Estimate Construction Costs From Revit/ifc Models with Gpt-4 and Claude

The workflow JSON

Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →

{
  "id": "Z1UKztds8E5oQSMe",
  "meta": {
    "templateCredsSetupCompleted": true
  },
  "name": "n8n_6_Construction_Price_Estimation_with_LLM_for_Revt_and_IFC",
  "tags": [],
  "nodes": [
    {
      "id": "44ac22bc-92ff-450d-ac53-b2b587cc0318",
      "name": "When clicking \u2018Execute workflow\u2019",
      "type": "n8n-nodes-base.manualTrigger",
      "position": [
        944,
        -64
      ],
      "parameters": {},
      "typeVersion": 1
    },
    {
      "id": "2b81e046-ebc1-4687-8fd2-b9d2a3347a12",
      "name": "Find Category Fields1",
      "type": "n8n-nodes-base.code",
      "position": [
        1360,
        768
      ],
      "parameters": {
        "jsCode": "\nconst items = $input.all();\nif (items.length === 0) {\n  return [{json: {error: 'No grouped data found'}}];\n}\n\n\nconst headers = Object.keys(items[0].json);\n\n\nconst categoryPatterns = [\n  { pattern: /^category$/i, type: 'Category' },\n  { pattern: /^ifc[\\s_-]?type$/i, type: 'IFC' },\n  { pattern: /^host[\\s_-]?category$/i, type: 'Host' },\n  { pattern: /^ifc[\\s_-]?export[\\s_-]?as$/i, type: 'Export' },\n  { pattern: /^layer$/i, type: 'Layer' }\n];\n\nlet categoryField = null;\nlet categoryFieldType = 'None';\n\n\nfor (const header of headers) {\n  for (const {pattern, type} of categoryPatterns) {\n    if (pattern.test(header)) {\n      categoryField = header;\n      categoryFieldType = type;\n      break;\n    }\n  }\n  if (categoryField) break;\n}\n\n\nconst volumetricPatterns = /volume|area|length|count|quantity|thickness|perimeter|depth|size|dimension|weight|mass/i;\nconst volumetricFields = headers.filter(header => volumetricPatterns.test(header));\n\n\nconst categoryValues = new Set();\nif (categoryField) {\n  items.forEach(item => {\n    const value = item.json[categoryField];\n    if (value && value !== '' && value !== null) {\n      categoryValues.add(value);\n    }\n  });\n}\n\nconsole.log('Category field analysis:');\nconsole.log('- Field found:', categoryField || 'None');\nconsole.log('- Field type:', categoryFieldType);\nconsole.log('- Unique values:', categoryValues.size);\nconsole.log('- Volumetric fields:', volumetricFields.length);\n\n\nreturn [{\n  json: {\n    categoryField: categoryField,\n    categoryFieldType: categoryFieldType,\n    categoryValues: Array.from(categoryValues),\n    volumetricFields: volumetricFields,\n    groupedData: items.map(item => item.json),\n    totalGroups: items.length\n  }\n}];"
      },
      "typeVersion": 2
    },
    {
      "id": "65f07357-2e47-41ac-87ee-43d692b7511d",
      "name": "Apply Classification to Groups1",
      "type": "n8n-nodes-base.code",
      "position": [
        1872,
        832
      ],
      "parameters": {
        "jsCode": "\nconst categoryInfo = $node['Find Category Fields1'].json;\nconst groupedData = categoryInfo.groupedData;\nconst categoryField = categoryInfo.categoryField;\nconst volumetricFields = categoryInfo.volumetricFields || [];\n\n\nlet classifications = {};\nlet buildingCategories = [];\nlet drawingCategories = [];\n\ntry {\n  const aiResponse = $input.first().json;\n  const content = aiResponse.content || aiResponse.message || aiResponse.response || '';\n  \n  const jsonMatch = content.match(/\\{[\\s\\S]*\\}/);\n  if (jsonMatch) {\n    const parsed = JSON.parse(jsonMatch[0]);\n    classifications = parsed.classifications || {};\n    buildingCategories = parsed.building_categories || [];\n    drawingCategories = parsed.drawing_categories || [];\n    console.log(`AI classified ${Object.keys(classifications).length} categories`);\n    console.log(`Building categories: ${buildingCategories.length}`);\n    console.log(`Drawing categories: ${drawingCategories.length}`);\n  }\n} catch (error) {\n  console.error('Error parsing AI classification:', error.message);\n}\n\n\nreturn groupedData.map(group => {\n  let isBuildingElement = false;\n  let reason = '';\n  let confidence = 0;\n  \n  if (categoryField && group[categoryField]) {\n    \n    const categoryValue = group[categoryField];\n    \n    if (classifications[categoryValue] !== undefined) {\n      isBuildingElement = classifications[categoryValue];\n      confidence = 95;\n      reason = `Category '${categoryValue}' classified by AI as ${isBuildingElement ? 'building element' : 'drawing/annotation'}`;\n    } else {\n      \n      const lowerCategory = categoryValue.toLowerCase();\n      const drawingKeywords = /annotation|drawing|text|dimension|tag|view|sheet|grid|section|elevation|callout|revision|legend|symbol|mark|note|detail items|filled region|detail line/i;\n      const buildingKeywords = /wall|floor|roof|column|beam|door|window|stair|pipe|duct|equipment|fixture|furniture/i;\n      \n      if (drawingKeywords.test(lowerCategory)) {\n        isBuildingElement = false;\n        confidence = 85;\n        reason = `Category '${categoryValue}' matched drawing keywords`;\n      } else if (buildingKeywords.test(lowerCategory)) {\n        isBuildingElement = true;\n        confidence = 85;\n        reason = `Category '${categoryValue}' matched building keywords`;\n      } else {\n        \n        isBuildingElement = true;\n        confidence = 70;\n        reason = `Category '${categoryValue}' assumed as building element (no clear match)`;\n      }\n    }\n  } else {\n    \n    let hasSignificantVolumetricData = false;\n    let volumetricCount = 0;\n    \n    for (const field of volumetricFields) {\n      const value = parseFloat(group[field]);\n      if (!isNaN(value) && value > 0) {\n        hasSignificantVolumetricData = true;\n        volumetricCount++;\n      }\n    }\n    \n    isBuildingElement = hasSignificantVolumetricData;\n    confidence = hasSignificantVolumetricData ? 80 : 60;\n    reason = hasSignificantVolumetricData ? \n      `Has ${volumetricCount} volumetric parameters with values` : \n      'No category field and no significant volumetric data';\n  }\n  \n  return {\n    json: {\n      ...group,\n      is_building_element: isBuildingElement,\n      element_confidence: confidence,\n      element_reason: reason\n    }\n  };\n});"
      },
      "typeVersion": 2
    },
    {
      "id": "50462cce-7978-4147-b215-25749d3bbf79",
      "name": "Non-Building Elements Output1",
      "type": "n8n-nodes-base.set",
      "position": [
        2272,
        848
      ],
      "parameters": {
        "options": {},
        "assignments": {
          "assignments": [
            {
              "id": "message",
              "name": "message",
              "type": "string",
              "value": "Non-building elements (drawings, annotations, etc.)"
