Rudi Afandi
This workflow corresponds to n8n.io template #5709 — we link there as the canonical source.
This workflow follows the Telegram → Telegram Trigger recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "lNBuLeOYDLRMZhF0",
"meta": {
"templateCredsSetupCompleted": true
},
"name": "Url Shortner",
"tags": [],
"nodes": [
{
"id": "3699e2c1-9b17-4975-adfa-40c5955f1d51",
"name": "Telegram Trigger",
"type": "n8n-nodes-base.telegramTrigger",
"position": [
0,
-105
],
"parameters": {
"updates": [
"message"
],
"additionalFields": {}
},
"credentials": {
"telegramApi": {
"name": "<your credential>"
}
},
"typeVersion": 1.2
},
{
"id": "ab26cb35-e5cd-4011-a2f1-3b3630155799",
"name": "Insert shortCode",
"type": "n8n-nodes-base.mongoDb",
"position": [
1460,
220
],
"parameters": {
"fields": "=longUrl,shortUrl",
"options": {},
"operation": "insert",
"collection": "url"
},
"credentials": {
"mongoDb": {
"name": "<your credential>"
}
},
"typeVersion": 1.2
},
{
"id": "0aa4998d-d44d-49ff-8620-ffc299a90a82",
"name": "New link",
"type": "n8n-nodes-base.telegram",
"position": [
1680,
220
],
"parameters": {
"text": "=Here is your Short URL : https://s.lamdi.id/{{ $('shortCode Data').item.json.shortUrl }}",
"chatId": "={{ $('Telegram Trigger').item.json.message.chat.id }}",
"additionalFields": {
"appendAttribution": false
}
},
"credentials": {
"telegramApi": {
"name": "<your credential>"
}
},
"typeVersion": 1.2
},
{
"id": "ce0adffc-a7cb-4d40-ba1a-312a817d1646",
"name": "Sticky Note",
"type": "n8n-nodes-base.stickyNote",
"position": [
-80,
-180
],
"parameters": {
"width": 1180,
"height": 280,
"content": "## Validating\n"
},
"typeVersion": 1
},
{
"id": "591e81f5-d1ad-45dc-af47-6e94f1558315",
"name": "Sticky Note1",
"type": "n8n-nodes-base.stickyNote",
"position": [
-80,
-480
],
"parameters": {
"color": 3,
"width": 1180,
"height": 280,
"content": "## Link not valid\n\n"
},
"typeVersion": 1
},
{
"id": "792a1a83-6c38-4d18-ab7e-45a54b7fe64c",
"name": "Sticky Note3",
"type": "n8n-nodes-base.stickyNote",
"position": [
-80,
120
],
"parameters": {
"color": 4,
"width": 2000,
"height": 280,
"content": "## Creating new link\n\n"
},
"typeVersion": 1
},
{
"id": "63434047-e655-4490-aac0-3f2a98461b3d",
"name": "Exist?",
"type": "n8n-nodes-base.mongoDb",
"position": [
440,
220
],
"parameters": {
"query": "={\n\"shortUrl\": \"{{ $json.shortUrl }}\"\n}",
"options": {
"limit": 1
},
"collection": "url"
},
"credentials": {
"mongoDb": {
"name": "<your credential>"
}
},
"typeVersion": 1.2,
"alwaysOutputData": true
},
{
"id": "035410fc-07fe-41ac-9acd-d8c7e86de9d5",
"name": "no exist?",
"type": "n8n-nodes-base.if",
"position": [
1020,
220
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "8ad72bb8-6b19-4a69-bc43-2d1d31fe4026",
"operator": {
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.exist }}",
"rightValue": "false"
}
]
}
},
"typeVersion": 2.2
},
{
"id": "687c1422-6ade-4279-929e-05279d815d6e",
"name": "exist?",
"type": "n8n-nodes-base.set",
"position": [
660,
220
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "36d39222-59ad-48ec-887f-ddb78a7f7239",
"name": "exist",
"type": "string",
"value": "={{ !!$json._id }}"
},
{
"id": "102add96-c1ac-4174-92c4-8d6608fedcd5",
"name": "shortUrl",
"type": "string",
"value": "={{ $('Reply Data').item.json.shortUrl }}"
},
{
