Handle Shopify Admin Graphql Requests with Error Handling and Retries

The workflow JSON

Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →

{
  "id": "RbTZGV78TEOAoyh4",
  "meta": {
    "builderVariant": "mcp",
    "aiBuilderAssisted": true
  },
  "name": "Shopify GraphQL Handler (Sub-Workflow)",
  "tags": [
    {
      "id": "wBDwWiycBUtKEx8T",
      "name": "shopify",
      "createdAt": "2026-06-16T12:01:25.538Z",
      "updatedAt": "2026-06-16T12:01:25.538Z"
    },
    {
      "id": "Vl0f4XUqxv6hiNs2",
      "name": "graphql",
      "createdAt": "2026-06-16T12:01:29.552Z",
      "updatedAt": "2026-06-16T12:01:29.552Z"
    },
    {
      "id": "L0MIXHsN63oUPZFs",
      "name": "api",
      "createdAt": "2026-06-16T12:01:32.912Z",
      "updatedAt": "2026-06-16T12:01:32.912Z"
    }
  ],
  "nodes": [
    {
      "id": "2d297dff-7ca9-4283-a923-fcbc5e81226c",
      "name": "When Executed by Another Workflow",
      "type": "n8n-nodes-base.executeWorkflowTrigger",
      "position": [
        128,
        304
      ],
      "parameters": {
        "inputSource": "passthrough"
      },
      "typeVersion": 1.1
    },
    {
      "id": "26b5ae6e-6a93-4f27-9406-b95e194ed6d4",
      "name": "Prepare Request",
      "type": "n8n-nodes-base.code",
      "position": [
        352,
        304
      ],
      "parameters": {
        "jsCode": "// Get input from parent workflow\nconst input = $json;\n\n// Validate required fields\nif (!input.query) {\n  throw new Error('Missing required field: query');\n}\nif (!input.api_endpoint) {\n  throw new Error('Missing required field: api_endpoint');\n}\nif (!input.access_token) {\n  throw new Error('Missing required field: access_token');\n}\n\n// Normalize api_endpoint (remove trailing slash)\nconst apiEndpoint = input.api_endpoint.replace(/\\/$/, '');\n\nreturn {\n  json: {\n    api_endpoint: apiEndpoint,\n    access_token: input.access_token,\n    api_version: input.api_version ?? '2026-01',\n    body: {\n      query: input.query,\n      variables: input.variables ?? {}\n    },\n    // Retry configuration\n    retry_count: input.retry_count ?? 0,\n    max_retries: input.max_retries ?? 5,\n    retry_on_server_error: input.retry_on_server_error ?? true\n  }\n};"
      },
      "retryOnFail": true,
      "typeVersion": 2,
      "waitBetweenTries": 5000
    },
    {
      "id": "eb676907-9e88-4676-9cd1-dc19ed444c3f",
      "name": "Shopify GraphQL",
      "type": "n8n-nodes-base.httpRequest",
      "onError": "continueRegularOutput",
      "position": [
        576,
        304
      ],
      "parameters": {
        "url": "={{ $json.api_endpoint }}/admin/api/{{ $json.api_version }}/graphql.json",
        "method": "POST",
        "options": {
          "timeout": 30000,
          "response": {
            "response": {
              "fullResponse": true,
              "responseFormat": "json"
            }
          }
        },
        "jsonBody": "={{ $json.body }}",
        "sendBody": true,
        "sendHeaders": true,
        "specifyBody": "json",
        "headerParameters": {
          "parameters": [
            {
              "name": "Content-Type",
              "value": "application/json"
            },
            {
              "name": "X-Shopify-Access-Token",
              "value": "={{ $json.access_token }}"
            }
          ]
        }
      },
      "typeVersion": 4.2
    },
    {
      "id": "cc7752b1-de8a-4cc0-bf5c-eb45118bc64e",
      "name": "Check Errors & Throttle",
      "type": "n8n-nodes-base.code",
      "position": [
        800,
        304
      ],
      "parameters": {
