This workflow corresponds to n8n.io template #5873 — we link there as the canonical source.
This workflow follows the HTTP Request → n8n recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "XIPHhh3HU6jfTgyC",
"meta": {
"templateCredsSetupCompleted": true
},
"name": "Send N8N Audits and Failed Workflows to InfluxDB",
"tags": [
{
"id": "vfJ7DxaB1BnsVQhe",
"name": "Public",
"createdAt": "2025-06-23T09:52:14.318Z",
"updatedAt": "2025-06-23T09:52:14.318Z"
}
],
"nodes": [
{
"id": "8ed8f8ed-5352-4eb2-a0cf-2dbbc78f2a9a",
"name": "When clicking \u2018Execute workflow\u2019",
"type": "n8n-nodes-base.manualTrigger",
"position": [
-780,
220
],
"parameters": {},
"typeVersion": 1
},
{
"id": "001ca208-f181-4270-be91-e30a316e624b",
"name": "Sticky Note",
"type": "n8n-nodes-base.stickyNote",
"position": [
300,
-120
],
"parameters": {
"width": 1100,
"height": 520,
"content": "## Parse for Influx-understandable data\nInflux sample data sent via CURL is following:\n\ncurl --request POST \\\n\"http://localhost:8086/api/v2/write?org=YOUR_ORG&bucket=YOUR_BUCKET&precision=ns\" \\\n --header \"Authorization: Token YOUR_API_TOKEN\" \\\n --header \"Content-Type: text/plain; charset=utf-8\" \\\n --header \"Accept: application/json\" \\\n --data-binary '\n airSensors,sensor_id=TLM0201 temperature=73.97038159354763,humidity=35.23103248356096,co=0.48445310567793615 1630424257000000000\n airSensors,sensor_id=TLM0202 temperature=75.30007505999716,humidity=35.651929918691714,co=0.5141876544505826 1630424257000000000\n '\n\nWhat this part does, is it formats data into --data-binary that can be sent into influx"
},
"typeVersion": 1
},
{
"id": "e4f3e592-8c71-4c0e-998e-3bb93ee12751",
"name": "Database Audit",
"type": "n8n-nodes-base.n8n",
"position": [
-180,
180
],
"parameters": {
"resource": "audit",
"operation": "generate",
"requestOptions": {},
"additionalOptions": {
"categories": [
"database"
]
}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "c719a748-8048-4471-a560-7abfe1249235",
"name": "Filesystem Audit",
"type": "n8n-nodes-base.n8n",
"position": [
-180,
360
],
"parameters": {
"resource": "audit",
"operation": "generate",
"requestOptions": {},
"additionalOptions": {
"categories": [
"filesystem"
]
}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "d0b36463-ee8d-4455-bffd-0217dacf3f47",
"name": "Instance Audit",
"type": "n8n-nodes-base.n8n",
"position": [
-180,
540
],
"parameters": {
"resource": "audit",
"operation": "generate",
"requestOptions": {},
"additionalOptions": {
"categories": [
"instance"
]
}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "d17b1536-0322-443b-a431-cbb60684e399",
"name": "Nodes Audit",
"type": "n8n-nodes-base.n8n",
"position": [
-180,
720
],
"parameters": {
"resource": "audit",
"operation": "generate",
"requestOptions": {},
"additionalOptions": {
"categories": [
"nodes"
]
}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "a0750d26-f5bf-42e1-bd8b-ceb357d1c331",
"name": "Credentials Audit",
"type": "n8n-nodes-base.n8n",
"position": [
-180,
0
],
"parameters": {
"resource": "audit",
"operation": "generate",
"requestOptions": {},
"additionalOptions": {
"categories": [
"credentials"
]
}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "11e65615-0b5e-4e36-932b-3f2b335ea937",
"name": "Split Report Data",
"type": "n8n-nodes-base.splitOut",
"position": [
440,
200
],
"parameters": {
"include": "selectedOtherFields",
"options": {},
"fieldToSplitOut": "report",
"fieldsToInclude": "risk, report[0].title"
},
