This workflow follows the Error Trigger → HTTP Request recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "mlops-nmt-pipeline",
"name": "MLOps Pipeline EN-PT",
"nodes": [
{
"parameters": {
"content": "## Logica Principal\nWebhook -> Preparar Parametros -> Validar Parametros -> Preparar Dados -> Treinar -> Validar -> Publicar Artefatos -> Deploy -> Resposta JSON",
"height": 220,
"width": 360,
"color": 4
},
"id": "5f41d731-3c71-4cf0-89e0-5f37de629061",
"name": "Sticky Note - Logica Principal",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-720,
-240
]
},
{
"parameters": {
"content": "## Monitoramento de Erros\nError Trigger captura falhas do workflow e envia notificacao dinamica com execution_id, node, erro e timestamp.",
"height": 220,
"width": 360,
"color": 3
},
"id": "8fdf8dd5-80ad-4578-9935-08ecb55502db",
"name": "Sticky Note - Monitoramento de Erros",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-720,
420
]
},
{
"parameters": {
"httpMethod": "POST",
"path": "mlops-nmt-pipeline",
"responseMode": "lastNode",
"options": {}
},
"id": "99e6fe73-9839-4671-a990-87f240e6819f",
"name": "Webhook - Iniciar Pipeline",
"type": "n8n-nodes-base.webhook",
"typeVersion": 2,
"position": [
-660,
40
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "dataset-name",
"name": "dataset_name",
"type": "string",
"value": "={{ $json.body?.dataset_name || 'para_crawl/enpt' }}"
},
{
"id": "max-tokens",
"name": "max_tokens",
"type": "number",
"value": "={{ Number($json.body?.max_tokens || 64) }}"
},
{
"id": "train-records",
"name": "train_records",
"type": "number",
"value": "={{ Number($json.body?.train_records || 20000) }}"
},
{
"id": "val-records",
"name": "val_records",
"type": "number",
"value": "={{ Number($json.body?.val_records || 2000) }}"
},
{
"id": "seed",
"name": "seed",
"type": "number",
"value": "={{ Number($json.body?.seed || 42) }}"
},
{
"id": "epochs",
"name": "epochs",
"type": "number",
"value": "={{ Number($json.body?.epochs || 10) }}"
},
{
"id": "batch-size",
"name": "batch_size",
"type": "number",
"value": "={{ Number($json.body?.batch_size || 32) }}"
},
{
"id": "threshold",
"name": "threshold",
"type": "number",
"value": "={{ Number($json.body?.threshold || 0.30) }}"
},
{
"id": "git-sha",
"name": "git_sha",
"type": "string",
"value": "={{ $json.body?.git_sha || 'unknown' }}"
},
{
"id": "api-base-url",
"name": "api_base_url",
"type": "string",
"value": "={{ $json.body?.api_base_url || '' }}"
},
{
"id": "api-gateway-api-key",
"name": "api_gateway_api_key",
"type": "string",
"value": "={{ $json.body?.api_gateway_api_key || $json.headers?.['x-api-key'] || '' }}"
}
]
},
"options": {}
},
"id": "bb214e1e-e542-4129-bb6b-e0125ee611f1",
"name": "Preparar Parametros",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-420,
40
]
},
{
"parameters": {
"jsCode": "const input = $json;\nconst positiveIntegerFields = ['max_tokens', 'train_records', 'val_records', 'seed', 'epochs', 'batch_size'];\nconst errors = [];\n\nfor (const field of positiveIntegerFields) {\n const value = Number(input[field]);\n if (!Number.isInteger(value) || value <= 0) {\n errors.push(`${field} deve ser um inteiro positivo. Valor recebido: ${input[field]}`);\n }\n}\n\nconst threshold = Number(input.threshold);\nif (!Number.isFinite(threshold) || threshold < 0 || threshold > 1) {\n errors.push(`threshold deve ser um numero entre 0 e 1. Valor recebido: ${input.threshold}`);\n}\n\nconst apiBaseUrl = String(input.api_base_url || '').trim();\nif (!