Tilda Order Processing to Google Sheets & Telegram

The workflow JSON

Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →

{
  "name": "01_order_processing_tilda",
  "nodes": [
    {
      "parameters": {
        "content": "## Earning",
        "height": 256,
        "width": 1056,
        "color": 4
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        416,
        448
      ],
      "typeVersion": 1,
      "id": "06cd60f6-0ff3-4e19-934f-66289c818596",
      "name": "Sticky Note"
    },
    {
      "parameters": {
        "content": "## Spending",
        "height": 240,
        "width": 1056,
        "color": 3
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        416,
        0
      ],
      "typeVersion": 1,
      "id": "118a2be3-28eb-4a19-b4d2-f9f306808366",
      "name": "Sticky Note1"
    },
    {
      "parameters": {
        "conditions": {
          "options": {
            "caseSensitive": true,
            "leftValue": "",
            "typeValidation": "strict",
            "version": 3
          },
          "conditions": [
            {
              "id": "6da41e92-2b4b-44f7-8b1c-cd533e774999",
              "leftValue": "={{ $json.order_id }}",
              "rightValue": "",
              "operator": {
                "type": "string",
                "operation": "notEmpty",
                "singleValue": true
              }
            }
          ],
          "combinator": "and"
        },
        "options": {}
      },
      "type": "n8n-nodes-base.if",
      "typeVersion": 2.3,
      "position": [
        -496,
        176
      ],
      "id": "912fa65d-a2c6-42cc-8bee-8af33a5759ea",
      "name": "Check Duplicate"
    },
    {
      "parameters": {
        "documentId": {
          "__rl": true,
          "value": "1IH1j7tDItMlfPUjawuXSywX83fMQ_6m9ToIN6exWiMk",
          "mode": "list",
          "cachedResultName": "n8n_execution_logs",
          "cachedResultUrl": "https://docs.google.com/spreadsheets/d/1IH1j7tDItMlfPUjawuXSywX83fMQ_6m9ToIN6exWiMk/edit?usp=drivesdk"
        },
        "sheetName": {
          "__rl": true,
          "value": "gid=0",
          "mode": "list",
          "cachedResultName": "logs",
          "cachedResultUrl": "https://docs.google.com/spreadsheets/d/1IH1j7tDItMlfPUjawuXSywX83fMQ_6m9ToIN6exWiMk/edit#gid=0"
        },
        "filtersUI": {
          "values": [
            {
              "lookupColumn": "order_id",
              "lookupValue": "={{ $json.body.payment.orderid }}"
            }
          ]
        },
        "options": {}
      },
      "type": "n8n-nodes-base.googleSheets",
      "typeVersion": 4.7,
      "position": [
        -704,
        176
      ],
      "id": "c24315a0-4372-48bb-b388-be99539c52b8",
      "name": "Search Existing Order",
      "alwaysOutputData": true,
      "credentials": {
        "googleSheetsOAuth2Api": {
          "name": "<your credential>"
        }
      }
    },
    {
      "parameters": {
        "httpMethod": "POST",
        "path": "tilda-order",
        "options": {}
      },
      "type": "n8n-nodes-base.webhook",
      "typeVersion": 2.1,
      "position": [
        -912,
        176
      ],
      "id": "43ee4582-bfd5-4682-acf3-ccc15cd863a3",
      "name": "Receive Tilda Order"
    },
    {
      "parameters": {
        "method": "POST",
        "url": "https://api-ru.iiko.services/api/1/access_token",
        "sendBody": true,
        "bodyParameters": {
          "parameters": [
            {
              "name": "apiLogin",
              "value": "my_api"
            }
          ]
        },
        "options": {}
      },
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.3,
      "position": [
        -256,
        192
      ],
      "id": "c9137c48-1663-461d-a637-1dec5bca776c",
      "name": "iiko Auth (Get Token)",
      "retryOnFail": true,
      "waitBetweenTries": 3000
    },
    {
      "parameters": {
        "method": "POST",
        "url": "https://api-ru.iiko.services/api/1/loyalty/iiko/customer/create_or_update",
        "sendHeaders": true,