"typeVersion": 1
},
{
"id": "55071cff-b94b-4f15-b5ab-42a65ba90ed9",
"name": "Prepare Influx Input Strings",
"type": "n8n-nodes-base.set",
"position": [
700,
200
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "a62768f8-431f-48e7-b2a9-95971d9e1dc1",
"name": "title_key_count",
"type": "string",
"value": "={{ $json.report.title.toLowerCase().replaceAll(\" \",\"_\") }}={{ $json.report.location?.length ?? 0 }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "718a1193-1b98-4def-9a29-a81925d67e06",
"name": "Contactenate with Commas",
"type": "n8n-nodes-base.summarize",
"position": [
960,
200
],
"parameters": {
"options": {},
"fieldsToSummarize": {
"values": [
{
"field": "title_key_count",
"aggregation": "concatenate"
}
]
}
},
"typeVersion": 1.1
},
{
"id": "bf04e182-1028-4e21-930e-8c3097fa060c",
"name": "Pull Report Data and Risk Credentials",
"type": "n8n-nodes-base.set",
"position": [
60,
0
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "de836603-6982-4b43-ae85-440f0852cd74",
"name": "report",
"type": "array",
"value": "={{ $json['Credentials Risk Report'].sections }}"
},
{
"id": "012bd4f1-9877-48fb-b5ab-f8e3e1d81dd3",
"name": "risk",
"type": "string",
"value": "={{ $json['Credentials Risk Report'].risk }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "b502d235-ddc4-49ce-8ae6-fdcfab1ca1a9",
"name": "Pull Report Data and Risk Database",
"type": "n8n-nodes-base.set",
"position": [
60,
180
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "de836603-6982-4b43-ae85-440f0852cd74",
"name": "report",
"type": "array",
"value": "={{ $json['Database Risk Report'].sections }}"
},
{
"id": "012bd4f1-9877-48fb-b5ab-f8e3e1d81dd3",
"name": "risk",
"type": "string",
"value": "={{ $json['Database Risk Report'].risk }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "fe8dfa8a-6363-49a6-808e-1feed4b627d1",
"name": "Pull Report Data and Risk Filesystem",
"type": "n8n-nodes-base.set",
"position": [
60,
360
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "de836603-6982-4b43-ae85-440f0852cd74",
"name": "report",
"type": "array",
"value": "={{ $json['Filesystem Risk Report'].sections }}"
},
{
"id": "012bd4f1-9877-48fb-b5ab-f8e3e1d81dd3",
"name": "risk",
"type": "string",
"value": "={{ $json['Filesystem Risk Report'].risk }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "d47b4d10-3abe-41bc-868e-4b855b9e8052",
"name": "Pull Report Data and Risk Instance",
"type": "n8n-nodes-base.set",
"position": [
60,
540
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "de836603-6982-4b43-ae85-440f0852cd74",
"name": "report",
"type": "array",
"value": "={{ $json['Instance Risk Report'].sections }}"
},
{
"id": "012bd4f1-9877-48fb-b5ab-f8e3e1d81dd3",
"name": "risk",
"type": "string",
"value": "={{ $json['Instance Risk Report'].risk }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "14bb0859-d7ca-4177-a833-94cb4c94990e",
"name": "Pull Report Data and Risk Nodes",
"type": "n8n-nodes-base.set",
"position": [
60,
720
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "de836603-6982-4b43-ae85-440f0852cd74",
"name": "report",
"type": "array",
"value": "={{ $json['Nodes Risk Report'].sections }}"
},
{
"id": "012bd4f1-9877-48fb-b5ab-f8e3e1d81dd3",
"name": "risk",
"type": "string",
"value": "={{ $json['Nodes Risk Report'].risk }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "852bf036-611c-416e-83d5-e926e38bb8ba",
"name": "Sticky Note1",
"type": "n8n-nodes-base.stickyNote",
"position": [
-280,
-120
],
"parameters": {
