This workflow follows the Agent → Documentdefaultdataloader recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "Security incidents",
"nodes": [
{
"parameters": {
"content": "Recibir XML del escaneo de NMAP, convertirlo, filtrarlo y mapearlo para procesamiento final.",
"height": 112,
"width": 304,
"color": 5
},
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
-464,
560
],
"id": "430143d9-4c4d-457c-8bba-d73502d867d9",
"name": "Sticky Note"
},
{
"parameters": {
"pollTimes": {
"item": [
{
"mode": "everyMinute"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"value": "13NpxBrNndvUDNFDP3VQCyN8FrltHEKY6",
"mode": "list",
"cachedResultName": "Store Seguridad",
"cachedResultUrl": "https://drive.google.com/drive/folders/13NpxBrNndvUDNFDP3VQCyN8FrltHEKY6"
},
"event": "fileCreated",
"options": {}
},
"id": "764793f7-eabe-485a-a1bc-38a4077ec2d6",
"name": "Google Drive Trigger",
"type": "n8n-nodes-base.googleDriveTrigger",
"position": [
-368,
-48
],
"typeVersion": 1,
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "download",
"fileId": {
"__rl": true,
"mode": "id",
"value": "={{ $json.id }}"
},
"options": {}
},
"id": "7f6cf6ac-51f7-412f-91a9-b21f6a375623",
"name": "Download file",
"type": "n8n-nodes-base.googleDrive",
"position": [
-160,
-48
],
"typeVersion": 3,
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"mode": "insert",
"pineconeIndex": {
"__rl": true,
"value": "services-sheet-data",
"mode": "list",
"cachedResultName": "services-sheet-data"
},
"options": {}
},
"id": "1f4eb5cf-7156-4da7-99dd-3904a6e01f09",
"name": "Pinecone Vector Store",
"type": "@n8n/n8n-nodes-langchain.vectorStorePinecone",
"position": [
432,
-48
],
"typeVersion": 1.3,
"credentials": {
"pineconeApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"textSplittingMode": "custom",
"options": {
"metadata": {
"metadataValues": [
{
"name": "file-name",
"value": "={{ $('Download file').item.json.name }}"
}
]
}
}
},
"id": "6c85d66d-71d6-45c9-82e8-02284e7127c1",
"name": "Default Data Loader",
"type": "@n8n/n8n-nodes-langchain.documentDefaultDataLoader",
"position": [
528,
160
],
"typeVersion": 1.1
},
{
"parameters": {
"chunkSize": 100,
"chunkOverlap": 20,
"options": {}
},
"id": "915d5b69-1614-492c-a139-3e13bb1c48ec",
"name": "Recursive Character Text Splitter1",
"type": "@n8n/n8n-nodes-langchain.textSplitterRecursiveCharacterTextSplitter",
"position": [
528,
320
],
"typeVersion": 1
},
{
"parameters": {
"model": "nvidia/nv-embed-v1",
"options": {}
},
"id": "7e0fd019-6e5f-4ca7-8906-19bdc0b85849",
"name": "Embeddings OpenAI1",
"type": "@n8n/n8n-nodes-langchain.embeddingsOpenAi",
"position": [
288,
272
],
"typeVersion": 1.2,
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"content": "### Procesamiento de documentos & Embeddings\n\nMonitorea la carpeta \"Store Seguridad\" en Google Drive cada minuto. Al detectar un archivo nuevo, lo descarga, extrae el texto del PDF y lo vectoriza usando el modelo nvidia/nv-embed-v1. Los chunks se insertan en el \u00edndice services-sheet-data de Pinecone con el nombre del archivo como metadato.\nUna vez procesado, el archivo se mueve autom\u00e1ticamente a \"Store Seguridad Procesados\" para evitar reprocesamiento.",