"id": "bc5964bc-95ac-4e44-929c-264b3f71270a",
"name": "longUrl",
"type": "string",
"value": "={{ $('Reply Data').item.json.longUrl }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "024156e2-423c-476d-bd74-6ad6b18631d3",
"name": "Webhook",
"type": "n8n-nodes-base.webhook",
"position": [
-20,
640
],
"parameters": {
"path": "redirect",
"options": {},
"responseMode": "responseNode"
},
"typeVersion": 2
},
{
"id": "af608dbd-b6f4-47ea-8eb9-7c7095fcc72d",
"name": "Sticky Note7",
"type": "n8n-nodes-base.stickyNote",
"position": [
-80,
420
],
"parameters": {
"color": 5,
"width": 1420,
"height": 580,
"content": "## Handle Redirects\n"
},
"typeVersion": 1
},
{
"id": "aaa66b70-a6c4-472a-8ad5-78ddddaa6b60",
"name": "Is it reply?",
"type": "n8n-nodes-base.if",
"position": [
220,
-100
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "8b3fa1be-6cde-4ac6-95aa-969e84c035d5",
"operator": {
"type": "object",
"operation": "notEmpty",
"singleValue": true
},
"leftValue": "={{ $json.message.reply_to_message }}",
"rightValue": ""
}
]
}
},
"typeVersion": 2.2
},
{
"id": "76ecf7ff-0ce6-4d0c-8f88-ccfe6b9c10ed",
"name": "Reply Data",
"type": "n8n-nodes-base.set",
"position": [
220,
220
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "947ede9e-ddc8-4ed3-8edd-af0b03de78e2",
"name": "longUrl",
"type": "string",
"value": "={{ $json.longUrl }}"
},
{
"id": "41204ee4-cac2-4f1c-a95c-1af0cdded6dc",
"name": "shortUrl",
"type": "string",
"value": "={{ $('Is it reply?').item.json.message.text }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "fd5152fa-fa5a-4408-be08-e1ae6c78c791",
"name": "askShortCode",
"type": "n8n-nodes-base.telegram",
"position": [
880,
-100
],
"parameters": {
"text": "=Link detected: {{ $json.longUrl }} What code do you want to use?",
"chatId": "={{ $('Telegram Trigger').item.json.message.chat.id }}",
"forceReply": {
"force_reply": true
},
"replyMarkup": "forceReply",
"additionalFields": {
"appendAttribution": false
}
},
"credentials": {
"telegramApi": {
"name": "<your credential>"
}
},
"typeVersion": 1.2
},
{
"id": "3bc6b432-0e8b-49b8-89fa-4b232b6bd1b1",
"name": "Clean Data",
"type": "n8n-nodes-base.code",
"position": [
0,
220
],
"parameters": {
"jsCode": "const urlRegex = /(https?:\\/\\/[^\\s]+)/g;\nconst text = $input.first().json.message.reply_to_message.text;\nconst urls = text.match(urlRegex);\n\nif (!urls || urls.length === 0) {\n return {\n json: {\n error: \"There is not detected URL. Please input valid URL that start with http:// or https://\",\n chat_id: $input.item.json.chat_id // Take chat_id for error message\n }\n };\n}\n\nconst longUrl = urls[0]; // Take first URL appear\n\n// Function for generate random URL\nfunction generateRandomCode(length = 7) {\n const characters = 'ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789';\n let result = '';\n for (let i = 0; i < length; i++) {\n result += characters.charAt(Math.floor(Math.random() * characters.length));\n }\n return result;\n}\n\nlet shortCode = generateRandomCode();\n\n// Prepare data for MongoDB\nreturn {\n json: {\n longUrl: longUrl,\n shortCode: shortCode,\n chat_id: $input.item.json.chat_id,\n message_id: $input.item.json.message_id\n }\n};"
},
"typeVersion": 2
},
{
"id": "e6b64f7a-4f51-42b0-8c2e-1dff1e09defa",
"name": "askShortCode1",
"type": "n8n-nodes-base.telegram",
