This workflow follows the Documentdefaultdataloader → OpenAI Embeddings recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "RAG_Ingest",
"nodes": [
{
"parameters": {
"method": "POST",
"url": "https://api.mistral.ai/v1/files",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "mistralCloudApi",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{}
]
},
"sendBody": true,
"contentType": "multipart-form-data",
"bodyParameters": {
"parameters": [
{
"name": "purpose",
"value": "ocr"
},
{
"parameterType": "formBinaryData",
"name": "file",
"inputDataFieldName": "data"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-1984,
1072
],
"id": "56ca873a-cb23-4839-ae45-18dfcb170314",
"name": "HTTP Request-Upload file to Mistral",
"credentials": {
"mistralCloudApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"url": "=https://api.mistral.ai/v1/files/{{ $json.id }}/url",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "mistralCloudApi",
"sendQuery": true,
"queryParameters": {
"parameters": [
{
"name": "expiry",
"value": "24"
}
]
},
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Accept",
"value": "application/json"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-1760,
1072
],
"id": "61d458e6-6b2e-4e5a-89b4-e38638a26e3e",
"name": "HTTP Request Get signed URL",
"credentials": {
"mistralCloudApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"method": "POST",
"url": "https://api.mistral.ai/v1/ocr",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "mistralCloudApi",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={\n \"model\": \"mistral-ocr-latest\",\n \"document\": {\n \"type\": \"document_url\",\n \"document_url\": \"{{ $json.url }}\"\n },\n \"include_image_base64\": true,\n \"bbox_annotation_format\": {\n \"type\": \"json_schema\",\n \"json_schema\": {\n \"schema\": {\n \"properties\": {\n \"document_type\": {\n \"title\": \"Document_Type\",\n \"description\": \"The type of the image.\",\n \"type\": \"string\"\n },\n \"short_description\": {\n \"title\": \"Short_Description\",\n \"description\": \"A description in English describing the image based on the figure description below or above image.\",\n \"type\": \"string\"\n }\n },\n \"required\": [\"document_type\", \"short_description\"],\n \"title\": \"BBOXAnnotation\",\n \"type\": \"object\",\n \"additionalProperties\": false\n },\n \"name\": \"document_annotation\",\n \"strict\": true\n }\n }\n}\n",
"options": {
"response": {
"response": {
"responseFormat": "json"
}
}
}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-1536,
1072
],
"id": "22815164-8386-4603-bd39-dc61b69f6642",
"name": "HTTP Request Image BBox Annotation",
"credentials": {
"mistralCloudApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"fieldToSplitOut": "pages",
"options": {}
},
"type": "n8n-nodes-base.splitOut",
"typeVersion": 1,
"position": [
-1104,
1072
],
"id": "98fe5aa6-d8cb-41be-b1fb-78f279496f1f",
"name": "Split Out - by pages"
},
{
"parameters": {
"mode": "runOnceForEachItem",
"jsCode": "// 1) Grab the existing markdown and image list from the current item\nlet markdown = $json.markdown;\nconst images = $json.images || [];\n\n// 2) For each image, build the annotated markdown and replace the plain tag\nfor (const image of images) {\n // assume image.id is the filename (e.g. \"img-35.jpeg\")\n const fileName = image.id;\n // your OCR/AI result lives in image.image_annotation\n const annotation = image.image_annotation || '';\n\n // the original markdown tag\n const imageMarkdown = ``;\n // plus its annotation\n const annotatedMarkdown = `${imageMarkdown}\\n\\n${annotation}`;\n\n // do an in-place replacement\n markdown = markdown.replaceAll(imageMarkdown, annotatedMarkdown);\n}\n\n// 3) Return the full JSON, spreading in any other fields but with updated markdown\nreturn {\n json: {\n ...$json,\n markdown\n }\n};\n"
},
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
-880,
1072
],
"id": "e8fd558a-1c76-4736-8041-58d6a489ceea",
"name": "Code"
},
{
"parameters": {
"mode": "insert",
"tableName": {
"__rl": true,
"value": "={{ $('Superbase Bucket - Text').item.json.superbase_storage_bucket_name }}",
"mode": "id"
},
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.vectorStoreSupabase",
"typeVersion": 1.3,
"position": [
-640,
1072
],
"id": "67c2ae80-4d05-43bd-884e-61e205d53f7f",
"name": "Supabase Vector Store",
"credentials": {
"supabaseApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"jsonMode": "expressionData",
