The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "Knowledge Management Database Setup",
"nodes": [
{
"parameters": {
"httpMethod": "POST",
"path": "setup-knowledge-database",
"responseMode": "responseNode",
"options": {}
},
"id": "database-setup-webhook",
"name": "Database Setup Webhook",
"type": "n8n-nodes-base.webhook",
"typeVersion": 2,
"position": [
200,
400
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "setup-mode",
"name": "setupMode",
"value": "={{ $json.body.mode || 'full' }}",
"type": "string"
},
{
"id": "force-recreate",
"name": "forceRecreate",
"value": "={{ $json.body.forceRecreate || false }}",
"type": "boolean"
},
{
"id": "enable-extensions",
"name": "enableExtensions",
"value": "={{ $json.body.enableExtensions || true }}",
"type": "boolean"
},
{
"id": "setup-timestamp",
"name": "timestamp",
"value": "={{ $now }}",
"type": "string"
}
]
},
"options": {}
},
"id": "process-setup-request",
"name": "Process Setup Request",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
450,
400
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "extensions-enabled",
"leftValue": "={{ $json.enableExtensions }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-extensions-enabled",
"name": "Check Extensions Enabled",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
700,
300
]
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Enable required PostgreSQL extensions\nCREATE EXTENSION IF NOT EXISTS \"uuid-ossp\";\nCREATE EXTENSION IF NOT EXISTS \"pgcrypto\";\nCREATE EXTENSION IF NOT EXISTS \"vector\";\nCREATE EXTENSION IF NOT EXISTS \"pg_trgm\";\nCREATE EXTENSION IF NOT EXISTS \"btree_gin\";\n\nSELECT 'Extensions enabled successfully' as status;",
"options": {}
},
"id": "enable-postgresql-extensions",
"name": "Enable PostgreSQL Extensions",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
950,
200
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Knowledge Sync Log Table\nCREATE TABLE IF NOT EXISTS knowledge_sync_log (\n id UUID PRIMARY KEY DEFAULT uuid_generate_v4(),\n document_id VARCHAR(255) NOT NULL,\n source_system VARCHAR(50) NOT NULL,\n source_id VARCHAR(255) NOT NULL,\n content_hash VARCHAR(64) NOT NULL,\n metadata JSONB DEFAULT '{}',\n sync_timestamp TIMESTAMPTZ NOT NULL DEFAULT NOW(),\n status VARCHAR(20) NOT NULL DEFAULT 'synced',\n error_message TEXT,\n created_at TIMESTAMPTZ NOT NULL DEFAULT NOW(),\n updated_at TIMESTAMPTZ NOT NULL DEFAULT NOW()\n);\n\n-- Indexes for performance\nCREATE INDEX IF NOT EXISTS idx_knowledge_sync_log_document_id ON knowledge_sync_log(document_id);\nCREATE INDEX IF NOT EXISTS idx_knowledge_sync_log_source_system ON knowledge_sync_log(source_system);\nCREATE INDEX IF NOT EXISTS idx_knowledge_sync_log_status ON knowledge_sync_log(status);\nCREATE INDEX IF NOT EXISTS idx_knowledge_sync_log_sync_timestamp ON knowledge_sync_log(sync_timestamp);\nCREATE INDEX IF NOT EXISTS idx_knowledge_sync_log_content_hash ON knowledge_sync_log(content_hash);\n\nSELECT 'knowledge_sync_log table created' as status;",
"options": {}
},
"id": "create-knowledge-sync-log",
"name": "Create Knowledge Sync Log",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
950,
400
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Knowledge Sync Mapping Table\nCREATE TABLE IF NOT EXISTS knowledge_sync_mapping (\n id UUID PRIMARY KEY DEFAULT uuid_generate_v4(),\n source_system VARCHAR(50) NOT NULL,\n source_id VARCHAR(255) NOT NULL,\n target_system VARCHAR(50) NOT NULL,\n target_id VARCHAR(255) NOT NULL,\n mapping_type VARCHAR(50) NOT NULL DEFAULT 'document',\n sync_direction VARCHAR(20) NOT NULL DEFAULT 'bidirectional',\n status VARCHAR(20) NOT NULL DEFAULT 'active',\n metadata JSONB DEFAULT '{}',\n created_at TIMESTAMPTZ NOT NULL DEFAULT NOW(),\n updated_at TIMESTAMPTZ NOT NULL DEFAULT NOW(),\n UNIQUE(source_system, source_id, target_system, target_id)\n);\n\n-- Indexes\nCREATE INDEX IF NOT EXISTS idx_knowledge_sync_mapping_source ON knowledge_sync_mapping(source_system, source_id);\nCREATE INDEX IF NOT EXISTS idx_knowledge_sync_mapping_target ON knowledge_sync_mapping(target_system, target_id);\nCREATE INDEX IF NOT EXISTS idx_knowledge_sync_mapping_status ON knowledge_sync_mapping(status);\n\nSELECT 'knowledge_sync_mapping table created' as status;",
