll need

Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.

• anthropicApi
• dhlApi

About this workflow

This AI-powered workflow automatically compares shipping rates across four major carriers, uses Claude AI to recommend the best option based on cost and delivery time, and optionally books shipments instantly. Receive request - Webhook accepts shipment details (origin,…

Source: https://n8n.io/workflows/10500/ — original creator credit. Request a take-down →

More AI & RAG workflows → · Browse all categories →

Related workflows

Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
