This workflow follows the Editimage → HTTP Request recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "Content Creator - Social Media Mockup Batch",
"nodes": [
{
"parameters": {
"content": "## \ud83c\udfa8 Content Creator Mockup Automation\n\n**What this workflow does:**\nAuto-creates platform-optimized mockups for Instagram, Twitter, LinkedIn when you upload a design\n\n**Requirements:**\n- SudoMock API key ([Free tier: 500 credits](https://sudomock.com))\n- Google Drive folder setup\n- Device mockup PSDs (laptop, phone, billboard)\n- Buffer account (optional for auto-scheduling)\n\n**Output:**\nEvery design \u2192 12 mockup variants\n(3 devices \u00d7 4 platforms)",
"height": 372,
"width": 428,
"color": 4
},
"id": "7bda0224-f7c8-4ced-a21e-0daacb4f4660",
"name": "Sticky Note",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
10720,
5040
]
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyMinute"
}
]
},
"triggerOn": "fileCreated"
},
"id": "cbe34a0b-8ea4-415f-b65c-7d04c8518a97",
"name": "Watch Designs Folder",
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
10720,
5440
],
"notes": "Trigger when new design uploaded to Google Drive"
},
{
"parameters": {
"operation": "listMockups",
"additionalOptions": {}
},
"id": "27b74eb1-d8f6-47f2-a2d0-6af8bff5f4d0",
"name": "Get Mockup Templates",
"type": "n8n-nodes-sudomock.sudoMock",
"typeVersion": 1,
"position": [
10944,
5440
],
"notes": "Get context mockups: MacBook, iPhone, Billboard, etc."
},
{
"parameters": {
"jsCode": "const designFile = $('Watch Designs Folder').item.json;\nconst mockups = $input.item.json.data.mockups;\n\n// Social media platforms and their optimal sizes\nconst platforms = [\n { name: 'Instagram-Post', size: 1080, ratio: '1:1' },\n { name: 'Instagram-Story', size: 1080, ratio: '9:16' },\n { name: 'Twitter-Post', size: 1200, ratio: '16:9' },\n { name: 'LinkedIn-Post', size: 1200, ratio: '1.91:1' }\n];\n\nconst combinations = [];\n\nfor (const mockup of mockups) {\n for (const platform of platforms) {\n const smartObject = mockup.smart_objects[0];\n \n combinations.push({\n designName: designFile.name,\n designUrl: designFile.webViewLink,\n mockupName: mockup.name,\n mockupUuid: mockup.uuid,\n smartObjectUuid: smartObject.uuid,\n platform: platform.name,\n targetSize: platform.size,\n aspectRatio: platform.ratio,\n outputName: `${designFile.name.split('.')[0]}_${mockup.name}_${platform.name}`\n });\n }\n}\n\nreturn combinations.map(c => ({ json: c }));"
},
"id": "f5c0f48d-3ecf-4f1d-b34a-fb340c4569a3",
"name": "Create Mockup\u00d7Platform Matrix",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
11168,
5440
],
"notes": "Create: design\u00d7laptop\u00d7Instagram, design\u00d7phone\u00d7Twitter, etc."
},
{
"parameters": {
"content": "## \ud83d\udd04 Platform Optimization\n\n**What happens:**\n1. Design uploaded to Google Drive\n2. Creates mockup \u00d7 platform combinations:\n - Instagram Post (1080\u00d71080)\n - Instagram Story (1080\u00d71920)\n - Twitter Post (1200\u00d7675)\n - LinkedIn Post (1200\u00d7628)\n3. Renders each with correct device mockup\n4. Adds watermark automatically\n5. Resizes for platform specs\n\n**Time saved:**\n12 variants per design (~12 seconds to render)\nManual: ~1 hour \u2192 Automated: ~30 seconds",
"height": 380,
"width": 400,
"color": 5
},
"id": "0e8bb9b1-b5cb-4b1b-8e66-8dfcb25ba1ac",
"name": "Sticky Note1",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
11376,
5040
]
},
{
"parameters": {
"options": {}
},
"id": "c8e1c3f9-6e0b-4741-a440-f0ec0503b5d8",
"name": "Loop Through Variants",
"type": "n8n-nodes-base.splitInBatches",
"typeVersion": 3,
"position": [
11376,
5440
]
},
{
"parameters": {