            }
          ]
        }
      },
      "typeVersion": 3.4
    },
    {
      "id": "93e37bf0-a126-4174-9bc6-a8a5378885a1",
      "name": "AI Classify Categories1",
      "type": "@n8n/n8n-nodes-langchain.openAi",
      "position": [
        1536,
        832
      ],
      "parameters": {
        "modelId": {
          "__rl": true,
          "mode": "list",
          "value": "chatgpt-4o-latest",
          "cachedResultName": "CHATGPT-4O-LATEST"
        },
        "options": {
          "maxTokens": 4000,
          "temperature": 0.1
        },
        "messages": {
          "values": [
            {
              "role": "system",
              "content": "You are an expert in Revit, BIM (Building Information Modeling) and construction classification. Your task is to classify category values as either building elements or non-building elements (drawings, annotations, etc.).\n\nBuilding elements include:\n- Structural elements (walls, floors, roofs, columns, beams, foundations, slabs)\n- MEP elements (pipes, ducts, equipment, fixtures, mechanical equipment)\n- Architectural elements (doors, windows, stairs, railings, curtain walls)\n- Site elements (parking, roads, landscaping)\n- Furniture and fixtures\n- Any physical construction element that has volume, area, or physical properties\n\nNon-building elements include:\n- Drawings and sheets\n- Annotations, dimensions, text notes\n- Views, sections, elevations, plans\n- Tags, symbols, legends, schedules\n- Grids, levels, reference planes\n- Revision clouds, callouts, detail items\n- Lines, filled regions, detail lines\n- Any 2D documentation or annotation element\n\nIMPORTANT: Analyze the actual category name, not just keywords. For example:\n- \"Detail Items\" = non-building (annotation)\n- \"Plumbing Fixtures\" = building element\n- \"Room Tags\" = non-building (annotation)\n- \"Structural Columns\" = building element\n\nReturn ONLY valid JSON in this exact format:\n{\n  \"classifications\": {\n    \"category_value_1\": true,\n    \"category_value_2\": false\n  },\n  \"building_categories\": [\"list\", \"of\", \"building\", \"categories\"],\n  \"drawing_categories\": [\"list\", \"of\", \"drawing\", \"categories\"]\n}"
            },
            {
              "content": "{{ $json.categoryField ? `Classify these ${$json.categoryValues.length} category values from field '${$json.categoryField}' as building elements (true) or drawings/annotations (false):\n\nCategory values:\n${JSON.stringify($json.categoryValues, null, 2)}\n\nCategory field type: ${$json.categoryFieldType}` : 'No category field found. Please classify based on volumetric data presence.'}}"
            }
          ]
        }
      },
      "credentials": {
        "openAiApi": {
          "name": "<your credential>"
        }
      },
      "typeVersion": 1.3
    },
    {
      "id": "2adc7c4e-1133-43bd-a3b8-8648a95861be",
      "name": "Is Building Element1",
      "type": "n8n-nodes-base.if",
      "position": [
        2064,
        832
      ],
      "parameters": {
        "conditions": {
          "boolean": [
            {
              "value1": "={{ $json.is_building_element }}",
              "value2": true
            }
          ]
        }
      },
      "typeVersion": 1
    },
    {
      "id": "a6b94ddd-8674-4072-8bb0-f2a813b4c042",
      "name": "Check If All Batches Done",
      "type": "n8n-nodes-base.if",
      "position": [
        1024,
        1280
      ],
      "parameters": {
        "options": {},
        "conditions": {
          "options": {
            "leftValue": "",
            "caseSensitive": true,
            "typeValidation": "strict"
          },
          "combinator": "and",
          "conditions": [
            {
              "id": "9af8b6d4-3a3a-4c4a-8d4d-d5a8c2958f5f",
              "operator": {
                "type": "boolean",
                "operation": "true",
                "singleValue": true
              },
              "leftValue": "={{ $node['Process in Batches1'].context['noItemsLeft'] }}",
              "rightValue": true
            }
          ]
        }
      },
      "typeVersion": 2
    },
    {
      "id": "6a62ad33-7c47-495d-b81b-3be78ae0cd81",
      "name": "Collect All Results",
      "type": "n8n-nodes-base.code",
      "position": [
        1200,
        1568
      ],
      "parameters": {
        "jsCode": "// Get all accumulated data and prepare for reporting\nconst storedData = $getWorkflowStaticData('global');\nconst allProcessedItems = storedData.accumulatedData || [];\n\nconsole.log(`\\n=== BATCH PROCESSING COMPLETE ===`);\nconsole.log(`Total items processed: ${allProcessedItems.length}`);\n\n// Clear accumulated data for next run\nstoredData.accumulatedData = [];\n\n// Return all items for report generation\nreturn allProcessedItems;"
      },
      "typeVersion": 2
    },
    {
      "id": "e3ab164d-d34c-4415-9ecc-d1e2dcd35ebe",
      "name": "Process in Batches1",
      "type": "n8n-nodes-base.splitInBatches",
      "position": [
        1184,
        1152
      ],
      "parameters": {
        "options": {},
        "batchSize": 1
      },
      "typeVersion": 1
    },
    {
      "id": "b1504e4e-6a04-4014-aeed-b38dbaa9b12d",
      "name": "Clean Empty Values1",
      "type": "n8n-nodes-base.code",
      "position": [
        1360,
        1152
      ],
      "parameters": {
        "jsCode": "// Clean empty values from the item\nreturn $input.all().map(item => {\n  const cleanedJson = {};\n  Object.entries(item.json).forEach(([key, value]) => {\n    if (value !== null) {\n      if (typeof value === 'number') {\n        if (value !== 0 || key === 'Element Count') {\n          cleanedJson[key] = value;\n        }\n      } else if (value !== '') {\n        cleanedJson[key] = value;\n      }\n    }\n  });\n  return { json: cleanedJson };\n});"
      },
      "typeVersion": 2
    },
    {
      "id": "d152a0a9-71c9-4532-9743-15225429bcc8",
      "name": "AI Agent Enhanced",
      "type": "@n8n/n8n-nodes-langchain.agent",
      "position": [
        1712,
        1152
      ],
      "parameters": {
        "text": "={{ $json.userPrompt }}",
        "options": {
          "systemMessage": "={{ $json.systemPrompt }}"
        },
        "promptType": "define"
      },
      "typeVersion": 1.7
    },
    {
      "id": "72e3dd39-013c-43b4-a0e1-9ce4167d37f0",
      "name": "Accumulate Results",
      "type": "n8n-nodes-base.code",
      "position": [
        2288,
        1264
      ],
      "parameters": {
        "jsCode": "// Accumulate all processed items\nconst currentItem = $input.first();\nconst storedData = $getWorkflowStaticData('global');\n\n// Initialize accumulator if needed\nif (!storedData.accumulatedData) {\n  storedData.accumulatedData = [];\n}\n\n// Add current item to accumulated data\nstoredData.accumulatedData.push(currentItem);\n\nconsole.log(`Item processed. Total accumulated: ${storedData.accumulatedData.length} items`);\n\n// Return the current item to continue the flow\nreturn [currentItem];"
      },
      "typeVersion": 2
    },
    {
      "id": "7f62341e-e758-4664-aa1d-62cdba49cd84",
      "name": "Anthropic Chat Model1",
      "type": "@n8n/n8n-nodes-langchain.lmChatAnthropic",
      "position": [
        1472,
        1312
      ],
      "parameters": {
        "model": {
          "__rl": true,
          "mode": "list",
          "value": "claude-opus-4-20250514",
          "cachedResultName": "Claude Opus 4"
        },
        "options": {}
      },
      "credentials": {
        "anthropicApi": {
          "name": "<your credential>"
        }
      },
      "typeVersion": 1.3
    },
    {
      "id": "dfb09d43-49c8-47be-af77-e3bef30a5053",