"color": 7,
"width": 560,
"height": 1020,
"content": "## Get N8N Audits\nGet different type of audits and parse them into format that will be understandable for further processing"
},
"typeVersion": 1
},
{
"id": "127908d3-de5e-443b-a920-47569ea890b0",
"name": "Influx Globals",
"type": "n8n-nodes-base.set",
"position": [
-520,
60
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "c764e57c-9936-48ad-a496-f6c9fc0e89b8",
"name": "influx_url",
"type": "string",
"value": "https://example.com"
},
{
"id": "a92bc5cc-0a87-4dd7-a49d-5c2584eaa57f",
"name": "influx_org",
"type": "string",
"value": "myorg"
},
{
"id": "c2f8fb92-64a5-4993-97ee-8c69a8c9865a",
"name": "influx_bucket",
"type": "string",
"value": "n8n"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "38b364a6-7d0a-4f63-bbd8-d6bab99515a8",
"name": "Sticky Note2",
"type": "n8n-nodes-base.stickyNote",
"position": [
-560,
-120
],
"parameters": {
"color": 4,
"width": 260,
"height": 500,
"content": "## Influx Vars\nYou will need 3 variables:\n- InfluxDB URL\n- Organization\n- Bucket name\nPut it in here"
},
"typeVersion": 1
},
{
"id": "545f2f20-0a55-4960-8455-c4e6323ba198",
"name": "Sticky Note3",
"type": "n8n-nodes-base.stickyNote",
"position": [
-920,
-120
],
"parameters": {
"color": 5,
"width": 340,
"height": 500,
"content": "## Schedule Audits\nAudits don't need to be run often, but I would recommend it to be run on regular basis. This way you can see real data series in InfluxDB. I think that once a day should be enough, but it depends on your N8N usage of course"
},
"typeVersion": 1
},
{
"id": "2beef8e7-7e88-4778-9e54-09dd9c6efca1",
"name": "Once a Day",
"type": "n8n-nodes-base.scheduleTrigger",
"position": [
-780,
60
],
"parameters": {
"rule": {
"interval": [
{
"triggerAtHour": 5
}
]
}
},
"typeVersion": 1.2
},
{
"id": "a3408974-4c32-4900-86cf-111dd3e5f9c6",
"name": "Get Active Workflows",
"type": "n8n-nodes-base.n8n",
"position": [
-200,
-460
],
"parameters": {
"filters": {
"activeWorkflows": true
},
"requestOptions": {}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "ef5c8f0c-07ed-447a-a582-0659fad71972",
"name": "Get Failed Executions",
"type": "n8n-nodes-base.n8n",
"position": [
-200,
-300
],
"parameters": {
"filters": {
"status": "error"
},
"options": {},
"resource": "execution",
"returnAll": true,
"requestOptions": {}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "e842c4bd-a335-4144-b580-c92fc343d804",
"name": "Count Active",
"type": "n8n-nodes-base.summarize",
"position": [
40,
-460
],
"parameters": {
"options": {},
"fieldsToSummarize": {
"values": [
{
"field": "active"
}
]
}
},
"typeVersion": 1.1
},
{
"id": "e0dda14c-6d80-42fe-ae2e-1e79c8b8733b",
"name": "Count Failed",
"type": "n8n-nodes-base.summarize",
"position": [
40,
-300
],
"parameters": {
"options": {},
"fieldsToSummarize": {
"values": [
{
"field": "id"
}
]
}
},
"typeVersion": 1.1
},
{
"id": "a2189f25-d741-434b-bf1d-acf4567239d2",
"name": "Merge Into One Reporting Line",
"type": "n8n-nodes-base.merge",
"position": [
300,
-440
],
"parameters": {
"mode": "combine",
"options": {},
"combineBy": "combineByPosition"
},
"typeVersion": 3.2
},
{
"id": "104c9d98-1d76-44c6-962e-433761e8a14f",
"name": "Adjust Field Name",
"type": "n8n-nodes-base.set",
"position": [
540,
-440
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "a7e43bc0-7e7a-4095-855f-3d9c885180c6",
"name": "title_key_count",
"type": "string",
