This workflow follows the Emailreadimap → Emailsend recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "ATxZ5QYhdJq9mZDO",
"meta": {
"templateCredsSetupCompleted": true
},
"name": "Parse DMARC reports",
"tags": [
{
"id": "w055QEEFrp6ZYNCr",
"name": "DevOps",
"createdAt": "2023-12-19T18:45:02.513Z",
"updatedAt": "2023-12-19T18:45:02.513Z"
}
],
"nodes": [
{
"id": "ce9ce59c-3cf6-45db-97fc-825cb8516da8",
"name": "Email Trigger (IMAP)",
"type": "n8n-nodes-base.emailReadImap",
"position": [
580,
300
],
"parameters": {
"options": {},
"downloadAttachments": true
},
"credentials": {
"imap": {
"name": "<your credential>"
}
},
"typeVersion": 2
},
{
"id": "903f949d-ab1e-48ec-a903-a1ebde4cfbe9",
"name": "End date format",
"type": "n8n-nodes-base.dateTime",
"position": [
800,
880
],
"parameters": {
"date": "={{ $json.date_range_end.toDateTime('s') }}",
"format": "custom",
"options": {
"includeInputFields": true
},
"operation": "formatDate",
"customFormat": "yyyy-MM-dd hh:mm:ss",
"outputFieldName": "=date_range_end"
},
"typeVersion": 2
},
{
"id": "3303e551-8557-4220-ab24-48fcb0859a26",
"name": "If multiple records to parse",
"type": "n8n-nodes-base.if",
"position": [
560,
620
],
"parameters": {
"options": {},
"conditions": {
"options": {
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "b809e758-c3d2-4cbf-bab8-54d278a435dd",
"operator": {
"type": "object",
"operation": "exists",
"singleValue": true
},
"leftValue": "={{ $json.feedback.record[0] }}",
"rightValue": ""
}
]
}
},
"typeVersion": 2
},
{
"id": "513864bc-c124-452d-8be3-44feb73454ed",
"name": "Map fields for DB input and parse",
"type": "n8n-nodes-base.set",
"position": [
1200,
660
],
"parameters": {
"options": {
"ignoreConversionErrors": true
},
"assignments": {
"assignments": [
{
"id": "621508ee-fbea-4233-aaf3-96b573a60bd5",
"name": "full_data",
"type": "object",
"value": "={{ $json.feedback }}"
},
{
"id": "d605e93a-0e0a-4584-aa1e-e38b49f264e7",
"name": "org_name",
"type": "string",
"value": "={{ $json.feedback.report_metadata.org_name }}"
},
{
"id": "604a5573-67db-4bb6-80d8-4421dce2406b",
"name": "date_range_begin",
"type": "string",
"value": "={{ $json.feedback.report_metadata.date_range.begin }}"
},
{
"id": "b9d7244f-9d58-43fc-a477-f0750c31e5e2",
"name": "date_range_end",
"type": "string",
"value": "={{ $json.feedback.report_metadata.date_range.end }}"
},
{
"id": "3570869a-9dc9-4b20-b48c-5f382825d021",
"name": "domain",
"type": "string",
"value": "={{ $json.feedback.policy_published.domain }}"
},
{
"id": "979e4eb4-6e39-4a3c-8f0a-21ecf8086a3c",
"name": "policy_published",
"type": "object",
"value": "={{ $json.feedback.policy_published }}"
},
{
"id": "91cdfa19-49c6-4e5d-a423-d76bbb61eddc",
"name": "source_ip",
"type": "string",
"value": "={{ $json['fbr'].row.source_ip }}"
},
{
"id": "2434b04e-3c5e-4e61-8be9-1f9c1ec2a6ce",
"name": "mail_count",
"type": "string",
"value": "={{ $json['fbr'].row.count }}"
},
{
"id": "09b73b84-0f6a-443b-8da0-c7ad9742a9c1",
"name": "evaluated_disposition",
"type": "string",
"value": "={{ $json['fbr'].row.policy_evaluated.disposition }}"
},
{
"id": "6c8e81ab-abc6-497c-8919-6b2e8008a1e8",
"name": "evaluated_dkim",
"type": "string",
"value": "={{ $json['fbr'].row.policy_evaluated.dkim }}"
},
{
"id": "fa8ca9d6-5e1b-402c-9afc-e6bf42e2c6ad",
"name": "evaluated_spf",
"type": "string",
"value": "={{ $json['fbr'].row.policy_evaluated.spf }}"
},
{
"id": "42f269c3-978a-45f6-bfe5-1fa1536500fb",
"name": "identifiers",
"type": "object",
"value": "={{ $json['fbr'].identifiers }}"
},
{
"id": "3375dc26-a739-4bf9-8a46-2f6739337921",
"name": "auth_results",
"type": "object",
"value": "={{ $json['fbr'].auth_results }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "00cca3ae-1f0a-4ea9-8fb7-ac52d35c261b",
"name": "Begin format date",
"type": "n8n-nodes-base.dateTime",