      "name": "Calculate Project Totals1",
      "type": "n8n-nodes-base.code",
      "position": [
        1376,
        1568
      ],
      "parameters": {
        "jsCode": "// Aggregate all results and calculate project totals\nconst items = $input.all();\n\n// Initialize aggregators\nconst projectTotals = {\n  totalElements: 0,\n  totalCost: 0,\n  totalVolume: 0,\n  totalArea: 0,\n  byMaterial: {},\n  byCategory: {},\n  byImpact: {}\n};\n\n// Process each item\nitems.forEach(item => {\n  const data = item.json;\n  const elementCount = parseFloat(data['Element Count']) || 1;\n  const cost = parseFloat(data['Total Cost (EUR)']) || 0;\n  const volume = parseFloat(data['Volume (m\u00b3)']) || 0;\n  const area = parseFloat(data['Area (m\u00b2)']) || 0;\n  const material = data['Material (EU Standard)'] || 'Unknown';\n  const category = data['Element Category'] || 'Unknown';\n  const impact = data['Impact Category'] || 'Unknown';\n  \n  // Update totals\n  projectTotals.totalElements += elementCount;\n  projectTotals.totalCost += cost;\n  projectTotals.totalVolume += volume;\n  projectTotals.totalArea += area;\n  \n  // Aggregate by material\n  if (!projectTotals.byMaterial[material]) {\n    projectTotals.byMaterial[material] = {\n      elements: 0,\n      cost: 0,\n      volume: 0,\n      types: new Set()\n    };\n  }\n  projectTotals.byMaterial[material].elements += elementCount;\n  projectTotals.byMaterial[material].cost += cost;\n  projectTotals.byMaterial[material].volume += volume;\n  projectTotals.byMaterial[material].types.add(data['Element Name']);\n  \n  // Aggregate by category\n  if (!projectTotals.byCategory[category]) {\n    projectTotals.byCategory[category] = {\n      elements: 0,\n      cost: 0\n    };\n  }\n  projectTotals.byCategory[category].elements += elementCount;\n  projectTotals.byCategory[category].cost += cost;\n  \n  // Aggregate by impact\n  if (!projectTotals.byImpact[impact]) {\n    projectTotals.byImpact[impact] = {\n      elements: 0,\n      cost: 0\n    };\n  }\n  projectTotals.byImpact[impact].elements += elementCount;\n  projectTotals.byImpact[impact].cost += cost;\n});\n\n// Add percentages and rankings to each item\nconst enrichedItems = items.map((item, index) => {\n  const data = item.json;\n  const cost = parseFloat(data['Total Cost (EUR)']) || 0;\n  const elementCount = parseFloat(data['Element Count']) || 1;\n  \n  return {\n    json: {\n      ...data,\n      // Add project percentages\n      'Cost % of Total': projectTotals.totalCost > 0 ? \n        ((cost / projectTotals.totalCost) * 100).toFixed(2) : '0.00',\n      'Elements % of Total': projectTotals.totalElements > 0 ? \n        ((elementCount / projectTotals.totalElements) * 100).toFixed(2) : '0.00',\n      // Add ranking\n      'Cost Rank': index + 1,\n      // Project totals (same for all rows)\n      'Project Total Elements': projectTotals.totalElements,\n      'Project Total Cost (EUR)': projectTotals.totalCost.toFixed(3),\n      'Project Total Volume (m\u00b3)': projectTotals.totalVolume.toFixed(2),\n      'Project Total Area (m\u00b2)': projectTotals.totalArea.toFixed(2)\n    }\n  };\n});\n\n// Sort by Cost (highest first)\nenrichedItems.sort((a, b) => \n  parseFloat(b.json['Total Cost (EUR)']) - parseFloat(a.json['Total Cost (EUR)'])\n);\n\n// Store aggregated data for summary\n$getWorkflowStaticData('global').projectTotals = projectTotals;\n\nreturn enrichedItems;"
      },
      "typeVersion": 2
    },
    {
      "id": "4d061758-4051-4bcc-85db-d7ed7fa06ec7",
      "name": "Enhance Excel Output",
      "type": "n8n-nodes-base.code",
      "position": [
        1936,
        1744
      ],
      "parameters": {
        "jsCode": "// Enhanced Excel styling configuration\nconst excelBuffer = $input.first().binary.data;\nconst fileName = `Price_Estimation_Report_${new Date().toISOString().slice(0,10)}.xlsx`;\n\n// Add metadata to the file\nconst metadata = {\n  title: 'Price Estimation Analysis Report',\n  author: 'DataDrivenConstruction.io',\n  company: 'Automated Price Estimation System',\n  created: new Date().toISOString(),\n  description: 'Comprehensive project cost assessment with multi-standard material classification',\n  keywords: 'Price, Cost Estimation, Building Materials'\n};\n\n// Return the enhanced Excel file\nreturn [{\n  json: {\n    fileName: fileName,\n    fileSize: excelBuffer.data.length,\n    sheets: 8,\n    metadata: metadata,\n    timestamp: new Date().toISOString()\n  },\n  binary: {\n    data: {\n      ...excelBuffer,\n      fileName: fileName,\n      fileExtension: 'xlsx',\n      mimeType: 'application/vnd.openxmlformats-officedocument.spreadsheetml.sheet'\n    }\n  }\n}];"
      },
      "typeVersion": 2
    },
    {
      "id": "d006c84f-3df6-493e-8965-2552f06cc862",
      "name": "Prepare Excel Data",
      "type": "n8n-nodes-base.code",
      "position": [
        1600,
        1744
      ],
      "parameters": {
        "jsCode": "// Prepare comprehensive data for multi-sheet Excel export\nconst items = $input.all();\nconst projectTotals = $getWorkflowStaticData('global').projectTotals;\n\n// Helper function to format numbers\nconst formatNumber = (num, decimals = 2) => {\n  return typeof num === 'number' ? parseFloat(num.toFixed(decimals)) : 0;\n};\n\n// Sheet 1: Executive Summary with project metrics\nconst executiveSummary = [\n  {\n    'Category': 'PROJECT OVERVIEW',\n    'Metric': 'Total Elements Analyzed',\n    'Value': projectTotals.totalElements,\n    'Unit': 'elements'\n  },\n  {\n    'Category': 'PROJECT OVERVIEW',\n    'Metric': 'Element Groups',\n    'Value': items.length,\n    'Unit': 'groups'\n  },\n  {\n    'Category': 'COST METRICS',\n    'Metric': 'Total Estimated Cost',\n    'Value': formatNumber(projectTotals.totalCost, 2),\n    'Unit': 'EUR'\n  },\n  {\n    'Category': 'COST METRICS',\n    'Metric': 'Average Cost per Element',\n    'Value': formatNumber(projectTotals.totalCost / projectTotals.totalElements, 3),\n    'Unit': 'EUR/element'\n  },\n  {\n    'Category': 'MATERIAL METRICS',\n    'Metric': 'Unique Material Types',\n    'Value': Object.keys(projectTotals.byMaterial).length,\n    'Unit': 'materials'\n  },\n  {\n    'Category': 'VOLUMETRIC DATA',\n    'Metric': 'Total Volume',\n    'Value': formatNumber(projectTotals.totalVolume, 2),\n    'Unit': 'm\u00b3'\n  },\n  {\n    'Category': 'VOLUMETRIC DATA',\n    'Metric': 'Total Area',\n    'Value': formatNumber(projectTotals.totalArea, 2),\n    'Unit': 'm\u00b2'\n  }\n];\n\n// Sheet 2: Detailed Elements Analysis - ALL fields from processing\nconst detailedElements = items.map((item, index) => {\n  const data = item.json;\n  return {\n    'Cost_Rank': index + 1,\n    'Element_Group': data['Element Name'] || data['Type Name'] || 'Unknown',\n    'Element_Category': data['Element Category'] || 'Unknown',\n    'Element_Type': data['Element Type'] || 'Unknown',\n    'Element_Function': data['Element Function'] || 'Unknown',\n    'Element_Count': parseInt(data['Element Count']) || 0,\n    'Material_EU_Standard': data['Material (EU Standard)'] || 'Unknown',\n    'Material_DE_Standard': data['Material (DE Standard)'] || 'Unknown',\n    'Material_US_Standard': data['Material (US Standard)'] || 'Unknown',\n    'Primary_Material': data['Primary Material'] || 'Unknown',\n    'Secondary_Materials': data['Secondary Materials'] || 'None',\n    'Quantity_Value': formatNumber(data['Quantity'] || 0, 3),\n    'Quantity_Unit': data['Quantity Unit'] || 'piece',\n    'Volume_m3': formatNumber(data['Volume (m\u00b3)'] || 0, 3),\n    'Area_m2': formatNumber(data['Area (m\u00b2)'] || 0, 3),\n    'Price_per_Unit_EUR': formatNumber(data['Price per Unit (EUR)'] || 0, 2),\n    'Total_Cost_EUR': formatNumber(data['Total Cost (EUR)'] || 0, 2),\n    'Cost_per_Element_EUR': formatNumber(data['Cost per Element (EUR)'] || 0, 2),\n    'Cost_Percent_of_Total': formatNumber(data['Cost % of Total'] || 0, 2),\n    'Price_Source': data['Price Source'] || 'Unknown',\n    'Overall_Confidence_%': parseInt(data['Overall Confidence (%)']) || 0,\n    'Assumptions': data['Assumptions'] || 'None',\n    'Warnings': data['Warnings'] || 'None'\n  };\n});\n\n// Sheet 3: Material Summary with detailed breakdown\nconst materialSummary = Object.entries(projectTotals.byMaterial)\n  .sort((a, b) => b[1].cost - a[1].cost)\n  .map(([material, data], index) => {\n    const costPercent = (data.cost / projectTotals.totalCost) * 100;\n    return {\n      'Rank': index + 1,\n      'Material_Type': material,\n      'Element_Count': data.elements,\n      'Cost_EUR': formatNumber(data.cost, 2),\n      'Cost_%': formatNumber(costPercent, 1),\n      'Volume_m3': formatNumber(data.volume, 2)\n    };\n  });\n\n// Sheet 4: Top 10 Expensive Groups\nconst top10Groups = items\n  .slice(0, 10)\n  .map((item, index) => {\n    const data = item.json;\n    const cost = parseFloat(data['Total Cost (EUR)']) || 0;\n    const costPercent = parseFloat(data['Cost % of Total']) || 0;\n    const elementCount = parseInt(data['Element Count']) || 1;\n    \n    return {\n      'Rank': index + 1,\n      'Element_Group': data['Element Name'] || 'Unknown',\n      'Category': data['Element Category'] || 'Unknown',\n      'Material': data['Material (EU Standard)'] || 'Unknown',\n      'Element_Count': elementCount,\n      'Cost_EUR': formatNumber(cost, 2),\n      'Cost_%': formatNumber(costPercent, 1),\n      'Cost_per_Element': formatNumber(cost / elementCount, 1)\n    };\n  });\n\n// Create worksheet structure with proper sheet names\nconst worksheets = [\n  { name: 'Summary', data: executiveSummary },\n  { name: 'Detailed Elements', data: detailedElements },\n  { name: 'Material Summary', data: materialSummary },\n  { name: 'Top 10 Groups', data: top10Groups }\n];\n\n// Flatten all data with sheet markers\nconst allData = [];\nworksheets.forEach(sheet => {\n  sheet.data.forEach(row => {\n    allData.push({\n      json: {\n        ...row,\n        _sheetName: sheet.name\n      }\n    });\n  });\n});\n\nreturn allData;"
      },
      "typeVersion": 2
    },
    {
      "id": "b55dc4f5-1309-4a06-9924-d796733a21f5",
      "name": "Create Excel File",
      "type": "n8n-nodes-base.spreadsheetFile",
      "position": [
        1760,
        1744
      ],
      "parameters": {
        "options": {
          "fileName": "=Price_Estimation_Report_{{ $now.format('yyyy-MM-dd') }}",
          "headerRow": true,
          "sheetName": "={{ $json._sheetName }}"
        },
        "operation": "toFile",
        "fileFormat": "xlsx"
      },
      "typeVersion": 2
    },
    {
      "id": "750047a0-76ea-41a6-8e6e-83447eaef026",
      "name": "Prepare Enhanced Prompts",
      "type": "n8n-nodes-base.code",
      "position": [
        1536,
        1152
      ],
      "parameters": {
        "jsCode": "// Enhanced prompts for comprehensive price estimation analysis\nconst inputData = $input.first().json;\nconst originalGroupedData = { ...inputData };\nconst country = $node['Process AI Response1'].json.country;\n\nconst systemPrompt = `You are an expert in construction cost estimation, material pricing, and building element classification. Analyze the provided building element data and return a comprehensive price estimation assessment.\n\nUse tools like web_search or browse_page to find current prices from reliable sources (e.g., manufacturer websites, construction databases like RSMeans, \u00d6KOBAUDAT for ${country}, etc.). Prioritize sources from ${country} or relevant region.\n\nIMPORTANT NOTE ON DATA:\n- All quantitative fields like Volume, Area, Length, etc. in the input data represent ALREADY AGGREGATED TOTALS for the entire group of elements.\n- 'Element Count' indicates the number of individual elements in this group.\n- DO NOT multiply volumes/areas by Element Count - they are already total sums.\n- Infer the best unit for pricing (e.g., per m\u00b3 for volumes, per m\u00b2 for areas, per piece for counts) based on parameters.\n- Search for prices using element parameters (material, dimensions, type).\n- If exact price not found, use average or rough estimate and note it.\n- Consider secondary materials if possible, otherwise focus on primary.\n- For additional factors (e.g., labor, transport), note percentages but do not include in calculations.\n- If no price found, state 'Price not found' and suggest average if possible.\n\n## Your Analysis Must Include:\n\n### 1. Element Identification\n- Element type and category\n- Primary material composition\n- Secondary materials if applicable\n- Functional classification\n\n### 2. Material Classification (All 3 Standards, prioritize ${country}'s if applicable)\n- **European (EN 15978/15804)**: YOUR_AWS_SECRET_KEY_HERE.\n- **German (\u00d6KOBAUDAT)**: Mineralische/Metalle/Holz/D\u00e4mmstoffe/etc.\n- **US (MasterFormat)**: Division classifications\n\n### 3. Quantity Analysis\n- Primary quantity with unit (m\u00b3, m\u00b2, m, kg, pieces) - use aggregated total from input\n- Calculation method used (e.g., 'Direct from provided total volume')\n- Confidence level (0-100%)\n- Data quality assessment\n\n### 4. Price Estimation\n- Price per unit (EUR/unit)\n- Total price (for the entire group)\n- Price source (URL or database name)\n- Additional factors (percentages only, e.g., labor: 20%)\n\n### 5. Data Quality & Confidence\n- Overall confidence score\n- Data completeness assessment\n- Key assumptions made\n- Warnings or limitations\n\n## Output Format\nReturn ONLY valid JSON with this exact structure:\n{\n  \"element_identification\": {\n    \"name\": \"string\",\n    \"category\": \"string\",\n    \"type\": \"string\",\n    \"function\": \"string\"\n  },\n  \"material_classification\": {\n    \"european\": \"string\",\n    \"german\": \"string\",\n    \"us\": \"string\",\n    \"primary_material\": \"string\",\n    \"secondary_materials\": [\"string\"]\n  },\n  \"quantities\": {\n    \"value\": number,\n    \"unit\": \"string\",\n    \"calculation_method\": \"string\",\n    \"raw_dimensions\": {\n      \"length\": number,\n      \"width\": number,\n      \"height\": number,\n      \"thickness\": number,\n      \"area\": number,\n      \"volume\": number\n    }\n  },\n  \"price_analysis\": {\n    \"price_per_unit_eur\": number,\n    \"total_price_eur\": number,\n    \"price_source\": \"string\",\n    \"additional_factors\": {\"labor\": number, \"transport\": number},\n    \"data_source\": \"string\"\n  },\n  \"confidence\": {\n    \"overall_score\": number,\n    \"material_confidence\": number,\n    \"quantity_confidence\": number,\n    \"price_confidence\": number,\n    \"data_quality\": \"high/medium/low\"\n  },\n  \"metadata\": {\n    \"assumptions\": [\"string\"],\n    \"warnings\": [\"string\"],\n    \"notes\": \"string\"\n  }\n}`;\n\nconst userPrompt = `Analyze this building element group for price estimation in ${country}. Remember: Volumes and areas are already total for the group, not per element. Use tools to search for prices.\n\n${JSON.stringify(inputData, null, 2)}\n\nProvide comprehensive price analysis following the specified format. Focus on accuracy and use conservative estimates where data is uncertain.`;\n\nreturn [{\n  json: {\n    ...originalGroupedData,\n    systemPrompt,\n    userPrompt,\n    _originalGroupedData: originalGroupedData\n  }\n}];"
      },
      "typeVersion": 2
    },
    {
      "id": "f5d3ae3d-68fe-43e3-a6df-4bed5a82aefa",
