Docsify AI Documentation Generator

The workflow JSON

Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →

{
  "id": "VY4TXYGmqth57Een",
  "meta": {
    "templateCredsSetupCompleted": true
  },
  "name": "Docsify example",
  "tags": [],
  "nodes": [
    {
      "id": "f41906c3-ee4c-4333-bfd5-426f82ba4bd9",
      "name": "CONFIG",
      "type": "n8n-nodes-base.set",
      "position": [
        660,
        60
      ],
      "parameters": {
        "options": {},
        "assignments": {
          "assignments": [
            {
              "id": "b48986ec-f58d-4a7f-afba-677edcb28d31",
              "name": "project_path",
              "type": "string",
              "value": "./.n8n/test_docs"
            },
            {
              "id": "cf632419-f839-4045-922c-03784bb3ae07",
              "name": "instance_url",
              "type": "string",
              "value": "={{$env[\"N8N_PROTOCOL\"]}}://{{$env[\"N8N_HOST\"]}}"
            },
            {
              "id": "7a7c70a6-1853-4ca7-b5b1-e36bb0e190d0",
              "name": "HTML_headers",
              "type": "string",
              "value": "= <meta http-equiv=\"X-UA-Compatible\" content=\"IE=edge,chrome=1\" />\n <meta name=\"viewport\" content=\"width=device-width,initial-scale=1\" />\n <meta charset=\"UTF-8\" />\n <link rel=\"stylesheet\" href=\"//cdn.jsdelivr.net/npm/docsify@4/themes/vue.css\" />\n <script src=\"https://cdn.jsdelivr.net/npm/mermaid/dist/mermaid.min.js\"></script>"
            },
            {
              "id": "1e785afe-f05f-4e51-a164-f341da81ccac",
              "name": "HTML_styles_editor",
              "type": "string",
              "value": "= <style>\n body {\n margin: 0;\n padding: 0;\n overflow: hidden;\n }\n \n .container {\n display: flex;\n flex-direction: column;\n height: 100vh;\n margin: 0;\n }\n\n .button-container {\n display: flex;\n justify-content: center;\n gap: 10px;\n padding: 10px;\n background: #f8f8f8;\n border-bottom: 1px solid #eee;\n width: 50%;\n }\n\n .button {\n padding: 8px 16px;\n border: none;\n border-radius: 4px;\n cursor: pointer;\n font-size: 14px;\n }\n\n .save-button {\n background: #42b983;\n color: white;\n }\n\n .cancel-button {\n background: #666;\n color: white;\n }\n\n .editor-preview-container {\n display: flex;\n flex: 1;\n overflow: hidden;\n }\n \n #editor {\n width: 50%;\n height: 100%;\n resize: none;\n padding: 20px;\n box-sizing: border-box;\n font-family: monospace;\n border: none;\n border-right: 1px solid #eee;\n }\n \n .preview-container {\n width: 50%;\n height: 100%;\n overflow-y: auto;\n }\n\n /* Remove width from main */\n main {\n width: auto !important;\n }\n\n /* Fix code block wrapping */\n .markdown-section pre > code {\n white-space: pre-wrap !important;\n }\n </style>"
            },
            {
              "id": "37e22865-7b6b-438d-83a0-dc680d4775cc",
              "name": "HTML_docsify_include",
              "type": "string",
              "value": "= <script src=\"//cdn.jsdelivr.net/npm/docsify@4\"></script>"
            }
          ]
        },
        "includeOtherFields": true
      },
      "typeVersion": 3.4
    },
    {
      "id": "75cdf7fc-3dfa-49c1-bdbf-01d8be08aaa4",
      "name": "Convert to File",
      "type": "n8n-nodes-base.convertToFile",
      "position": [
        4020,
        1600
      ],
      "parameters": {
        "options": {},
        "operation": "toText",
        "sourceProperty": "workflowdata"
      },
      "typeVersion": 1.1
    },
    {
      "id": "3868011e-8374-496a-b3f5-4cbf7bde4e56",
      "name": "HasFile?",
      "type": "n8n-nodes-base.if",
      "position": [
        2400,
        880
      ],
      "parameters": {
        "options": {},
        "conditions": {
          "options": {
            "version": 2,
            "leftValue": "",
            "caseSensitive": true,
            "typeValidation": "strict"
          },
          "combinator": "and",
          "conditions": [
            {
              "id": "2d9feb22-49d1-4354-9b0b-b82da2b20678",
              "operator": {
                "type": "number",
                "operation": "gt"
              },
              "leftValue": "={{ Object.keys($json).length }}",
              "rightValue": 0
            }
          ]
        }
      },
      "typeVersion": 2.2
    },
    {
      "id": "0bf2317b-2534-4022-9a16-395d4b44680c",
      "name": "Extract from File",
      "type": "n8n-nodes-base.extractFromFile",
      "position": [
        2660,
        860
      ],
      "parameters": {
        "options": {},
        "operation": "text",
        "destinationKey": "workflowdata"
      },
      "typeVersion": 1
    },
    {
      "id": "4b44a7f3-09bf-46a8-9520-247993af654b",
      "name": "Main Page",
      "type": "n8n-nodes-base.html",
      "position": [
        4660,
        -100
      ],
      "parameters": {
        "html": "<!DOCTYPE html>\n<html>\n <head>\n{{ $('CONFIG').first().json.HTML_headers }}\n <body>\n <div data-app id=\"main\">Please wait...</div>\n <script>\n \n mermaid.initialize({\n startOnLoad: false,\n });\n let svgCounter = 0;\n\n window.$docsify = {\n el: '#main',\n auto2top: true,\n loadSidebar: 'summary.md',\n basePath: '{{ $json.webhookUrl.split($json.webhookUrl.extractDomain())[1] }}/',\n name: 'All Workflows',\n markdown: {\n renderer: {\n code(code, lang) {\n if (lang === \"mermaid\") {\n const svgName = `mermaid-svg-${svgCounter++}`;\n const MERMAID_CONTAINER_ID = `${svgName}-container`;\n mermaid.render(svgName, code).then(({ svg }) => {\n const containerElement = document.querySelector(\n `#${MERMAID_CONTAINER_ID}`\n );\n if (containerElement) {\n containerElement.innerHTML = svg;\n } else {\n console.error(`Error: #${MERMAID_CONTAINER_ID} not found`);\n }\n });\n return `<div class=\"mermaid\" id=\"${MERMAID_CONTAINER_ID}\"></div>`;\n }\n return this.origin.code.apply(this, arguments);\n },\n },\n }, \n plugins: [\n function(hook, vm) {\n hook.ready(function() {\n // Check if URL doesn't end with slash but also isn't a file path\n if (!window.location.pathname.endsWith('/') && !window.location.pathname.includes('.')) {\n // Use history.replaceState to avoid adding to browser history\n const newUrl = window.location.pathname + '/' + window.location.hash;\n window.history.replaceState(null, null, newUrl);\n }\n });\n }\n ], \n };\n </script>\n{{ $('CONFIG').first().json.HTML_docsify_include }}\n </body>\n</html>"
      },
      "typeVersion": 1.2
    },
    {
      "id": "28c29cec-7efd-4f05-bf53-ac08cc3834a1",
      "name": "Instance overview",
      "type": "n8n-nodes-base.html",
      "position": [
        4660,
        160
      ],
      "parameters": {
        "html": "# Your n8n instance workflows:\n\n| Workflow | Status | Docs | Created | Updated | Nodes | Triggers |\n|----------|:------:|------|---------|---------|-------|----------|\n{{ $jmespath($input.all(),'[].json.content').join('\\n') }}"
      },
      "executeOnce": true,
      "typeVersion": 1.2
    },
    {
      "id": "3e8eb52e-8d35-4aa3-a485-6674d67720dc",
      "name": "Sort-workflows",
      "type": "n8n-nodes-base.sort",
      "position": [