"options": {}
},
"id": "create-sync-mapping-table",
"name": "Create Sync Mapping Table",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1200,
300
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Chat Sessions Table\nCREATE TABLE IF NOT EXISTS chat_sessions (\n id UUID PRIMARY KEY DEFAULT uuid_generate_v4(),\n session_id VARCHAR(255) NOT NULL,\n user_input TEXT NOT NULL,\n response TEXT,\n knowledge_context JSONB DEFAULT '{}',\n metadata JSONB DEFAULT '{}',\n timestamp TIMESTAMPTZ NOT NULL DEFAULT NOW(),\n processing_time_ms INTEGER,\n tokens_used INTEGER,\n created_at TIMESTAMPTZ NOT NULL DEFAULT NOW()\n);\n\n-- Indexes\nCREATE INDEX IF NOT EXISTS idx_chat_sessions_session_id ON chat_sessions(session_id);\nCREATE INDEX IF NOT EXISTS idx_chat_sessions_timestamp ON chat_sessions(timestamp);\nCREATE INDEX IF NOT EXISTS idx_chat_sessions_user_input_gin ON chat_sessions USING GIN (to_tsvector('english', user_input));\n\nSELECT 'chat_sessions table created' as status;",
"options": {}
},
"id": "create-chat-sessions-table",
"name": "Create Chat Sessions Table",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1200,
400
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Query Analytics Table\nCREATE TABLE IF NOT EXISTS query_analytics (\n id UUID PRIMARY KEY DEFAULT uuid_generate_v4(),\n query_text TEXT NOT NULL,\n query_type VARCHAR(50) NOT NULL,\n results_count INTEGER NOT NULL DEFAULT 0,\n response_time_ms INTEGER,\n query_metadata JSONB DEFAULT '{}',\n created_at TIMESTAMPTZ NOT NULL DEFAULT NOW()\n);\n\n-- Indexes\nCREATE INDEX IF NOT EXISTS idx_query_analytics_query_type ON query_analytics(query_type);\nCREATE INDEX IF NOT EXISTS idx_query_analytics_created_at ON query_analytics(created_at);\nCREATE INDEX IF NOT EXISTS idx_query_analytics_query_text_gin ON query_analytics USING GIN (to_tsvector('english', query_text));\n\nSELECT 'query_analytics table created' as status;",
"options": {}
},
"id": "create-query-analytics-table",
"name": "Create Query Analytics Table",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1200,
500
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Cross-Platform Search Analytics Table\nCREATE TABLE IF NOT EXISTS cross_platform_search_analytics (\n id UUID PRIMARY KEY DEFAULT uuid_generate_v4(),\n query_text TEXT NOT NULL,\n search_mode VARCHAR(50) NOT NULL,\n platforms_searched TEXT[] NOT NULL,\n total_results INTEGER NOT NULL DEFAULT 0,\n platform_breakdown JSONB DEFAULT '{}',\n processing_time_ms INTEGER,\n deduplication_enabled BOOLEAN DEFAULT true,\n created_at TIMESTAMPTZ NOT NULL DEFAULT NOW()\n);\n\n-- Indexes\nCREATE INDEX IF NOT EXISTS idx_cross_platform_search_mode ON cross_platform_search_analytics(search_mode);\nCREATE INDEX IF NOT EXISTS idx_cross_platform_search_created_at ON cross_platform_search_analytics(created_at);\nCREATE INDEX IF NOT EXISTS idx_cross_platform_search_platforms ON cross_platform_search_analytics USING GIN (platforms_searched);\n\nSELECT 'cross_platform_search_analytics table created' as status;",
"options": {}
},
"id": "create-cross-platform-analytics",
"name": "Create Cross-Platform Analytics",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1450,
300
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Bidirectional Sync Log Table\nCREATE TABLE IF NOT EXISTS bidirectional_sync_log (\n id UUID PRIMARY KEY DEFAULT uuid_generate_v4(),\n sync_session_id VARCHAR(255) NOT NULL,\n source_system VARCHAR(50),\n items_synced INTEGER NOT NULL DEFAULT 0,\n sync_direction VARCHAR(20) NOT NULL DEFAULT 'bidirectional',\n status VARCHAR(20) NOT NULL DEFAULT 'in_progress',\n started_at TIMESTAMPTZ NOT NULL DEFAULT NOW(),\n completed_at TIMESTAMPTZ,\n errors JSONB DEFAULT '[]',\n metadata JSONB DEFAULT '{}'\n);\n\n-- Indexes\nCREATE INDEX IF NOT EXISTS idx_bidirectional_sync_session_id ON bidirectional_sync_log(sync_session_id);\nCREATE INDEX IF NOT EXISTS idx_bidirectional_sync_status ON bidirectional_sync_log(status);\nCREATE INDEX IF NOT EXISTS idx_bidirectional_sync_started_at ON bidirectional_sync_log(started_at);\n\nSELECT 'bidirectional_sync_log table created' as status;",