      "name": "Parse Enhanced Response",
      "type": "n8n-nodes-base.code",
      "position": [
        2064,
        1152
      ],
      "parameters": {
        "jsCode": "// Parse and enrich AI response with all necessary data\nconst aiResponse = $input.first().json.output || $input.first().json.response || $input.first().json.text || $input.first().json;\nconst originalData = $node[\"Prepare Enhanced Prompts\"].json._originalGroupedData || $node[\"Prepare Enhanced Prompts\"].json;\n\ntry {\n  // Extract JSON from response\n  let jsonStr = aiResponse;\n  if (typeof jsonStr === 'string') {\n    const jsonMatch = jsonStr.match(/```json\\n?([\\s\\S]*?)\\n?```/) || jsonStr.match(/\\{[\\s\\S]*\\}/);\n    if (jsonMatch) {\n      jsonStr = jsonMatch[1] || jsonMatch[0];\n    }\n  }\n  \n  const analysis = typeof jsonStr === 'string' ? JSON.parse(jsonStr) : jsonStr;\n  \n  // Calculate additional metrics - use total price for group\n  const total_price_eur = analysis.price_analysis?.total_price_eur || 0;\n  const elementCount = parseFloat(originalData['Element Count']) || 1;\n  const price_per_element = total_price_eur / elementCount;\n  \n  // Determine impact category\n  let impactCategory = 'Unknown';\n  const pricePerUnit = analysis.price_analysis?.price_per_unit_eur || 0;\n  if (pricePerUnit <= 10) {\n    impactCategory = 'Very Low Cost';\n  } else if (pricePerUnit <= 50) {\n    impactCategory = 'Low Cost';\n  } else if (pricePerUnit <= 200) {\n    impactCategory = 'Medium Cost';\n  } else if (pricePerUnit <= 500) {\n    impactCategory = 'High Cost';\n  } else {\n    impactCategory = 'Very High Cost';\n  }\n  \n  // Create comprehensive output record\n  return [{\n    json: {\n      // Original data\n      ...originalData,\n      \n      // Element identification\n      'Element Name': analysis.element_identification?.name || originalData['Type Name'] || 'Unknown',\n      'Element Category': analysis.element_identification?.category || originalData['Category'] || 'Unknown',\n      'Element Type': analysis.element_identification?.type || 'Unknown',\n      'Element Function': analysis.element_identification?.function || 'Unknown',\n      \n      // Material classification\n      'Material (EU Standard)': analysis.material_classification?.european || 'Unknown',\n      'Material (DE Standard)': analysis.material_classification?.german || 'Unknown',\n      'Material (US Standard)': analysis.material_classification?.us || 'Unknown',\n      'Primary Material': analysis.material_classification?.primary_material || 'Unknown',\n      'Secondary Materials': (analysis.material_classification?.secondary_materials || []).join(', ') || 'None',\n      \n      // Quantities\n      'Quantity': analysis.quantities?.value || 0,\n      'Quantity Unit': analysis.quantities?.unit || 'piece',\n      'Calculation Method': analysis.quantities?.calculation_method || 'Not specified',\n      \n      // Dimensions (from raw data) - these are totals\n      'Length (mm)': analysis.quantities?.raw_dimensions?.length || originalData['Length'] || 0,\n      'Width (mm)': analysis.quantities?.raw_dimensions?.width || originalData['Width'] || 0,\n      'Height (mm)': analysis.quantities?.raw_dimensions?.height || originalData['Height'] || 0,\n      'Thickness (mm)': analysis.quantities?.raw_dimensions?.thickness || originalData['Thickness'] || 0,\n      'Area (m\u00b2)': analysis.quantities?.raw_dimensions?.area || originalData['Area'] || 0,\n      'Volume (m\u00b3)': analysis.quantities?.raw_dimensions?.volume || originalData['Volume'] || 0,\n      \n      // Price Analysis\n      'Price per Unit (EUR)': analysis.price_analysis?.price_per_unit_eur || 0,\n      'Total Cost (EUR)': total_price_eur,\n      'Cost per Element (EUR)': price_per_element,\n      'Price Source': analysis.price_analysis?.price_source || 'Unknown',\n      'Additional Factors': JSON.stringify(analysis.price_analysis?.additional_factors || {}),\n      'Data Source': analysis.price_analysis?.data_source || 'Industry average',\n      'Impact Category': impactCategory,\n      \n      // Confidence scores\n      'Overall Confidence (%)': analysis.confidence?.overall_score || 0,\n      'Material Confidence (%)': analysis.confidence?.material_confidence || 0,\n      'Quantity Confidence (%)': analysis.confidence?.quantity_confidence || 0,\n      'Price Confidence (%)': analysis.confidence?.price_confidence || 0,\n      'Data Quality': analysis.confidence?.data_quality || 'unknown',\n      \n      // Metadata\n      'Assumptions': (analysis.metadata?.assumptions || []).join('; ') || 'None',\n      'Warnings': (analysis.metadata?.warnings || []).join('; ') || 'None',\n      'Analysis Notes': analysis.metadata?.notes || '',\n      'Processing Timestamp': new Date().toISOString(),\n      'Analysis Status': 'Complete'\n    }\n  }];\n  \n} catch (error) {\n  // Return error record with original data preserved\n  return [{\n    json: {\n      ...originalData,\n      'Analysis Status': 'Failed',\n      'Error': error.message,\n      'Processing Timestamp': new Date().toISOString()\n    }\n  }];\n}"
      },
      "typeVersion": 2
    },
    {
      "id": "428bb655-a1e9-45df-a80c-57c00810e5e9",
      "name": "Generate HTML Report",
      "type": "n8n-nodes-base.code",
      "position": [
        1600,
        1568
      ],
      "parameters": {
        "jsCode": "// Generate professional McKinsey/Accenture style HTML report with visualizations\nconst items = $input.all();\nconst projectTotals = $getWorkflowStaticData('global').projectTotals;\n\n// Get project name from file path\nconst projectFile = $node['Setup - Define file paths'].json.project_file || '';\nconst projectName = projectFile.split('\\\\').pop().replace('.rvt', '').replace(/_/g, ' ').toUpperCase();\n\n// Sort items by total cost descending\nconst sortedItems = [...items].sort((a, b) => \n  parseFloat(b.json['Total Cost (EUR)'] || 0) - parseFloat(a.json['Total Cost (EUR)'] || 0)\n);\n\n// Calculate additional metrics\nconst avgConfidence = sortedItems.reduce((sum, item) => sum + (parseInt(item.json['Overall Confidence (%)']) || 0), 0) / sortedItems.length;\nconst completeItems = sortedItems.filter(item => item.json['Analysis Status'] === 'Complete').length;\nconst coveragePercent = (completeItems / sortedItems.length) * 100;\n\n// Get top material\nconst topMaterial = Object.entries(projectTotals.byMaterial)\n  .sort((a, b) => b[1].cost - a[1].cost)[0];\n\n// Calculate high impact items\nconst highImpactItems = sortedItems.filter(item => \n  parseFloat(item.json['Total Cost (EUR)']) >= projectTotals.totalCost * 0.05\n).length;\n\n// Calculate top 3 materials percentage\nconst top3Materials = Object.entries(projectTotals.byMaterial)\n  .sort((a, b) => b[1].cost - a[1].cost)\n  .slice(0, 3);\nconst top3Percentage = (top3Materials.reduce((sum, [, data]) => sum + data.cost, 0) / projectTotals.totalCost) * 100;\n\n// Prepare data for charts\nconst materialChartData = Object.entries(projectTotals.byMaterial)\n  .sort((a, b) => b[1].cost - a[1].cost)\n  .slice(0, 6)\n  .map(([material, data]) => ({\n    label: material,\n    value: data.cost\n  }));\n\nconst barChartData = sortedItems.slice(0, 10).map(item => ({\n  label: item.json['Element Name'] || 'Unknown',\n  value: parseFloat(item.json['Total Cost (EUR)'] || 0)\n}));\n\n// Generate HTML\nconst html = `<!DOCTYPE html>\n<html lang=\"en\">\n<head>\n    <meta charset=\"UTF-8\">\n    <meta name=\"viewport\" content=\"width=device-width, initial-scale=1.0\">\n    <title>Project Cost Intelligence | Executive Report</title>\n    <script src=\"https://cdn.jsdelivr.net/npm/chart.js\"></script>\n    <link