        2080,
        160
      ],
      "parameters": {
        "options": {},
        "sortFieldsUi": {
          "sortField": [
            {
              "order": "descending",
              "fieldName": "updatedAt"
            }
          ]
        }
      },
      "typeVersion": 1
    },
    {
      "id": "2178e1cf-90b8-4779-9b5c-3d6180823c95",
      "name": "doc action",
      "type": "n8n-nodes-base.switch",
      "position": [
        1740,
        1080
      ],
      "parameters": {
        "rules": {
          "values": [
            {
              "outputKey": "view",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "id": "ee386c7d-1abe-4864-bb3a-a19d3816c906",
                    "operator": {
                      "name": "filter.operator.equals",
                      "type": "string",
                      "operation": "equals"
                    },
                    "leftValue": "={{ $json.query.action }}",
                    "rightValue": "view"
                  }
                ]
              },
              "renameOutput": true
            },
            {
              "outputKey": "edit",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "id": "aa1a33ee-ac38-4ea4-9a4c-d355e7de1312",
                    "operator": {
                      "name": "filter.operator.equals",
                      "type": "string",
                      "operation": "equals"
                    },
                    "leftValue": "={{ $json.query.action }}",
                    "rightValue": "edit"
                  }
                ]
              },
              "renameOutput": true
            },
            {
              "outputKey": "recreate",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "id": "676c36e1-4c88-4314-9317-abc877ff3d17",
                    "operator": {
                      "name": "filter.operator.equals",
                      "type": "string",
                      "operation": "equals"
                    },
                    "leftValue": "={{ $json.query.action }}",
                    "rightValue": "recreate"
                  }
                ]
              },
              "renameOutput": true
            },
            {
              "outputKey": "save",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "id": "164314cf-7d99-4716-9949-b9196ce47959",
                    "operator": {
                      "name": "filter.operator.equals",
                      "type": "string",
                      "operation": "equals"
                    },
                    "leftValue": "={{ $json.query.action }}",
                    "rightValue": "save"
                  }
                ]
              },
              "renameOutput": true
            }
          ]
        },
        "options": {
          "fallbackOutput": "extra"
        }
      },
      "typeVersion": 3.2
    },
    {
      "id": "7f4aab9b-b7e8-4920-98e8-af8f504a1333",
      "name": "Empty Set",
      "type": "n8n-nodes-base.set",
      "position": [
        2000,
        960
      ],
      "parameters": {
        "options": {}
      },
      "typeVersion": 3.4
    },
    {
      "id": "1f35bc3e-29d7-47a2-a1c7-cf6052d99993",
      "name": "Load Doc File",
      "type": "n8n-nodes-base.readWriteFile",
      "position": [
        1900,
        860
      ],
      "parameters": {
        "options": {},
        "fileSelector": "={{ $('CONFIG').first().json.project_path }}/{{ $json.params.file }}"
      },
      "typeVersion": 1,
      "alwaysOutputData": true
    },
    {
      "id": "c0805f50-8f8c-49ba-b0c7-6768bf89798c",
      "name": "Respond with markdown",
      "type": "n8n-nodes-base.respondToWebhook",
      "position": [
        4920,
        1040
      ],
      "parameters": {
        "options": {
          "responseCode": 200,
          "responseHeaders": {
            "entries": [
              {
                "name": "Content-Type",
                "value": "text/markdown"
              }
            ]
          }
        },
        "respondWith": "text",
        "responseBody": "={{ $json.html }}"
      },
      "typeVersion": 1.1
    },
    {
      "id": "9c7a18b9-a081-4162-94f4-e125d666cbcc",
      "name": "Respond with HTML",
      "type": "n8n-nodes-base.respondToWebhook",
      "position": [
        4920,
        860
      ],
      "parameters": {
        "options": {
          "responseCode": 200,
          "responseHeaders": {
            "entries": [
              {
                "name": "Content-Type",
                "value": "text/html"
              }
            ]
          }
        },
        "respondWith": "text",
        "responseBody": "={{ $json.html }}"
      },
      "typeVersion": 1.1
    },
    {
      "id": "50944148-eb7c-4c28-99c5-478ddb2596f2",
      "name": "Save New Doc File",
      "type": "n8n-nodes-base.readWriteFile",
      "position": [
        4180,
        1600
      ],
      "parameters": {
        "options": {},
        "fileName": "={{ $('CONFIG').first().json.project_path }}/{{ $('CONFIG').first().json.params.file }}",
        "operation": "write"
      },
      "typeVersion": 1,
      "alwaysOutputData": true
    },
    {
      "id": "6d7e0dcf-d12b-4428-9c5e-ef7fb2c6be28",
      "name": "Blank Doc File",
      "type": "n8n-nodes-base.set",
      "position": [
        4000,
        1080
      ],
      "parameters": {
        "options": {},
        "assignments": {
          "assignments": [
            {
              "id": "b168d9b1-1a13-4915-b59b-8a17258fd9cc",
              "name": "workflowdata",
              "type": "string",
              "value": "=# {{ $json.name }}\n\n## Workflow Description\n!> Please write what is this workflow doing\n\n## Workflow schematic\n\n```mermaid\n{{ $json.mermaidChart }}\n```\n\n## Any further information\n\n> You can also add tables like this:\n\n| Parameter | Value |\n|-----------|-------|\n| Created | {{ $json.createdAt }} |\n| Last updated | {{ $json.updatedAt }} |\n| Author | {{ $json.shared[0].project.name }} |\n\n"
            }
          ]
        },
        "includeOtherFields": true
      },
      "typeVersion": 3.4
    },
    {
      "id": "778a97eb-f7a2-4537-81fc-979dc6c674a2",
      "name": "Fetch Single Workflow1",
      "type": "n8n-nodes-base.n8n",
      "position": [
        2820,
        1200
      ],
      "parameters": {
        "operation": "get",
        "workflowId": {
          "__rl": true,
          "mode": "id",
          "value": "={{ $('CONFIG').first().json.params.file.replaceAll('docs_','').split('.md')[0] }}"
        },
        "requestOptions": {}
      },
      "credentials": {
        "n8nApi": {
          "name": "<your credential>"
        }
      },
      "typeVersion": 1
    },
    {
      "id": "092b8c67-77f9-4d4b-aa26-8f0e3ea3ed29",
      "name": "Fill Workflow Table",
      "type": "n8n-nodes-base.set",
      "position": [
        2280,
        160
      ],
      "parameters": {
        "options": {},
        "assignments": {
          "assignments": [
            {
              "id": "3bed44f3-7fa6-4d28-8a6e-7074ca354cd6",
              "name": "content",