"height": 256,
"width": 752,
"color": 5
},
"id": "9776ee1f-b7b5-4e27-aa2c-666b1c20dfaa",
"name": "Sticky Note1",
"type": "n8n-nodes-base.stickyNote",
"position": [
-400,
-368
],
"typeVersion": 1
},
{
"parameters": {
"operation": "pdf",
"options": {}
},
"type": "n8n-nodes-base.extractFromFile",
"typeVersion": 1.1,
"position": [
96,
-48
],
"id": "53449d2f-c16d-40a0-a81d-52aec676983d",
"name": "Extract from File"
},
{
"parameters": {
"operation": "move",
"fileId": {
"__rl": true,
"value": "={{ $('Google Drive Trigger').item.json.id }}",
"mode": "id"
},
"driveId": {
"__rl": true,
"mode": "list",
"value": "My Drive"
},
"folderId": {
"__rl": true,
"value": "1JBOObm5gHj90LRoXTSa2FCXoa_XLYRDs",
"mode": "list",
"cachedResultName": "Store Seguridad Procesados",
"cachedResultUrl": "https://drive.google.com/drive/folders/1JBOObm5gHj90LRoXTSa2FCXoa_XLYRDs"
}
},
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
784,
-48
],
"id": "3b9b57e9-5d37-4f84-8aa4-db15526a7274",
"name": "Move file",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"httpMethod": "POST",
"path": "scan-results",
"responseMode": "responseNode",
"options": {
"rawBody": true
}
},
"type": "n8n-nodes-base.webhook",
"typeVersion": 2.1,
"position": [
-512,
752
],
"id": "dac6f73a-f31f-45ef-b6b6-333a0afaf3c3",
"name": "01 - Webhook Receptor",
"alwaysOutputData": true
},
{
"parameters": {
"mode": "retrieve-as-tool",
"toolDescription": "Utiliza esta herramienta para consultar informaci\u00f3n t\u00e9cnica, vulnerabilidades conocidas, riesgos asociados y recomendaciones de seguridad sobre servicios, productos y versiones detectadas en el escaneo.",
"pineconeIndex": {
"__rl": true,
"value": "services-sheet-data",
"mode": "list",
"cachedResultName": "services-sheet-data"
},
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.vectorStorePinecone",
"typeVersion": 1.3,
"position": [
944,
864
],
"id": "c502b99d-f646-453d-b110-ae9c4d0b4340",
"name": "Pinecone Vector Store2",
"credentials": {
"pineconeApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"model": "nvidia/nv-embed-v1",
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.embeddingsOpenAi",
"typeVersion": 1.2,
"position": [
944,
1056
],
"id": "161b2b56-c995-462b-9780-57f3d3888690",
"name": "Embeddings OpenAI2",
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"model": {
"__rl": true,
"value": "openai/gpt-oss-20b",
"mode": "list",
"cachedResultName": "openai/gpt-oss-20b"
},
"builtInTools": {},
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.lmChatOpenAi",
"typeVersion": 1.3,
"position": [
720,
800
],
"id": "9bb6eb32-4ea4-4b8a-b87d-e96901f3f08c",
"name": "OpenAI Chat Model",
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict",
"version": 3
},
"conditions": [
{
"id": "c67a5b0c-153a-4344-91fe-417a3f83b789",
"leftValue": "={{ $json.headers['content-type'] }}",
"rightValue": "xml",
"operator": {
"type": "string",
"operation": "contains"
}
}
],
"combinator": "and"
},
"options": {}
},
"type": "n8n-nodes-base.if",
"typeVersion": 2.3,
"position": [
-288,
752
],
"id": "5235526f-9395-4d85-a9dd-8f679163f5a4",
"name": "02 - \u00bfContent-Type es XML?"