"jsonData": "={{ $('Code').item.json.markdown }}",
"textSplittingMode": "custom",
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.documentDefaultDataLoader",
"typeVersion": 1.1,
"position": [
-496,
1280
],
"id": "9beba435-3d5e-4bc1-97b1-d8b7a43a9a3b",
"name": "Default Data Loader1"
},
{
"parameters": {
"chunkOverlap": 200,
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.textSplitterRecursiveCharacterTextSplitter",
"typeVersion": 1,
"position": [
-416,
1504
],
"id": "638271db-bb39-4774-8040-3776598da46f",
"name": "Recursive Character Text Splitter1"
},
{
"parameters": {
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.embeddingsOpenAi",
"typeVersion": 1.2,
"position": [
-640,
1232
],
"id": "a021f796-3b92-42c6-8a61-d77e4bb0faa9",
"name": "Embeddings OpenAI",
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"content": "# Text Data Ingestion - VectorStore (Superbase)\n### Connect to any persistant PDF storage (in this case google drive)\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n",
"height": 1500,
"width": 3640
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-3728,
368
],
"id": "65768942-83ba-4959-bf25-a7745b9779df",
"name": "Sticky Note1"
},
{
"parameters": {
"method": "POST",
"url": "https://api.mistral.ai/v1/files",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "mistralCloudApi",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{}
]
},
"sendBody": true,
"contentType": "multipart-form-data",
"bodyParameters": {
"parameters": [
{
"name": "purpose",
"value": "ocr"
},
{
"parameterType": "formBinaryData",
"name": "file",
"inputDataFieldName": "data"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-1968,
-448
],
"id": "623a68d8-6381-42cb-b109-41e6e1e217c1",
"name": "HTTP Request - Upload PDF to Mistral",
"credentials": {
"mistralCloudApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"url": "=https://api.mistral.ai/v1/files/{{ $json.id }}/url ",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "mistralCloudApi",
"sendQuery": true,
"queryParameters": {
"parameters": [
{
"name": "expiry",
"value": "24"
}
]
},
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Accept",
"value": "application/json"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-1744,
-448
],
"id": "1ce22cec-ed3a-4395-946d-acf112929957",
"name": "HTTP Request - Get signed URL if uploaded to Mistral",
"credentials": {
"mistralCloudApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"content": "**NOTE**: When uploaded file to Mistral, you need to ask Mistral to generate a pre-signed URl for the file you have uploaded with the **$id** filled out - since the files in the Mistrals storage are private by default - you need to request URL.",
"height": 140,
"width": 320,
"color": 4
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-1968,
-608
],
"id": "affb5760-0da6-4eff-b2d1-a1f047a7ce5b",
"name": "Sticky Note2"
},
{
"parameters": {
"method": "POST",
"url": "https://api.mistral.ai/v1/ocr",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "mistralCloudApi",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={\n \"model\": \"mistral-ocr-latest\",\n \"document\": {\n \"type\": \"document_url\",\n \"document_url\": \"{{ $json.url }}\"\n },\n \"include_image_base64\": true,\n \"bbox_annotation_format\": {\n \"type\": \"json_schema\",\n \"json_schema\": {\n \"schema\": {\n \"properties\": {\n \"document_type\": {\n \"title\": \"Document_Type\",\n \"description\": \"The type of the image.\",\n \"type\": \"string\"\n },\n \"short_description\": {\n \"title\": \"Short_Description\",\n \"description\": \"A description in English describing the image based on the figure description below or above image.\",\n \"type\": \"string\"\n }\n },\n \"required\": [\"document_type\", \"short_description\"],\n \"title\": \"BBOXAnnotation\",\n \"type\": \"object\",\n \"additionalProperties\": false\n },\n \"name\": \"document_annotation\",\n \"strict\": true\n }\n }\n}\n",
"options": {
"response": {
"response": {
"responseFormat": "json"
}
}
}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-1520,
-448
],
"id": "8c5f9a44-31ea-4c78-ac98-6393d75b4a0c",
"name": "HTTP Request - OCR and Image Annotation",
"credentials": {
"mistralCloudApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"content": "**NOTE**: When uploaded file to Mistral, you need to ask Mistral to generate a pre-signed URl for the file you have uploaded with the **$id** filled out - since the files in the Mistrals storage are private by default - you need to request URL.",