              "type": "string",
              "value": "=| [{{ `${$json.name.replace(/[|\\\\[\\]`_*{}()<>#+-]/g, '\\\\$&')}` }}]({{ `${$('CONFIG').first().json.instance_url}/workflow/${$json.id}` }} \"Click to open workflow in n8n\") | {{ $json.active ? '[:green_circle:](# \"Active\")' : '[:white_circle:](# \"Inactive\")' }} | <nobr>[:book:]({{ `docs_${$json.id}?action=view` }} \"View docs\") [:memo:]({{ `docs_${$json.id}.md?action=edit` }} \":ignore Edit\") [:arrows_counterclockwise:]({{ `docs_${$json.id}?action=recreate` }} \"Recreate docs\")</nobr> | <nobr>{{ `${new Date($json.createdAt).toISOString().replace('T', ' ').slice(0, 16)}` }}</nobr> | <nobr>{{ `${new Date($json.updatedAt).toISOString().replace('T', ' ').slice(0, 16)}` }}</nobr> | {{ $json.nodes.length }} | {{ $json.nodes.filter(n => n.type.includes('Trigger')).length }} |"
            }
          ]
        }
      },
      "executeOnce": false,
      "typeVersion": 3.4
    },
    {
      "id": "18c58a09-0dfe-4cb4-ae7f-503957eabadb",
      "name": "Basic LLM Chain",
      "type": "@n8n/n8n-nodes-langchain.chainLlm",
      "onError": "continueRegularOutput",
      "position": [
        3480,
        1200
      ],
      "parameters": {
        "text": "=Here's the workflow data:\n{{Object.assign(\n Object.fromEntries(Object.entries($json).filter(([key]) => !['staticData', 'pinData'].includes(key))),\n {nodes: $json.nodes.map(node => Object.fromEntries(Object.entries(node).filter(([key]) => !['id', 'position'].includes(key))))}\n).toJsonString() }}",
        "messages": {
          "messageValues": [
            {
              "message": "=Your task is to generate simple workflow documentation for the n8n workflows. The user will provide a JSON structure. Reply \nin JSON format in 2 sections: workflow_desription and nodes_settings. Important! Each json key should be a simple markdown text without any additional comments or remarks from your end.\n\nInstruction for `workflow_desription`:\n```\n## Section header with H2\n\\n\n> subline with who created workflow and when, when it was last edited and the status (active / inactive as the green / grey round emoji). Also, when the documentation was generated. Now is: {{ $now }}.\n\\n\\n\nShould contain a description of the workflow. in a couple of paragraphs. Use direct voice without the fluff\n```\n\nInstruction for `nodes_settings`:\n```\n## Section header with H2.\n\\n\n### Node 1 name as H3 title\n - For each node make a bullet list with the main node configs. Ignore irrelevant configs. Enclose each config value in code backticks (`). Look:\n - Parameter 1 name: `Parameter 1 value`\n - Parameter 2 name: `Parameter 2 value`\n\\n\\n\n### Node 2 name as H3 title\n - For each node make a bullet list with the main node configs. Ignore irrelevant configs. Enclose each config value in code backticks (`). Look:\n - Parameter 1 name: `Parameter 1 value`\n - Parameter 2 name: `Parameter 2 value`\n\\n\\n\n```"
            }
          ]
        },
        "promptType": "define",
        "hasOutputParser": true
      },
      "typeVersion": 1.4,
      "alwaysOutputData": false
    },
    {
      "id": "9bc58cd3-a55e-4cda-95b5-7fa8dc0e7076",
      "name": "OpenAI Chat Model",
      "type": "@n8n/n8n-nodes-langchain.lmChatOpenAi",
      "position": [
        3480,
        1360
      ],
      "parameters": {
        "model": "gpt-4-turbo",
        "options": {
          "timeout": 120000,
          "temperature": 0.2
        }
      },
      "credentials": {
        "openAiApi": {
          "name": "<your credential>"
        }
      },
      "typeVersion": 1
    },
    {
      "id": "38fb6192-b8ce-4241-a9fe-aebda09aa8d5",
      "name": "Structured Output Parser",
      "type": "@n8n/n8n-nodes-langchain.outputParserStructured",
      "position": [
        3820,
        1360
      ],
      "parameters": {
        "jsonSchemaExample": "{\n\t\"workflow_description\": \"## Workflow overview\\n\\n>some additiona info\\n\\nWorkflow desctiption\",\n\t\"nodes_settings\": \"## Nodes settings\\n\\n###Node name 1\\n\\n- Setting 1\\n- Setting 2###Node name 2\\n\\n- Setting 1\\n- Setting 2\"\n}"
      },
      "typeVersion": 1.2
    },
    {
      "id": "29261bbb-dbbb-44df-b99d-bb084df7d846",
      "name": "Auto-fixing Output Parser",
      "type": "@n8n/n8n-nodes-langchain.outputParserAutofixing",
      "position": [
        3580,
        1360
      ],
      "parameters": {
        "options": {}
      },
      "typeVersion": 1
    },
    {
      "id": "086a57cf-a2b4-4f32-8ca6-38546e4856c1",
      "name": "Respond with main page HTML",
      "type": "n8n-nodes-base.respondToWebhook",
      "position": [
        4920,
        -100
      ],
      "parameters": {
        "options": {
          "responseCode": 200,
          "responseHeaders": {
            "entries": [
              {
                "name": "Content-Type",
                "value": "text/html"
              }
            ]
          }
        },
        "respondWith": "text",
        "responseBody": "={{ $json.html }}"
      },
      "typeVersion": 1.1
    },
    {
      "id": "fdbfe60b-e677-4897-ab1a-9a9f506bba27",
      "name": "Workflow Tags",
      "type": "n8n-nodes-base.html",
      "position": [
        4660,
        500
      ],
      "parameters": {
        "html": "- **Click to filter by tag:**\n{{ [...new Set($jmespath($input.all(),'[].json.tags[].name'))].map(tag => `- [${tag}](tag-${encodeURIComponent(tag)})`).join('\\n') }}"
      },
      "executeOnce": true,
      "typeVersion": 1.2
    },
    {
      "id": "94a258ed-c07c-42d4-8d37-3395fad205b0",
      "name": "No Operation, do nothing",
      "type": "n8n-nodes-base.noOp",
      "position": [
        1740,
        1880
      ],
      "parameters": {},
      "typeVersion": 1
    },
    {
      "id": "c35ca075-52e7-4c2f-9891-f709afe36e52",
      "name": "Merge",
      "type": "n8n-nodes-base.merge",
      "position": [
        3140,
        1100
      ],
      "parameters": {
        "mode": "combine",
        "options": {},
        "combineBy": "combineByPosition",
        "numberInputs": 3
      },
      "typeVersion": 3
    },
    {
      "id": "55a1e32f-b20c-4b1f-9d6f-9bc4ec221fab",
      "name": "Fallback file name",
      "type": "n8n-nodes-base.html",
      "position": [
        4660,
        1900
      ],
      "parameters": {
        "html": "> File: {{ $json.params.file }}"
      },
      "typeVersion": 1.2
    },
    {
      "id": "3eef159b-99ad-4c9a-82f4-13bf16972521",
      "name": "mkdir",
      "type": "n8n-nodes-base.executeCommand",
      "position": [
        2100,
        1060
      ],
      "parameters": {
        "command": "=mkdir -p {{$('CONFIG').first().json.project_path}}"
      },
      "typeVersion": 1
    },
    {
      "id": "15fda233-925b-4a4d-964e-1916c0cd39a2",
      "name": "Merge1",
      "type": "n8n-nodes-base.merge",
      "position": [
        2240,
        880
      ],
      "parameters": {
        "mode": "chooseBranch"
      },
      "typeVersion": 3
    },
    {
      "id": "3e6c9243-d5f7-4f04-8231-9994963df36d",
      "name": "Edit Page",