        "headerParameters": {
          "parameters": [
            {
              "name": "Authorization",
              "value": "=Bearer {{ $('iiko Auth (Get Token)').item.json.token }}"
            }
          ]
        },
        "sendBody": true,
        "specifyBody": "json",
        "jsonBody": "={\n  \"organizationId\": \"org_id\",\n  \"phone\": \"+7{{ ($('Receive Tilda Order').item.json.body.phone || $('Receive Tilda Order').item.json.body.Phone).toString().replace(/\\D/g, '').slice(-10) }}\",\n  \"name\": \"{{ $('Receive Tilda Order').item.json.body.name }}\"\n}",
        "options": {}
      },
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.3,
      "position": [
        -16,
        192
      ],
      "id": "fd2fe9f3-cbc3-482a-9a6a-d0befff6e7e9",
      "name": "Sync Customer Profile",
      "retryOnFail": true,
      "waitBetweenTries": 3000
    },
    {
      "parameters": {
        "conditions": {
          "options": {
            "caseSensitive": true,
            "leftValue": "",
            "typeValidation": "strict",
            "version": 2
          },
          "conditions": [
            {
              "id": "df188b1e-3ae0-4c35-b089-012da4709064",
              "leftValue": "={{ $('Receive Tilda Order').item.json.body.spend_bonus }}",
              "rightValue": "yes",
              "operator": {
                "type": "string",
                "operation": "equals"
              }
            }
          ],
          "combinator": "and"
        },
        "options": {}
      },
      "type": "n8n-nodes-base.if",
      "typeVersion": 2.2,
      "position": [
        192,
        192
      ],
      "id": "85732a3d-7d82-42bf-a0cd-7dadf2830e20",
      "name": "Router: Spend or Earn"
    },
    {
      "parameters": {
        "method": "POST",
        "url": "https://api-ru.iiko.services/api/1/loyalty/iiko/customer/info",
        "sendHeaders": true,
        "headerParameters": {
          "parameters": [
            {
              "name": "Authorization",
              "value": "=Bearer {{ $('iiko Auth (Get Token)').item.json.token }}"
            }
          ]
        },
        "sendBody": true,
        "specifyBody": "json",
        "jsonBody": "={\n  \"organizationId\": \"org_id\",\n  \"phone\": \"+7{{ ($('Receive Tilda Order').item.json.body.phone || $('Receive Tilda Order').item.json.body.Phone).toString().replace(/\\D/g, '').slice(-10) }}\",\n  \"type\": \"phone\"\n}",
        "options": {}
      },
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.3,
      "position": [
        464,
        64
      ],
      "id": "aac6cc25-4657-4a5c-9107-6c24e0dd84e1",
      "name": "Get Current Balance",
      "retryOnFail": true,
      "waitBetweenTries": 3000
    },
    {
      "parameters": {
        "method": "POST",
        "url": "https://api-ru.iiko.services/api/1/loyalty/iiko/customer/wallet/chargeoff",
        "sendHeaders": true,
        "headerParameters": {
          "parameters": [
            {
              "name": "Authorization",
              "value": "=Bearer {{ $('iiko Auth (Get Token)').item.json.token }}"
            }
          ]
        },
        "sendBody": true,
        "specifyBody": "json",
        "jsonBody": "={\n  \"organizationId\": \"org_id\",\n  \"customerId\": \"{{ $json.id }}\",\n  \"walletId\": \"my_wallet_id\",\n  \"sum\": {{ Math.min($json.walletBalances[0].balance, $('Receive Tilda Order').item.json.body.payment.products.reduce((sum, p) => sum + p.amount, 0)) }},\n  \"comment\": \"Bonus write-off\"\n}",
        "options": {}
      },
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.3,
      "position": [
        672,
        64
      ],
      "id": "224bfde1-900f-46f2-88df-b1b084c465d3",
      "name": "Withdraw Bonuses",
      "retryOnFail": true,
      "waitBetweenTries": 3000
    },
    {
      "parameters": {
        "method": "POST",
        "url": "https://api-ru.iiko.services/api/1/loyalty/iiko/customer/wallet/topup",
        "sendHeaders": true,
        "headerParameters": {
          "parameters": [
            {