"height": 140,
"width": 320,
"color": 4
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-1984,
912
],
"id": "48058eb9-6a16-4321-8dd4-110ced0bf63d",
"name": "Sticky Note3"
},
{
"parameters": {
"fieldToSplitOut": "pages",
"options": {}
},
"type": "n8n-nodes-base.splitOut",
"typeVersion": 1,
"position": [
-1328,
-624
],
"id": "56be117b-cb90-4fd9-a504-7cb77f22fc72",
"name": "Split Out - (pages)"
},
{
"parameters": {
"fieldToSplitOut": "images",
"options": {}
},
"type": "n8n-nodes-base.splitOut",
"typeVersion": 1,
"position": [
-1104,
-624
],
"id": "5ad402be-f34d-4430-b6c8-dc2a71e3eeef",
"name": "Split Out - (images)"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "6731d779-aaf6-474d-ba31-01ce46601207",
"name": "=file_name",
"value": "={{ \n (\n Date.now().toString(36)\n + Math.random().toString(36).substring(2,10)\n + Math.random().toString(36).substring(2,10)\n + Math.random().toString(36).substring(2,10)\n ).toLowerCase()\n}}",
"type": "string"
},
{
"id": "374e8312-d304-4a55-bc1a-efcb6a603121",
"name": "original_id",
"value": "={{ $json.id }}",
"type": "string"
},
{
"id": "e42e5cc5-aee5-4d84-9a35-c67a6d80dfbe",
"name": "image_annotation",
"value": "={{ $json.image_annotation }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-864,
-624
],
"id": "cd83892e-6a10-44d9-a0b9-371032d10dde",
"name": "Extract the file name, id, and annotation"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "fad321ce-9612-4d43-bdda-47e4bb9fd88e",
"name": "image_base64",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-640,
-784
],
"id": "f6936cae-57c0-4ad9-af0b-8f48548fb0f7",
"name": "Extract image_base64"
},
{
"parameters": {
"operation": "toBinary",
"sourceProperty": "=image_base64",
"options": {
"fileName": "={{ $('Extract the file name, id, and annotation').item.json.file_name }}"
}
},
"type": "n8n-nodes-base.convertToFile",
"typeVersion": 1.1,
"position": [
-416,
-784
],
"id": "01b75083-b11d-40bc-834a-ec03b5ddc501",
"name": "Convert to File"
},
{
"parameters": {
"content": "### **NOTE:** for \"Upload base64 strings to superbase storage\"\n\nWhenever you want to hit Supabase Storage via HTTP, you use your project\u2019s base URL (the same one you see in your Dashboard) plus the Storage REST path. Concretely:\n\n{project_ref}/storage/v1/object/{bucket}/{your-path-and-filename.ext}\n\n- {project_ref} \u2013 found in your Dashboard under Settings \u2192 API \u2192 Project URL\n\n- {bucket} \u2013 the name of the Storage bucket you created (e.g. avatars)\n\n- {your-path-and-filename.ext} \u2013 where you want it saved, e.g. uploads/user123.png - in my case due to aggregation later I used {{ $binary.data.fileName }} - to match the binary file name.\n\n- If you open the Supabase docs for Upload a new object, you\u2019ll see exactly that endpoint listed (and examples in cURL, JS, etc.)",
"height": 280,
"width": 680,
"color": 4
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-608,
-1088
],
"id": "cbe9dc52-0d81-488f-87bb-b90a03473300",
"name": "Sticky Note4"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "688f1256-cfab-491f-b466-d96c09954c76",
"name": "file_name",
"value": "={{ $json.Key.split('/').slice(1).join('/') }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
32,
-784
],
"id": "95588fa7-ec69-4a07-992b-77fbe75de792",
"name": "Get Uploaded Filename"
},
{
"parameters": {
"mode": "combine",
"fieldsToMatchString": "file_name",
"options": {}
},
"type": "n8n-nodes-base.merge",
"typeVersion": 3.2,
"position": [
240,
-640
],
"id": "505da9d2-f1a7-4c75-81fc-4f202c61d35a",
"name": "Merge results"
},
{
"parameters": {
"method": "POST",
"url": "={{ $('Superbase Bucket - Image').item.json.superbase_base_url }}/storage/v1/object/{{ $('Superbase Bucket - Image').item.json.superbase_storage_bucket_name }}/{{ $binary.data.fileName }}",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "supabaseApi",
"sendBody": true,
"contentType": "binaryData",
"inputDataFieldName": "data",
"options": {}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-208,
-784
],
"id": "4f35d463-50ad-42d8-9f09-d70be1e2e70f",
"name": "Upload base64 strings to superbase storage",
"credentials": {
"supabaseApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"aggregate": "aggregateAllItemData",
"destinationFieldName": "uploaded_images",
"options": {}
},