      "type": "n8n-nodes-base.html",
      "position": [
        4660,
        860
      ],
      "parameters": {
        "html": "<!DOCTYPE html>\n<html>\n <head>\n{{ $('CONFIG').first().json.HTML_headers }}\n{{ $('CONFIG').first().json.HTML_styles_editor }}\n </head>\n <body>\n <div class=\"container\">\n <div class=\"button-container\">\n <button class=\"button save-button\" onclick=\"saveContent()\">Save</button>\n <button class=\"button cancel-button\" onclick=\"closeWindow()\">Cancel</button>\n </div>\n <div class=\"editor-preview-container\">\n <textarea id=\"editor\">{{ $json.workflowdata }}</textarea>\n <div class=\"preview-container\">\n <div id=\"preview\"></div>\n </div>\n </div>\n </div>\n \n<script>\n const editor = document.getElementById('editor');\n let vm;\n\n mermaid.initialize({\n startOnLoad: false,\n });\n\n let svgCounter = 0;\n\n // Function to save content\n async function saveContent() {\n try {\n const response = await fetch(window.location.pathname + '?action=save', {\n method: 'POST',\n headers: {\n 'Content-Type': 'application/json',\n },\n body: JSON.stringify({\n content: editor.value\n })\n });\n \n if (response.ok) {\n alert('Successfully saved!');\n } else {\n alert('Failed to save content');\n }\n } catch (error) {\n console.error('Error saving content:', error);\n alert('Error saving content');\n }\n }\n \n // Function to close window\n function closeWindow() {\n window.close();\n }\n \n window.$docsify = {\n el: '#preview',\n loadSidebar: false,\n loadNavbar: false,\n basePath: '/',\n hideSidebar: true,\n markdown: {\n renderer: {\n code(code, lang) {\n if (lang === \"mermaid\") {\n const svgName = `mermaid-svg-${svgCounter++}`;\n const MERMAID_CONTAINER_ID = `${svgName}-container`;\n mermaid.render(svgName, code).then(({ svg }) => {\n const containerElement = document.querySelector(\n `#${MERMAID_CONTAINER_ID}`\n );\n if (containerElement) {\n containerElement.innerHTML = svg;\n } else {\n console.error(`Error: #${MERMAID_CONTAINER_ID} not found`);\n }\n });\n return `<div class=\"mermaid\" id=\"${MERMAID_CONTAINER_ID}\"></div>`;\n }\n return this.origin.code.apply(this, arguments);\n },\n },\n },\n plugins: [\n function(hook, _vm) {\n vm = _vm;\n \n hook.beforeEach(function(content) {\n return editor.value;\n });\n }\n ]\n };\n \nlet timeout;\nfunction updatePreview() {\n clearTimeout(timeout);\n timeout = setTimeout(() => {\n if (vm) {\n const markdownSection = document.querySelector('.markdown-section');\n if (markdownSection) {\n const compiler = new window.DocsifyCompiler({\n basePath: '/',\n relativePath: false,\n fallbackLanguages: [],\n nameLink: '/',\n routerMode: 'hash'\n }, vm.router);\n \n const html = compiler.compile(editor.value);\n markdownSection.innerHTML = html;\n window.Prism.highlightAll();\n\n // Re-render all mermaid diagrams\n const mermaidDivs = markdownSection.querySelectorAll('pre[data-lang=\"mermaid\"] code');\n mermaidDivs.forEach((div, index) => {\n const code = div.textContent;\n const svgName = `mermaid-svg-${svgCounter++}`;\n const MERMAID_CONTAINER_ID = `${svgName}-container`;\n \n // Replace the <pre> element with our container\n const container = document.createElement('div');\n container.className = 'mermaid';\n container.id = MERMAID_CONTAINER_ID;\n div.parentElement.replaceWith(container);\n \n // Render the diagram\n mermaid.render(svgName, code).then(({ svg }) => {\n const containerElement = document.getElementById(MERMAID_CONTAINER_ID);\n if (containerElement) {\n containerElement.innerHTML = svg;\n }\n });\n });\n }\n }\n }, 500);\n};\n \n editor.addEventListener('input', updatePreview);\n</script>\n{{ $('CONFIG').first().json.HTML_docsify_include }}\n </body>\n</html>"
      },
      "typeVersion": 1.2
    },
    {
      "id": "71e136d5-bb5b-4eab-8cab-bfc50ea2a5a5",
      "name": "Workflow md content",
      "type": "n8n-nodes-base.html",
      "position": [
        4660,
        1040
      ],
      "parameters": {
        "html": "{{ $json.workflowdata }}"
      },
      "executeOnce": true,
      "typeVersion": 1.2
    },
    {
      "id": "6cb6f3b8-de65-43a5-9df3-48299ba7fcce",
      "name": "Is Action Edit?1",
      "type": "n8n-nodes-base.if",
      "position": [
        3300,
        1100
      ],
      "parameters": {
        "options": {},
        "conditions": {
          "options": {
            "version": 2,
            "leftValue": "",
            "caseSensitive": true,
            "typeValidation": "strict"
          },
          "combinator": "and",
          "conditions": [
            {
              "id": "856cdb3b-a187-4db5-b77b-43ee086780ee",
              "operator": {
                "name": "filter.operator.equals",
                "type": "string",
                "operation": "equals"
              },
              "leftValue": "={{ $json.query.action }}",
              "rightValue": "edit"
            }
          ]
        }
      },
      "typeVersion": 2.2
    },
    {
      "id": "aff9ed71-bb49-4170-9ae3-5f05f89bab05",
      "name": "Is Action Edit?2",
      "type": "n8n-nodes-base.if",
      "position": [
        4180,
        880
      ],
      "parameters": {
        "options": {},
        "conditions": {
          "options": {
            "version": 2,
            "leftValue": "",
            "caseSensitive": true,
            "typeValidation": "strict"
          },
          "combinator": "and",
          "conditions": [
            {
              "id": "e3648023-8cb7-4b82-bd35-1ba196458327",
              "operator": {
                "name": "filter.operator.equals",
                "type": "string",
                "operation": "equals"
              },
              "leftValue": "={{ $json.query.action }}",
              "rightValue": "edit"
            }
          ]
        }
      },
      "typeVersion": 2.2
    },
    {
      "id": "7b3d31a9-ee01-4bce-bc5b-78161536999d",
      "name": "Generate Mermaid Chart",
      "type": "n8n-nodes-base.code",
      "position": [
        3000,
        1260
      ],
      "parameters": {