"mockupUuid": "={{ $json.mockupUuid }}",
"smartObjects": {
"items": [
{
"uuid": "={{ $json.smartObjectUuid }}",
"assetUrl": "={{ $json.designUrl }}",
"additionalOptions": {}
}
]
},
"exportOptions": {
"imageFormat": "webp",
"imageSize": "={{ $json.targetSize }}",
"quality": 90,
"exportLabel": "={{ $json.outputName }}"
}
},
"id": "19854909-3008-41ea-b810-23d28e146a83",
"name": "Render Mockup",
"type": "n8n-nodes-sudomock.sudoMock",
"typeVersion": 1,
"position": [
11600,
5440
],
"continueOnFail": true,
"notes": "Render with platform-specific size optimization"
},
{
"parameters": {},
"id": "d8e16b38-ff96-4a88-a7dd-1eca8f96aeda",
"name": "Add Watermark & Resize",
"type": "n8n-nodes-base.editImage",
"typeVersion": 1.1,
"position": [
11824,
5440
],
"notes": "Add branding watermark and resize for platform"
},
{
"parameters": {
"jsCode": "const loopData = $('Loop Through Variants').item.json;\nconst renderResult = $('Render Mockup').item.json;\nconst editedImage = $input.item.json;\n\nreturn [{\n json: {\n designName: loopData.designName,\n mockupName: loopData.mockupName,\n platform: loopData.platform,\n outputName: loopData.outputName,\n aspectRatio: loopData.aspectRatio,\n mockupUrl: renderResult.renderedImageUrl || null,\n finalImageData: editedImage.data,\n success: !!renderResult.renderedImageUrl\n }\n}];"
},
"id": "3ba02331-f8f7-4c75-95da-b6c67c2c0d06",
"name": "Collect Result",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
12048,
5440
]
},
{
"parameters": {
"jsCode": "const allResults = $input.all();\n\n// Group by platform for Buffer scheduling\nconst byPlatform = {\n 'Instagram-Post': [],\n 'Instagram-Story': [],\n 'Twitter-Post': [],\n 'LinkedIn-Post': []\n};\n\nallResults.forEach(r => {\n const platform = r.json.platform;\n if (byPlatform[platform]) {\n byPlatform[platform].push(r.json);\n }\n});\n\nconst designName = allResults[0]?.json?.designName || 'Design';\n\nreturn [{\n json: {\n designName: designName,\n totalVariants: allResults.length,\n successCount: allResults.filter(r => r.json.success).length,\n byPlatform: byPlatform,\n allUrls: allResults.filter(r => r.json.mockupUrl).map(r => r.json.mockupUrl)\n }\n}];"
},
"id": "3c5f12b1-09aa-4fef-b4ec-a5b24047d63b",
"name": "Group by Platform",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
12048,
5632
],
"notes": "Organize variants by social media platform"
},
{
"parameters": {
"content": "## \ud83d\udcf1 Auto-Schedule & Organize\n\n**Organized output:**\nGoogle Drive folder structure:\n```\nMyDesign - Social Media Pack/\n\u251c\u2500\u2500 Instagram-Post/\n\u251c\u2500\u2500 Instagram-Story/\n\u251c\u2500\u2500 Twitter-Post/\n\u2514\u2500\u2500 LinkedIn-Post/\n```\n\n**Buffer integration:**\n- Auto-schedules posts across platforms\n- Optimal posting times\n- Includes mockup images\n\n**Team notification:**\nSlack message with summary + Drive link",
"height": 408,
"width": 400,
"color": 6
},
"id": "c6ac651f-2435-4c8f-8a6e-048152e3c848",
"name": "Sticky Note2",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
12704,
5200
]
},
{
"parameters": {
"resource": "folder",
"name": "={{ $json.designName + ' - Social Media Pack' }}",
"driveId": {
"__rl": true,
"mode": "list",
"value": "My Drive"
},
"folderId": {
"__rl": true,
"mode": "list",
"value": "root",
"cachedResultName": "/ (Root folder)"
},
"options": {}
},
"id": "e2a9e8c1-24d1-4387-a9f9-f93c0e9cce56",
"name": "Create Drive Folder",
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
12256,
5632
]
},
{
"parameters": {
"mode": "combine",
"combinationMode": "multiplex",
"options": {}
},
"id": "7ecd6c3d-872e-4ea9-abdf-625e6b6cc47d",
"name": "Merge URLs with Folder",
"type": "n8n-nodes-base.merge",