              "name": "Authorization",
              "value": "=Bearer {{ $('iiko Auth (Get Token)').item.json.token }}"
            }
          ]
        },
        "sendBody": true,
        "specifyBody": "json",
        "jsonBody": "={\n  \"organizationId\": \"org_id\",\n  \"customerId\": \"{{ $('Get Current Balance').item.json.id }}\",\n  \"walletId\": \"my_id\",\n  \"sum\": {{ \nMath.round(($('Receive Tilda Order').item.json.body.payment.amount - Math.min($('Get Current Balance').item.json.walletBalances[0].balance, $('Receive Tilda Order').item.json.body.payment.products.reduce((sum, p) => sum + p.amount, 0))) * 0.05 ) }},\n  \"comment\": \"Bonuses for orders in the online store\"\n}",
        "options": {}
      },
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.3,
      "position": [
        880,
        64
      ],
      "id": "2ebbc37a-cce0-418a-8daa-195ee11499e2",
      "name": "Update Local Balance",
      "retryOnFail": true,
      "waitBetweenTries": 3000
    },
    {
      "parameters": {
        "jsCode": "// 1. Extract initial data\nconst walletBalance = $('Get Current Balance').item.json.walletBalances[0].balance;\nconst products = $('Receive Tilda Order').item.json.body.payment.products;\n// Parse order total to number (ensure type safety)\nconst orderTotal = parseInt($('Receive Tilda Order').item.json.body.payment.amount);\n\n// 2. Calculate total product sum (to check write-off limits)\nconst productsSum = products.reduce((sum, p) => sum + parseInt(p.amount), 0);\n\n// 3. Calculate redeemed amount (min of wallet balance vs product total)\nconst spentBonus = Math.min(walletBalance, productsSum);\n\n// 4. Calculate remaining amount to pay (Cash/Card)\nconst finalPay = orderTotal - spentBonus;\n\n// 5. Calculate new accrual on the remaining amount (5%)\nconst addedBonus = Math.round(finalPay * 0.05);\n\n// Return calculated figures for next steps\nreturn {\n  json: {\n    added: addedBonus,   // How much was accrued?\n    spent: spentBonus,   // How much was written off?\n    pay: finalPay        // Total to be paid\n  }\n}"
      },
      "type": "n8n-nodes-base.code",
      "typeVersion": 2,
      "position": [
        1088,
        64
      ],
      "id": "1b144579-9a32-42c6-b9e9-286dcf449cb3",
      "name": "Format Admin Message"
    },
    {
      "parameters": {
        "jsCode": "// 1. We get the order amount from Tilda\nconst orderTotal = parseInt($('Receive Tilda Order').item.json.body.payment.amount);\n\n// 2. We calculate 5% (round up to the nearest whole number)\nconst bonusToAdd = Math.round(orderTotal * 0.05);\n\n// 3. Return calculated bonus object\nreturn {\n  json: {\n    bonus: bonusToAdd\n  }\n}"
      },
      "type": "n8n-nodes-base.code",
      "typeVersion": 2,
      "position": [
        464,
        512
      ],
      "id": "af45c33e-af74-4932-9de1-fc18eeea59c7",
      "name": "Calc Bonus Amount"
    },
    {
      "parameters": {
        "method": "POST",
        "url": "https://api-ru.iiko.services/api/1/loyalty/iiko/customer/wallet/topup",
        "sendHeaders": true,
        "headerParameters": {
          "parameters": [
            {
              "name": "Authorization",
              "value": "=Bearer {{ $('iiko Auth (Get Token)').item.json.token }}"
            }
          ]
        },
        "sendBody": true,
        "specifyBody": "json",
        "jsonBody": "={\n  \"organizationId\": \"org_id\",\n  \"customerId\": \"{{ $('Router: Spend or Earn').item.json.id }}\",\n  \"walletId\": \"my_id\",\n  \"sum\": {{ $json.bonus }},\n  \"comment\": \"Bonuses for ordering on the website\"\n}",
        "options": {}
      },
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.3,
      "position": [
        672,
        512
      ],
      "id": "b54b6a26-5a0d-4390-bb0d-09f2b08cce8c",
      "name": "Accrue Bonuses",
      "retryOnFail": true,
      "waitBetweenTries": 3000
    },
    {
      "parameters": {
        "operation": "append",
        "documentId": {
          "__rl": true,
          "value": "1IH1j7tDItMlfPUjawuXSywX83fMQ_6m9ToIN6exWiMk",