href=\"https://fonts.googleapis.com/css2?family=Inter:wght@300;400;500;600;700;800&family=Poppins:wght@600;700;800&display=swap\" rel=\"stylesheet\">\n    <style>\n        * {\n            margin: 0;\n            padding: 0;\n            box-sizing: border-box;\n        }\n        \n        :root {\n            --primary-gradient: linear-gradient(135deg, #0F4C75 0%, #3282B8 50%, #1B262C 100%);\n            --secondary-gradient: linear-gradient(135deg, #3282B8 0%, #0F4C75 100%);\n            --light-gradient: linear-gradient(180deg, #f8fafc 0%, #f1f5f9 100%);\n            --accent-gradient: linear-gradient(135deg, #BBE1FA 0%, #3282B8 100%);\n        }\n        \n        body {\n            font-family: 'Inter', -apple-system, BlinkMacSystemFont, 'Segoe UI', sans-serif;\n            background: linear-gradient(180deg, #fafbfc 0%, #ffffff 100%);\n            min-height: 100vh;\n            color: #0f172a;\n            line-height: 1.6;\n        }\n        \n        .container {\n            max-width: 1600px;\n            margin: 0 auto;\n            background: white;\n            box-shadow: 0 0 40px rgba(0, 0, 0, 0.05);\n            position: relative;\n        }\n        \n        /* Professional Header */\n        .header {\n            background: var(--primary-gradient);\n            color: white;\n            padding: 45px 80px;\n            position: relative;\n            overflow: hidden;\n        }\n        \n        .header::before {\n            content: '';\n            position: absolute;\n            top: -50%;\n            right: -10%;\n            width: 800px;\n            height: 800px;\n            background: radial-gradient(circle, rgba(50, 130, 184, 0.15) 0%, transparent 70%);\n            animation: float 6s ease-in-out infinite;\n        }\n        \n        .header::after {\n            content: '';\n            position: absolute;\n            bottom: -30%;\n            left: -10%;\n            width: 600px;\n            height: 600px;\n            background: radial-gradient(circle, rgba(187, 225, 250, 0.1) 0%, transparent 70%);\n            animation: float 6s ease-in-out infinite 3s;\n        }\n        \n        @keyframes float {\n            0%, 100% { transform: translateY(0) scale(1); }\n            50% { transform: translateY(-20px) scale(1.05); }\n        }\n        \n        .header-content {\n            position: relative;\n            z-index: 1;\n        }\n        \n        .header-top {\n            display: flex;\n            justify-content: space-between;\n            align-items: center;\n            margin-bottom: 50px;\n        }\n        \n        .company-brand {\n            display: flex;\n            align-items: center;\n            gap: 20px;\n        }\n        \n        .company-logo {\n            font-size: 13px;\n            font-weight: 800;\n            letter-spacing: 3px;\n            text-transform: uppercase;\n            padding-left: 20px;\n            border-left: 4px solid #BBE1FA;\n            opacity: 0.95;\n        }\n        \n        .report-badge {\n            background: linear-gradient(135deg, rgba(255,255,255,0.2) 0%, rgba(255,255,255,0.05) 100%);\n            backdrop-filter: blur(20px);\n            padding: 12px 24px;\n            border-radius: 50px;\n            font-size: 11px;\n            font-weight: 700;\n            letter-spacing: 2px;\n            text-transform: uppercase;\n            border: 1px solid rgba(255,255,255,0.2);\n            box-shadow: 0 4px 20px rgba(0,0,0,0.1);\n        }\n        \n        h1 {\n            font-family: 'Poppins', sans-serif;\n            font-size: 48px;\n            font-weight: 800;\n            margin-bottom: 16px;\n            letter-spacing: -2px;\n            line-height: 1.1;\n            color: white;\n        }\n        \n        .subtitle {\n            font-size: 18px;\n            font-weight: 300;\n            opacity: 0.9;\n            margin-bottom: 30px;\n            color: #cbd5e1;\n            letter-spacing: 0.5px;\n        }\n        \n        .meta-grid {\n            display: grid;\n            grid-template-columns: repeat(auto-fit, minmax(200px, 1fr));\n            gap: 30px;\n            padding-top: 30px;\n            border-top: 1px solid rgba(255,255,255,0.15);\n        }\n        \n        .meta-card {\n            display: flex;\n            align-items: flex-start;\n            gap: 16px;\n            flex-direction: column;\n        }\n        \n        .meta-info {\n            flex: 1;\n        }\n        \n        .meta-label {\n            font-size: 12px;\n            opacity: 0.8;\n            text-transform: uppercase;\n            letter-spacing: 1px;\n            margin-bottom: 4px;\n            font-weight: 500;\n        }\n        \n        .meta-value {\n            font-size: 20px;\n            font-weight: 700;\n        }\n        \n        /* KPI Cards Section */\n        .kpi-section {\n            padding: 80px;\n            background: linear-gradient(180deg, #f8fafc 0%, #ffffff 100%);\n            position: relative;\n        }\n        \n        .kpi-section::before {\n            content: '';\n            position: absolute;\n            top: 0;\n            left: 0;\n            right: 0;\n            height: 2px;\n            background: var(--accent-gradient);\n        }\n        \n        .kpi-grid {\n            display: grid;\n            grid-template-columns: repeat(auto-fit, minmax(300px, 1fr));\n            gap: 32px;\n        }\n        \n        .kpi-card {\n            background: white;\n            padding: 40px;\n            border-radius: 20px;\n            border: 1px solid #e5e7eb;\n            box-shadow: 0 4px 20px rgba(0, 0, 0, 0.04);\n            transition: all 0.4s cubic-bezier(0.4, 0, 0.2, 1);\n            position: relative;\n            overflow: hidden;\n        }\n        \n        .kpi-card::before {\n            content: '';\n            position: absolute;\n            top: 0;\n            left: 0;\n            width: 100%;\n            height: 3px;\n            background: linear-gradient(90deg, #3282B8 0%, #0F4C75 100%);\n        }\n        \n        .kpi-card:hover {\n            transform: translateY(-8px);\n            box-shadow: 0 12px 40px rgba(0, 0, 0, 0.08);\n            border-color: #cbd5e1;\n        }\n        \n        .kpi-icon {\n            width: 56px;\n            height: 56px;\n            background: linear-gradient(180deg, #f8fafc 0%, #f1f5f9 100%);\n            border-radius: 16px;\n            display: flex;\n            align-items: center;\n            justify-content: center;\n            font-size: 24px;\n            margin-bottom: 20px;\n            border: 1px solid #e5e7eb;\n            color: #94a3b8;\n        }\n        \n        .kpi-label {\n            font-size: 11px;\n            color: #64748b;\n            text-transform: uppercase;\n            letter-spacing: 1.5px;\n            margin-bottom: 12px;\n            font-weight: 700;\n        }\n        \n        .kpi-value {\n            font-size: 42px;\n            font-weight: 800;\n            color: #1e293b;\n            margin-bottom: 8px;\n            font-family: 'Poppins', sans-serif;\n        }\n        \n        .kpi-unit {\n            font-size: 14px;\n            color: #94a3b8;\n            font-weight: 500;\n        }\n        \n        .kpi-trend {\n            position: absolute;\n            top: 24px;\n            right: 24px;\n            padding: 8px 16px;\n            background: linear-gradient(135deg, #dbeafe 0%, #e0f2fe 100%);\n            border-radius: 20px;\n            font-size: 12px;\n            font-weight: 600;\n            