},
{
"parameters": {
"respondWith": "json",
"responseBody": "{\n \"error\": \"Se esperaba un archivo XML. Aseg\u00farate de enviar Content-Type: application/xml\"\n}",
"options": {}
},
"type": "n8n-nodes-base.respondToWebhook",
"typeVersion": 1.5,
"position": [
-64,
960
],
"id": "67ba2860-9302-4c42-829a-9d6229f78a67",
"name": "03 - Error 400: No es XML"
},
{
"parameters": {
"operation": "xml",
"options": {}
},
"type": "n8n-nodes-base.extractFromFile",
"typeVersion": 1.1,
"position": [
-64,
560
],
"id": "d2dcc293-e39c-4e55-8b0d-4aa185949768",
"name": "04 - XML texto a archivo"
},
{
"parameters": {
"jsCode": "// 1. Capturamos el texto crudo que viene de la IA\nlet rawText = $input.first().json.output[0].content[0].text\n\nif (!rawText) {\n throw new Error(\"No se recibi\u00f3 texto del nodo de IA anterior.\");\n}\n\n// 2. Limpiamos las marcas de c\u00f3digo Markdown (```json y ```) si existen\nrawText = rawText.replace(/```json/gi, '');\nrawText = rawText.replace(/```/g, '');\nrawText = rawText.trim();\n\n// 3. Convertimos esa cadena de texto limpia en un objeto JSON real de JavaScript\nconst objetoLimpio = JSON.parse(rawText);\n\n// 4. Se lo devolvemos a n8n para que el siguiente nodo lo lea de forma nativa\nreturn objetoLimpio;"
},
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
1936,
560
],
"id": "f279e7ee-60c1-4c79-9466-847ec7eeb5a5",
"name": "Code: Parsear Texto a JSON"
},
{
"parameters": {
"html": "<html>\n<head>\n<style>\n body { font-family: 'Segoe UI', Arial, sans-serif; color: #2D3748; padding: 45px; background-color: #ffffff; }\n .header { border-bottom: 4px solid #1A365D; padding-bottom: 15px; margin-bottom: 30px; display: flex; justify-content: space-between; align-items: center; }\n h1 { color: #1A365D; margin: 0; font-size: 26px; }\n h2 { color: #2C5282; margin-top: 30px; font-size: 20px; border-bottom: 2px solid #E2E8F0; padding-bottom: 5px; }\n \n /* Sistema de alertas visuales para el Estado Global */\n .status-box { padding: 8px 16px; border-radius: 6px; font-weight: bold; font-size: 14px; text-transform: uppercase; }\n .Critico { background: #FED7D7; color: #9B2C2C; }\n .Alerta { background: #FEEBC8; color: #9C4221; }\n .Seguro { background: #C6F6D5; color: #22543D; }\n \n /* Tabla de inventario */\n table { width: 100%; border-collapse: collapse; margin: 20px 0; }\n th { background: #F7FAFC; padding: 12px; text-align: left; border-bottom: 2px solid #CBD5E0; color: #4A5568; font-weight: 600; }\n td { padding: 12px; border-bottom: 1px solid #E2E8F0; font-size: 14px; }\n .port-badge { background: #EDF2F7; padding: 2px 6px; border-radius: 4px; font-family: monospace; font-size: 12px; }\n \n /* Tarjetas de Mitigaci\u00f3n por Host */\n .host-card { background: #F8FAFC; border: 1px solid #E2E8F0; padding: 20px; border-radius: 8px; margin-bottom: 20px; page-break-inside: avoid; }\n .host-card h3 { margin-top: 0; margin-bottom: 12px; color: #2B6CB0; font-size: 16px; }\n .section-title { font-weight: bold; color: #4A5568; margin-top: 8px; display: block; }\n</style>\n</head>\n<body>\n\n <div class=\"header\">\n <div>\n <h1>Reporte Consolidado de Vulnerabilidades</h1>\n <p style=\"margin: 5px 0 0 0; color: #718096;\">Analizador DevSecOps Automatizado | Fecha: <strong>{{ new Date().toLocaleDateString() }}</strong></p>\n </div>\n <div class=\"status-box {{ $json.estado_global }}\">\n Riesgo: {{ $json.estado_global }}\n </div>\n </div>\n\n <h2>1. Resumen Ejecutivo</h2>\n <p style=\"line-height: 1.6; font-size: 15px;\">{{ $json.resumen_ejecutivo }}</p>\n\n <h2>2. Inventario de Superficie de Ataque ({{ $json.conteo_hosts }} Hosts Detectados)</h2>\n <table>\n <thead>\n <tr>\n <th style=\"width: 25%;\">Direcci\u00f3n IP</th>\n <th