"value": "=active_workflows={{ $json.count_active }},failed_executions={{ $json.count_id }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "006dbe41-daab-46b4-bdf7-17af73878f80",
"name": "Send Workflows and Fails to InfluxDB",
"type": "n8n-nodes-base.httpRequest",
"position": [
800,
-440
],
"parameters": {
"url": "={{ $('Influx Globals').item.json.influx_url }}/api/v2/write?org={{ $('Influx Globals').item.json.influx_org }}&bucket={{ $('Influx Globals').item.json.influx_bucket }}&precision=ms",
"body": "=audit,operational=workflows_and_failed {{ $json.title_key_count }} {{ $now.toMillis() }}",
"method": "POST",
"options": {},
"sendBody": true,
"contentType": "raw",
"sendHeaders": true,
"authentication": "genericCredentialType",
"rawContentType": "text/plain; charset=utf-8",
"genericAuthType": "httpHeaderAuth",
"headerParameters": {
"parameters": [
{
"name": "Accept",
"value": "application/json"
}
]
}
},
"credentials": {
"httpHeaderAuth": {
"name": "<your credential>"
}
},
"typeVersion": 4.2
},
{
"id": "260f51c8-f69b-4b09-96ee-23a9c83b5ac3",
"name": "Send Audit to InfluxDB",
"type": "n8n-nodes-base.httpRequest",
"position": [
1200,
200
],
"parameters": {
"url": "={{ $('Influx Globals').item.json.influx_url }}/api/v2/write?org={{ $('Influx Globals').item.json.influx_org }}&bucket={{ $('Influx Globals').item.json.influx_bucket }}&precision=ms",
"body": "=audit,risk={{ $('Split Report Data').first().json.risk }} {{ $json.concatenated_title_key_count }} {{ $now.toMillis() }}",
"method": "POST",
"options": {},
"sendBody": true,
"contentType": "raw",
"sendHeaders": true,
"authentication": "genericCredentialType",
"rawContentType": "text/plain; charset=utf-8",
"genericAuthType": "httpHeaderAuth",
"headerParameters": {
"parameters": [
{
"name": "Accept",
"value": "application/json"
}
]
}
},
"credentials": {
"httpHeaderAuth": {
"name": "<your credential>"
}
},
"typeVersion": 4.2
},
{
"id": "4830f6e4-efbc-4476-a515-1c4afaf6d5ec",
"name": "Sticky Note4",
"type": "n8n-nodes-base.stickyNote",
"position": [
-280,
-580
],
"parameters": {
"color": 3,
"width": 1280,
"height": 440,
"content": "## Active Worfklows and Failed Executions\nIf you are feeling advanterous, you can also send data about workflows and executions to Influx. Since there can be a lot of executions, keep in mind to rather count one group (\"failed\") in this example"
},
"typeVersion": 1
}
],
"active": false,
"settings": {
"executionOrder": "v1"
},
"versionId": "ca8f70df-803e-4b9b-921d-2f2e65a961bb",
"connections": {
"Once a Day": {
"main": [
[
{
"node": "Influx Globals",
"type": "main",
"index": 0
}
]
]
},
"Nodes Audit": {
"main": [
[
{
"node": "Pull Report Data and Risk Nodes",
"type": "main",
"index": 0
}
]
]
},
"Count Active": {
"main": [
[
{
"node": "Merge Into One Reporting Line",
"type": "main",
"index": 0
}
]
]
},
"Count Failed": {
"main": [
[
{
"node": "Merge Into One Reporting Line",
"type": "main",
"index": 1
}
]
]
},
"Database Audit": {
"main": [
[
{
"node": "Pull Report Data and Risk Database",
"type": "main",
"index": 0
}
]
]
},
"Influx Globals": {
"main": [
[
{
"node": "Credentials Audit",
"type": "main",
"index": 0
},
{
"node": "Nodes Audit",
"type": "main",
"index": 0
},
{
"node": "Database Audit",
"type": "main",
"index": 0
},
{
"node": "Filesystem Audit",
"type": "main",
"index": 0
},
{
"node": "Instance Audit",
"type": "main",
"index": 0
},
{
"node": "Get Failed Executions",
"type": "main",
"index": 0
},
{
"node": "Get Active Workflows",
"type": "main",
"index": 0
}
]
]
},
"Instance Audit": {
"main": [
[
{