"options": {}
},
"id": "create-bidirectional-sync-log",
"name": "Create Bidirectional Sync Log",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1450,
400
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Orchestration Log Table\nCREATE TABLE IF NOT EXISTS orchestration_log (\n id UUID PRIMARY KEY DEFAULT uuid_generate_v4(),\n session_id VARCHAR(255) NOT NULL,\n mode VARCHAR(50) NOT NULL,\n target_systems TEXT[] NOT NULL,\n maintenance_performed BOOLEAN DEFAULT false,\n sync_triggered BOOLEAN DEFAULT false,\n system_health JSONB DEFAULT '{}',\n orchestration_summary JSONB DEFAULT '{}',\n created_at TIMESTAMPTZ NOT NULL DEFAULT NOW()\n);\n\n-- Indexes\nCREATE INDEX IF NOT EXISTS idx_orchestration_log_session_id ON orchestration_log(session_id);\nCREATE INDEX IF NOT EXISTS idx_orchestration_log_mode ON orchestration_log(mode);\nCREATE INDEX IF NOT EXISTS idx_orchestration_log_created_at ON orchestration_log(created_at);\n\nSELECT 'orchestration_log table created' as status;",
"options": {}
},
"id": "create-orchestration-log",
"name": "Create Orchestration Log",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1450,
500
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Deep Analysis Reports Table\nCREATE TABLE IF NOT EXISTS deep_analysis_reports (\n id UUID PRIMARY KEY DEFAULT uuid_generate_v4(),\n analysis_timestamp VARCHAR(255) NOT NULL,\n analysis_type VARCHAR(100) NOT NULL,\n findings TEXT,\n recommendations JSONB DEFAULT '[]',\n metadata JSONB DEFAULT '{}',\n created_at TIMESTAMPTZ NOT NULL DEFAULT NOW()\n);\n\n-- Indexes\nCREATE INDEX IF NOT EXISTS idx_deep_analysis_type ON deep_analysis_reports(analysis_type);\nCREATE INDEX IF NOT EXISTS idx_deep_analysis_timestamp ON deep_analysis_reports(analysis_timestamp);\nCREATE INDEX IF NOT EXISTS idx_deep_analysis_created_at ON deep_analysis_reports(created_at);\nCREATE INDEX IF NOT EXISTS idx_deep_analysis_findings_gin ON deep_analysis_reports USING GIN (to_tsvector('english', findings));\n\nSELECT 'deep_analysis_reports table created' as status;",
"options": {}
},
"id": "create-deep-analysis-reports",
"name": "Create Deep Analysis Reports",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1700,
300
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Create useful views for analytics and reporting\n\n-- View: Recent Knowledge Activity\nCREATE OR REPLACE VIEW recent_knowledge_activity AS\nSELECT \n source_system,\n source_id,\n document_id,\n status,\n sync_timestamp,\n metadata->>'title' as title,\n metadata->>'type' as content_type\nFROM knowledge_sync_log \nWHERE sync_timestamp >= NOW() - INTERVAL '24 hours'\nORDER BY sync_timestamp DESC;\n\n-- View: Platform Health Summary\nCREATE OR REPLACE VIEW platform_health_summary AS\nSELECT \n source_system,\n COUNT(*) as total_documents,\n COUNT(CASE WHEN status = 'synced' THEN 1 END) as synced_documents,\n COUNT(CASE WHEN status = 'error' THEN 1 END) as error_documents,\n MAX(sync_timestamp) as last_sync,\n ROUND(\n (COUNT(CASE WHEN status = 'synced' THEN 1 END)::FLOAT / COUNT(*)) * 100, 2\n ) as sync_success_rate\nFROM knowledge_sync_log \nWHERE sync_timestamp >= NOW() - INTERVAL '7 days'\nGROUP BY source_system;\n\n-- View: Search Analytics Summary\nCREATE OR REPLACE VIEW search_analytics_summary AS\nSELECT \n query_type,\n COUNT(*) as total_queries,\n AVG(results_count) as avg_results,\n AVG(response_time_ms) as avg_response_time_ms,\n DATE_TRUNC('hour', created_at) as hour_bucket\nFROM query_analytics \nWHERE created_at >= NOW() - INTERVAL '24 hours'\nGROUP BY query_type, DATE_TRUNC('hour', created_at)\nORDER BY hour_bucket DESC;\n\nSELECT 'Analytics views created successfully' as status;",