          "mode": "list",
          "cachedResultName": "n8n_execution_logs",
          "cachedResultUrl": "https://docs.google.com/spreadsheets/d/1IH1j7tDItMlfPUjawuXSywX83fMQ_6m9ToIN6exWiMk/edit?usp=drivesdk"
        },
        "sheetName": {
          "__rl": true,
          "value": "gid=0",
          "mode": "list",
          "cachedResultName": "logs",
          "cachedResultUrl": "https://docs.google.com/spreadsheets/d/1IH1j7tDItMlfPUjawuXSywX83fMQ_6m9ToIN6exWiMk/edit#gid=0"
        },
        "columns": {
          "mappingMode": "defineBelow",
          "value": {
            "date": "={{ $now }}",
            "order_id": "={{ $('Receive Tilda Order').item.json.body.payment.orderid }}",
            "status": "Success"
          },
          "matchingColumns": [],
          "schema": [
            {
              "id": "date",
              "displayName": "date",
              "required": false,
              "defaultMatch": false,
              "display": true,
              "type": "string",
              "canBeUsedToMatch": true
            },
            {
              "id": "order_id",
              "displayName": "order_id",
              "required": false,
              "defaultMatch": false,
              "display": true,
              "type": "string",
              "canBeUsedToMatch": true
            },
            {
              "id": "status",
              "displayName": "status",
              "required": false,
              "defaultMatch": false,
              "display": true,
              "type": "string",
              "canBeUsedToMatch": true
            }
          ],
          "attemptToConvertTypes": false,
          "convertFieldsToString": false
        },
        "options": {}
      },
      "type": "n8n-nodes-base.googleSheets",
      "typeVersion": 4.7,
      "position": [
        1296,
        512
      ],
      "id": "303c9cc1-3b96-4bc0-a5d3-d2715b171a91",
      "name": "Log Transaction to DB",
      "credentials": {
        "googleSheetsOAuth2Api": {
          "name": "<your credential>"
        }
      }
    },
    {
      "parameters": {
        "chatId": "admin_id",
        "text": "=<b>\u041d\u041e\u0412\u042b\u0419 \u0417\u0410\u041a\u0410\u0417 \u0421 \u0418\u041d\u0422\u0415\u0420\u041d\u0415\u0422-\u041c\u0410\u0413\u0410\u0417\u0418\u041d\u0410 \n\u0421\u041e \u0421\u041f\u0418\u0421\u0410\u041d\u0418\u0415\u041c \u0411\u041e\u041d\u0423\u0421\u041e\u0412\n#{{ $('Receive Tilda Order').item.json.body.payment.orderid }}</b>\n\n<b>\u0421\u043f\u043e\u0441\u043e\u0431 \u043e\u043f\u043b\u0430\u0442\u044b:</b> {{ $('Receive Tilda Order').item.json.body.paymentsystem == 'banktransfer' ? '\u041f\u043e Kaspi' : '\u041d\u0430\u043b\u0438\u0447\u043d\u044b\u043c\u0438 \u043f\u0440\u0438 \u043f\u043e\u043b\u0443\u0447\u0435\u043d\u0438\u0438' }}\n\n<b>\u0418\u043c\u044f:</b> {{ $('Receive Tilda Order').item.json.body.name }}\n<b>\u0422\u0435\u043b\u0435\u0444\u043e\u043d:</b> +{{ ($('Receive Tilda Order').item.json.body.phone || $('Receive Tilda Order').item.json.body.Phone).replace(/\\D/g, '') }}\n<b>\u0410\u0434\u0440\u0435\u0441:</b> {{ $('Receive Tilda Order').item.json.body.address }}\n<b>\u0414\u0435\u043d\u044c \u0434\u043e\u0441\u0442\u0430\u0432\u043a\u0438:</b> {{ $('Receive Tilda Order').item.json.body.den_dostavki }} ({{ $('Receive Tilda Order').item.json.body.vremya_dostavki_c }} - {{ $('Receive Tilda Order').item.json.body.vremya_dostavki_do }})\n\n<b>\u0417\u0410\u041a\u0410\u0417:</b>\n{{ $('Receive Tilda Order').item.json.body.payment.products.map(p => `${p.name} ${p.options ? `\n${p.options[0].option}: ${p.options[0].variant}` : ''}\n${p.quantity} \u0448\u0442 \u0445 ${p.price.toLocaleString('ru-RU')} = ${p.amount.toLocaleString('ru-RU')} \u20b8`).join('\\n\\n') }}\n{{ $('Receive Tilda Order').item.json.body.commentary ? `\n<b>\u041a\u043e\u043c\u043c\u0435\u043d\u0442\u0430\u0440\u0438\u0439:</b> ${$('Receive Tilda Order').item.json.body.commentary}` : '' }}\n{{ $('Receive Tilda Order').item.json.body.podpiska ? `\n<b>\u041a\u043b\u0438\u0435\u043d\u0442 \u0445\u043e\u0447\u0435\u0442 \u043f\u043e\u0434\u043f\u0438\u0441\u043a\u0443 \u043d\u0430 \u043a\u043e\u0444\u0435!