        "jsCode": "/**\n * Comprehensive Shopify GraphQL Error Checker with Throttle Detection\n * \n * Handles:\n * - Network errors (DNS, connection refused, timeout)\n * - HTTP errors (401, 403, 429, 500, etc.)\n * - GraphQL errors\n * - Shopify userErrors (all types)\n * - Search warnings\n * - Rate limiting / throttling\n * - Bulk operation errors\n * - Job errors\n */\n\nconst httpResponse = $json;\nconst prepareInput = $('Prepare Request').item.json;\nconst errors = [];\nlet needsRetry = false;\nlet waitSeconds = 0;\nlet isThrottled = false;\nlet isServerError = false;\nlet isNetworkError = false;\n\n// ============================================\n// 0. NETWORK/HTTP ERROR HANDLING\n// ============================================\n\n// Check if this is a network-level failure (no response at all)\nif (httpResponse.error || httpResponse.code) {\n  // Network error - no HTTP response received\n  isNetworkError = true;\n  isServerError = true; // Treat as server error for retry purposes\n  errors.push({\n    type: 'NETWORK_ERROR',\n    message: httpResponse.message || httpResponse.error?.message || `Network error: ${httpResponse.code || 'Unknown'}`,\n    code: httpResponse.code || null\n  });\n}\n\n// Determine response structure\n// fullResponse: true returns { body, headers, statusCode }\n// On error with continueOnFail, might return error object\nlet statusCode = 200;\nlet response = null;\nlet headers = null;\n\nif (!isNetworkError) {\n  if (httpResponse.statusCode !== undefined) {\n    // fullResponse format\n    statusCode = httpResponse.statusCode;\n    response = httpResponse.body;\n    headers = httpResponse.headers;\n  } else if (httpResponse.data !== undefined) {\n    // GraphQL response directly (shouldn't happen with fullResponse: true)\n    response = httpResponse;\n  } else if (httpResponse.errors !== undefined) {\n    // GraphQL response directly\n    response = httpResponse;\n  } else {\n    // Unknown format - try to use as-is\n    response = httpResponse;\n  }\n}\n\n// Handle HTTP errors\nif (!isNetworkError && statusCode >= 400) {\n  if (statusCode === 429) {\n    isThrottled = true;\n    errors.push({\n      type: 'HTTP_THROTTLED',\n      message: 'HTTP 429 Too Many Requests',\n      statusCode: statusCode\n    });\n    // Check Retry-After header (case-insensitive)\n    const retryAfterKey = headers ? Object.keys(headers).find(k => k.toLowerCase() === 'retry-after') : null;\n    if (retryAfterKey && headers[retryAfterKey]) {\n      const retryAfterValue = parseInt(headers[retryAfterKey], 10);\n      if (!isNaN(retryAfterValue)) {\n        waitSeconds = retryAfterValue;\n      }\n    }\n  } else if (statusCode >= 500) {\n    isServerError = true;\n    errors.push({\n      type: 'HTTP_SERVER_ERROR',\n      message: `HTTP ${statusCode} Server Error`,\n      statusCode: statusCode\n    });\n  } else if (statusCode === 401) {\n    errors.push({\n      type: 'HTTP_AUTH_ERROR',\n      message: 'HTTP 401 Unauthorized - Check your access token',\n      statusCode: statusCode\n    });\n  } else if (statusCode === 403) {\n    errors.push({\n      type: 'HTTP_AUTH_ERROR',\n      message: 'HTTP 403 Forbidden - Insufficient permissions',\n      statusCode: statusCode\n    });\n  } else if (statusCode === 404) {\n    errors.push({\n      type: 'HTTP_NOT_FOUND',\n      message: 'HTTP 404 Not Found - Check API endpoint',\n      statusCode: statusCode\n    });\n  } else {\n    errors.push({\n      type: 'HTTP_ERROR',\n      message: `HTTP ${statusCode} Error`,\n      statusCode: statusCode\n    });\n  }\n}\n\n// ============================================\n// 1. GRAPHQL ERRORS (Top Level)\n// ============================================\nif (response?.errors && Array.isArray(response.errors) && response.errors.length > 0) {\n  for (const error of response.errors) {\n    const errorInfo = {\n      type: 'GRAPHQL_ERROR',\n      message: error.message || 'Unknown GraphQL error',\n      locations: error.locations ?? null,\n      path: error.path ?? null\n    };\n    \n    if (error.extensions?.code) {\n      errorInfo.code = error.extensions.code;\n      \n      switch (error.extensions.code) {\n        case 'THROTTLED':\n          errorInfo.type = 'THROTTLED';\n          isThrottled = true;\n          if (typeof error.extensions.retryAfter === 'number') {\n            waitSeconds = Math.max(waitSeconds, error.extensions.retryAfter);\n          }\n          break;\n        case 