"options": {}
},
"id": "create-analytics-views",
"name": "Create Analytics Views",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1700,
400
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "executeQuery",
"query": "-- Create triggers for automatic timestamp updates\n\nCREATE OR REPLACE FUNCTION update_updated_at_column()\nRETURNS TRIGGER AS $$\nBEGIN\n NEW.updated_at = NOW();\n RETURN NEW;\nEND;\n$$ LANGUAGE plpgsql;\n\n-- Apply to tables with updated_at columns\nDROP TRIGGER IF EXISTS update_knowledge_sync_log_updated_at ON knowledge_sync_log;\nCREATE TRIGGER update_knowledge_sync_log_updated_at\n BEFORE UPDATE ON knowledge_sync_log\n FOR EACH ROW EXECUTE FUNCTION update_updated_at_column();\n\nDROP TRIGGER IF EXISTS update_knowledge_sync_mapping_updated_at ON knowledge_sync_mapping;\nCREATE TRIGGER update_knowledge_sync_mapping_updated_at\n BEFORE UPDATE ON knowledge_sync_mapping\n FOR EACH ROW EXECUTE FUNCTION update_updated_at_column();\n\nSELECT 'Database triggers created successfully' as status;",
"options": {}
},
"id": "create-database-triggers",
"name": "Create Database Triggers",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
1700,
500
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "setup-summary",
"name": "setupSummary",
"value": "={{ {\n setupMode: $('Process Setup Request').item.json.setupMode,\n timestamp: $('Process Setup Request').item.json.timestamp,\n extensionsEnabled: $('Process Setup Request').item.json.enableExtensions,\n tablesCreated: [\n 'knowledge_sync_log',\n 'knowledge_sync_mapping', \n 'chat_sessions',\n 'query_analytics',\n 'cross_platform_search_analytics',\n 'bidirectional_sync_log',\n 'orchestration_log',\n 'deep_analysis_reports'\n ],\n viewsCreated: [\n 'recent_knowledge_activity',\n 'platform_health_summary',\n 'search_analytics_summary'\n ],\n triggersCreated: [\n 'update_knowledge_sync_log_updated_at',\n 'update_knowledge_sync_mapping_updated_at'\n ],\n status: 'completed',\n completedAt: $now\n} }}",
"type": "object"
}
]
},
"options": {}
},
"id": "compile-setup-summary",
"name": "Compile Setup Summary",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
1950,
400
]
},
{
"parameters": {
"operation": "insert",
"table": {
"__rl": true,
"value": "orchestration_log",
"mode": "list"
},
"data": {
"insert": [
{
"column": "session_id",
"value": "database_setup_{{ $('Process Setup Request').item.json.timestamp }}"
},
{
"column": "mode",
"value": "database_setup"
},
{
"column": "target_systems",
"value": "{{ ['postgresql', 'knowledge_management'] }}"
},
{
"column": "maintenance_performed",
"value": true
},
{
"column": "sync_triggered",
"value": false
},
{
"column": "system_health",
"value": "{{ { database: 'healthy', setup_completed: true } }}"
},
{
"column": "orchestration_summary",
"value": "={{ $json.setupSummary }}"
}
]
},
"options": {}
},
"id": "log-setup-completion",
"name": "Log Setup Completion",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
2200,
400
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"options": {}
},
"id": "respond-to-setup-request",
"name": "Respond to Setup Request",
"type": "n8n-nodes-base.respondToWebhook",
"typeVersion": 1.1,
"position": [
2450,
400
]
},
{
"parameters": {