"node": "Pull Report Data and Risk Instance",
"type": "main",
"index": 0
}
]
]
},
"Filesystem Audit": {
"main": [
[
{
"node": "Pull Report Data and Risk Filesystem",
"type": "main",
"index": 0
}
]
]
},
"Adjust Field Name": {
"main": [
[
{
"node": "Send Workflows and Fails to InfluxDB",
"type": "main",
"index": 0
}
]
]
},
"Credentials Audit": {
"main": [
[
{
"node": "Pull Report Data and Risk Credentials",
"type": "main",
"index": 0
}
]
]
},
"Split Report Data": {
"main": [
[
{
"node": "Prepare Influx Input Strings",
"type": "main",
"index": 0
}
]
]
},
"Get Active Workflows": {
"main": [
[
{
"node": "Count Active",
"type": "main",
"index": 0
}
]
]
},
"Get Failed Executions": {
"main": [
[
{
"node": "Count Failed",
"type": "main",
"index": 0
}
]
]
},
"Send Audit to InfluxDB": {
"main": [
[]
]
},
"Contactenate with Commas": {
"main": [
[
{
"node": "Send Audit to InfluxDB",
"type": "main",
"index": 0
}
]
]
},
"Prepare Influx Input Strings": {
"main": [
[
{
"node": "Contactenate with Commas",
"type": "main",
"index": 0
}
]
]
},
"Merge Into One Reporting Line": {
"main": [
[
{
"node": "Adjust Field Name",
"type": "main",
"index": 0
}
]
]
},
"Pull Report Data and Risk Nodes": {
"main": [
[
{
"node": "Split Report Data",
"type": "main",
"index": 0
}
]
]
},
"Pull Report Data and Risk Database": {
"main": [
[
{
"node": "Split Report Data",
"type": "main",
"index": 0
}
]
]
},
"Pull Report Data and Risk Instance": {
"main": [
[
{
"node": "Split Report Data",
"type": "main",
"index": 0
}
]
]
},
"Pull Report Data and Risk Filesystem": {
"main": [
[
{
"node": "Split Report Data",
"type": "main",
"index": 0
}
]
]
},
"When clicking \u2018Execute workflow\u2019": {
"main": [
[
{
"node": "Influx Globals",
"type": "main",
"index": 0
}
]
]
},
"Pull Report Data and Risk Credentials": {
"main": [
[
{
"node": "Split Report Data",
"type": "main",
"index": 0
}
]
]
}
}
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
httpHeaderAuthn8nApi
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
This workflow is for anyone who is using N8N. It's especially helpful if you are a DevOps and your N8N instance is self hosted. If you carea lot about security and number of failed executions and at the same time you are using InfluxDB to monitor status of your systems, this…
Source: https://n8n.io/workflows/5873/ — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
This n8n workflow monitors significant register, financial, and news-related events for German companies. It takes a list of companies (for example from a CRM or lead list), resolves them via the Impl
HTTP Request
[](https://xqus.relezy.com/haveibeenpwnedcom-breaches) Security professionals Developers Individuals interested in data breach awareness Automated monitoring for new breaches Proactive identity protec
HTTP Request, Read Write File
Stay ahead of credential expirations by automatically detecting Entra ID application client secrets and certificates that are about to expire, and sending a neatly formatted email report.
HTTP Request, Email Send
This n8n template shows how to upload a file in your Google Drive desired folder, compress it with the iLovePDF tool and move the compressed file to another folder.
Google Drive, Google Drive Trigger, HTTP Request
This n8n workflow automates the process of collecting sign-in IP addresses from SaaS Alerts over the past 24 hours and emailing the results using SMTP2Go. Designed for security teams, IT administrator
HTTP Request, Move Binary Data, Form Trigger