</b>` : '' }}\n\u2500\u2500\u2500\u2500\u2500\u2500\u2500\u2500\n<b>\u0421\u0423\u041c\u041c\u0410 \u0417\u0410\u041a\u0410\u0417\u0410:</b> {{ parseInt($('Receive Tilda Order').item.json.body.payment.amount).toLocaleString('ru-RU') }} \u20b8\n\n<b>\u0411\u041e\u041d\u0423\u0421\u042b:</b>\n\u0421\u043f\u0438\u0441\u0430\u043d\u043e: -{{ $json.spent.toLocaleString('ru-RU') }}\n\u041d\u0430\u0447\u0438\u0441\u043b\u0435\u043d\u043e \u0437\u0430 \u043d\u043e\u0432\u044b\u0439 \u0437\u0430\u043a\u0430\u0437: +{{ $json.added.toLocaleString('ru-RU') }}\n\n<b>\u0418\u0422\u041e\u0413\u041e \u041a \u041e\u041f\u041b\u0410\u0422\u0415: {{ $json.pay.toLocaleString('ru-RU') }} \u20b8</b>",
        "replyMarkup": "inlineKeyboard",
        "inlineKeyboard": {
          "rows": [
            {
              "row": {
                "buttons": [
                  {
                    "text": "\u274c Order cancellation",
                    "additionalFields": {
                      "callback_data": "=undo_mix|{{ $('Receive Tilda Order').item.json.body.phone.replace(/\\D/g, '') }}|{{ $('Format Admin Message').item.json.spent }}|{{ $('Format Admin Message').item.json.added }}"
                    }
                  }
                ]
              }
            }
          ]
        },
        "additionalFields": {
          "appendAttribution": false,
          "parse_mode": "HTML"
        }
      },
      "type": "n8n-nodes-base.telegram",
      "typeVersion": 1.2,
      "position": [
        1280,
        64
      ],
      "id": "38efb35a-926b-4a3f-a05e-f20979fd499e",
      "name": "Notify Admin (Spending) RU",
      "credentials": {
        "telegramApi": {
          "name": "<your credential>"
        }
      }
    },
    {
      "parameters": {
        "chatId": "admin_id",
        "text": "=<b>\u041d\u041e\u0412\u042b\u0419 \u0417\u0410\u041a\u0410\u0417 \u0421 \u0418\u041d\u0422\u0415\u0420\u041d\u0415\u0422-\u041c\u0410\u0413\u0410\u0417\u0418\u041d\u0410 \n#{{ $('Receive Tilda Order').item.json.body.payment.orderid }}</b>\n\n<b>\u0421\u043f\u043e\u0441\u043e\u0431 \u043e\u043f\u043b\u0430\u0442\u044b:</b> {{ $('Receive Tilda Order').item.json.body.paymentsystem == 'banktransfer' ? '\u041f\u043e Kaspi' : '\u041d\u0430\u043b\u0438\u0447\u043d\u044b\u043c\u0438 \u043f\u0440\u0438 \u043f\u043e\u043b\u0443\u0447\u0435\u043d\u0438\u0438' }}\n\n<b>\u0418\u043c\u044f:</b> {{ $('Receive Tilda Order').item.json.body.name }}\n<b>\u0422\u0435\u043b\u0435\u0444\u043e\u043d:</b> +{{ ($('Receive Tilda Order').item.json.body.phone || $('Receive Tilda Order').item.json.body.Phone).replace(/\\D/g, '') }}\n<b>\u0410\u0434\u0440\u0435\u0441:</b> {{ $('Receive Tilda Order').item.json.body.address }}\n<b>\u0414\u0435\u043d\u044c \u0434\u043e\u0441\u0442\u0430\u0432\u043a\u0438:</b> {{ $('Receive Tilda Order').item.json.body.den_dostavki }} ({{ $('Receive Tilda Order').item.json.body.vremya_dostavki_c }} - {{ $('Receive Tilda Order').item.json.body.vremya_dostavki_do }})\n\n<b>\u0417\u0410\u041a\u0410\u0417:</b>\n{{ $('Receive Tilda Order').item.json.body.payment.products.map(p => `${p.name} ${p.options ? `\n${p.options[0].option}: ${p.options[0].variant}` : ''}\n${p.quantity} \u0448\u0442 \u0445 ${p.price.toLocaleString('ru-RU')} = ${p.amount.toLocaleString('ru-RU')} \u20b8`).join('\\n\\n') }}\n{{ $('Receive Tilda Order').item.json.body.commentary ? `\n<b>\u041a\u043e\u043c\u043c\u0435\u043d\u0442\u0430\u0440\u0438\u0439:</b> ${$('Receive Tilda Order').item.json.body.commentary}` : '' }}\n{{ $('Receive Tilda Order').item.json.body.podpiska ? `\n<b>\u041a\u043b\u0438\u0435\u043d\u0442 \u0445\u043e\u0447\u0435\u0442 \u043f\u043e\u0434\u043f\u0438\u0441\u043a\u0443 \u043d\u0430 \u043a\u043e\u0444\u0435!</b>` : '' }}\n\n\u2500\u2500\u2500\u2500\u2500\u2500\u2500\u2500\u2500\n<b>\u0421\u0423\u041c\u041c\u0410: {{ parseInt($('Receive Tilda Order').item.json.body.payment.amount).toLocaleString('ru-RU') }} \u20b8</b>\n\n<b>\u0411\u041e\u041d\u0423\u0421\u042b:</b>\n\u041d\u0430\u0447\u0438\u0441\u043b\u0435\u043d\u043e: +{{ $('Calc Bonus Amount').item.json.bonus.toLocaleString('ru-RU') }} \u0431\u043e\u043d\u0443\u0441\u043e\u0432",