"type": "n8n-nodes-base.aggregate",
"typeVersion": 1,
"position": [
432,
-640
],
"id": "792587f7-b699-4741-8d59-e44f3f90c794",
"name": "Aggregate"
},
{
"parameters": {},
"type": "n8n-nodes-base.merge",
"typeVersion": 3.2,
"position": [
624,
-464
],
"id": "657f0b75-438a-4990-92ec-8408a4abe101",
"name": "Merge"
},
{
"parameters": {
"resource": "fileFolder",
"queryString": "*",
"returnAll": true,
"filter": {
"folderId": {
"__rl": true,
"value": "={{ $json.id }}",
"mode": "id"
}
},
"options": {}
},
"id": "2a392e7e-f7fa-4a3d-964c-3549b329dd6a",
"name": "Search files and folders",
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
-2480,
-448
],
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"mode": "insert",
"tableName": {
"__rl": true,
"value": "={{ $('Superbase Bucket - Image').item.json.superbase_storage_bucket_name }}",
"mode": "id"
},
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.vectorStoreSupabase",
"typeVersion": 1.3,
"position": [
1392,
-464
],
"id": "ece29956-0ee6-4388-b8c2-5fb1985db8fc",
"name": "Supabase Vector Store (image)",
"credentials": {
"supabaseApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"jsonMode": "expressionData",
"jsonData": "={{ $json.markdown }}",
"textSplittingMode": "custom",
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.documentDefaultDataLoader",
"typeVersion": 1.1,
"position": [
1488,
-304
],
"id": "837117d8-ac5d-47ca-b491-dabebf9c12f3",
"name": "Default Data Loader (image)"
},
{
"parameters": {
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.embeddingsOpenAi",
"typeVersion": 1.2,
"position": [
1360,
-304
],
"id": "3b5f2cd0-352e-408f-839d-5ae9f348322a",
"name": "Embeddings OpenAI (image)",
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"chunkSize": 800,
"chunkOverlap": 200,
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.textSplitterRecursiveCharacterTextSplitter",
"typeVersion": 1,
"position": [
1504,
-160
],
"id": "a8d8dd0a-980e-4a5a-9a06-af92b8a17609",
"name": "Recursive Character Text Splitter (image)"
},
{
"parameters": {
"mode": "runOnceForEachItem",
"jsCode": "// Safely access uploaded_images from Merge1\nconst mergeItems = $items('Merge');\n// const uploadedImages = mergeItems.json.uploaded_images || [];\nconst uploadedImages = mergeItems.flatMap(i => i.json.uploaded_images || []);\n\n// return {\n// json: {\n// debug_uploadCount: uploadedImages.length,\n// debug_mergeItems: mergeItems.map(i => i.json.uploaded_images),\n// },\n// };\n\nlet markdown = $json.markdown;\nconst supabaseBaseUrl = $('Superbase Bucket - Image').item.json.superbase_base_url;\nconst bucketName = $('Superbase Bucket - Image').item.json.superbase_storage_bucket_name;\nconst fullBaseUrl = `${supabaseBaseUrl}/storage/v1/object/public/${bucketName}/`;\n\n// Only run replacement if uploadedImages is a non-empty array\n// if (uploadedImages.length > 0) {\nfor (const image of uploadedImages) {\n const originalId = image.original_id;\n const fileName = image.file_name;\n // 1) Normalize the annotation into a JS object (if needed)\n let annObj = image.image_annotation || \"\";\n if (typeof annObj === 'string') {\n try {\n annObj = JSON.parse(annObj);\n } catch {\n // leave it as the raw string if it isn't valid JSON\n }\n }\n\n // 2) Pull out the text you actually want (e.g. short_description)\n const annotationText =\n (annObj && annObj.short_description) // common key\n || (annObj && annObj.text) // alternate key\n || `${annObj}` // fallback to whatever it is\n\n // 3) Build your regex + replacement exactly as before\n const re = new RegExp(`!\\\\[${originalId}\\\\]\\\\(${originalId}\\\\)`, 'g');\n const replacement =\n `\\n\\n${annotationText}`;\n\n markdown = markdown.replace(re, replacement);\n}\n\n\nreturn {\n json: {\n ...$json,\n markdown,\n },\n};"
},
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
1104,
-464
],
"id": "d71e54ef-e389-4596-ac30-efd682409625",
"name": "Code (B)"
},
{
"parameters": {
"url": "=https://www.googleapis.com/drive/v3/files/{{ $json.folder_id }}?fields=*",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "googleDriveOAuth2Api",
"options": {}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-2736,
-448
],
"id": "8fc7308d-54ca-491d-8e45-92be0c687347",
"name": "Get File Metadata",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "download",
"fileId": {
"__rl": true,
"value": "={{ $json.id }}",
"mode": "id"
},
"options": {}
},
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