"content": "## Knowledge Management Database Setup\n\n**Purpose:** Initialize all required database tables, indexes, views, and triggers for the comprehensive knowledge management system.\n\n**Database Schema:**\n\n**Core Tables:**\n- `knowledge_sync_log`: Track all sync operations and content changes\n- `knowledge_sync_mapping`: Bidirectional mappings between platforms\n- `chat_sessions`: AI agent conversation history and context\n- `query_analytics`: Search performance and usage analytics\n- `cross_platform_search_analytics`: Multi-platform search metrics\n- `bidirectional_sync_log`: Sync session tracking and status\n- `orchestration_log`: System orchestration and health monitoring\n- `deep_analysis_reports`: AI-generated insights and recommendations\n\n**Analytics Views:**\n- `recent_knowledge_activity`: 24-hour activity summary\n- `platform_health_summary`: Per-platform sync success rates\n- `search_analytics_summary`: Hourly search performance metrics\n\n**Database Features:**\n- **pgvector Extension**: Vector similarity search support\n- **Full-Text Search**: GIN indexes for content search\n- **UUID Primary Keys**: Globally unique identifiers\n- **JSONB Metadata**: Flexible schema evolution\n- **Automatic Timestamps**: Trigger-based update tracking\n- **Performance Indexes**: Optimized for common queries\n\n**Setup Modes:**\n- `full`: Complete setup with all tables and features\n- `minimal`: Core tables only\n- `analytics_only`: Analytics tables and views only\n\n**API Parameters:**\n- `mode`: Setup mode to execute\n- `forceRecreate`: Drop and recreate existing tables\n- `enableExtensions`: Install PostgreSQL extensions\n\n**Post-Setup:**\nAfter running this setup, all knowledge management workflows will have the required database schema for proper operation.",
"height": 750,
"width": 800,
"color": 2
},
"id": "database-setup-documentation",
"name": "Database Setup Documentation",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
100,
100
]
}
],
"connections": {
"Database Setup Webhook": {
"main": [
[
{
"node": "Process Setup Request",
"type": "main",
"index": 0
}
]
]
},
"Process Setup Request": {
"main": [
[
{
"node": "Check Extensions Enabled",
"type": "main",
"index": 0
},
{
"node": "Create Knowledge Sync Log",
"type": "main",
"index": 0
}
]
]
},
"Check Extensions Enabled": {
"main": [
[
{
"node": "Enable PostgreSQL Extensions",
"type": "main",
"index": 0
}
]
]
},
"Enable PostgreSQL Extensions": {
"main": [
[
{
"node": "Create Sync Mapping Table",
"type": "main",
"index": 0
}
]
]
},
"Create Knowledge Sync Log": {
"main": [
[
{
"node": "Create Sync Mapping Table",
"type": "main",
"index": 0
}
]
]
},
"Create Sync Mapping Table": {
"main": [
[
{
"node": "Create Chat Sessions Table",
"type": "main",
"index": 0
}
]
]
},
"Create Chat Sessions Table": {
"main": [
[
{
"node": "Create Query Analytics Table",
"type": "main",
"index": 0
}
]
]
},
"Create Query Analytics Table": {
"main": [
[
{
"node": "Create Cross-Platform Analytics",
"type": "main",
"index": 0
}
]
]
},
"Create Cross-Platform Analytics": {
"main": [
[
{
"node": "Create Bidirectional Sync Log",
"type": "main",
"index": 0
}
]
]
},
"Create Bidirectional Sync Log": {
"main": [
[
{
"node": "Create Orchestration Log",
"type": "main",
"index": 0
}
]
]
},
"Create Orchestration Log": {
"main": [
[
{
"node": "Create Deep Analysis Reports",
"type": "main",
"index": 0
}
]
]
},
"Create Deep Analysis Reports": {
"main": [
[
{
"node": "Create Analytics Views",
"type": "main",
"index": 0
}
]
]
},
"Create Analytics Views": {
"main": [
[
{
"node": "Create Database Triggers",
"type": "main",
"index": 0
}
]
]
},
"Create Database Triggers": {
"main": [
[
{
"node": "Compile Setup Summary",
"type": "main",
"index": 0
}
]
]
},
"Compile Setup Summary": {
"main": [
[
{
"node": "Log Setup Completion",
"type": "main",
"index": 0
}
]
]
},
"Log Setup Completion": {
"main": [
[
{
"node": "Respond to Setup Request",
"type": "main",
"index": 0
}
]
]
}
},
"active": true,
"settings": {
"executionOrder": "v1"
},
"versionId": "database-setup-v1",
"meta": {
"templateCredsSetupCompleted": true
},
"id": "DatabaseSetup",
"tags": [
"database",
"setup",
"postgresql",
"schema",
"knowledge-management"
]
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
postgres
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
Knowledge Management Database Setup. Uses postgres. Webhook trigger; 18 nodes.
Source: https://github.com/161sam/n8n-installer/blob/main/modularium/ai-workspace/Database-Setup.json — original creator credit. Request a take-down →