        "replyMarkup": "inlineKeyboard",
        "inlineKeyboard": {
          "rows": [
            {
              "row": {
                "buttons": [
                  {
                    "text": "=\u274c Order cancellation",
                    "additionalFields": {
                      "callback_data": "=undo_add|{{ ($('Receive Tilda Order').item.json.body.phone || $('Receive Tilda Order').item.json.body.Phone).toString().replace(/\\D/g, '').slice(-10) }}|{{ $('Calc Bonus Amount').item.json.bonus }}"
                    }
                  }
                ]
              }
            }
          ]
        },
        "additionalFields": {
          "appendAttribution": false,
          "parse_mode": "HTML"
        }
      },
      "type": "n8n-nodes-base.telegram",
      "typeVersion": 1.2,
      "position": [
        880,
        512
      ],
      "id": "ac142b41-f69a-440d-a106-d4af5bda3e50",
      "name": "Notify Admin (Earning) RU",
      "credentials": {
        "telegramApi": {
          "name": "<your credential>"
        }
      }
    },
    {
      "parameters": {
        "method": "POST",
        "url": "https://7105.api.greenapi.com/waInstance****/SendMessage/******",
        "sendBody": true,
        "specifyBody": "json",
        "jsonBody": "={\n  \"chatId\": \"{{ $('Receive Tilda Order').item.json.body.phone.replace(/\\D/g, '') }}@c.us\",\n  \"message\": \"\u2615\ufe0f *\u0412\u0430\u0448 \u0437\u0430\u043a\u0430\u0437 \u2116{{ $('Receive Tilda Order').item.json.body.payment.orderid }} \u043f\u0440\u0438\u043d\u044f\u0442!*\\n\\n\n\ud83d\udcc5 \u0414\u043e\u0441\u0442\u0430\u0432\u043a\u0430: {{ $('Receive Tilda Order').item.json.body.den_dostavki }} ({{ $('Receive Tilda Order').item.json.body.vremya_dostavki_c }} - {{ $('Receive Tilda Order').item.json.body.vremya_dostavki_do }})\\n\ud83d\udccd \u0410\u0434\u0440\u0435\u0441: {{ $('Receive Tilda Order').item.json.body.address }}\\n\\n\n\ud83d\uded2 *\u0421\u043e\u0441\u0442\u0430\u0432 \u0437\u0430\u043a\u0430\u0437\u0430:*\\n{{ $('Receive Tilda Order').item.json.body.payment.products.map(p => `- *${p.name}* (${p.quantity} \u0448\u0442)${p.options ? '\\n  ' + p.options.map(o => o.variant).join(', ') : ''}`).join('\\n\\n') }}\\n\\n{{ $('Receive Tilda Order').item.json.body.podpiska ? \n'\ud83d\udd04 *\u0412\u044b \u043e\u0444\u043e\u0440\u043c\u0438\u043b\u0438 \u043f\u043e\u0434\u043f\u0438\u0441\u043a\u0443 \u043d\u0430 \u043a\u043e\u0444\u0435!*' : '' }}\\n\\n\ud83d\udcb0 *\u0421\u0443\u043c\u043c\u0430: {{ parseInt($('Receive Tilda Order').item.json.body.payment.amount).toLocaleString('ru-RU') }} \u20b8*\\n\n\ud83d\udcb3 \u041e\u043f\u043b\u0430\u0442\u0430: {{ $('Receive Tilda Order').item.json.body.paymentsystem == 'banktransfer' ? 'Kaspi' : '\u041d\u0430\u043b\u0438\u0447\u043d\u044b\u0435' }}\\n\\n\n\ud83c\udf81 *\u0411\u041e\u041d\u0423\u0421\u042b:*\\n{{ $('Calc Bonus Amount').item.json.bonus > 0 ? \n`\u2705 \u041d\u0430\u0447\u0438\u0441\u043b\u0435\u043d\u043e: ${$('Calc Bonus Amount').item.json.bonus} BONUS` : '\u0411\u043e\u043d\u0443\u0441\u044b \u043d\u0435 \u043d\u0430\u0447\u0438\u0441\u043b\u0435\u043d\u044b' }}\\n\\n\u041c\u044b \u0443\u0436\u0435 \u043d\u0430\u0447\u0430\u043b\u0438 \u0433\u043e\u0442\u043e\u0432\u0438\u0442\u044c \u0432\u0430\u0448 \u043a\u043e\u0444\u0435! \u0416\u0434\u0438\u0442\u0435 \u0437\u0432\u043e\u043d\u043a\u0430 \u043a\u0443\u0440\u044c\u0435\u0440\u0430.\"\n}",
        "options": {}
      },
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.3,
      "position": [
        1088,
        512
      ],
      "id": "6afc47ed-b637-4797-b273-17c88f4fe0d6",
      "name": "Notify Customer (WhatsApp) RU",
      "retryOnFail": true,
      "waitBetweenTries": 3000
    },
    {
      "parameters": {
        "content": "Formats admin notification with order details and payment method.",