-2224,
-448
],
"id": "b70d4874-de6e-42b2-8878-1f7508fa73fb",
"name": "Download Drive File",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"content": "# Image Data Ingestion - VectorStore (Superbase)\n### Connect to any persistant PDF storage (in this case google drive)\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n",
"height": 1440,
"width": 5480,
"color": 6
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-3728,
-1120
],
"id": "ee84a971-72ab-43c4-951d-56da594fb54c",
"name": "Sticky Note6"
},
{
"parameters": {
"fieldToSplitOut": "pages",
"options": {}
},
"type": "n8n-nodes-base.splitOut",
"typeVersion": 1,
"position": [
864,
-464
],
"id": "b127feb5-7389-4e84-ac4f-5f024a5c899f",
"name": "Split Out-pages"
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1RMKBn30Fupnj-cIIC_fR0dN8PXutCKhZ",
"mode": "list",
"cachedResultName": "B",
"cachedResultUrl": "https://drive.google.com/drive/folders/1RMKBn30Fupnj-cIIC_fR0dN8PXutCKhZ"
},
"event": "fileUpdated",
"options": {
"fileType": "all"
}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3600,
528
],
"id": "40a06bed-63f6-427d-9bf2-7c56e887c13e",
"name": "Google Drive Trigger (B) - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1rrFtRwuiiK6Y6WAuSaweGsMgVH-sqjoy",
"mode": "list",
"cachedResultName": "C",
"cachedResultUrl": "https://drive.google.com/drive/folders/1rrFtRwuiiK6Y6WAuSaweGsMgVH-sqjoy"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3600,
704
],
"id": "809ad928-72dd-474f-8b57-77acb1084c6a",
"name": "Google Drive Trigger (C) - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1IRgTR4ahn5DDGuiji3mSL94OTeHEyAui",
"mode": "list",
"cachedResultName": "D",
"cachedResultUrl": "https://drive.google.com/drive/folders/1IRgTR4ahn5DDGuiji3mSL94OTeHEyAui"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3600,
880
],
"id": "8c4b3a4b-b271-4139-bb11-a9437348ecdd",
"name": "Google Drive Trigger (D) - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1OWdxpEEc5d6UzXumaTCuwzdnmBZVQCi2",
"mode": "list",
"cachedResultName": "E",
"cachedResultUrl": "https://drive.google.com/drive/folders/1OWdxpEEc5d6UzXumaTCuwzdnmBZVQCi2"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3600,
1072
],
"id": "9a67396d-9a67-49f6-8cff-c973138c44e4",
"name": "Google Drive Trigger (E) - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1FQJB48L1gyf0CEXgxj0o8kW6IaeMdHBd",
"mode": "list",
"cachedResultName": "F",
"cachedResultUrl": "https://drive.google.com/drive/folders/1FQJB48L1gyf0CEXgxj0o8kW6IaeMdHBd"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3600,
1248
],
"id": "82e426f9-2843-4aae-80c2-fe483cb8868d",
"name": "Google Drive Trigger (F) - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1Q-ND07j0klS1Dz2AhRIUT4rOuJPxcmdk",
"mode": "list",
"cachedResultName": "G",
"cachedResultUrl": "https://drive.google.com/drive/folders/1Q-ND07j0klS1Dz2AhRIUT4rOuJPxcmdk"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3600,
1424
],
"id": "28ad656d-6758-4ab7-bca2-1db061fa0f5a",
"name": "Google Drive Trigger (G) - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1EdNbm4tHJO_XeQJ6JRrzAFFm3XezMIT2",
"mode": "list",
"cachedResultName": "H",
"cachedResultUrl": "https://drive.google.com/drive/folders/1EdNbm4tHJO_XeQJ6JRrzAFFm3XezMIT2"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3600,
1600
],
"id": "5d2403ae-c203-412f-929d-5d07ab3e019e",
"name": "Google Drive Trigger (H) - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-h",
"type": "string"
},
{
"id": "8cd7560d-c6cf-477e-97a3-0cab98fc6ccc",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3328,
1600
],
"id": "7b2bb0e1-c3c8-49e6-a6cd-733ed42b6bef",
"name": "Superbase Bucket (code_h) - Text"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-g",
"type": "string"
},
{
"id": "f5e143db-043e-4da6-9df2-e8493c169398",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3328,
1424
],
"id": "740dc07f-91b2-4352-9459-3467477e7d2b",
"name": "Superbase Bucket (code_g) - Text"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-f",
"type": "string"
},
{
"id": "db6318eb-b8f6-4737-b88e-a84189e8f04d",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3328,
1248
],
"id": "035b1c0b-be42-4f8a-a015-157d156a099c",
"name": "Superbase Bucket (code_f) - Text"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-e",
"type": "string"
},
{
"id": "791a3f88-f902-44c1-a764-9e9234e0dd87",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3328,
1072
],