style=\"width: 75%;\">Puertos y Servicios Identificados</th>\n </tr>\n </thead>\n <tbody>\n {{ $json.detalle_hosts.map(host => `\n <tr>\n <td><strong>${host.ip}</strong></td>\n <td><span class=\"port-badge\">${host.puertos}</span></td>\n </tr>\n `).join('') }}\n </tbody>\n </table>\n\n <div style=\"page-break-before: always;\"></div>\n\n <h2>3. Hallazgos y Planes de Mitigaci\u00f3n</h2>\n {{ $json.detalle_hosts.map(host => `\n <div class=\"host-card\">\n <h3>\ud83d\udea8 Host Destino: ${host.ip}</h3>\n <p><span class=\"section-title\">\ud83d\udd0d Hallazgos del Escaneo:</span> ${host.hallazgos}</p>\n <p><span class=\"section-title\">\ud83d\udee1\ufe0f Acciones de Mitigaci\u00f3n Requeridas:</span> ${host.mitigacion}</p>\n </div>\n `).join('') }}\n\n</body>\n</html>"
},
"type": "n8n-nodes-base.html",
"typeVersion": 1,
"position": [
2128,
560
],
"id": "c3b2bd9d-c4c3-4bc3-bc8c-26c0d8c684f5",
"name": "HTML: Renderizar Plantilla"
},
{
"parameters": {
"method": "POST",
"url": "https://api.pdfshift.io/v3/convert/pdf",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "X-API-Key",
"value": "sk_bd0870b03db031d43d928466e23b753b9890c2e5"
}
]
},
"sendBody": true,
"bodyParameters": {
"parameters": [
{
"name": "source",
"value": "={{ $json.html }}"
}
]
},
"options": {
"response": {
"response": {
"responseFormat": "file"
}
}
}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.4,
"position": [
2336,
560
],
"id": "188def6b-03f4-48e3-9aee-3bde6da79859",
"name": "API: PDFShift (HTML a PDF)"
},
{
"parameters": {
"name": "=Reporte_Auditoria_{{ $now.toFormat('yyyy_MM_dd') }}.pdf",
"driveId": {
"__rl": true,
"value": "My Drive",
"mode": "list",
"cachedResultName": "My Drive",
"cachedResultUrl": "https://drive.google.com/drive/my-drive"
},
"folderId": {
"__rl": true,
"value": "1waUel7x50pKeibn9EbfhJELr17A3KnkJ",
"mode": "list",
"cachedResultName": "reportes_Seguridad",
"cachedResultUrl": "https://drive.google.com/drive/folders/1waUel7x50pKeibn9EbfhJELr17A3KnkJ"
},
"options": {}
},
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
2544,
560
],
"id": "5d84ad6b-8b22-4698-b1dc-982df1391a84",
"name": "Drive: Guardar Reporte Diario",
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"modelId": {
"__rl": true,
"value": "gpt-4o-mini",
"mode": "list",
"cachedResultName": "GPT-4O-MINI"
},
"responses": {
"values": [
{
"role": "system",
"content": "=Act\u00faa como un extractor de datos de seguridad. Tu objetivo es resumir los resultados de la auditor\u00eda en un formato JSON estrictamente v\u00e1lido.\n\nDATOS A PROCESAR:\n{{ JSON.stringify($json) }}\n\nESTRUCTURA JSON REQUERIDA (Responde SOLO el JSON):\n{\n\"resumen_ejecutivo\": \"texto breve del estado general\",\n\"estado_global\": \"Seguro | Alerta | Cr\u00edtico\",\n\"conteo_hosts\": n\u00famero,\n\"detalle_hosts\": [\n{\n\"ip\": \"...\",\n\"puertos\": \"lista de puertos y servicios\",\n\"hallazgos\": \"resumen de 1 p\u00e1rrafo de vulnerabilidades\",\n\"mitigacion\": \"pasos exactos a seguir\"\n}\n]\n}\n\nSi un host no tiene problemas, en 'hallazgos' pon 'Sin vulnerabilidades detectadas'.\""
}
]
},
"builtInTools": {},
"options": {}
},
"type": "@n8n/n8n-nodes-langchain.openAi",
"typeVersion": 2.3,
"position": [
1632,
560
],
"id": "4f989c13-4016-4ce8-a913-012c1c0c0d06",
"name": "LLM: Redactar Resumen Ejecutivo",
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"aggregate": "aggregateAllItemData",
"options": {}
},
"id": "4cd9133a-fc50-45ea-a7fc-e5cc84f41c5e",
"name": "Aggregate: Unificar An\u00e1lisis",
"type": "n8n-nodes-base.aggregate",
"typeVersion": 1,
"position": [
1456,
560
],
"notes": "C3: Espera que TODOS los hosts terminen de procesarse y los une en un array. Sin este nodo no hay resumen global."