        "jsCode": "const workflow = $input.first().json;\n\n// Extract nodes from the workflow\nconst nodes = workflow.nodes || [];\n\n// Node types to exclude\nconst excludedNodeTypes = ['n8n-nodes-base.stickyNote'];\n\n// Define shapes and their corresponding brackets\n// https://mermaid.js.org/syntax/flowchart.html\nconst shapes = {\n 'rect': ['[', ']'],\n 'rhombus': ['{', '}'],\n 'circle': ['((', '))'],\n 'hexagon': ['{{', '}}'],\n 'subroutine': ['[[', ']]'],\n 'parallelogram': ['[\\/', '\\/]'],\n 'wait': ['(', ')']\n // Add more shapes here as needed\n};\n\n// Define special shapes for specific node types\nconst specialShapes = {\n 'n8n-nodes-base.if': 'rhombus',\n 'n8n-nodes-base.switch': 'rhombus',\n 'n8n-nodes-base.code': 'subroutine',\n 'n8n-nodes-base.executeWorkflow': 'subroutine',\n 'n8n-nodes-base.httpRequest':'parallelogram',\n 'n8n-nodes-base.wait':'wait'\n // List more special node types\n};\n\n// Function to get the shape for a node type\nfunction getNodeShape(nodeType) {\n return specialShapes[nodeType] || 'rect';\n}\n\n// Create a map of node names to their \"EL<N>\" identifiers, disabled status, and shape\nconst nodeMap = {};\nlet nodeCounter = 1;\nnodes.forEach((node) => {\n if (!excludedNodeTypes.includes(node.type)) {\n const shape = getNodeShape(node.type);\n nodeMap[node.name] = {\n id: `EL${nodeCounter}`,\n disabled: node.disabled || false,\n shape: shape,\n brackets: shapes[shape] || shapes['rect'] // Default to rect if shape not found\n };\n nodeCounter++;\n }\n});\n\n// Function to convert special characters to HTML entities\nfunction convertToHTMLEntities(str) {\n return str.replaceAll('\"',\"'\").replace(/[^\\w\\s-]/g, function(char) {\n return '&#' + char.charCodeAt(0) + ';';\n });\n}\n\n// Function to format node text (with strike-through if disabled)\nfunction formatNodeText(nodeName, isDisabled) {\n const escapedName = convertToHTMLEntities(nodeName);\n return isDisabled ? `<s>${escapedName}</s>` : escapedName;\n}\n\n// Generate connections and isolated nodes\nconst connections = [];\nconst isolatedNodes = new Set(Object.keys(nodeMap));\n\nif (workflow.connections) {\n Object.entries(workflow.connections).forEach(([sourceName, targetConnections]) => {\n Object.entries(targetConnections).forEach(([connectionType, targets]) => {\n targets.forEach(targetArray => {\n targetArray.forEach(target => {\n const sourceNode = nodeMap[sourceName];\n const targetNode = nodeMap[target.node];\n if (sourceNode && targetNode) {\n let connectionLine = ` ${sourceNode.id}${sourceNode.brackets[0]}${formatNodeText(sourceName, sourceNode.disabled)}${sourceNode.brackets[1]}`;\n if (connectionType === 'main') {\n connectionLine += ` -->`;\n } else {\n connectionLine += ` -.- |${connectionType}|`;\n }\n connectionLine += ` ${targetNode.id}${targetNode.brackets[0]}${formatNodeText(target.node, targetNode.disabled)}${targetNode.brackets[1]}`;\n connections.push(connectionLine);\n isolatedNodes.delete(sourceName);\n isolatedNodes.delete(target.node);\n }\n });\n });\n });\n });\n}\n\n// Add isolated nodes to the connections array\nisolatedNodes.forEach(nodeName => {\n const node = nodeMap[nodeName];\n connections.push(` ${node.id}${node.brackets[0]}${formatNodeText(nodeName, node.disabled)}${node.brackets[1]}`);\n});\n\n// Generate the Mermaid flowchart string\nconst mermaidChart = `---\nconfig:\n look: neo\n theme: default\n---\nflowchart LR\n${connections.join('\\n')}`;\n\n// Output the result\nreturn {\n json: {\n mermaidChart: mermaidChart\n }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "77a35cd5-cb8f-4ac5-a699-dff5e65cda09",
      "name": "Merge2",
      "type": "n8n-nodes-base.merge",
      "position": [
        3840,
        1140
      ],
      "parameters": {
        "mode": "combine",
        "options": {},
        "combineBy": "combineByPosition"
      },
      "typeVersion": 3
    },
    {
      "id": "f8119590-e9d7-4513-9da4-fa911165baff",
      "name": "Generated Doc",
      "type": "n8n-nodes-base.set",
      "position": [
        4000,
        1240
      ],
      "parameters": {
        "options": {},
        "assignments": {
          "assignments": [
            {
              "id": "7693348d-5129-4a07-809d-b0619b9fc44b",
              "name": "workflowdata",
              "type": "string",
              "value": "=# {{ $json.name }}\n\n{{ $json?.output?.workflow_description || \"## <SORRY, COULD NOT GENERATE WORKFLOW DESCRIPTION>\" }}\n\n## Workflow schematic\n\n```mermaid\n{{ $json.mermaidChart }}\n```\n\n{{ $json?.output?.nodes_settings || \"## <SORRY, COULD NOT GENERATE DOCS FOR NODE SETTING>\" }}"
            }
          ]
        }
      },
      "typeVersion": 3.4
    },
    {
      "id": "92565206-6cf2-4243-9143-4f6def4b524d",
      "name": "Passthrough",
      "type": "n8n-nodes-base.noOp",
      "position": [
        2100,
        1240
      ],
      "parameters": {},
      "typeVersion": 1
    },
    {
      "id": "73081fc3-9554-4a12-b985-da02b356616f",
      "name": "Merge3",
      "type": "n8n-nodes-base.merge",
      "position": [
        3140,
        880
      ],
      "parameters": {
        "mode": "combine",
        "options": {},
        "combineBy": "combineByPosition"
      },
      "typeVersion": 3
    },
    {
      "id": "f50e72f8-9027-4ca7-9df7-700e828f48eb",
      "name": "Merge4",
      "type": "n8n-nodes-base.merge",
      "position": [
        960,
        -100
      ],
      "parameters": {
        "mode": "combine",
        "options": {},
        "combineBy": "combineByPosition"
      },
      "typeVersion": 3
    },
    {
      "id": "306820ac-7c87-45c2-b76f-55d772ac7300",
      "name": "Merge5",
      "type": "n8n-nodes-base.merge",
      "position": [
        960,
        240
      ],
      "parameters": {
        "mode": "combine",
        "options": {},
        "combineBy": "combineByPosition"
      },
      "typeVersion": 3
    },
    {
      "id": "96fd7265-7920-453f-8309-bdbd10880d03",
      "name": "Edit Fields",
      "type": "n8n-nodes-base.set",
      "position": [
        2100,
        1600
      ],
      "parameters": {
        "options": {},
        "assignments": {
          "assignments": [
            {
              "id": "8bc55c5b-e09a-459b-bbb6-ed5f70d4f353",
              "name": "workflowdata",
              "type": "string",
              "value": "={{ $json.body.content }}"
            }
          ]
        },
        "includeOtherFields": true
      },
      "typeVersion": 3.4
    },
    {
      "id": "2fffb547-1c11-4663-aed5-29b9557e8738",
      "name": "Is Action Save?",
      "type": "n8n-nodes-base.if",
      "position": [
        4540,
        1600
      ],
      "parameters": {
        "options": {},
        "conditions": {
          "options": {
            "version": 2,
            "leftValue": "",
            "caseSensitive": true,
            "typeValidation": "strict"
          },
          "combinator": "and",
          "conditions": [
            {
              "id": "e3648023-8cb7-4b82-bd35-1ba196458327",
              "operator": {
                "name": "filter.operator.equals",
                "type": "string",
                "operation": "equals"
              },
              "leftValue": "={{ $json?.query?.action }}",
              "rightValue": "save"
            },
            {
              "id": "a44c9cc5-5717-4c34-978b-e644219a9cc1",
              "operator": {
                "type": "string",
                "operation": "exists",
                "singleValue": true
              },
              "leftValue": "={{ $json?.query?.action }}",
              "rightValue": ""
            }
          ]
        }
      },
      "typeVersion": 2.2
    },
    {
      "id": "15825037-a8e2-4fbc-b529-2bf89810a116",
      "name": "Merge6",
      "type": "n8n-nodes-base.merge",
      "position": [
        4360,
        1700
      ],
      "parameters": {
        "mode": "chooseBranch",
        "useDataOfInput": 2
      },
      "typeVersion": 3
    },
    {
      "id": "b47f18a4-9b59-4278-890d-b6f6c596c554",
      "name": "Respond OK on Save",
      "type": "n8n-nodes-base.respondToWebhook",
      "position": [
        4920,
        1580
      ],
