This workflow follows the Documentdefaultdataloader → OpenAI Embeddings recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "WceMkVib0VLlF1BZ",
"meta": {
"templateCredsSetupCompleted": true
},
"name": "Vector DB Loader from Google Drive",
"tags": [
{
"id": "6rb8rVhKZj4t0Kne",
"name": "Current",
"createdAt": "2025-02-04T18:13:17.427Z",
"updatedAt": "2025-02-04T18:13:17.427Z"
}
],
"nodes": [
{
"id": "6652e41a-d14a-4e17-9dcd-34df114d219a",
"name": "Default Data Loader",
"type": "@n8n/n8n-nodes-langchain.documentDefaultDataLoader",
"position": [
1240,
1100
],
"parameters": {
"options": {}
},
"typeVersion": 1
},
{
"id": "8ae38b72-52fd-46bc-ab47-50bebe5ac4ee",
"name": "Recursive Character Text Splitter",
"type": "@n8n/n8n-nodes-langchain.textSplitterRecursiveCharacterTextSplitter",
"position": [
1320,
1300
],
"parameters": {
"options": {},
"chunkOverlap": 50
},
"typeVersion": 1
},
{
"id": "57ce64af-88d4-4dc4-8c8e-01717c1bd47d",
"name": "Embeddings OpenAI",
"type": "@n8n/n8n-nodes-langchain.embeddingsOpenAi",
"position": [
1120,
1100
],
"parameters": {
"model": "text-embedding-3-small",
"options": {}
},
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "e6bed8bc-f629-41fd-aa6e-9158b1cbc323",
"name": "Postgres PGVector Store",
"type": "@n8n/n8n-nodes-langchain.vectorStorePGVector",
"position": [
1140,
880
],
"parameters": {
"mode": "insert",
"options": {
"collection": {
"values": {
"useCollection": true,
"collectionName": "n8n_wfs"
}
}
},
"tableName": "n8n_vectors_wfs"
},
"credentials": {
"postgres": {
"name": "<your credential>"
}
},
"typeVersion": 1.1
},
{
"id": "96fbc1f3-920d-44c9-9314-742efa3a698a",
"name": "When clicking \u2018Test workflow\u2019",
"type": "n8n-nodes-base.manualTrigger",
"position": [
-280,
740
],
"parameters": {},
"typeVersion": 1
},
{
"id": "4cd7a934-04cc-47b5-a771-db554680ba77",
"name": "Loop Over Items",
"type": "n8n-nodes-base.splitInBatches",
"position": [
160,
740
],
"parameters": {
"options": {}
},
"typeVersion": 3
},
{
"id": "778593d8-fe1c-4eb9-865a-e6ce9ed5f900",
"name": "Move File",
"type": "n8n-nodes-base.googleDrive",
"position": [
1500,
880
],
"parameters": {
"fileId": {
"__rl": true,
"mode": "id",
"value": "={{ $('Loop Over Items').item.json.id }}"
},
"driveId": {
"__rl": true,
"mode": "list",
"value": "My Drive"
},
"folderId": {
"__rl": true,
"mode": "list",
"value": "1Re6vg-PZxBoUU6sTRDbGs-77bAJ40u8F",
"cachedResultUrl": "https://drive.google.com/drive/folders/1Re6vg-PZxBoUU6sTRDbGs-77bAJ40u8F",
"cachedResultName": "vectorized"
},
"operation": "move"
},
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 3
},
{
"id": "3a6584f5-ed86-4900-9177-40ffe82d0ad3",
"name": "Download File",
"type": "n8n-nodes-base.googleDrive",
"position": [
380,
680
],
"parameters": {
"fileId": {
"__rl": true,
"mode": "id",
"value": "={{ $json.id }}"
},
"options": {},
"operation": "download"
},
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 3
},
{
"id": "e1931ab6-4391-46c3-9d7d-22cbfbf90327",
"name": "Search Folder",
"type": "n8n-nodes-base.googleDrive",
"position": [
-60,
740
],
"parameters": {
"filter": {
"folderId": {
"__rl": true,
"mode": "list",
"value": "1mBHrP8UzUnfn3dj_3QS1r0XhQQyVPAGX",
"cachedResultUrl": "https://drive.google.com/drive/folders/1mBHrP8UzUnfn3dj_3QS1r0XhQQyVPAGX",
"cachedResultName": "n8n Workflow JSON Files"
},
"whatToSearch": "files"
},
"options": {},
"resource": "fileFolder",
"returnAll": true
},
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 3
},
{
"id": "95134ab4-806f-4c47-96a6-e261b3176ebf",
"name": "Schedule Trigger",
"type": "n8n-nodes-base.scheduleTrigger",
"position": [
-280,
940
],
"parameters": {
"rule": {
"interval": [
{
"triggerAtHour": 3
}
]
}
},
"typeVersion": 1.2
},
{
"id": "0fe604ed-e886-4aa3-856f-c46fb79ce0de",
"name": "Sticky Note",
"type": "n8n-nodes-base.stickyNote",
"position": [
1700,
960
],
"parameters": {
"color": 7,
"width": 380,
"height": 240,
"content": "## Creative Commons License\n*License*: **Creative Commons Attribution-ShareAlike 4.0 International** (CC BY-SA 4.0)\n\n*Author*: **AlexK1919**\nYou are free to use, adapt, and share this workflow\u2014even commercially\u2014under the terms of this license.\n\nFull license details: https://creativecommons.org/licenses/by-sa/4.0/"
},
"typeVersion": 1
},
{
"id": "f8055452-b487-46c7-92fe-14b3c88d193f",
"name": "Switch",
"type": "n8n-nodes-base.switch",
"position": [
560,
680
],
"parameters": {
"rules": {
"values": [
{
"outputKey": "pdf",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "7b4e792b-ab6d-4b9b-88a1-d8e51bea6853",
"operator": {
"type": "string",
"operation": "equals"
},
"leftValue": "={{$binary[\"data\"].mimeType}}",
"rightValue": "application/pdf"
}
]
},