},
{
"parameters": {
"authentication": "oAuth2",
"select": "channel",
"channelId": {
"__rl": true,
"value": "C0BA0NFJXB8",
"mode": "list",
"cachedResultName": "incidentes"
},
"text": "={{ $json.output }}",
"otherOptions": {
"mrkdwn": true
}
},
"type": "n8n-nodes-base.slack",
"typeVersion": 2.5,
"position": [
1216,
560
],
"id": "d867505c-8185-42bd-aab6-d460876b1604",
"name": "Slack: Notificar Canal Interno",
"credentials": {
"slackOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"promptType": "define",
"text": "=Eres un analista experto en ciberseguridad ofensiva y defensiva. Tu tarea es analizar un host espec\u00edfico de un reporte Nmap.\nJSON DEL HOST:\n{{ JSON.stringify($json) }}\n\nREGLAS DE FORMATO (Usa Markdown de Slack):\n- Usa emojis para jerarquizar.\n- Usa negritas (*) para conceptos clave y guiones (-) para las listas. pero los * deben ir pegado a cada letra, nada de espacio\n- Separa las secciones con una l\u00ednea de guiones (-----).\n- No uses tablas complejas, usa listas con vi\u00f1etas.\n\n---\n\ud83d\udea8 REPORTE DE AUDITOR\u00cdA: {{ $json.hosts.ip }} \ud83d\udea8\nFecha: {{ $json.scan_date }}\n---------------------------------------------------\n\ud83d\udd0d An\u00e1lisis de Superficie de Ataque:\n\n\ud83d\udcbb Puertos de Sistema:\n(Lista aqu\u00ed los servicios cr\u00edticos detectados)\n\n\ud83d\uddc4\ufe0f Bases de Datos:\n(Lista aqu\u00ed los servicios de BD y riesgos)\n\n\ud83c\udf10 Servicios Web:\n(Lista aqu\u00ed los servicios web y versiones)\n\n\u26a0\ufe0f Riesgo Global:* [ALTO/MEDIO/BAJO]\n\ud83d\udee0 Acciones Prioritarias:\n- (Recomendaci\u00f3n 1)\n- (Recomendaci\u00f3n 2)",
"options": {
"systemMessage": "IMPORTANTE: Si la informaci\u00f3n t\u00e9cnica de Pinecone no menciona vulnerabilidades espec\u00edficas para una versi\u00f3n, no inventes riesgos; clasifica bas\u00e1ndote \u00fanicamente en la exposici\u00f3n del puerto"
}
},
"type": "@n8n/n8n-nodes-langchain.agent",
"typeVersion": 3.1,
"position": [
832,
560
],
"id": "f895385c-8e3d-4bd1-98cf-fff872570f72",
"name": "Agent: Analista de Seguridad"
},
{
"parameters": {
"fieldToSplitOut": "hosts",
"include": "allOtherFields",
"options": {}
},
"type": "n8n-nodes-base.splitOut",
"typeVersion": 1,
"position": [
560,
560
],
"id": "59cef263-2bec-4318-9d4e-b087c4950f67",
"name": "Loop: Separar por Host Afectado"
},
{
"parameters": {
"jsCode": "function extractIPWithMask(command) {\n const match = command.match(/\\b(\\d{1,3}(?:\\.\\d{1,3}){3}(?:\\/\\d{1,2})?)\\b/);\n return match ? match[1] : null;\n}\n\nconst nmapData = $input.first().json.nmaprun;\n\nif (!nmapData) {\n throw new Error('El XML no tiene formato nmap v\u00e1lido');\n}\n\nreturn {\n scan_date: nmapData?.startstr,\n network: extractIPWithMask(nmapData?.args),\n\n hosts: (nmapData?.host || [])\n .map(host => {\n const address = host.address;\n\n let ipItem;\n\n if (Array.isArray(address)) {\n ipItem = address.find(h => h.addrtype === \"ipv4\")?.addr;\n } else {\n ipItem = address?.addr;\n }\n\n const openPorts = host.ports?.port || [];\n\n const mappedOpenPorts = openPorts\n .filter(port => port.state?.state === 'open')\n .map(port => ({\n state: port.state?.state,\n port: port.portid,\n protocol: port.protocol,\n service: port.service?.name,\n product: port.service?.product,\n cpe: port.service?.cpe,\n ostype: port.service?.ostype\n }));\n\n return {\n ip: ipItem,\n openPorts: mappedOpenPorts\n };\n })\n\n // ELIMINA hosts sin puertos abiertos\n .filter(host => host.openPorts.length > 0)\n};"