"id": "47cea84d-33a6-4fa0-a20b-887c2c86dbaa",
"name": "Superbase Bucket (code_e) - Text"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-d",
"type": "string"
},
{
"id": "6d120749-d748-4dba-af49-29ac572c5fe6",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3328,
880
],
"id": "f0877f91-0d6b-471b-b34b-880482ada06d",
"name": "Superbase Bucket (code_d) - Text"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-c",
"type": "string"
},
{
"id": "2998ce44-55e9-4404-b2aa-6247ce2b378e",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3328,
704
],
"id": "cdd85e31-bc8d-44c7-b807-72b15536bef6",
"name": "Superbase Bucket (code_c) - Text"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-b",
"type": "string"
},
{
"id": "37323b0e-3c37-4d4e-b74c-dcb56ed198ca",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3328,
528
],
"id": "4d3a2fc0-c767-4278-8195-4c350e3c3202",
"name": "Superbase Bucket (code_b) - Text"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "={{ $json.superbase_storage_bucket_name }}",
"type": "string"
},
{
"id": "6d120749-d748-4dba-af49-29ac572c5fe6",
"name": "folder_id",
"value": "={{ $json.folder_id }}",
"type": "string"
},
{
"id": "b765ed82-2930-47fb-838f-869bfd43f3df",
"name": "superbase_base_url",
"value": "={{ $json.superbase_base_url }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3008,
1072
],
"id": "100de973-0b28-4598-b32a-ff54da94c6cc",
"name": "Superbase Bucket - Text"
},
{
"parameters": {
"url": "=https://www.googleapis.com/drive/v3/files/{{ $json.folder_id }}?fields=*",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "googleDriveOAuth2Api",
"options": {}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
-2720,
1072
],
"id": "e20d1ec8-6f30-4968-841d-50756daec5fd",
"name": "Get File Metadata - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"resource": "fileFolder",
"queryString": "*",
"returnAll": true,
"filter": {
"folderId": {
"__rl": true,
"value": "={{ $json.id }}",
"mode": "id"
}
},
"options": {}
},
"id": "47205665-88e2-401e-a876-f6b9ca3da1a4",
"name": "Search files and folders - Text",
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
-2464,
1072
],
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "download",
"fileId": {
"__rl": true,
"value": "={{ $json.id }}",
"mode": "id"
},
"options": {}
},
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
-2208,
1072
],
"id": "5ead6472-7e44-4564-8f5b-643f00bb3fb7",
"name": "Download Drive File - Text",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1RMKBn30Fupnj-cIIC_fR0dN8PXutCKhZ",
"mode": "list",
"cachedResultName": "B",
"cachedResultUrl": "https://drive.google.com/drive/folders/1RMKBn30Fupnj-cIIC_fR0dN8PXutCKhZ"
},
"event": "fileUpdated",
"options": {
"fileType": "all"
}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3616,
-976
],
"id": "1d726d0e-b67c-42ab-8d01-c2eec273eb46",
"name": "Google Drive Trigger (B) - Image",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1rrFtRwuiiK6Y6WAuSaweGsMgVH-sqjoy",
"mode": "list",
"cachedResultName": "C",
"cachedResultUrl": "https://drive.google.com/drive/folders/1rrFtRwuiiK6Y6WAuSaweGsMgVH-sqjoy"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3616,
-800
],
"id": "ae236eef-9414-49fe-a8dd-caed4586509a",
"name": "Google Drive Trigger (C) - Image",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1IRgTR4ahn5DDGuiji3mSL94OTeHEyAui",
"mode": "list",
"cachedResultName": "D",
"cachedResultUrl": "https://drive.google.com/drive/folders/1IRgTR4ahn5DDGuiji3mSL94OTeHEyAui"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3616,
-624
],
"id": "34e1eb1e-3fc6-47dc-a315-72700e074189",
"name": "Google Drive Trigger (D) - Image",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1OWdxpEEc5d6UzXumaTCuwzdnmBZVQCi2",
"mode": "list",
"cachedResultName": "E",
"cachedResultUrl": "https://drive.google.com/drive/folders/1OWdxpEEc5d6UzXumaTCuwzdnmBZVQCi2"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3616,
-448
],
"id": "4c86b224-b48f-4dca-8843-afb292b52fbe",
"name": "Google Drive Trigger (E) - Image",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1FQJB48L1gyf0CEXgxj0o8kW6IaeMdHBd",
"mode": "list",
"cachedResultName": "F",
"cachedResultUrl": "https://drive.google.com/drive/folders/1FQJB48L1gyf0CEXgxj0o8kW6IaeMdHBd"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3616,
-256
],
"id": "78bb0db3-e20d-437e-8240-0654ce6a3730",
"name": "Google Drive Trigger (F) - Image",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1Q-ND07j0klS1Dz2AhRIUT4rOuJPxcmdk",