"position": [
560,
880
],
"parameters": {
"date": "={{ $json.date_range_begin.toDateTime('s') }}",
"format": "custom",
"options": {
"includeInputFields": true
},
"operation": "formatDate",
"customFormat": "yyyy-MM-dd hh:mm:ss",
"outputFieldName": "=date_range_begin"
},
"typeVersion": 2
},
{
"id": "18c2305a-db44-4e4d-97b9-1f04018085b0",
"name": "Input into database",
"type": "n8n-nodes-base.mySql",
"position": [
620,
1100
],
"parameters": {
"table": {
"__rl": true,
"mode": "list",
"value": "dmarc",
"cachedResultName": "dmarc"
},
"options": {
"detailedOutput": true
},
"dataMode": "defineBelow",
"valuesToSend": {
"values": [
{
"value": "={{ $json.full_data.toJsonString() }}",
"column": "full_data"
},
{
"value": "={{ $json.org_name }}",
"column": "org_name"
},
{
"value": "={{ $json.date_range_begin }}",
"column": "date_range_begin"
},
{
"value": "={{ $json.date_range_end }}",
"column": "date_range_end"
},
{
"value": "={{ $json.domain }}",
"column": "domain"
},
{
"value": "={{ $json.policy_published.toJsonString() }}",
"column": "policy_published"
},
{
"value": "={{ $json.source_ip }}",
"column": "source_ip"
},
{
"value": "={{ $json.mail_count }}",
"column": "mail_count"
},
{
"value": "={{ $json.evaluated_disposition }}",
"column": "evaluated_disposition"
},
{
"value": "={{ $json.evaluated_dkim }}",
"column": "evaluated_dkim"
},
{
"value": "={{ $json.evaluated_spf }}",
"column": "evaluated_spf"
},
{
"value": "={{ $json.identifiers == null ? null : $json.identifiers.toJsonString() }}",
"column": "identifiers"
},
{
"value": "={{ $json.auth_results == null ? null : $json.auth_results.toJsonString() }}",
"column": "auth_results"
}
]
}
},
"credentials": {
"mySql": {
"name": "<your credential>"
}
},
"typeVersion": 2.4
},
{
"id": "c65c4cfb-3912-4b45-a5e0-3ab787e018c8",
"name": "If issue with DKIM or SPF",
"type": "n8n-nodes-base.if",
"position": [
580,
1260
],
"parameters": {
"options": {},
"conditions": {
"options": {
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "or",
"conditions": [
{
"id": "818b461b-4bdc-4842-9f89-d1d8966b8c0a",
"operator": {
"type": "string",
"operation": "notEquals"
},
"leftValue": "={{ $json.evaluated_dkim }}",
"rightValue": "pass"
},
{
"id": "4322cb26-5ff1-4278-94ae-7ff278c61c6c",
"operator": {
"type": "string",
"operation": "notEquals"
},
"leftValue": "={{ $json.evaluated_spf }}",
"rightValue": "pass"
}
]
}
},
"typeVersion": 2
},
{
"id": "5d17bf15-ecef-40e8-acc4-6af5ad1c712d",
"name": "Rename Keys",
"type": "n8n-nodes-base.renameKeys",
"position": [
1000,
500
],
"parameters": {
"keys": {
"key": [
{
"newKey": "fbr",
"currentKey": "feedback.record"
}
]
},
"additionalOptions": {}
},
"typeVersion": 1
},
{
"id": "0e2b8c73-0f53-46f9-9692-cbe87c97862d",
"name": "Rename column for consistency",
"type": "n8n-nodes-base.set",
"position": [
800,
660
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "f563d673-bc82-4863-b132-d431ebe8f651",
"name": "fbr",
"type": "object",
"value": "={{ $json.feedback.record }}"
}
]
},
"includeOtherFields": true
},
"typeVersion": 3.4
},
{
"id": "5796c124-645d-460e-88df-0a909a33b6b1",
"name": "Sticky Note",
"type": "n8n-nodes-base.stickyNote",
"position": [
100,
300
],
"parameters": {
"width": 394.2691415313225,
"height": 304.36194895591655,
"content": "## How it works\n- monitor postmaster email for DKIM reprots\n- unpack report and parse XML\n- map and format fields for DB input\n\t- input into database\n\t- send notification on DKIM or SPF failure\n\n## Remember to set up\n- email input mailbox\n- notification channels"
},
"typeVersion": 1
},
{
"id": "1457272e-630e-44ee-bb18-ac650d192cbf",
"name": "Unzip File",
"type": "n8n-nodes-base.compression",
"position": [
800,
300
],
"parameters": {
"binaryPropertyName": "attachment_0"
},
"typeVersion": 1.1
},
{
"id": "89ade90c-c7e3-4c6f-89cf-0e7ce1e55333",