"renameOutput": true
},
{
"outputKey": "text",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "09b7d7c5-5353-4719-b4e2-072e4da39948",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{$binary[\"data\"].mimeType}}",
"rightValue": "text/plain"
}
]
},
"renameOutput": true
},
{
"outputKey": "json",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "d2763a45-a592-47c8-868f-59dfcd17a71c",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{$binary[\"data\"].mimeType}}",
"rightValue": "application/json"
}
]
},
"renameOutput": true
}
]
},
"options": {}
},
"typeVersion": 3.2
},
{
"id": "c704f48e-a1f5-4539-bde2-545862d21bc6",
"name": "Extract from PDF",
"type": "n8n-nodes-base.extractFromFile",
"position": [
780,
480
],
"parameters": {
"options": {},
"operation": "pdf"
},
"typeVersion": 1
},
{
"id": "63b3a751-5726-4821-8379-72af15226584",
"name": "Extract from Text",
"type": "n8n-nodes-base.extractFromFile",
"position": [
780,
680
],
"parameters": {
"options": {},
"operation": "text"
},
"typeVersion": 1
},
{
"id": "44a5980a-17aa-4a09-8040-a7d9804c7998",
"name": "Extract from JSON",
"type": "n8n-nodes-base.extractFromFile",
"position": [
780,
880
],
"parameters": {
"options": {},
"operation": "fromJson"
},
"typeVersion": 1
}
],
"active": false,
"settings": {
"timezone": "America/Los_Angeles",
"callerPolicy": "workflowsFromSameOwner",
"errorWorkflow": "lYgdNzdEapw2W8gK",
"executionOrder": "v1"
},
"versionId": "4f54c70a-b18b-4e4c-8959-ace70dd41218",
"connections": {
"Switch": {
"main": [
[
{
"node": "Extract from PDF",
"type": "main",
"index": 0
}
],
[
{
"node": "Extract from Text",
"type": "main",
"index": 0
}
],
[
{
"node": "Extract from JSON",
"type": "main",
"index": 0
}
]
]
},
"Move File": {
"main": [
[
{
"node": "Loop Over Items",
"type": "main",
"index": 0
}
]
]
},
"Download File": {
"main": [
[
{
"node": "Switch",
"type": "main",
"index": 0
}
]
]
},
"Search Folder": {
"main": [
[
{
"node": "Loop Over Items",
"type": "main",
"index": 0
}
]
]
},
"Loop Over Items": {
"main": [
[],
[
{
"node": "Download File",
"type": "main",
"index": 0
}
]
]
},
"Extract from PDF": {
"main": [
[
{
"node": "Postgres PGVector Store",
"type": "main",
"index": 0
}
]
]
},
"Schedule Trigger": {
"main": [
[
{
"node": "Search Folder",
"type": "main",
"index": 0
}
]
]
},
"Embeddings OpenAI": {
"ai_embedding": [
[
{
"node": "Postgres PGVector Store",
"type": "ai_embedding",
"index": 0
}
]
]
},
"Extract from JSON": {
"main": [
[
{
"node": "Postgres PGVector Store",
"type": "main",
"index": 0
}
]
]
},
"Extract from Text": {
"main": [
[
{
"node": "Postgres PGVector Store",
"type": "main",
"index": 0
}
]
]
},
"Default Data Loader": {
"ai_document": [
[
{
"node": "Postgres PGVector Store",
"type": "ai_document",
"index": 0
}
]
]
},
"Postgres PGVector Store": {
"main": [
[
{
"node": "Move File",
"type": "main",
"index": 0
}
]
]
},
"Recursive Character Text Splitter": {
"ai_textSplitter": [
[
{
"node": "Default Data Loader",
"type": "ai_textSplitter",
"index": 0
}
]
]
},
"When clicking \u2018Test workflow\u2019": {
"main": [
[
{
"node": "Search Folder",
"type": "main",
"index": 0
}
]
]
}
}
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
googleDriveOAuth2ApiopenAiApipostgres
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
How this works
This workflow effortlessly transforms documents from your Google Drive into searchable vectors in a PostgreSQL database using PGVector, enabling rapid AI-powered queries and semantic searches across your content. It's ideal for knowledge workers, researchers, or developers building RAG applications who need to index files like PDFs or docs without manual hassle. The key step involves loading and splitting the documents with the default data loader and recursive text splitter, then generating embeddings via OpenAI before storing them efficiently in the vector database.
Use this workflow when you have unstructured files in Google Drive that require periodic vectorisation for AI retrieval, such as updating a chatbot's knowledge base after adding new reports. Avoid it for real-time processing of massive datasets, where a more scalable solution like batch jobs would suit better, or if your files are already in a structured format needing no splitting. Common variations include swapping OpenAI for alternative embeddings providers or integrating with cloud storage like Dropbox for broader file sourcing.
About this workflow
Vector DB Loader from Google Drive. Uses documentDefaultDataLoader, textSplitterRecursiveCharacterTextSplitter, embeddingsOpenAi, vectorStorePGVector. Event-driven trigger; 15 nodes.
Source: https://github.com/Zie619/n8n-workflows — original creator credit. Request a take-down →