"typeVersion": 2.1,
"position": [
12480,
5632
]
},
{
"parameters": {
"options": {}
},
"id": "486704cb-a99f-49d8-8efd-d2daeeb89a64",
"name": "Loop Upload Files",
"type": "n8n-nodes-base.splitInBatches",
"typeVersion": 3,
"position": [
12704,
5632
]
},
{
"parameters": {
"url": "={{ $json.url }}",
"options": {
"response": {
"response": {
"responseFormat": "file"
}
}
}
},
"id": "71c9f2a4-3d86-4689-8a6e-33dfcaf83605",
"name": "Download Image",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.1,
"position": [
12928,
5632
]
},
{
"parameters": {
"driveId": {
"__rl": true,
"mode": "list",
"value": "My Drive"
},
"folderId": "={{ $('Create Drive Folder').item.json.id }}",
"options": {}
},
"id": "7580a36d-0412-4bc1-834e-44a195a2a855",
"name": "Upload to Folder",
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
13136,
5632
]
},
{
"parameters": {},
"id": "05b851ba-fc25-404a-ad9c-64a16be564e4",
"name": "Continue Loop",
"type": "n8n-nodes-base.noOp",
"typeVersion": 1,
"position": [
13360,
5632
]
},
{
"parameters": {},
"id": "526fe38c-198c-4cf4-bdac-2bfe0614b1e9",
"name": "Schedule to Buffer",
"type": "n8n-nodes-base.buffer",
"typeVersion": 1,
"position": [
12704,
5840
],
"notes": "Schedule posts across all platforms"
},
{
"parameters": {
"text": "={{ '\ud83c\udfa8 *New Design Ready for Social Media!*\\n\\n*Design:* ' + $json.designName + '\\n*Variants:* ' + $json.successCount + ' mockups created\\n*Platforms:* Instagram, Twitter, LinkedIn\\n\\n\u2705 Uploaded to Google Drive\\n\ud83d\udcc5 Scheduled in Buffer for ' + $now.plus(1, 'hour').toFormat('HH:mm') }}",
"otherOptions": {}
},
"id": "1096f624-f736-4f7d-979c-d18676222a90",
"name": "Notify Team",
"type": "n8n-nodes-base.slack",
"typeVersion": 2.1,
"position": [
12928,
5840
]
}
],
"connections": {
"Watch Designs Folder": {
"main": [
[
{
"node": "Get Mockup Templates",
"type": "main",
"index": 0
}
]
]
},
"Get Mockup Templates": {
"main": [
[
{
"node": "Create Mockup\u00d7Platform Matrix",
"type": "main",
"index": 0
}
]
]
},
"Create Mockup\u00d7Platform Matrix": {
"main": [
[
{
"node": "Loop Through Variants",
"type": "main",
"index": 0
}
]
]
},
"Loop Through Variants": {
"main": [
[
{
"node": "Group by Platform",
"type": "main",
"index": 0
}
],
[
{
"node": "Render Mockup",
"type": "main",
"index": 0
}
]
]
},
"Collect Result": {
"main": [
[
{
"node": "Loop Through Variants",
"type": "main",
"index": 0
}
]
]
},
"Group by Platform": {
"main": [
[
{
"node": "Create Drive Folder",
"type": "main",
"index": 0
}
]
]
},
"Create Drive Folder": {
"main": [
[
{
"node": "Merge URLs with Folder",
"type": "main",
"index": 0
}
]
]
},
"Merge URLs with Folder": {
"main": [
[
{
"node": "Loop Upload Files",
"type": "main",
"index": 0
}
]
]
},
"Loop Upload Files": {
"main": [
[
{
"node": "Continue Loop",
"type": "main",
"index": 0
}
],
[
{
"node": "Download Image",
"type": "main",
"index": 0
}
]
]
},
"Download Image": {
"main": [
[
{
"node": "Upload to Folder",
"type": "main",
"index": 0
}
]
]
},
"Upload to Folder": {
"main": [
[
{
"node": "Loop Upload Files",
"type": "main",
"index": 0
}
]
]
}
},
"active": false,
"settings": {
"executionOrder": "v1",
"availableInMCP": false
},
"versionId": "672ca7bb-6223-488d-9fa8-dc6a0937dbb1",
"meta": {
"templateCredsSetupCompleted": true
},
"id": "hJ48C57K9kadS90L",
"tags": []
}
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
Content Creator - Social Media Mockup Batch. Uses googleDriveTrigger, n8n-nodes-sudomock, editImage, googleDrive. Event-driven trigger; 19 nodes.
Source: https://github.com/sudomock/n8n-nodes-sudomock/blob/main/demos/content-creator-mockup-batch-workflow.json — original creator credit. Request a take-down →