      "parameters": {
        "options": {
          "responseCode": 200
        },
        "respondWith": "noData"
      },
      "typeVersion": 1.1
    },
    {
      "id": "273dfd58-abef-49b7-8f12-5abc3d3515a6",
      "name": "single workflow",
      "type": "n8n-nodes-base.webhook",
      "position": [
        240,
        240
      ],
      "parameters": {
        "path": "/:file",
        "options": {},
        "responseMode": "responseNode",
        "multipleMethods": true
      },
      "typeVersion": 2
    },
    {
      "id": "a7d7ee50-1420-475b-9028-0c80e1ae2241",
      "name": "Sticky Note",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        140,
        -242.54375384615383
      ],
      "parameters": {
        "width": 296.5956923076922,
        "height": 277.9529846153844,
        "content": "## Main Docsify webhook\nIn response, n8n serves the main html page with the [Docsify JS library](https://docsify.js.org/)"
      },
      "typeVersion": 1
    },
    {
      "id": "b7c4b82a-9722-48ae-ab6a-4335981356ad",
      "name": "Sticky Note1",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        -77.62340912473337,
        108.96056004923076
      ],
      "parameters": {
        "width": 509.1040245093486,
        "height": 287.9568584558579,
        "content": "## Single page requests\n* Docsify may request default pages (i.e. `readme.md` or a `summary.md`)\n* GET request for the workflow documentation pages\n* POST request for saving manually edited doc page"
      },
      "typeVersion": 1
    },
    {
      "id": "18e1f4c5-3652-4244-9a09-cd7a498a9310",
      "name": "Sticky Note2",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        460,
        -240.54580345183416
      ],
      "parameters": {
        "color": 3,
        "width": 489.50636350106504,
        "height": 462.9720128227216,
        "content": "## EDIT THIS!\n* `project_path` to link to a writable directory that is accessible to n8n\n* update `instance_url` when running in the cloud version. If using in self-hosted mode, make sure N8N_PROTOCOL and N8N_HOST .env variables are correct"
      },
      "typeVersion": 1
    },
    {
      "id": "d505d2ec-33e9-4983-8265-ff55f0df3da8",
      "name": "file types",
      "type": "n8n-nodes-base.switch",
      "position": [
        1180,
        240
      ],
      "parameters": {
        "rules": {
          "values": [
            {
              "outputKey": ".md",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "operator": {
                      "type": "string",
                      "operation": "endsWith"
                    },
                    "leftValue": "={{ $json.params.file.toLowerCase() }}",
                    "rightValue": ".md"
                  }
                ]
              },
              "renameOutput": true
            }
          ]
        },
        "options": {
          "fallbackOutput": "extra",
          "renameFallbackOutput": "unknown"
        }
      },
      "typeVersion": 3.2
    },
    {
      "id": "59362792-4a3e-4f97-95e2-d7b33b870e1d",
      "name": "Sticky Note3",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        4620,
        -245.7696645512633
      ],
      "parameters": {
        "width": 446.67466982248516,
        "height": 309.89805271694365,
        "content": "## Construct main HTML page and send it back to the user\n* `HTML_headers` and `HTML_docsify_include` are stored in the CONFIG node for the page simplicity"
      },
      "typeVersion": 1
    },
    {
      "id": "83189146-4d1f-454e-9591-bdbfda676683",
      "name": "Get All Workflows",
      "type": "n8n-nodes-base.n8n",
      "position": [
        1880,
        160
      ],
      "parameters": {
        "filters": {
          "tags": "={{ decodeURIComponent(($json.params.file?.match(/^tag-(.+)\\.md$/))?.[1] || '') }}"
        },
        "requestOptions": {}
      },
      "credentials": {
        "n8nApi": {
          "name": "<your credential>"
        }
      },
      "typeVersion": 1,
      "alwaysOutputData": true
    },
    {
      "id": "39aa6017-a0ef-4f05-81b8-cfc9bb2fcc20",
      "name": "Sticky Note4",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        1780,
        20.913927466176517
      ],
      "parameters": {
        "width": 820.1843305645202,
        "height": 307.51990359708003,
        "content": "## Serve main Markdown table with the workflow overview\n*NOTE! Here we don't reply with HTML content. Only Markdown elements are sent back and processed by the JS library*\n* Create an overall table when `README.md` (the home page) is requested\n* Create a table with a subset of workflows when a tag from a navigation pane is selected"
      },
      "typeVersion": 1
    },
    {
      "id": "2d087c25-b998-4abc-b0ce-ede8e62e28b4",
      "name": "md files",
      "type": "n8n-nodes-base.switch",
      "position": [
        1440,
        180
      ],
      "parameters": {
        "rules": {
          "values": [
            {
              "outputKey": "README.md",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "operator": {
                      "type": "string",
                      "operation": "equals"
                    },
                    "leftValue": "={{ $json.params.file }}",
                    "rightValue": "README.md"
                  }
                ]
              },
              "renameOutput": true
            },
            {
              "outputKey": "docs",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "id": "c1c1aecc-8faa-47ea-b831-4674c3c0db61",
                    "operator": {
                      "type": "string",
                      "operation": "contains"
                    },
                    "leftValue": "={{ $json.params.file }}",
                    "rightValue": "docs_"
                  }
                ]
              },
              "renameOutput": true
            },
            {
              "outputKey": "summary.md",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "id": "fde643c9-31cd-4cbd-b4de-99a8ad6202af",
                    "operator": {
                      "name": "filter.operator.equals",
                      "type": "string",
                      "operation": "equals"
                    },
                    "leftValue": "={{ $json.params.file }}",
                    "rightValue": "summary.md"
                  }
                ]
              },
              "renameOutput": true
            },
            {
              "outputKey": "tags",
              "conditions": {
                "options": {
                  "version": 2,
                  "leftValue": "",
                  "caseSensitive": true,
                  "typeValidation": "strict"
                },
                "combinator": "and",
                "conditions": [
                  {
                    "id": "df4bc9f8-9285-49a6-b31c-d7173bf42901",
                    "operator": {
                      "type": "string",
                      "operation": "startsWith"
                    },
                    "leftValue": "={{ $json.params.file }}",