'ACCESS_DENIED':\n          errorInfo.type = 'ACCESS_DENIED';\n          break;\n        case 'INTERNAL_SERVER_ERROR':\n          errorInfo.type = 'SERVER_ERROR';\n          isServerError = true;\n          break;\n        case 'NOT_FOUND':\n          errorInfo.type = 'NOT_FOUND';\n          break;\n      }\n    }\n    \n    errors.push(errorInfo);\n  }\n}\n\n// ============================================\n// 2. DATA-LEVEL ERRORS (userErrors patterns)\n// ============================================\nconst data = response?.data ?? {};\n\n// Match any field ending in 'Errors' or 'UserErrors' for future compatibility\nconst isUserErrorField = (key) => {\n  return key === 'userErrors' || \n         key === 'errors' ||\n         key.endsWith('Errors') || \n         key.endsWith('UserErrors');\n};\n\nfunction findUserErrors(obj, path = '') {\n  if (!obj || typeof obj !== 'object') return [];\n  \n  const foundErrors = [];\n  \n  for (const key of Object.keys(obj)) {\n    const value = obj[key];\n    const currentPath = path ? `${path}.${key}` : key;\n    \n    // Check for userErrors-style arrays\n    if (isUserErrorField(key) && Array.isArray(value) && value.length > 0) {\n      for (const userError of value) {\n        if (userError && typeof userError === 'object' && userError.message) {\n          foundErrors.push({\n            type: 'USER_ERROR',\n            category: key,\n            path: currentPath,\n            field: Array.isArray(userError.field) ? userError.field.join('.') : (userError.field ?? null),\n            message: userError.message,\n            code: userError.code ?? null\n          });\n        } else if (typeof userError === 'string') {\n          foundErrors.push({\n            type: 'USER_ERROR',\n            category: key,\n            path: currentPath,\n            field: null,\n            message: userError,\n            code: null\n          });\n        }\n      }\n    }\n    \n    // Recurse into nested objects and arrays\n    if (typeof value === 'object' && value !== null && !isUserErrorField(key)) {\n      if (Array.isArray(value)) {\n        value.forEach((item, index) => {\n          if (item && typeof item === 'object') {\n            foundErrors.push(...findUserErrors(item, `${currentPath}[${index}]`));\n          }\n        });\n      } else {\n        foundErrors.push(...findUserErrors(value, currentPath));\n      }\n    }\n  }\n  \n  return foundErrors;\n}\n\nerrors.push(...findUserErrors(data));\n\n// ============================================\n// 3. SEARCH WARNINGS (extensions.search)\n// ============================================\nconst searchResults = response?.extensions?.search;\nif (Array.isArray(searchResults)) {\n  for (const search of searchResults) {\n    if (Array.isArray(search?.warnings) && search.warnings.length > 0) {\n      for (const warning of search.warnings) {\n        errors.push({\n          type: 'SEARCH_WARNING',\n          field: warning.field ?? null,\n          message: warning.message || 'Unknown search warning',\n          query: search.query ?? null,\n          path: Array.isArray(search.path) ? search.path.join('.') : (search.path ?? null)\n        });\n      }\n    }\n  }\n}\n\n// ============================================\n// 4. COST/THROTTLE CHECK\n// ============================================\nconst cost = response?.extensions?.cost;\nlet rateLimit = null;\n\nif (cost?.throttleStatus) {\n  const throttleStatus = cost.throttleStatus;\n  \n  rateLimit = {\n    currentlyAvailable: throttleStatus.currentlyAvailable,\n    maximumAvailable: throttleStatus.maximumAvailable,\n    restoreRate: throttleStatus.restoreRate,\n    requestCost: cost.requestedQueryCost,\n    actualCost: cost.actualQueryCost\n  };\n  \n  // Check if throttled (no points available)\n  if (typeof throttleStatus.currentlyAvailable === 'number' && \n      throttleStatus.currentlyAvailable <= 0 && \n      !isThrottled) {\n    isThrottled = true;\n    errors.push({\n      type: 'THROTTLED',\n      message: 'API rate limit exceeded - no points available',\n      currentlyAvailable: throttleStatus.currentlyAvailable,\n      maximumAvailable: throttleStatus.maximumAvailable,\n      restoreRate: throttleStatus.restoreRate\n    });\n  }\n  \n  // Calculate wait time if throttled\n  if (isThrottled && waitSeconds === 0 && typeof throttleStatus.restoreRate === 'number' && throttleStatus.restoreRate > 0) {\n    const neededPoints = ((cost.requestedQueryCost ?? 