},
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
336,
560
],
"id": "a4b00450-9e5c-4b91-82b5-6e29a274680a",
"name": "code: Limpieza y Filtro Nmap"
},
{
"parameters": {
"options": {
"mergeAttrs": true
}
},
"type": "n8n-nodes-base.xml",
"typeVersion": 1,
"position": [
128,
560
],
"id": "623a69fa-b196-4f28-b4ae-9e9256cfc103",
"name": "XML archivo a JSON"
},
{
"parameters": {
"authentication": "oAuth2",
"select": "channel",
"channelId": {
"__rl": true,
"value": "C0BA0NFJXB8",
"mode": "list",
"cachedResultName": "incidentes"
},
"text": "==\ud83d\ude80 *Auditor\u00eda Finalizada con \u00c9xito* El an\u00e1lisis consolidado de la infraestructura ha terminado.\n\ud83d\udcc2 *Reporte:* `{{ $json.name }}`\n\ud83d\udd17 *Enlace en Drive:* {{ $json.webContentLink }}",
"otherOptions": {
"mrkdwn": true
}
},
"id": "b14886b5-0567-4800-8754-4d3d22795823",
"name": "C7 - Slack: Mensaje Cierre",
"type": "n8n-nodes-base.slack",
"typeVersion": 2.5,
"position": [
2800,
560
],
"credentials": {
"slackOAuth2Api": {
"name": "<your credential>"
}
},
"notes": "C7: Mensaje de cierre en Slack con estad\u00edsticas globales y resumen ejecutivo generado por IA."
}
],
"connections": {
"Google Drive Trigger": {
"main": [
[
{
"node": "Download file",
"type": "main",
"index": 0
}
]
]
},
"Download file": {
"main": [
[
{
"node": "Extract from File",
"type": "main",
"index": 0
}
]
]
},
"Pinecone Vector Store": {
"main": [
[
{
"node": "Move file",
"type": "main",
"index": 0
}
]
]
},
"Default Data Loader": {
"ai_document": [
[
{
"node": "Pinecone Vector Store",
"type": "ai_document",
"index": 0
}
]
]
},
"Recursive Character Text Splitter1": {
"ai_textSplitter": [
[
{
"node": "Default Data Loader",
"type": "ai_textSplitter",
"index": 0
}
]
]
},
"Embeddings OpenAI1": {
"ai_embedding": [
[
{
"node": "Pinecone Vector Store",
"type": "ai_embedding",
"index": 0
}
]
]
},
"Extract from File": {
"main": [
[
{
"node": "Pinecone Vector Store",
"type": "main",
"index": 0
}
]
]
},
"01 - Webhook Receptor": {
"main": [
[
{
"node": "02 - \u00bfContent-Type es XML?",
"type": "main",
"index": 0
}
]
]
},
"Pinecone Vector Store2": {
"ai_tool": [
[
{
"node": "Agent: Analista de Seguridad",
"type": "ai_tool",
"index": 0
}
]
]
},
"Embeddings OpenAI2": {
"ai_embedding": [
[
{
"node": "Pinecone Vector Store2",
"type": "ai_embedding",
"index": 0
}
]
]
},
"OpenAI Chat Model": {
"ai_languageModel": [
[
{
"node": "Agent: Analista de Seguridad",
"type": "ai_languageModel",
"index": 0
}
]
]
},
"02 - \u00bfContent-Type es XML?": {
"main": [
[
{
"node": "04 - XML texto a archivo",
"type": "main",
"index": 0
}
],
[
{
"node": "03 - Error 400: No es XML",
"type": "main",
"index": 0
}
]
]
},
"04 - XML texto a archivo": {
"main": [
[
{
"node": "XML archivo a JSON",
"type": "main",
"index": 0
}
]
]
},