        "height": 80,
        "width": 320
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        864,
        736
      ],
      "typeVersion": 1,
      "id": "94d152a9-b7a3-4111-bb8e-cadba56a78f9",
      "name": "Sticky Note2"
    },
    {
      "parameters": {
        "content": "**Workflow Overview**\n1.  **Goal:** Processes Tilda orders, manages loyalty points (earn/burn) via iikoCard API.\n2.  **Input:** Webhook from Tilda (JSON payload with order details).\n3.  **Idempotency:** Prevents duplicate processing via Google Sheets lookup (`order_id`).\n4.  **Logic:** Routes execution based on `spend_bonus` flag (True = Withdraw, False = Accrue).\n5.  **Notifications:** Admin (Telegram), Customer (WhatsApp).\n6.  **Error Handling:** Global workflow catches 4xx/5xx errors.",
        "height": 336,
        "width": 352
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        -1360,
        80
      ],
      "typeVersion": 1,
      "id": "ef0ab0aa-7823-4c04-bc03-a37087cf6682",
      "name": "Sticky Note3"
    },
    {
      "parameters": {
        "content": "**Spending Logic (Complex)**\n1.  **Redeem:** Deduced bonuses based on wallet balance (covers full or partial order).\n2.  **Calc Remainder:** Calculates how much the customer must pay by card.\n3.  **Accrue on Remainder:** Calculates new points (5%) based on the actual cash payment amount.\n4.  **Sync:** Updates iikoCard and notifies Admin.",
        "height": 144,
        "width": 672
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        416,
        -176
      ],
      "typeVersion": 1,
      "id": "24406ca1-b7cc-4faa-8b57-c494449fe4e9",
      "name": "Sticky Note4"
    },
    {
      "parameters": {
        "content": "**Earning Logic**\n1. Calculates loyalty points (5% of order total).\n2. Accrues points via iikoCard API (POST request).\n3. Sends WhatsApp notification to customer.\n4. Logs successful transaction to DB.",
        "height": 144,
        "width": 480
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        416,
        272
      ],
      "typeVersion": 1,
      "id": "fc8a467a-90c3-48e9-ad80-b1bf3dee1a55",
      "name": "Sticky Note5"
    },
    {
      "parameters": {
        "content": "**Idempotency Check**\n*   **Logic:** Checks if `order_id` exists in Google Sheets.\n*   **True:** Order exists -> Stop execution (prevent double-charging).\n*   **False:** New order -> Proceed.",
        "height": 176
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        -544,
        -32
      ],
      "typeVersion": 1,
      "id": "28b104bd-0241-48fc-a3e2-b41d93a43a92",
      "name": "Sticky Note6"
    },
    {
      "parameters": {
        "content": "**Business Logic Router**\nChecks the `spend_bonus` field from Tilda:\n*   **True:** Customer wants to pay with points.\n*   **False:** Standard accrual."
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        128,
        0
      ],
      "typeVersion": 1,
      "id": "ad18ce62-2899-4792-8dac-6aeb8a8b0eab",
      "name": "Sticky Note7"
    },
    {
      "parameters": {
        "content": "**Bonus Calculation**\n*   **Input:** `payment.amount` from Webhook.\n*   **Logic:** 5% of order total (rounded).\n*   **Output:** Integer value for API."
      },
      "type": "n8n-nodes-base.stickyNote",
      "position": [
        416,
        736
      ],
      "typeVersion": 1,
      "id": "ac2d8c50-50ad-4ba4-8947-3c5bfd58310e",
      "name": "Sticky Note8"
    }
  ],
  "connections": {
    "Check Duplicate": {
      "main": [
        [],
        [
          {
            "node": "iiko Auth (Get Token)",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Search Existing Order": {
      "main": [
        [
          {
            "node": "Check Duplicate",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Receive Tilda Order": {
      "main": [
        [
          {
            "node": "Search Existing Order",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "iiko Auth (Get Token)": {
      "main": [
        [
          {