"position": [
1240,
-80
],
"parameters": {
"text": "=Short code existed! Try another one? (You must reply this message)",
"chatId": "={{ $('Telegram Trigger').item.json.message.chat.id }}",
"forceReply": {
"force_reply": true
},
"replyMarkup": "forceReply",
"additionalFields": {
"appendAttribution": false
}
},
"credentials": {
"telegramApi": {
"name": "<your credential>"
}
},
"typeVersion": 1.2
},
{
"id": "e3dfe8fe-85a4-4682-b8d8-25f27f55d402",
"name": "Sticky Note2",
"type": "n8n-nodes-base.stickyNote",
"position": [
1120,
-180
],
"parameters": {
"color": 3,
"width": 800,
"height": 280,
"content": "## Link exist, ask another one\n\n"
},
"typeVersion": 1
},
{
"id": "e3b0449e-d305-412c-8521-d395df67c329",
"name": "Valid URL",
"type": "n8n-nodes-base.respondToWebhook",
"position": [
1080,
540
],
"parameters": {
"options": {},
"redirectURL": "={{ $('short code exist?1').item.json.longUrl }}",
"respondWith": "redirect"
},
"typeVersion": 1.4
},
{
"id": "7cd09931-b212-42f0-ae34-4fbb3c78b47e",
"name": "Sticky Note4",
"type": "n8n-nodes-base.stickyNote",
"position": [
-740,
-180
],
"parameters": {
"color": 7,
"width": 640,
"height": 1180,
"content": "## Workflow 1: Create Short URL\n\nI. Main Message & Reply Detection\n\n- Telegram Trigger: Receives all Telegram messages.\n- Is it Reply? (IF): Checks if message is a reply.\n- True: Reply (-> Code)\n- False: Initial message (-> Clean Data)\n\nII. Path: Initial Message (Long URL)\n\n- Clean Data (Function): Extracts and validates long URL.\n- Reply Data (Set): Stores URL/chat context for workflow.\n- Exist? (MongoDB - Find): Checks if long URL/short code exists.\n- exist? (Set): Flags if link exists (true/false).\n- no exist? (IF): Routes based on link existence.\n- True: Link exists (-> askShortCode1)\n- False: New link (-> Data)\n\nIII. Path: Existing Link / Ask Custom\n\n- askShortCode1 (Telegram Send Message): Notifies link exists, asks for custom code (Force Reply).\n\nIV. Path: Custom Code Submission & Validation\n\n- Code (Function): Validates custom short code format.\n- Not Valid? (IF): Checks custom code format validity.\n- True: Invalid format (-> Not Valid)\n- False: Valid format (-> connects to Exist? for existence check)\n- Not Valid (Telegram Send Message): Error: invalid code format.\n\nV. Path: Creating New Link (If Unique)\n\n- Data (Set): Prepares final link data for database insert.\n- Insert shortCode (MongoDB - Insert): Inserts new long/short URL pair.\n- New link (Telegram Send Message): Sends new short URL to user."
},
"typeVersion": 1
},
{
"id": "3c327cb0-c695-4792-840b-4964cb1a3a6e",
"name": "Sticky Note5",
"type": "n8n-nodes-base.stickyNote",
"position": [
1360,
420
],
"parameters": {
"color": 7,
"width": 560,
"height": 580,
"content": "## Workflow 2: URL Redirect Handler\n\n- Webhook (Webhook Trigger): Receives short URL requests from web server.\n- Data2 (Set): Extracts short code from webhook URL.\nExist?2 (MongoDB - Find): Finds original long URL for given short code.\n- Exist?3 (Set): Extracts found long URL.\n- if (IF): Checks if long URL was found.\n- True: URL found (-> Valid URL)\n- False: URL not found (-> Not valid URL)\n- Valid URL (Respond to Webhook): Redirects to original long URL (HTTP 302).\n- Not valid URL (Respond to Webhook): Sends 404 Not Found response."