color: #3282B8;\n        }\n        \n        /* Executive Summary */\n        .executive-section {\n            padding: 80px;\n            background: white;\n        }\n        \n        .section-header {\n            display: flex;\n            align-items: center;\n            gap: 20px;\n            margin-bottom: 50px;\n            padding-bottom: 30px;\n            border-bottom: 2px solid #e0f2fe;\n        }\n        \n        .section-number {\n            width: 60px;\n            height: 60px;\n            background: linear-gradient(135deg, #3282B8 0%, #0F4C75 100%);\n            color: white;\n            border-radius: 16px;\n            display: flex;\n            align-items: center;\n            justify-content: center;\n            font-weight: 800;\n            font-size: 24px;\n            box-shadow: 0 4px 12px rgba(0, 0, 0, 0.1);\n        }\n        \n        h2 {\n            font-size: 36px;\n            font-weight: 800;\n            color: #1e293b;\n            font-family: 'Poppins', sans-serif;\n            letter-spacing: -1px;\n        }\n        \n        .summary-grid {\n            display: grid;\n            grid-template-columns: 1.5fr 1fr;\n            gap: 60px;\n            margin-top: 50px;\n        }\n        \n        .summary-content {\n            font-size: 17px;\n            line-height: 1.9;\n            color: #475569;\n        }\n        \n        .summary-content p {\n            margin-bottom: 20px;\n        }\n        \n        .summary-content strong {\n            color: #3282B8;\n            font-weight: 700;\n        }\n        \n        .insight-panel {\n            background: linear-gradient(180deg, #f8fafc 0%, #f1f5f9 100%);\n            padding: 40px;\n            border-radius: 20px;\n            border: 1px solid #e5e7eb;\n            position: relative;\n            box-shadow: 0 4px 20px rgba(0, 0, 0, 0.04);\n        }\n        \n        .insight-panel h3 {\n            font-size: 20px;\n            margin-bottom: 30px;\n            color: #1e293b;\n            font-weight: 800;\n            font-family: 'Poppins', sans-serif;\n        }\n        \n        .insight-item {\n            display: flex;\n            align-items: center;\n            gap: 20px;\n            margin-bottom: 24px;\n            padding: 16px 20px;\n            background: white;\n            border-radius: 12px;\n            transition: all 0.3s;\n            border: 1px solid transparent;\n        }\n        \n        .insight-item:hover {\n            transform: translateX(8px);\n            border-color: #cbd5e1;\n            box-shadow: 0 4px 12px rgba(0, 0, 0, 0.05);\n        }\n        \n        .insight-icon {\n            width: 40px;\n            height: 40px;\n            background: linear-gradient(135deg, #3282B8 0%, #0F4C75 100%);\n            border-radius: 10px;\n            display: flex;\n            align-items: center;\n            justify-content: center;\n            color: white;\n            font-size: 18px;\n            font-weight: bold;\n            flex-shrink: 0;\n        }\n        \n        .insight-icon::before {\n            content: '\u29bf';\n            opacity: 0.7;\n        }\n        \n        .insight-text {\n            flex: 1;\n            font-size: 15px;\n            color: #334155;\n            font-weight: 500;\n        }\n        \n        /* Charts Section */\n        .charts-section {\n            padding: 80px;\n            background: linear-gradient(180deg, #f8fafc 0%, #ffffff 100%);\n        }\n        \n        .charts-grid {\n            display: grid;\n            grid-template-columns: repeat(auto-fit, minmax(500px, 1fr));\n            gap: 50px;\n            margin-top: 50px;\n        }\n        \n        .chart-container {\n            background: white;\n            padding: 50px;\n            border-radius: 20px;\n            border: 1px solid #e5e7eb;\n            box-shadow: 0 4px 20px rgba(0, 0, 0, 0.04);\n            transition: all 0.3s;\n        }\n        \n        .chart-container:hover {\n            box-shadow: 0 8px 30px rgba(0, 0, 0, 0.08);\n        }\n        \n        .chart-header {\n            display: flex;\n            justify-content: space-between;\n            align-items: center;\n            margin-bottom: 40px;\n            padding-bottom: 20px;\n            border-bottom: 2px solid #e0f2fe;\n        }\n        \n        .chart-title {\n            font-size: 22px;\n            font-weight: 700;\n            color: #1e293b;\n        }\n        \n        .chart-badge {\n            padding: 6px 12px;\n            background: linear-gradient(180deg, #f8fafc 0%, #f1f5f9 100%);\n            border-radius: 20px;\n            font-size: 11px;\n            font-weight: 600;\n            color: #64748b;\n            text-transform: uppercase;\n            letter-spacing: 1px;\n        }\n        \n        /* Data Tables */\n        .data-section {\n            padding: 80px;\n            background: white;\n        }\n        \n        .table-container {\n            margin-top: 50px;\n            border-radius: 16px;\n            overflow: hidden;\n            box-shadow: 0 0 0 1px #e0f2fe;\n        }\n        \n        .data-table {\n            width: 100%;\n            border-collapse: separate;\n            border-spacing: 0;\n            background: white;\n        }\n        \n        .data-table thead {\n            background: var(--primary-gradient);\n        }\n        \n        .data-table th {\n            padding: 20px;\n            text-align: left;\n            font-size: 11px;\n            font-weight: 800;\n            color: white;\n            text-transform: uppercase;\n            letter-spacing: 1.5px;\n        }\n        \n        .data-table td {\n            padding: 20px;\n            font-size: 14px;\n            color: #1e293b;\n            border-bottom: 1px solid #f1f5f9;\n            transition: all 0.2s;\n        }\n        \n        .data-table tbody tr {\n            transition: all 0.3s;\n        }\n        \n        .data-table tbody tr:hover {\n            background: linear-gradient(90deg, #f0f9ff 0%, #e0f2fe 100%);\n        }\n        \n        .rank-badge {\n            display: inline-flex;\n            width: 36px;\n            height: 36px;\n            background: linear-gradient(135deg, #3282B8 0%, #0F4C75 100%);\n            color: white;\n            border-radius: 10px;\n            align-items: center;\n            justify-content: center;\n            font-size: 14px;\n            font-weight: 800;\n            box-shadow: 0 2px 8px rgba(0, 0, 0, 0.1);\n        }\n        \n        .cost-bar-container {\n            display: flex;\n            align-items: center;\n            gap: 12px;\n        }\n        \n        .cost-bar {\n            height: 10px;\n            background: var(--accent-gradient);\n            border-radius: 5px;\n            box-shadow: 0 2px 8px rgba(50, 130, 184, 0.2);\n            transition: all 0.3s;\n        }\n        \n        .data-table tbody tr:hover .cost-bar {\n            transform: scaleY(1.4);\n        }\n        \n        .impact-badge {\n            padding: 6px 12px;\n            background: linear-gradient(135deg, #dbeafe 0%, #bae6fd 100%);\n            border-radius: 20px;\n            font-size: 12px;\n            font-weight: 700;\n            color: #0F4C75;\n        }\n        \n        /* Methodology Section */\n        .methodology-section {\n            padding: 80px;\n            background: linear-gradient(180deg, #f8fafc 0%, #f1f5f9 100%);\n        }\n        \n        .methodology-grid {\n            display: grid;\n            