"name": "Extract XML data",
"type": "n8n-nodes-base.extractFromFile",
"position": [
1020,
300
],
"parameters": {
"options": {},
"operation": "xml",
"binaryPropertyName": "file_0"
},
"typeVersion": 1
},
{
"id": "8fd70f3c-53d5-4d99-ad2c-d526089fe0f5",
"name": "Parse XML data to JSON",
"type": "n8n-nodes-base.xml",
"position": [
1220,
300
],
"parameters": {
"options": {}
},
"typeVersion": 1
},
{
"id": "b17352d9-135a-4c26-993f-0c1fdafc1fa3",
"name": "Sticky Note1",
"type": "n8n-nodes-base.stickyNote",
"position": [
1420,
300
],
"parameters": {
"width": 394.2691415313225,
"height": 159.80531276753783,
"content": "## Preparation\nThis line is responsible for taking data from email and parsing it into JSON understandable by n8n"
},
"typeVersion": 1
},
{
"id": "31d2f822-aea6-41b4-bb1e-25b48cb3e972",
"name": "Sticky Note2",
"type": "n8n-nodes-base.stickyNote",
"position": [
1420,
500
],
"parameters": {
"width": 394.2691415313225,
"height": 316.3177609714967,
"content": "## Mapping\nThis line is responsible for treating cases when XML has multiple info for domain. One DMARC report can contain more than one entries.\n\nLast node is responsible for matching data with database structure"
},
"typeVersion": 1
},
{
"id": "e8fc0f91-1bdf-4bc5-b488-4f2c169da9c0",
"name": "Split Out For Separate Entries",
"type": "n8n-nodes-base.splitOut",
"position": [
800,
500
],
"parameters": {
"include": "allOtherFields",
"options": {},
"fieldToSplitOut": "feedback.record"
},
"typeVersion": 1
},
{
"id": "9ba7a0b8-80e6-4559-83ec-894533194dc7",
"name": "Sticky Note3",
"type": "n8n-nodes-base.stickyNote",
"position": [
1420,
860
],
"parameters": {
"width": 394.2691415313225,
"height": 185.89072080153096,
"content": "## Date translate\nThis line is responsible for translating date format into understandable by MySQL/MariaDB\n\nIn next node data is being input into MySQL/MariaDB "
},
"typeVersion": 1
},
{
"id": "96461e30-87f0-48f1-a43f-60185ea1d835",
"name": "Sticky Note4",
"type": "n8n-nodes-base.stickyNote",
"position": [
1420,
1180
],
"parameters": {
"width": 394.2691415313225,
"height": 320.66532897716223,
"content": "## Notifications\nLast two nodes are responsible for sending notifications in case IF inside DMARC report is reported any issue with SPF or DKIM"
},
"typeVersion": 1
},
{
"id": "192b95c6-cdfe-4b5e-94e1-94deb728b0e2",
"name": "Slack Post Message On Channel",
"type": "n8n-nodes-base.slack",
"disabled": true,
"position": [
1200,
1180
],
"parameters": {
"text": "=DMARC evaluation failed for {{ $json.domain }} on {{ $json.mail_count }} mails with disposition: {{ $json.evaluated_disposition }}. DKIM: {{ $json.evaluated_dkim }} SPF: {{ $json.evaluated_spf }}",
"select": "channel",
"channelId": {
"__rl": true,
"mode": "list",
"value": "CCGJA1F1N",
"cachedResultName": "powiadomienia"
},
"otherOptions": {},
"authentication": "oAuth2"
},
"credentials": {
"slackOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 2.2
},
{
"id": "ce400c97-cae4-41db-ad8f-e678fc4a27fe",
"name": "Send Error Notification Email",
"type": "n8n-nodes-base.emailSend",
"disabled": true,
"position": [
1200,
1380
],
"parameters": {
"text": "DMARC evaluation failed for {{ $json.domain }} on {{ $json.mail_count }} mails with disposition: {{ $json.evaluated_disposition }}. DKIM: {{ $json.evaluated_dkim }} SPF: {{ $json.evaluated_spf }}",
"options": {},
"subject": "DMARC problem",
"emailFormat": "text"
},
"typeVersion": 2.1
}
],
"active": true,
"settings": {
"callerPolicy": "workflowsFromSameOwner",
"errorWorkflow": "5",
"executionOrder": "v1",
"saveManualExecutions": true,
"saveExecutionProgress": true,
"saveDataSuccessExecution": "all"
},
"versionId": "1add308c-4aef-4a83-a958-bc66dead234f",
"connections": {
"Unzip File": {
"main": [
[
{
"node": "Extract XML data",
"type": "main",