},
"typeVersion": 1
},
{
"id": "721bf395-5f9c-406c-a734-682c6f5f4a97",
"name": "take URL",
"type": "n8n-nodes-base.code",
"position": [
440,
-105
],
"parameters": {
"jsCode": "const urlRegex = /(https?:\\/\\/[^\\s]+)/g;\nconst text = $input.first().json.message.text;\nconst urls = text.match(urlRegex);\n\nif (!urls || urls.length === 0) {\n return {\n json: {\n error: \"There is not detected URL. Please input valid URL that start with http:// or https://\",\n chat_id: $input.item.json.chat_id // Take chat_id for error message\n }\n };\n}\n\nconst longUrl = urls[0]; // Take first URL appear\n\n// Function for generate random URL\nfunction generateRandomCode(length = 7) {\n const characters = 'ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789';\n let result = '';\n for (let i = 0; i < length; i++) {\n result += characters.charAt(Math.floor(Math.random() * characters.length));\n }\n return result;\n}\n\nlet shortCode = generateRandomCode();\n\n// Prepare data for MongoDB\nreturn {\n json: {\n longUrl: longUrl,\n shortCode: shortCode,\n chat_id: $input.item.json.chat_id,\n message_id: $input.item.json.message_id\n }\n};"
},
"typeVersion": 2
},
{
"id": "2dfc05a3-b928-4277-ba3c-38e1fb7fd944",
"name": "Not Valid URL?",
"type": "n8n-nodes-base.if",
"position": [
660,
-105
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "6d06a585-e477-45db-9a06-8f6faa151beb",
"operator": {
"type": "string",
"operation": "notEmpty",
"singleValue": true
},
"leftValue": "={{ $json.error }}",
"rightValue": ""
}
]
}
},
"typeVersion": 2.2
},
{
"id": "f38169f6-efdb-4e1a-b0b9-6740ef59f693",
"name": "Not Valid URL1",
"type": "n8n-nodes-base.telegram",
"position": [
440,
-380
],
"parameters": {
"text": "Please input valid url (https://domain.com)",
"chatId": "={{ $('Telegram Trigger').item.json.message.chat.id }}",
"additionalFields": {
"appendAttribution": false
}
},
"credentials": {
"telegramApi": {
"name": "<your credential>"
}
},
"typeVersion": 1.2
},
{
"id": "e1e5911c-afae-4cdf-a043-01e3dad1f598",
"name": "take short code",
"type": "n8n-nodes-base.set",
"position": [
200,
640
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "937b7cd7-77f7-4668-8d39-ba17a606b049",
"name": "shortCode",
"type": "string",
"value": "={{ $json.query.code }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "daff4473-50f5-4cf2-8ae4-0734fb0523ca",
"name": "short code exist?",
"type": "n8n-nodes-base.mongoDb",
"position": [
420,
640
],
"parameters": {
"query": "={\"shortUrl\":\"{{ $json.shortCode }}\"}",
"options": {},
"collection": "url"
},
"credentials": {
"mongoDb": {
"name": "<your credential>"
}
},
"typeVersion": 1.2,
"alwaysOutputData": true
},
{
"id": "5102ca6d-e5d5-4828-88f0-4e761cd77825",
"name": "short code exist?1",
"type": "n8n-nodes-base.set",
"position": [
640,
640
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "16a2153c-2115-42cd-bcce-e6d016c1588d",
"name": "exist",
"type": "string",
"value": "={{ !!$json._id }}"
},
{
"id": "382fc55c-6d4b-4a70-b087-7173165edea1",
"name": "longUrl",
"type": "string",
"value": "={{ $json.longUrl }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "3cd11299-1aef-4b29-87e1-f6370e227056",
"name": "If short code exist",
"type": "n8n-nodes-base.if",
"position": [
860,
640
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "9e62aeda-3c42-4d30-a0f0-d64f34db5a94",
"operator": {
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $('short code exist?1').item.json.exist }}",
"rightValue": "true"
}
]
}
},
"typeVersion": 2.2
},
{
"id": "a7649e38-53a9-4023-bfaf-433b6c7ec473",
"name": "404 page",
"type": "n8n-nodes-base.respondToWebhook",
"position": [
1080,
740
],
"parameters": {
"options": {},
"redirectURL": "https://s3-cdn.cmlabs.co/page/2023/01/24/a-guideline-on-how-to-fix-error-404-not-found-effectively-519451.png",