grid-template-columns: repeat(auto-fit, minmax(250px, 1fr));\n            gap: 40px;\n            margin-top: 50px;\n        }\n        \n        .step-card {\n            text-align: center;\n            padding: 40px 30px;\n            background: white;\n            border-radius: 20px;\n            border: 1px solid #e5e7eb;\n            transition: all 0.4s cubic-bezier(0.4, 0, 0.2, 1);\n            position: relative;\n            overflow: hidden;\n        }\n        \n        .step-card::before {\n            content: '';\n            position: absolute;\n            top: 0;\n            left: 0;\n            right: 0;\n            height: 3px;\n            background: linear-gradient(90deg, #1B262C 0%, #3282B8 100%);\n            transform: scaleX(0);\n            transition: transform 0.4s;\n        }\n        \n        .step-card:hover {\n            transform: translateY(-12px);\n            box-shadow: 0 12px 30px rgba(0, 0, 0, 0.1);\n        }\n        \n        .step-card:hover::before {\n            transform: scaleX(1);\n        }\n        \n        .step-number {\n            width: 80px;\n            height: 80px;\n            background: linear-gradient(135deg, #ffffff 0%, #f0f9ff 100%);\n            border: 4px solid;\n            border-image: var(--secondary-gradient) 1;\n            border-radius: 24px;\n            display: flex;\n            align-items: center;\n            justify-content: center;\n            margin: 0 auto 24px;\n            font-size: 32px;\n            font-weight: 800;\n            color: #3282B8;\n            font-family: 'Poppins', sans-serif;\n        }\n        \n        .step-title {\n            font-size: 18px;\n            font-weight: 700;\n            color: #0c4a6e;\n            margin-bottom: 12px;\n            font-family: 'Poppins', sans-serif;\n        }\n        \n        .step-description {\n            font-size: 14px;\n            color: #64748b;\n            line-height: 1.6;\n        }\n        \n        /* Footer */\n        .footer {\n            background: linear-gradient(135deg, #0F4C75 0%, #3282B8 50%, #1B262C 100%);\n            color: white;\n            padding: 60px 80px;\n            position: relative;\n            overflow: hidden;\n        }\n        \n        .footer::before {\n            content: '';\n            position: absolute;\n            top: 0;\n            left: 0;\n            right: 0;\n            height: 2px;\n            background: linear-gradient(90deg, transparent 0%, #BBE1FA 50%, transparent 100%);\n        }\n        \n        .footer-grid {\n            display: grid;\n            grid-template-columns: repeat(auto-fit, minmax(300px, 1fr));\n            gap: 60px;\n            margin-bottom: 50px;\n        }\n        \n        .footer-section h3 {\n            font-size: 20px;\n            font-weight: 700;\n            margin-bottom: 24px;\n            color: #bae6fd;\n            font-family: 'Poppins', sans-serif;\n        }\n        \n        .footer-text {\n            color: #cbd5e1;\n            font-size: 14px;\n            line-height: 1.8;\n            margin-bottom: 20px;\n        }\n        \n        .footer-links {\n            display: flex;\n            flex-direction: column;\n            gap: 12px;\n        }\n        \n        .footer-link {\n            color: #cbd5e1;\n            text-decoration: none;\n            font-size: 14px;\n            transition: all 0.3s;\n            display: inline-flex;\n            align-items: center;\n            gap: 8px;\n        }\n        \n        .footer-link:hover {\n            color: #BBE1FA;\n            transform: translateX(4px);\n        }\n        \n        .footer-link::before {\n            content: '\u2192';\n            color: #BBE1FA;\n        }\n        \n        .footer-bottom {\n            padding-top: 40px;\n            border-top: 1px solid rgba(255,255,255,0.1);\n            text-align: center;\n            font-size: 13px;\n            color: #94a3b8;\n        }\n        \n        /* Responsive Design */\n        @media (max-width: 768px) {\n            .header {\n                padding: 60px 40px;\n            }\n            \n            h1 {\n                font-size: 48px;\n            }\n            \n            .kpi-section,\n            .executive-section,\n            .charts-section,\n            .data-section,\n            .methodology-section {\n                padding: 50px 30px;\n            }\n            \n            .summary-grid {\n                grid-template-columns: 1fr;\n            }\n            \n            .charts-grid {\n                grid-template-columns: 1fr;\n            }\n            \n            .data-table {\n                font-size: 12px;\n            }\n            \n            .data-table th,\n            .data-table td {\n                padding: 12px;\n            }\n        }\n        \n        /* Print Styles */\n        @media print {\n            body {\n                background: white;\n            }\n            \n            .container {\n                box-shadow: none;\n            }\n            \n            .header {\n                background: #3282B8;\n                print-color-adjust: exact;\n                -webkit-print-color-adjust: exact;\n            }\n        }\n    </style>\n</head>\n<body>\n    <div class=\"container\">\n        <!-- Professional Header -->\n        <div class=\"header\">\n            <div class=\"header-content\">\n                <div class=\"header-top\">\n                    <div class=\"company-brand\">\n                        <div class=\"company-logo\">${projectName}</div>\n                    </div>\n                    <div class=\"report-badge\">Cost Analysis</div>\n                </div>\n                \n                <h1>Project Cost Intelligence</h1>\n                <div class=\"subtitle\">Building Element Cost Analysis & Strategic Insights</div>\n                \n                <div class=\"meta-grid\">\n                    <div class=\"meta-card\">\n                        <div class=\"meta-info\">\n                            <div class=\"meta-label\">Report Date</div>\n                            <div class=\"meta-value\">${new Date().toLocaleDateString('en-US', { month: 'short', day: 'numeric', year: 'numeric' })}</div>\n                        </div>\n                    </div>\n                    <div class=\"meta-card\">\n                        <div class=\"meta-info\">\n                            <div class=\"meta-label\">Total Elements</div>\n                            <div class=\"meta-value\">${projectTotals.totalElements.toLocaleString()}</div>\n                        </div>\n                    </div>\n                    <div class=\"meta-card\">\n                        <div class=\"meta-info\">\n                            <div class=\"meta-label\">Element Groups</div>\n                            <div class=\"meta-value\">${items.length}</div>\n                        </div>\n                    </div>\n                    <div class=\"meta-card\">\n                        <div class=\"meta-info\">\n                            <div cl

Credentials you'll need

Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.

• anthropicApi
• openAiApi
• xAiApi

About this workflow

Estimate material price and total cost for grouped BIM/CAD elements using an LLM-driven analysis. The workflow accepts an existing XLSX (from your model) or, if missing, can trigger a local RvtExporter.exe to generate one. It enriches each element group with quantities, pricing,…

Source: https://n8n.io/workflows/7652/ — original creator credit. Request a take-down →