"index": 0
}
]
]
},
"Rename Keys": {
"main": [
[
{
"node": "Map fields for DB input and parse",
"type": "main",
"index": 0
}
]
]
},
"End date format": {
"main": [
[
{
"node": "Input into database",
"type": "main",
"index": 0
},
{
"node": "If issue with DKIM or SPF",
"type": "main",
"index": 0
}
]
]
},
"Extract XML data": {
"main": [
[
{
"node": "Parse XML data to JSON",
"type": "main",
"index": 0
}
]
]
},
"Begin format date": {
"main": [
[
{
"node": "End date format",
"type": "main",
"index": 0
}
]
]
},
"Email Trigger (IMAP)": {
"main": [
[
{
"node": "Unzip File",
"type": "main",
"index": 0
}
]
]
},
"Parse XML data to JSON": {
"main": [
[
{
"node": "If multiple records to parse",
"type": "main",
"index": 0
}
]
]
},
"If issue with DKIM or SPF": {
"main": [
[
{
"node": "Slack Post Message On Channel",
"type": "main",
"index": 0
},
{
"node": "Send Error Notification Email",
"type": "main",
"index": 0
}
]
]
},
"If multiple records to parse": {
"main": [
[
{
"node": "Split Out For Separate Entries",
"type": "main",
"index": 0
}
],
[
{
"node": "Rename column for consistency",
"type": "main",
"index": 0
}
]
]
},
"Rename column for consistency": {
"main": [
[
{
"node": "Map fields for DB input and parse",
"type": "main",
"index": 0
}
]
]
},
"Split Out For Separate Entries": {
"main": [
[
{
"node": "Rename Keys",
"type": "main",
"index": 0
}
]
]
},
"Map fields for DB input and parse": {
"main": [
[
{
"node": "Begin format date",
"type": "main",
"index": 0
}
]
]
}
}
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
imapmySqlslackOAuth2Api
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
How this works
DMARC reports provide essential insights into your email authentication, helping you identify and resolve delivery issues to protect your domain from spoofing and improve sender reputation. This workflow automates the parsing of these reports, extracting key data like SPF and DKIM alignment failures, and stores it in a MySQL database for easy analysis. Ideal for email administrators or security teams managing high-volume domains, the core step involves reading incoming IMAP emails, processing the XML attachments, and flagging anomalies to prevent blacklisting.
Use this workflow when you receive daily DMARC aggregate reports via email and need structured data for compliance audits or threat monitoring, especially with integrations like Slack for alerts on failures. Avoid it for real-time forensic reports, which require different parsing logic, or if your reports lack XML format. Common variations include adding emailSend nodes to notify stakeholders or compressing outputs for long-term storage.
About this workflow
Parse DMARC reports. Uses emailReadImap, dateTime, mySql, renameKeys. Manual trigger; 20 nodes.
Source: https://github.com/Zie619/n8n-workflows — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
debug. Uses httpRequest, slack, redis, mailgun. Scheduled trigger; 60 nodes.
HTTP Request, Slack, Redis +2
This workflow automates end-to-end research analysis by coordinating multiple AI models—including NVIDIA NIM (Llama), OpenAI GPT-4, and Claude to analyze uploaded documents, extract insights, and gene
HTTP Request, Postgres, Slack +1
Type in Slack. Walk away. Get a professional PDF report and a structured Excel fix sheet delivered to Google Drive and posted back in your Slack thread — fully automated, zero manual work.
Compression, HTTP Request, Google Drive +3
This workflow streamlines the entire inventory replenishment process by leveraging AI for demand forecasting and intelligent logic for supplier selection. It aggregates data from multiple sources—POS
HTTP Request, MySQL, Slack
Wait Slack. Uses httpRequest, xml, splitInBatches, stickyNote. Event-driven trigger; 28 nodes.
HTTP Request, XML, Execute Workflow Trigger +1