/^https?:\\/\\/[^\\s/$.?#].[^\\s]*$/.test(apiBaseUrl)) {\n errors.push(`api_base_url invalida: ${input.api_base_url}`);\n}\n\nif (!input.dataset_name || typeof input.dataset_name !== 'string') {\n errors.push('dataset_name deve ser uma string nao vazia.');\n}\n\nif (!input.api_gateway_api_key || typeof input.api_gateway_api_key !== 'string') {\n errors.push('api_gateway_api_key deve ser informado no payload ou no header x-api-key.');\n}\n\nif (errors.length > 0) {\n throw new Error(`Parametros invalidos: ${errors.join(' | ')}`);\n}\n\nreturn [{\n json: {\n ...input,\n api_base_url: apiBaseUrl,\n pipeline_status: 'parameters_validated',\n pipeline_started_at: new Date().toISOString()\n }\n}];"
},
"id": "8eb9e92f-6db1-4ba6-9d6e-d8df837a2674",
"name": "Validar Parametros",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
-290,
40
]
},
{
"parameters": {
"command": "=DATASET_NAME='{{ $json.dataset_name }}' MAX_TOKENS='{{ $json.max_tokens }}' TRAIN_RECORDS='{{ $json.train_records }}' VAL_RECORDS='{{ $json.val_records }}' SEED='{{ $json.seed }}' docker compose run --rm prepare_dataset"
},
"id": "1d64535d-f242-4c26-82c0-a15420672b06",
"name": "Preparar Dados - Container",
"type": "n8n-nodes-base.executeCommand",
"typeVersion": 1,
"position": [
-40,
40
]
},
{
"parameters": {
"command": "=EPOCHS='{{ $('Validar Parametros').item.json.epochs }}' BATCH_SIZE='{{ $('Validar Parametros').item.json.batch_size }}' THRESHOLD='{{ $('Validar Parametros').item.json.threshold }}' MAX_TOKENS='{{ $('Validar Parametros').item.json.max_tokens }}' GIT_SHA='{{ $('Validar Parametros').item.json.git_sha }}' docker compose run --rm train"
},
"id": "65e8c062-3a20-4600-8e6d-48f1a40ab6a5",
"name": "Treinar Modelo - Container",
"type": "n8n-nodes-base.executeCommand",
"typeVersion": 1,
"position": [
220,
40
]
},
{
"parameters": {
"jsCode": "const stdout = $json.stdout || '';\nconst stderr = $json.stderr || '';\nconst lines = stdout.split(/\\r?\\n/).map(line => line.trim()).filter(Boolean);\n\nconst summaryLine = [...lines].reverse().find(line => {\n try {\n const parsed = JSON.parse(line);\n return parsed.stage === 'train' && parsed.run_id;\n } catch (error) {\n return false;\n }\n});\n\nif (!summaryLine) {\n throw new Error(`Resumo JSON do treino nao encontrado. stderr=${stderr.slice(0, 1000)}`);\n}\n\nconst summary = JSON.parse(summaryLine);\nreturn [{\n json: {\n ...$('Validar Parametros').item.json,\n train_stdout: stdout,\n train_stderr: stderr,\n ...summary\n }\n}];"
},
"id": "b1be229a-6597-4d07-9512-371982e90a2c",
"name": "Extrair Run ID e Metricas",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
480,
40
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict",
"version": 2
},
"conditions": [
{
"id": "status-approved",
"leftValue": "={{ $json.status }}",
"rightValue": "approved",
"operator": {
"type": "string",
"operation": "equals"
}
},
{
"id": "metric-threshold",
"leftValue": "={{ Number($json.metric_value) }}",
"rightValue": "={{ Number($json.threshold) }}",
"operator": {
"type": "number",
"operation": "gte"
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "45f8359b-9b6f-4e29-8ad9-4b08a57972e6",
"name": "Validar Threshold de Qualidade",
"type": "n8n-nodes-base.if",
"typeVersion": 2.2,
"position": [
740,
40
]
},
{
"parameters": {