"respondWith": "redirect"
},
"typeVersion": 1.4
},
{
"id": "2987203f-83e2-4fd7-abde-25916d7d73bb",
"name": "shortCode Data",
"type": "n8n-nodes-base.set",
"position": [
1240,
220
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "5bbaa285-6b18-46bc-a547-8d1b999fd6c2",
"name": "shortUrl",
"type": "string",
"value": "={{ $('exist?').item.json.shortUrl }}"
},
{
"id": "a98b3245-9612-4b72-b844-7353c0941fb2",
"name": "longUrl",
"type": "string",
"value": "={{ $('exist?').item.json.longUrl }}"
}
]
}
},
"typeVersion": 3.4
}
],
"active": true,
"settings": {
"callerPolicy": "workflowsFromSameOwner",
"executionOrder": "v1",
"saveDataSuccessExecution": "none"
},
"versionId": "e2b51546-52fa-494f-a544-99d99e93754a",
"connections": {
"Exist?": {
"main": [
[
{
"node": "exist?",
"type": "main",
"index": 0
}
]
]
},
"exist?": {
"main": [
[
{
"node": "no exist?",
"type": "main",
"index": 0
}
]
]
},
"Webhook": {
"main": [
[
{
"node": "take short code",
"type": "main",
"index": 0
}
]
]
},
"take URL": {
"main": [
[
{
"node": "Not Valid URL?",
"type": "main",
"index": 0
}
]
]
},
"no exist?": {
"main": [
[
{
"node": "shortCode Data",
"type": "main",
"index": 0
}
],
[
{
"node": "askShortCode1",
"type": "main",
"index": 0
}
]
]
},
"Clean Data": {
"main": [
[
{
"node": "Reply Data",
"type": "main",
"index": 0
}
]
]
},
"Reply Data": {
"main": [
[
{
"node": "Exist?",
"type": "main",
"index": 0
}
]
]
},
"Is it reply?": {
"main": [
[
{
"node": "Clean Data",
"type": "main",
"index": 0
}
],
[
{
"node": "take URL",
"type": "main",
"index": 0
}
]
]
},
"askShortCode": {
"main": [
[]
]
},
"Not Valid URL?": {
"main": [
[
{
"node": "Not Valid URL1",
"type": "main",
"index": 0
}
],
[
{
"node": "askShortCode",
"type": "main",
"index": 0
}
]
]
},
"shortCode Data": {
"main": [
[
{
"node": "Insert shortCode",
"type": "main",
"index": 0
}
]
]
},
"take short code": {
"main": [
[
{
"node": "short code exist?",
"type": "main",
"index": 0
}
]
]
},
"Insert shortCode": {
"main": [
[
{
"node": "New link",
"type": "main",
"index": 0
}
]
]
},
"Telegram Trigger": {
"main": [
[
{
"node": "Is it reply?",
"type": "main",
"index": 0
}
]
]
},
"short code exist?": {
"main": [
[
{
"node": "short code exist?1",
"type": "main",
"index": 0
}
]
]
},
"short code exist?1": {
"main": [
[
{
"node": "If short code exist",
"type": "main",
"index": 0
}
]
]
},
"If short code exist": {
"main": [
[
{
"node": "Valid URL",
"type": "main",
"index": 0
}
],
[
{
"node": "404 page",
"type": "main",
"index": 0
}
]
]
}
}
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
mongoDbtelegramApi
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
This workflow contains community nodes that are only compatible with the self-hosted version of n8n.
Source: https://n8n.io/workflows/5709/ — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
This workflow contains community nodes that are only compatible with the self-hosted version of n8n.
Telegram Trigger, n8n, Telegram +4
This template is ideal for users managing Telegram channels who want to automate the process of posting messages, including text and images, directly from an bot.
Telegram Trigger, Postgres, Telegram
This template is for developers and automation specialists looking to create a Telegram bot that enables users to select items from a predefined list and save their choices to a Postgres database.
Telegram, Postgres, Telegram Trigger
This workflow is for Telegram bot developers or marketers who want to verify user subscriptions to specific Telegram channels and optionally reward them with downloadable files.
Telegram, Postgres, Google Drive +1
This workflow is ideal for businesses or individuals who want to run Telegram-based giveaways that require users to subscribe to certain channels in order to participate.
Telegram, Postgres, Telegram Trigger