"mode": "list",
"cachedResultName": "G",
"cachedResultUrl": "https://drive.google.com/drive/folders/1Q-ND07j0klS1Dz2AhRIUT4rOuJPxcmdk"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3616,
-80
],
"id": "a0636e73-f442-42fb-90bd-65ba9a11ae99",
"name": "Google Drive Trigger (G) - Image",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyWeek"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "1EdNbm4tHJO_XeQJ6JRrzAFFm3XezMIT2",
"mode": "list",
"cachedResultName": "H",
"cachedResultUrl": "https://drive.google.com/drive/folders/1EdNbm4tHJO_XeQJ6JRrzAFFm3XezMIT2"
},
"event": "fileUpdated",
"options": {}
},
"type": "n8n-nodes-base.googleDriveTrigger",
"typeVersion": 1,
"position": [
-3616,
112
],
"id": "6c4f5e7d-742f-4904-b064-fb11fa1a04c7",
"name": "Google Drive Trigger (H) - Image",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-b",
"type": "string"
},
{
"id": "37323b0e-3c37-4d4e-b74c-dcb56ed198ca",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3344,
-976
],
"id": "bc27413d-c8f9-4c2c-bf6b-d10beb5ded7f",
"name": "Superbase Bucket (code_b) - Image"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-c",
"type": "string"
},
{
"id": "2998ce44-55e9-4404-b2aa-6247ce2b378e",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3344,
-800
],
"id": "2aa67fcd-5f0d-4152-bf50-92480d7c179f",
"name": "Superbase Bucket (code_c) - Image"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-d",
"type": "string"
},
{
"id": "6d120749-d748-4dba-af49-29ac572c5fe6",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3344,
-624
],
"id": "f6ef704a-d2a0-458c-8667-b67145600253",
"name": "Superbase Bucket (code_d) - Image"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-e",
"type": "string"
},
{
"id": "791a3f88-f902-44c1-a764-9e9234e0dd87",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3344,
-448
],
"id": "cc968ba0-3621-4644-b850-76a3df531fa6",
"name": "Superbase Bucket (code_e) - Image"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-f",
"type": "string"
},
{
"id": "db6318eb-b8f6-4737-b88e-a84189e8f04d",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3344,
-256
],
"id": "34175fa0-1dd0-4948-81ae-c850d4db892c",
"name": "Superbase Bucket (code_f) - Image"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-g",
"type": "string"
},
{
"id": "f5e143db-043e-4da6-9df2-e8493c169398",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3344,
-80
],
"id": "7fc58e18-3203-46ac-aba7-25a3ac41091a",
"name": "Superbase Bucket (code_g) - Image"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a1a0c1b9-247a-47a2-8ada-eb34bcb2a6cd",
"name": "superbase_base_url",
"value": "https://evxduxdszbxukcjocizl.supabase.co",
"type": "string"
},
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "code-h",
"type": "string"
},
{
"id": "8cd7560d-c6cf-477e-97a3-0cab98fc6ccc",
"name": "folder_id",
"value": "={{ $json.parents[0] }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3344,
112
],
"id": "694206ed-bfa8-48a7-878a-40b8f7d52c98",
"name": "Superbase Bucket (code_h) - Image"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a0bbccc7-3be2-4ab9-9d13-0e24a4606d84",
"name": "superbase_storage_bucket_name",
"value": "={{ $json.superbase_storage_bucket_name }}",
"type": "string"
},
{
"id": "6d120749-d748-4dba-af49-29ac572c5fe6",
"name": "folder_id",
"value": "={{ $json.folder_id }}",
"type": "string"
},
{
"id": "b765ed82-2930-47fb-838f-869bfd43f3df",
"name": "superbase_base_url",
"value": "={{ $json.superbase_base_url }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
-3024,
-448
],
"id": "e5741ec3-46db-42aa-8b85-20437f4ae7a1",
"name": "Superbase Bucket - Image"
},
{
"parameters": {
"content": "**NOTE:** Code node is setup so that it adds uploaded image url (of superbase) into the markdown so that when ai agent retrieves the markdown it can directly render the retrieved image with annotation below.",
"width": 260,
"color": 4
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
1040,
-640
],
"id": "3da6dc09-9923-4545-bd2e-71722f28785a",
"name": "Sticky Note5"
},
{
"parameters": {
"content": "**NOTE**: Code node is setup so that the image annotation is also combined into the markdown as context for retrieval.",
"height": 120,
"width": 220,
"color": 4
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-1168,
928
],
"id": "abcee77f-cfbc-4d93-9158-9cf89670d547",
"name": "Sticky Note7"
},
{
"parameters": {