100) * 1.1);\n    const secondsToWait = Math.ceil(neededPoints / throttleStatus.restoreRate);\n    waitSeconds = Math.min(Math.max(secondsToWait, 2), 60);\n  }\n}\n\n// ============================================\n// 5. BULK OPERATION ERRORS\n// ============================================\nconst bulkOpRunQuery = data.bulkOperationRunQuery?.bulkOperation;\nif (bulkOpRunQuery?.status === 'FAILED') {\n  errors.push({\n    type: 'BULK_OPERATION_ERROR',\n    message: bulkOpRunQuery.errorCode || 'Bulk operation failed',\n    partialDataUrl: bulkOpRunQuery.partialDataUrl ?? null\n  });\n}\n\nconst currentBulkOp = data.currentBulkOperation;\nif (currentBulkOp?.status === 'FAILED') {\n  errors.push({\n    type: 'BULK_OPERATION_ERROR',\n    message: currentBulkOp.errorCode || 'Bulk operation failed',\n    partialDataUrl: currentBulkOp.partialDataUrl ?? null\n  });\n}\n\n// ============================================\n// 6. JOB ERRORS\n// ============================================\nfor (const key of Object.keys(data)) {\n  const operation = data[key];\n  if (operation?.job?.status === 'FAILED') {\n    errors.push({\n      type: 'JOB_ERROR',\n      operation: key,\n      message: operation.job.errorMessage || 'Async job failed'\n    });\n  }\n}\n\n// ============================================\n// DETERMINE IF SHOULD RETRY\n// ============================================\nconst retryCount = prepareInput.retry_count ?? 0;\nconst maxRetries = prepareInput.max_retries ?? 5;\nconst retryOnServerError = prepareInput.retry_on_server_error ?? true;\n\nconst canRetry = retryCount < maxRetries;\nconst shouldRetryThrottle = isThrottled && canRetry;\nconst shouldRetryServerError = isServerError && retryOnServerError && canRetry;\nconst shouldRetryNetwork = isNetworkError && canRetry;\n\nif (shouldRetryThrottle || shouldRetryServerError || shouldRetryNetwork) {\n  needsRetry = true;\n  \n  // Calculate wait time with exponential backoff if not already set\n  if (waitSeconds === 0) {\n    // Exponential backoff: 2, 4, 8, 16, 32 seconds (capped at 60)\n    waitSeconds = Math.min(2 * Math.pow(2, retryCount), 60);\n  }\n  \n  // Add jitter to prevent thundering herd (\u00b120%)\n  const jitterFactor = 1 + (0.4 * Math.random() - 0.2); // 0.8 to 1.2\n  waitSeconds = Math.max(1, Math.round(waitSeconds * jitterFactor));\n}\n\n// ============================================\n// BUILD RESPONSE\n// ============================================\n// Determine which errors are non-retryable\nconst retryableTypes = ['THROTTLED', 'HTTP_THROTTLED', 'SERVER_ERROR', 'HTTP_SERVER_ERROR', 'NETWORK_ERROR'];\nconst nonRetryableErrors = needsRetry \n  ? errors.filter(e => !retryableTypes.includes(e.type))\n  : errors;\n\nconst hasNonRetryableErrors = nonRetryableErrors.length > 0;\n\nreturn {\n  json: {\n    success: !hasNonRetryableErrors && !needsRetry,\n    needsRetry: needsRetry,\n    waitSeconds: waitSeconds,\n    retryCount: retryCount,\n    maxRetries: maxRetries,\n    isThrottled: isThrottled,\n    isServerError: isServerError,\n    isNetworkError: isNetworkError,\n    errors: errors,\n    data: response?.data ?? null,\n    rateLimit: rateLimit,\n    statusCode: statusCode,\n    // Pass through request data for retry (excluding sensitive data from error output)\n    _retryData: {\n      api_endpoint: prepareInput.api_endpoint,\n      access_token: prepareInput.access_token,\n      api_version: prepareInput.api_version,\n      query: prepareInput.body.query,\n      variables: prepareInput.body.variables,\n      retry_count: retryCount + 1,\n      max_retries: maxRetries,\n      retry_on_server_error: retryOnServerError\n    }\n  }\n};"