            "node": "Sync Customer Profile",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Sync Customer Profile": {
      "main": [
        [
          {
            "node": "Router: Spend or Earn",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Router: Spend or Earn": {
      "main": [
        [
          {
            "node": "Get Current Balance",
            "type": "main",
            "index": 0
          }
        ],
        [
          {
            "node": "Calc Bonus Amount",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Get Current Balance": {
      "main": [
        [
          {
            "node": "Withdraw Bonuses",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Withdraw Bonuses": {
      "main": [
        [
          {
            "node": "Update Local Balance",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Update Local Balance": {
      "main": [
        [
          {
            "node": "Format Admin Message",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Format Admin Message": {
      "main": [
        [
          {
            "node": "Notify Admin (Spending) RU",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Calc Bonus Amount": {
      "main": [
        [
          {
            "node": "Accrue Bonuses",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Accrue Bonuses": {
      "main": [
        [
          {
            "node": "Notify Admin (Earning) RU",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Notify Admin (Spending) RU": {
      "main": [
        [
          {
            "node": "Log Transaction to DB",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Notify Admin (Earning) RU": {
      "main": [
        [
          {
            "node": "Notify Customer (WhatsApp) RU",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Notify Customer (WhatsApp) RU": {
      "main": [
        [
          {
            "node": "Log Transaction to DB",
            "type": "main",
            "index": 0
          }
        ]
      ]
    }
  },
  "active": false,
  "settings": {
    "executionOrder": "v1",
    "availableInMCP": false,
    "timeSavedMode": "fixed",
    "timezone": "Asia/Almaty",
    "callerPolicy": "workflowsFromSameOwner",
    "errorWorkflow": "hqRcKQkYO4KNl7CpVzjbg"
  },
  "versionId": "5dacf37f-572c-40a2-903a-753b9ffcd072",
  "meta": {
    "templateCredsSetupCompleted": true
  },
  "id": "s9Ah877ioKzNigtUAcxiU",
  "tags": []
}

Credentials you'll need

Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.

• googleSheetsOAuth2Api
• telegramApi

How this works

This workflow streamlines order processing from Tilda forms by automatically capturing new submissions via webhook, validating for duplicates against a Google Sheets ledger, and synchronising customer details with iiko's backend for seamless restaurant operations. It's ideal for hospitality managers handling online bookings or deliveries who need to eliminate manual data entry and reduce errors in high-volume environments. The pivotal step involves authenticating with iiko via HTTP requests to update profiles and route orders based on spend thresholds, ensuring quick notifications through Telegram for team alerts.

Use this when integrating Tilda with iiko for real-time order syncing in a single-location setup, particularly if your volume justifies automation without custom coding. Avoid it for multi-venue chains requiring advanced inventory logic, or if you're not using Google Sheets for order tracking. Common variations include adding email confirmations instead of Telegram or adapting the router for loyalty point calculations.

About this workflow

01_order_processing_tilda. Uses stickyNote, googleSheets, httpRequest, telegram. Webhook trigger; 25 nodes.

Source: https://github.com/gulnaz-bakinova/n8n-automation-integrations-showcase/blob/main/01_order_processing_tilda.json — original creator credit. Request a take-down →

More Slack & Telegram workflows → · Browse all categories →

Related workflows

Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