"command": "=docker compose --profile publish run --rm -e RUN_DIR='artifacts/{{ $json.run_id }}' -e AWS_ACCESS_KEY_ID -e AWS_SECRET_ACCESS_KEY -e AWS_SESSION_TOKEN -e AWS_DEFAULT_REGION -e AWS_REGION -e AWS_ENDPOINT_URL -e AWS_ENDPOINT_URL_S3 -e ARTIFACT_BUCKET -e ARTIFACT_PREFIX -e MLOPS_CREATE_ARTIFACT_BUCKET publish_artifacts"
},
"id": "3af35e02-bccf-47f2-a1f2-3022b8d6d578",
"name": "Publicar Artefatos - Container",
"type": "n8n-nodes-base.executeCommand",
"typeVersion": 1,
"position": [
1020,
-60
]
},
{
"parameters": {
"jsCode": "const stdout = $json.stdout || '';\nconst publishedLine = stdout.split(/\\r?\\n/).map(line => line.trim()).filter(Boolean).reverse().find(line => line.startsWith('{'));\nconst published = publishedLine ? JSON.parse(publishedLine) : {};\nreturn [{\n json: {\n ...$('Extrair Run ID e Metricas').item.json,\n publication: published,\n publication_stdout: stdout,\n publication_stderr: $json.stderr || ''\n }\n}];"
},
"id": "2279646a-9734-4ec9-bd09-f2ff627b4a6d",
"name": "Consolidar Publicacao",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
1280,
-60
]
},
{
"parameters": {
"method": "POST",
"url": "={{ $('Validar Parametros').item.json.api_base_url }}/reload",
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={\"run_id\":\"{{ $('Consolidar Publicacao').item.json.run_id }}\",\"artifact_bucket\":\"{{ $('Consolidar Publicacao').item.json.publication.bucket }}\",\"artifact_prefix\":\"{{ $('Consolidar Publicacao').item.json.publication.prefix }}\"}",
"options": {
"timeout": 30000
},
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "x-api-key",
"value": "={{ $('Validar Parametros').item.json.api_gateway_api_key }}"
}
]
}
},
"id": "7419b202-09d5-49d8-940e-a6a26c87d4da",
"name": "Recarregar Modelo Publicado",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1800,
40
]
},
{
"parameters": {
"jsCode": "const consolidated = $('Consolidar Publicacao').item.json;\nconst reloadResponse = $json;\nreturn [{\n json: {\n execution_id: $execution.id,\n status: 'deployed',\n deploy_blocked: false,\n run_id: consolidated.run_id,\n metric_name: consolidated.metric_name,\n metric_value: consolidated.metric_value,\n threshold: consolidated.threshold,\n artifact_publication: consolidated.publication,\n reload_response: reloadResponse,\n pipeline_started_at: consolidated.pipeline_started_at,\n pipeline_finished_at: new Date().toISOString()\n }\n}];"
},
"id": "317ddc63-b5ed-4d98-afc3-d2645f2bda44",
"name": "Resposta - Sucesso",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
2060,
40
]
},
{
"parameters": {
"jsCode": "return [{\n json: {\n execution_id: $execution.id,\n status: 'rejected',\n deploy_blocked: true,\n reason: 'quality_gate_failed',\n run_id: $json.run_id,\n training_status: $json.status,\n metric_name: $json.metric_name,\n metric_value: $json.metric_value,\n threshold: $json.threshold,\n pipeline_started_at: $json.pipeline_started_at,\n pipeline_finished_at: new Date().toISOString()\n }\n}];"
},
"id": "b9d68117-f0e1-4a6d-8fb3-b1364a19d7cf",
"name": "Resposta - Modelo Rejeitado",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
1020,
180
]
},
{
"parameters": {},
"id": "dd51eef9-88ef-48e5-aa6c-c95d1e7a2214",
"name": "Error Trigger - Capturar Falhas",
"type": "n8n-nodes-base.errorTrigger",
"typeVersion": 1,
"position": [
-660,
700
]
},
{
"parameters": {
"jsCode": "return [{\n json: {\n execution_id: $execution.id,\n status: 'error',\n failed_node: $error.node?.name || 'unknown',\n message: $error.message,\n timestamp: new Date().toISOString()\n }\n}];"
},
"id": "fa3b82c9-60b8-4f64-981a-5222a636c357",