      },
      "retryOnFail": true,
      "typeVersion": 2,
      "waitBetweenTries": 5000
    },
    {
      "id": "e4bd7c99-7631-41d0-a820-bdf5b22c5360",
      "name": "Needs Retry?",
      "type": "n8n-nodes-base.if",
      "position": [
        1024,
        304
      ],
      "parameters": {
        "options": {},
        "conditions": {
          "options": {
            "version": 1,
            "leftValue": "",
            "caseSensitive": true,
            "typeValidation": "strict"
          },
          "combinator": "and",
          "conditions": [
            {
              "id": "needs-retry",
              "operator": {
                "type": "boolean",
                "operation": "equals"
              },
              "leftValue": "={{ $json.needsRetry }}",
              "rightValue": true
            }
          ]
        }
      },
      "typeVersion": 2
    },
    {
      "id": "446a7614-2318-4e00-9f7e-8a9ed265e410",
      "name": "Prepare Retry",
      "type": "n8n-nodes-base.code",
      "position": [
        1232,
        192
      ],
      "parameters": {
        "jsCode": "// Prepare for retry - flatten all data needed after wait\nconst input = $json;\nconst retryData = input._retryData;\n\n// Determine retry reason for logging\nlet retryReason = 'unknown';\nif (input.isThrottled) retryReason = 'rate_limited';\nelse if (input.isNetworkError) retryReason = 'network_error';\nelse if (input.isServerError) retryReason = 'server_error';\n\nreturn {\n  json: {\n    // Wait configuration\n    waitSeconds: input.waitSeconds,\n    \n    // Metadata (for debugging)\n    _meta: {\n      retryAttempt: retryData.retry_count,\n      maxRetries: retryData.max_retries,\n      reason: retryReason\n    },\n    \n    // All data needed to reconstruct request after wait\n    // These fields match what Prepare Request expects\n    api_endpoint: retryData.api_endpoint,\n    access_token: retryData.access_token,\n    api_version: retryData.api_version,\n    query: retryData.query,\n    variables: retryData.variables,\n    retry_count: retryData.retry_count,\n    max_retries: retryData.max_retries,\n    retry_on_server_error: retryData.retry_on_server_error\n  }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "7b7268d7-e284-4b1b-adfe-066687194bbb",
      "name": "Wait",
      "type": "n8n-nodes-base.wait",
      "position": [
        1456,
        192
      ],
      "parameters": {
        "amount": "={{ $json.waitSeconds }}"
      },
      "typeVersion": 1.1
    },
    {
      "id": "5419c1bd-1392-47f5-a51f-4d45c0640004",
      "name": "Format for Retry",
      "type": "n8n-nodes-base.code",
      "position": [
        1664,
        272
      ],
      "parameters": {
        "jsCode": "// After wait, pass data to Prepare Request\n// Wait node preserves $json in latest n8n versions\nconst input = $json;\n\n// Return in format expected by Prepare Request\nreturn {\n  json: {\n    api_endpoint: input.api_endpoint,\n    access_token: input.access_token,\n    api_version: input.api_version,\n    query: input.query,\n    variables: input.variables,\n    retry_count: input.retry_count,\n    max_retries: input.max_retries,\n    retry_on_server_error: input.retry_on_server_error\n  }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "f6655948-ac8d-4aa6-91e8-c1e08b7b3036",
      "name": "Has Errors?",
      "type": "n8n-nodes-base.if",
      "position": [
        1248,
        576
      ],
      "parameters": {
        "options": {},
        "conditions": {
          "options": {
            "version": 1,
            "leftValue": "",
            "caseSensitive": true,
            "typeValidation": "strict"
          },
          "combinator": "and",
          "conditions": [
            {
              "id": "has-errors",
              "operator": {
                "type": "number",
                "operation": "gt"
              },
              "leftValue": "={{ $json.errors.length }}",
              "rightValue": 0