"Code: Parsear Texto a JSON": {
"main": [
[
{
"node": "HTML: Renderizar Plantilla",
"type": "main",
"index": 0
}
]
]
},
"HTML: Renderizar Plantilla": {
"main": [
[
{
"node": "API: PDFShift (HTML a PDF)",
"type": "main",
"index": 0
}
]
]
},
"API: PDFShift (HTML a PDF)": {
"main": [
[
{
"node": "Drive: Guardar Reporte Diario",
"type": "main",
"index": 0
}
]
]
},
"LLM: Redactar Resumen Ejecutivo": {
"main": [
[
{
"node": "Code: Parsear Texto a JSON",
"type": "main",
"index": 0
}
]
]
},
"Aggregate: Unificar An\u00e1lisis": {
"main": [
[
{
"node": "LLM: Redactar Resumen Ejecutivo",
"type": "main",
"index": 0
}
]
]
},
"Slack: Notificar Canal Interno": {
"main": [
[
{
"node": "Aggregate: Unificar An\u00e1lisis",
"type": "main",
"index": 0
}
]
]
},
"Agent: Analista de Seguridad": {
"main": [
[
{
"node": "Slack: Notificar Canal Interno",
"type": "main",
"index": 0
}
]
]
},
"Loop: Separar por Host Afectado": {
"main": [
[
{
"node": "Agent: Analista de Seguridad",
"type": "main",
"index": 0
}
]
]
},
"code: Limpieza y Filtro Nmap": {
"main": [
[
{
"node": "Loop: Separar por Host Afectado",
"type": "main",
"index": 0
}
]
]
},
"XML archivo a JSON": {
"main": [
[
{
"node": "code: Limpieza y Filtro Nmap",
"type": "main",
"index": 0
}
]
]
},
"Drive: Guardar Reporte Diario": {
"main": [
[
{
"node": "C7 - Slack: Mensaje Cierre",
"type": "main",
"index": 0
}
]
]
}
},
"active": true,
"settings": {
"executionOrder": "v1",
"binaryMode": "separate",
"availableInMCP": false,
"timeSavedMode": "fixed",
"errorWorkflow": "x64sO6x67AiqtQGp",
"callerPolicy": "workflowsFromSameOwner"
},
"versionId": "5afa7a49-c50b-4e29-a30f-fe6bd6ecafac",
"meta": {
"templateCredsSetupCompleted": true
},
"nodeGroups": [],
"id": "olsp8QHULHlVOQbx",
"tags": []
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
googleDriveOAuth2ApiopenAiApipineconeApislackOAuth2Api
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
Security incidents. Uses googleDriveTrigger, googleDrive, vectorStorePinecone, documentDefaultDataLoader. Event-driven trigger; 29 nodes.
Source: https://github.com/sbsmrth/VulnTriage/blob/d51bb54e538991f4a79d63f5698955b85538582c/workflow/flujo_principal.json — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
Alfred (funcional). Uses gmailTool, googleCalendarTool, gmail, embeddingsOpenAi. Event-driven trigger; 83 nodes.
Gmail Tool, Google Calendar Tool, Gmail +24
Your AI workforce is ready. Are you?
Google Sheets Tool, Mcp Trigger, Google Drive +29
This comprehensive workflow bundle is designed as a powerful starter kit, enabling you to build a multi-functional AI assistant on Telegram. It seamlessly integrates AI-powered voice interactions, an
Telegram Trigger, Telegram, OpenAI +19
Agent IA Projet Client. Uses executeWorkflowTrigger, lmChatOpenAi, toolWorkflow, vectorStoreQdrant. Event-driven trigger; 79 nodes.
Execute Workflow Trigger, OpenAI Chat, Tool Workflow +16
This intelligent chatbot leverages cutting-edge financial APIs and AI-driven analysis to deliver comprehensive stock research reports. Get instant access to professional-grade investment analysis that
Tool Think, Supabase Vector Store, OpenAI Embeddings +15