                    "rightValue": "tag-"
                  }
                ]
              },
              "renameOutput": true
            }
          ]
        },
        "options": {
          "fallbackOutput": "extra"
        }
      },
      "typeVersion": 3.2
    },
    {
      "id": "08524df2-d555-42ca-8440-57ca5a780b74",
      "name": "Get Workflow tags",
      "type": "n8n-nodes-base.n8n",
      "position": [
        1880,
        500
      ],
      "parameters": {
        "filters": {},
        "requestOptions": {}
      },
      "credentials": {
        "n8nApi": {
          "name": "<your credential>"
        }
      },
      "typeVersion": 1
    },
    {
      "id": "06e383dc-b1ea-4c97-9ee4-c07084ffc4cc",
      "name": "Sticky Note5",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        1780,
        360
      ],
      "parameters": {
        "width": 817.6163848212657,
        "height": 288.20835077550953,
        "content": "## Serve left pane content\n* Here all workflows are fetched again when `summary.md` file is requested.\n\nIt contains Markdown for the left navigation pane: a list of all tags"
      },
      "typeVersion": 1
    },
    {
      "id": "c28ae282-7d83-42dd-8714-30d26b0f20af",
      "name": "Sticky Note6",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        1700,
        1780
      ],
      "parameters": {
        "width": 367.8950651848079,
        "height": 262.5093167050718,
        "content": "## Handle missing pages\nServe the Markdown content with the requested file name for edge cases, i.e. any unexpected files"
      },
      "typeVersion": 1
    },
    {
      "id": "6441cf8f-dace-45fb-984e-aa9e0589e495",
      "name": "Sticky Note7",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        1020,
        729
      ],
      "parameters": {
        "color": 6,
        "width": 4161.578473434268,
        "height": 1142.0268674813442,
        "content": "# Main functionality here\n\n## * View existing documentation\n## * Auto-generate doc page if no file available\n## * Re-created autodoc page\n## * Edit doc page: LIVE Markdown editor included!\n## * Save edited file. WARNING! No authentication"
      },
      "typeVersion": 1
    },
    {
      "id": "9116a4eb-18c6-4ec2-84e8-9a0b920d5c19",
      "name": "Sticky Note8",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        4460,
        751
      ],
      "parameters": {
        "width": 652.3100890494833,
        "height": 268.0620091282372,
        "content": "## Custom markdown editor\nThis is another HTML page for the live Markdown editor\n* `Mermaid.js` is supported\n* Docsify preview on edit\n* Save or Cancel buttons"
      },
      "typeVersion": 1
    },
    {
      "id": "920c1edb-29ad-4952-9e30-9020146ed88a",
      "name": "Sticky Note9",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        4000,
        1501
      ],
      "parameters": {
        "width": 522.870786668288,
        "height": 348.0868581511653,
        "content": "## Save new file\nOnce the doc page is generated or edited manually, a Markdown files is saved in the directory"
      },
      "typeVersion": 1
    },
    {
      "id": "cff4d2be-f627-4c7d-9f7a-093f6f9b2c27",
      "name": "Sticky Note10",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        1887,
        758
      ],
      "parameters": {
        "width": 639.8696984316115,
        "height": 429.7891698152571,
        "content": "## Load existing doc file\nCheck the existing file when the View or Edit button is pressed\n"
      },
      "typeVersion": 1
    },
    {
      "id": "b7f01785-99c7-47b2-967a-b7456bb8f562",
      "name": "Sticky Note11",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        2786.9421822644376,
        1023
      ],
      "parameters": {
        "width": 1369.2986733206085,
        "height": 466.42237140646773,
        "content": "## If the file is not available, then:\n* either auto-generate new doc\n* prepare a basic template for editing"
      },
      "typeVersion": 1
    },
    {
      "id": "6953bf0c-3122-4d80-9e74-1c07a892bf31",
      "name": "docsify",
      "type": "n8n-nodes-base.webhook",
      "position": [
        240,
        -100
      ],
      "parameters": {
        "path": "135bc21f-c7d0-4afe-be73-f984d444b43b",
        "options": {},
        "responseMode": "responseNode"
      },
      "typeVersion": 2
    }
  ],
  "active": true,
  "settings": {
    "callerPolicy": "workflowsFromSameOwner",
    "executionOrder": "v1",
    "executionTimeout": 120,
    "saveManualExecutions": true,
    "saveDataSuccessExecution": "all"
  },
  "versionId": "eee9144a-c7a0-4947-874b-728d9e8618b7",
  "connections": {
    "Merge": {
      "main": [
        [
          {
            "node": "Is Action Edit?1",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "mkdir": {
      "main": [
        [
          {
            "node": "Merge1",
            "type": "main",
            "index": 1
          }
        ]
      ]
    },
    "CONFIG": {
      "main": [
        [
          {
            "node": "Merge4",
            "type": "main",
            "index": 1
          },
          {
            "node": "Merge5",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Merge1": {
      "main": [
        [
          {
            "node": "HasFile?",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Merge2": {
      "main": [
        [
          {
            "node": "Generated Doc",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Merge3": {
      "main": [
        [
          {
            "node": "Is Action Edit?2",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Merge4": {
      "main": [
        [
          {
            "node": "Main Page",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Merge5": {
      "main": [
        [
          {
            "node": "file types",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Merge6": {
      "main": [
        [
          {
            "node": "Is Action Save?",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "docsify": {
      "main": [
        [
          {
            "node": "CONFIG",
            "type": "main",
            "index": 0
          },
          {
            "node": "Merge4",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "HasFile?": {
      "main": [
        [
          {
            "node": "Extract from File",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Fetch Single Workflow1",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "md files": {
      "main": [
        [
          {
            "node": "Get All Workflows",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "doc action",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Get Workflow tags",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Get All Workflows",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "No Operation, do nothing",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Edit Page": {
      "main": [
        [
          {
            "node": "Respond with HTML",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Empty Set": {