            },
            {
              "id": "95628357-dea3-462a-877e-9be46d137772",
              "operator": {
                "type": "string",
                "operation": "notEquals"
              },
              "leftValue": "={{ $json.errors[0].type }}",
              "rightValue": "=USER_ERROR"
            }
          ]
        }
      },
      "typeVersion": 2
    },
    {
      "id": "a5190f7a-a998-4fa5-889e-5d2e6fcc8a7c",
      "name": "Throw Error",
      "type": "n8n-nodes-base.code",
      "position": [
        1456,
        496
      ],
      "parameters": {
        "jsCode": "// Format error message\nconst input = $json;\n\nconst formatError = (e) => {\n  switch (e.type) {\n    case 'NETWORK_ERROR':\n      return `[Network] ${e.message}`;\n    case 'HTTP_THROTTLED':\n    case 'THROTTLED':\n      return `[Throttled] ${e.message}${e.currentlyAvailable !== undefined ? ` (${e.currentlyAvailable}/${e.maximumAvailable} points)` : ''}`;\n    case 'HTTP_SERVER_ERROR':\n    case 'SERVER_ERROR':\n      return `[Server Error] ${e.message}`;\n    case 'HTTP_AUTH_ERROR':\n      return `[Auth] ${e.message}`;\n    case 'HTTP_NOT_FOUND':\n      return `[Not Found] ${e.message}`;\n    case 'HTTP_ERROR':\n      return `[HTTP] ${e.message}`;\n    case 'GRAPHQL_ERROR':\n      return `[GraphQL] ${e.message}${e.code ? ` (${e.code})` : ''}`;\n    case 'ACCESS_DENIED':\n      return `[Access Denied] ${e.message}`;\n    case 'NOT_FOUND':\n      return `[Not Found] ${e.message}`;\n    case 'USER_ERROR':\n      return `[${e.category}] ${e.field ? e.field + ': ' : ''}${e.message}${e.code ? ` (${e.code})` : ''}`;\n    case 'SEARCH_WARNING':\n      return `[Search] ${e.field ? e.field + ': ' : ''}${e.message}${e.query ? ` (query: \"${e.query}\")` : ''}`;\n    case 'BULK_OPERATION_ERROR':\n      return `[Bulk Operation] ${e.message}`;\n    case 'JOB_ERROR':\n      return `[Job] ${e.operation}: ${e.message}`;\n    default:\n      return `[${e.type}] ${e.message}`;\n  }\n};\n\nconst errorSummary = input.errors.map(formatError).join('\\n');\n\nconst parentWorkflow = $execution.customData.get('parentWorkflowName');\nconst parentWorkflowId = $execution.customData.get('parentWorkflowId');\nconst parentExecutionId = $execution.customData.get('parentExecutionId');\n\nreturn {\n  errorMessage: `Shopify API Error (HTTP ${input.statusCode}):\\n${errorSummary}`,\n  statusCode: input.statusCode,\n  workflow: $workflow.name,\n  workflowId: $workflow.id,\n  executionId: $execution.id,\n  parentWorkflow: parentWorkflow || null,\n  parentWorkflowId: parentWorkflowId || null,\n  parentExecutionId: parentExecutionId || null\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "981d2e15-3ef3-43c4-9175-ceab0da05822",
      "name": "Success Response",
      "type": "n8n-nodes-base.code",
      "position": [
        1456,
        688
      ],
      "parameters": {
        "jsCode": "// Return successful response\nconst input = $json;\n\nreturn {\n  json: {\n    success: true,\n    data: input.data,\n    rateLimit: input.rateLimit,\n    statusCode: input.statusCode,\n    retriesUsed: input.retryCount\n  }\n};"
      },
      "typeVersion": 2
    },
    {
      "id": "3ff6b17a-650f-40eb-9b2f-2065941de87d",
      "name": "Stop and Error",
      "type": "n8n-nodes-base.stopAndError",
      "position": [
        1664,
        496
      ],
      "parameters": {
        "errorType": "errorObject",
        "errorObject": "={{ $json.toJsonString() }}"
      },
      "typeVersion": 1
    },
    {
      "id": "7dd2cd32-6466-4d47-b9d7-38fa6cf905f6",
      "name": "Overview",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        -496,
        64
      ],
      "parameters": {
        "width": 544,
        "height": 704,