"content": "**NOTE**: Extracts relevant triggered bucket name and folder id to access later in the flow. (as well as to access and download files from the triggered folder.)",
"width": 200,
"color": 4
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-3024,
-624
],
"id": "bd9916ad-713b-4694-ac5a-bd8ea2cc775b",
"name": "Sticky Note8"
},
{
"parameters": {
"jsCode": "// take each page, remove all Markdown image refs, return cleaned items\nreturn items.map(item => {\n const pages = item.json.pages?.map(page => {\n page.markdown = page.markdown.replace(/!\\[.*?\\]\\(.*?\\)/g, '');\n return page;\n });\n return {\n json: {\n ...item.json,\n pages,\n }\n };\n});\n"
},
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
-1328,
1072
],
"id": "bb9b97dc-eac5-43d8-a4f6-7d8d3b2840c4",
"name": "Clean markdown"
}
],
"connections": {
"HTTP Request-Upload file to Mistral": {
"main": [
[
{
"node": "HTTP Request Get signed URL",
"type": "main",
"index": 0
}
]
]
},
"HTTP Request Get signed URL": {
"main": [
[
{
"node": "HTTP Request Image BBox Annotation",
"type": "main",
"index": 0
}
]
]
},
"HTTP Request Image BBox Annotation": {
"main": [
[
{
"node": "Clean markdown",
"type": "main",
"index": 0
}
]
]
},
"Split Out - by pages": {
"main": [
[
{
"node": "Code",
"type": "main",
"index": 0
}
]
]
},
"Code": {
"main": [
[
{
"node": "Supabase Vector Store",
"type": "main",
"index": 0
}
]
]
},
"Default Data Loader1": {
"ai_document": [
[
{
"node": "Supabase Vector Store",
"type": "ai_document",
"index": 0
}
]
]
},
"Recursive Character Text Splitter1": {
"ai_textSplitter": [
[
{
"node": "Default Data Loader1"
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
googleDriveOAuth2ApimistralCloudApiopenAiApisupabaseApi
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
How this works
This workflow streamlines the ingestion of documents into a retrieval-augmented generation system, enabling seamless access to your data for AI-powered queries without manual setup. It's ideal for developers and teams building knowledge bases or chatbots that need to reference private files like PDFs or images from Google Drive. The key step involves splitting and embedding content using the recursive character text splitter and OpenAI embeddings before storing it efficiently in Supabase's vector database, ensuring quick retrieval for enhanced responses.
Use this when automating the upload and processing of unstructured data from cloud storage to fuel RAG applications, particularly for event-driven scenarios like new file arrivals. Avoid it for simple databases without AI needs, as the 73-node complexity suits advanced vector search setups only. Common variations include swapping Supabase for Pinecone or adding custom preprocessing for specific file types like annotated images.
About this workflow
RAG_Ingest. Uses httpRequest, vectorStoreSupabase, documentDefaultDataLoader, textSplitterRecursiveCharacterTextSplitter. Event-driven trigger; 73 nodes.
Source: https://github.com/Userdflt/YWS_Portfolio.github.io/blob/c12e417bb42d93b556d4fa5445f4b9406912ce31/n8n/RAG_Ingest.json — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
This n8n template automatically classifies incoming emails (Sales, Support, Internal, Finance, Promotions) and routes them to a dedicated OpenAI LLM Agent for processing. Depending on the category, th
OpenAI, Gmail, Text Classifier +16
Automate Outreach Prospect automates finding, enriching, and messaging potential partners (like restaurants, malls, and bars) using Apify Google Maps scraping, Perplexity enrichment, OpenAI LLMs, Goog
@Devlikeapro/N8N Nodes Waha, Google Drive Trigger, @Apify/N8N Nodes Apify +14
Chat with docs - 5minAI New version. Uses httpRequest, documentDefaultDataLoader, textSplitterRecursiveCharacterTextSplitter, embeddingsOpenAi. Event-driven trigger; 62 nodes.
HTTP Request, Document Default Data Loader, Text Splitter Recursive Character Text Splitter +10
I prepared a detailed guide that illustrates the entire process of building an AI agent using Supabase and Google Drive within N8N workflows.
HTTP Request, Document Default Data Loader, Text Splitter Recursive Character Text Splitter +10
Auto repost job with RAG is a workflow designed to automatically extract, process, and publish job listings from monitored sources using Google Drive, OpenAI, Supabase, and WordPress. This integration
Google Drive, Supabase Vector Store, OpenAI Embeddings +12