      "main": [
        [
          {
            "node": "Merge1",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Main Page": {
      "main": [
        [
          {
            "node": "Respond with main page HTML",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "doc action": {
      "main": [
        [
          {
            "node": "mkdir",
            "type": "main",
            "index": 0
          },
          {
            "node": "Load Doc File",
            "type": "main",
            "index": 0
          },
          {
            "node": "Passthrough",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "mkdir",
            "type": "main",
            "index": 0
          },
          {
            "node": "Load Doc File",
            "type": "main",
            "index": 0
          },
          {
            "node": "Passthrough",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "mkdir",
            "type": "main",
            "index": 0
          },
          {
            "node": "Empty Set",
            "type": "main",
            "index": 0
          },
          {
            "node": "Passthrough",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Edit Fields",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "file types": {
      "main": [
        [
          {
            "node": "md files",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Edit Fields": {
      "main": [
        [
          {
            "node": "Convert to File",
            "type": "main",
            "index": 0
          },
          {
            "node": "Merge6",
            "type": "main",
            "index": 1
          }
        ]
      ]
    },
    "Passthrough": {
      "main": [
        [
          {
            "node": "Merge3",
            "type": "main",
            "index": 1
          },
          {
            "node": "Merge",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Generated Doc": {
      "main": [
        [
          {
            "node": "Convert to File",
            "type": "main",
            "index": 0
          },
          {
            "node": "Is Action Edit?2",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Load Doc File": {
      "main": [
        [
          {
            "node": "Merge1",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Workflow Tags": {
      "main": [
        [
          {
            "node": "Respond with markdown",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Blank Doc File": {
      "main": [
        [
          {
            "node": "Is Action Edit?2",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Sort-workflows": {
      "main": [
        [
          {
            "node": "Fill Workflow Table",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Basic LLM Chain": {
      "main": [
        [
          {
            "node": "Merge2",
            "type": "main",
            "index": 1
          }
        ]
      ]
    },
    "Convert to File": {
      "main": [
        [
          {
            "node": "Save New Doc File",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Is Action Save?": {
      "main": [
        [
          {
            "node": "Respond OK on Save",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "single workflow": {
      "main": [
        [
          {
            "node": "CONFIG",
            "type": "main",
            "index": 0
          },
          {
            "node": "Merge5",
            "type": "main",
            "index": 1
          }
        ],
        [
          {
            "node": "CONFIG",
            "type": "main",
            "index": 0
          },
          {
            "node": "Merge5",
            "type": "main",
            "index": 1
          }
        ]
      ]
    },
    "Is Action Edit?1": {
      "main": [
        [
          {
            "node": "Blank Doc File",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Basic LLM Chain",
            "type": "main",
            "index": 0
          },
          {
            "node": "Merge2",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Is Action Edit?2": {
      "main": [
        [
          {
            "node": "Edit Page",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Workflow md content",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Extract from File": {
      "main": [
        [
          {
            "node": "Merge3",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Get All Workflows": {
      "main": [
        [
          {
            "node": "Sort-workflows",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Get Workflow tags": {
      "main": [
        [
          {
            "node": "Workflow Tags",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Instance overview": {
      "main": [
        [
          {
            "node": "Respond with markdown",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "OpenAI Chat Model": {
      "ai_languageModel": [
        [
          {
            "node": "Basic LLM Chain",
            "type": "ai_languageModel",
            "index": 0
          },
          {
            "node": "Auto-fixing Output Parser",
            "type": "ai_languageModel",
            "index": 0
          }
        ]
      ]
    },
    "Save New Doc File": {
      "main": [
        [
          {
            "node": "Merge6",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Fallback file name": {
      "main": [
        [
          {
            "node": "Respond with markdown",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Fill Workflow Table": {
      "main": [
        [
          {
            "node": "Instance overview",
            "type": "main",
            "index": 0
          }
        ]
      ]


Credentials you'll need

Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.

• n8nApi
• openAiApi

How this works

This workflow transforms raw documentation inputs into a polished, navigable HTML site using Docsify, delivering an instant knowledge base for your projects without manual coding. It's ideal for developers, technical writers, or teams managing guides who need quick, interactive docs from files or webhooks. The key step involves extracting content with the extractFromFile node, processing it through HTML generation and sorting for structure, then outputting a ready-to-deploy site integrated with OpenAI for smart content refinement.

Use this when you have unstructured docs needing fast conversion to a lightweight site, like onboarding materials or API references triggered by updates. Avoid it for complex sites requiring full CMS features, as it's best for simple, file-based setups. Common variations include swapping OpenAI for another LLM or adding email notifications for deployment alerts.

About this workflow

Docsify example. Uses convertToFile, extractFromFile, html, sort. Webhook trigger; 60 nodes.

Source: https://github.com/Zie619/n8n-workflows — original creator credit. Request a take-down →

More AI & RAG workflows → · Browse all categories →

Related workflows

Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