        "content": "## Shopify GraphQL Handler\nReusable sub-workflow that executes any Shopify GraphQL query or mutation with built-in error handling, rate limit detection, and automatic retry with exponential backoff.\n\n### How it works\n1. Parent workflow calls this via **Execute Workflow** with query, endpoint, and credentials.\n2. **Prepare Request** validates input and structures the API call.\n3. **Shopify GraphQL** sends the request with full response capture.\n4. **Check Errors & Throttle** inspects HTTP status, GraphQL errors, userErrors, throttle cost, bulk ops, and job failures.\n5. If throttled or server error, the workflow **retries automatically** (up to 5x) with exponential backoff and jitter.\n6. On success, returns `data`, `rateLimit`, and `retriesUsed`.\n7. On non-retryable error, stops execution with a formatted error message.\n\n### Setup steps\n- [ ] In your **parent workflow**, add an Execute Workflow node pointing to this workflow.\n- [ ] Pass `query`, `api_endpoint`, and `access_token` as input fields.\n- [ ] Optionally pass `variables`, `api_version`, `max_retries`.\n\n"
      },
      "typeVersion": 1
    },
    {
      "id": "1112eb2b-afbb-4ad9-a7de-1ce1bf599275",
      "name": "Section: Authentication",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        304,
        48
      ],
      "parameters": {
        "color": 7,
        "width": 650,
        "height": 454,
        "content": "### Preparing the request\nPrepare the request based on input parameters\n"
      },
      "typeVersion": 1
    },
    {
      "id": "4a1fdeed-17cf-4b4a-a693-3ffedcc26944",
      "name": "Section: Authentication1",
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        992,
        48
      ],
      "parameters": {
        "color": 7,
        "width": 890,
        "height": 790,
        "content": "### Retry & failure handling\nIn case of failure of throttle requirements, this part handles it\n"
      },
      "typeVersion": 1
    }
  ],
  "active": false,
  "settings": {
    "binaryMode": "separate",
    "callerPolicy": "workflowsFromSameOwner",
    "timeSavedMode": "fixed",
    "availableInMCP": true,
    "executionOrder": "v1"
  },
  "versionId": "4f3857f8-65fa-475f-9a38-ed0c3e262909",
  "nodeGroups": [],
  "connections": {
    "Wait": {
      "main": [
        [
          {
            "node": "Format for Retry",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Has Errors?": {
      "main": [
        [
          {
            "node": "Throw Error",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Success Response",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Throw Error": {
      "main": [
        [
          {
            "node": "Stop and Error",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Needs Retry?": {
      "main": [
        [
          {
            "node": "Prepare Retry",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Has Errors?",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Prepare Retry": {
      "main": [
        [
          {
            "node": "Wait",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Prepare Request": {
      "main": [
        [
          {
            "node": "Shopify GraphQL",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Shopify GraphQL": {
      "main": [
        [
          {
            "node": "Check Errors & Throttle",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Format for Retry": {
      "main": [
        [
          {
            "node": "Prepare Request",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Check Errors & Throttle": {
      "main": [
        [
          {
            "node": "Needs Retry?",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "When Executed by Another Workflow": {
      "main": [
        [
          {
            "node": "Prepare Request",
            "type": "main",
            "index": 0
          }
        ]
      ]
    }
  }
}

About this workflow

This sub-workflow is called by another n8n workflow to execute Shopify Admin GraphQL queries and mutations via HTTP, adding input validation, detailed error detection (including rate limits), and automatic retries with exponential backoff before returning the final Shopify…

Source: https://n8n.io/workflows/16874/ — original creator credit. Request a take-down →