"name": "Registrar Incidente",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
-380,
700
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "artifact-local-only",
"leftValue": "={{ Boolean($json.publication?.local_only) }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "8e5bc6ad-9f5f-4dbd-81a6-15c3775d4d7c",
"name": "Verificar Backend de Artefatos",
"type": "n8n-nodes-base.if",
"typeVersion": 2.2,
"position": [
1540,
-60
]
},
{
"parameters": {
"jsCode": "const consolidated = $json;\nreturn [{\n json: {\n execution_id: $execution.id,\n status: 'published_local_only',\n deploy_blocked: false,\n reload_skipped: true,\n reload_skip_reason: 'artifact_published_to_localstack',\n run_id: consolidated.run_id,\n metric_name: consolidated.metric_name,\n metric_value: consolidated.metric_value,\n threshold: consolidated.threshold,\n artifact_publication: consolidated.publication,\n pipeline_started_at: consolidated.pipeline_started_at,\n pipeline_finished_at: new Date().toISOString()\n }\n}];"
},
"id": "6d2b3bc1-ccef-4ef0-87e1-82e6c4a8220f",
"name": "Resposta - Publicacao Local",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
1800,
-180
]
}
],
"connections": {
"Webhook - Iniciar Pipeline": {
"main": [
[
{
"node": "Preparar Parametros",
"type": "main",
"index": 0
}
]
]
},
"Preparar Parametros": {
"main": [
[
{
"node": "Validar Parametros",
"type": "main",
"index": 0
}
]
]
},
"Validar Parametros": {
"main": [
[
{
"node": "Preparar Dados - Container",
"type": "main",
"index": 0
}
]
]
},
"Preparar Dados - Container": {
"main": [
[
{
"node": "Treinar Modelo - Container",
"type": "main",
"index": 0
}
]
]
},
"Treinar Modelo - Container": {
"main": [
[
{
"node": "Extrair Run ID e Metricas",
"type": "main",
"index": 0
}
]
]
},
"Extrair Run ID e Metricas": {
"main": [
[
{
"node": "Validar Threshold de Qualidade",
"type": "main",
"index": 0
}
]
]
},
"Validar Threshold de Qualidade": {
"main": [
[
{
"node": "Publicar Artefatos - Container",
"type": "main",
"index": 0
}
],
[
{
"node": "Resposta - Modelo Rejeitado",
"type": "main",
"index": 0
}
]
]
},
"Publicar Artefatos - Container": {
"main": [
[
{
"node": "Consolidar Publicacao",
"type": "main",
"index": 0
}
]
]
},
"Consolidar Publicacao": {
"main": [
[
{
"node": "Verificar Backend de Artefatos",
"type": "main",
"index": 0
}
]
]
},
"Recarregar Modelo Publicado": {
"main": [
[
{
"node": "Resposta - Sucesso",
"type": "main",
"index": 0
}
]
]
},
"Error Trigger - Capturar Falhas": {
"main": [
[
{
"node": "Registrar Incidente",
"type": "main",
"index": 0
}
]
]
},
"Verificar Backend de Artefatos": {
"main": [
[
{
"node": "Resposta - Publicacao Local",
"type": "main",
"index": 0
}
],
[
{
"node": "Recarregar Modelo Publicado",
"type": "main",
"index": 0
}
]
]
}
},
"settings": {
"executionOrder": "v1",
"saveDataErrorExecution": "all",
"saveDataSuccessExecution": "all",
"saveManualExecutions": true,
"timezone": "America/Sao_Paulo"
},
"staticData": null,
"tags": [
{
"name": "mlops"
},
{
"name": "error-monitoring"
},
{
"name": "n8n"
}
],
"triggerCount": 2,
"updatedAt": "2026-05-07T00:00:00.000Z",
"versionId": "1"
}
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
MLOps Pipeline EN-PT. Uses executeCommand, httpRequest, errorTrigger. Webhook trigger; 18 nodes.
Source: https://github.com/giuliazc/mlops-neural-machine-translation/blob/e071531509a02b27d5b3b4dd9ae718c8d1377478/n8n.json — original creator credit. Request a take-down →
