The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "WF-02 \u00b7 Instagram Incoming",
"nodes": [
{
"parameters": {
"httpMethod": "POST",
"path": "instagram",
"responseMode": "responseNode",
"options": {
"rawBody": true
}
},
"id": "wf02-webhook",
"name": "Webhook \u00b7 Instagram",
"type": "n8n-nodes-base.webhook",
"typeVersion": 2,
"position": [
-720,
300
],
"notes": "Meta posts here. Point the Instagram app's Callback URL at this path."
},
{
"parameters": {
"respondWith": "text",
"responseBody": "EVENT_RECEIVED",
"options": {
"responseCode": 200
}
},
"id": "wf02-ack",
"name": "Ack 200 Immediately",
"type": "n8n-nodes-base.respondToWebhook",
"typeVersion": 1,
"position": [
-500,
300
],
"notes": "Meta retries for ~24h on any non-200. Acknowledge first, then process \u2014 never make the platform wait on the AI call."
},
{
"parameters": {
"jsCode": "// Guard clause: only forward payloads that actually contain messages.\n// Status-only callbacks (delivered/read) go down the status branch instead.\nconst items = [];\nfor (const item of $input.all()) {\n const body = item.json.body ?? item.json;\n const entries = body.entry ?? [];\n let hasMessages = false;\n let hasStatuses = false;\n for (const entry of entries) {\n for (const change of entry.changes ?? []) {\n const value = change.value ?? {};\n if ((value.messages ?? []).length) hasMessages = true;\n if ((value.statuses ?? []).length) hasStatuses = true;\n }\n }\n items.push({\n json: {\n body,\n signature: item.json.headers?.['x-hub-signature-256'] ?? null,\n hasMessages,\n hasStatuses,\n },\n });\n}\nreturn items;"
},
"id": "wf02-classify",
"name": "Classify Payload",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
-280,
300
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"version": 2
},
"conditions": [
{
"id": "has-messages",
"leftValue": "={{ $json.hasMessages }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "wf02-is-message",
"name": "Contains a Message?",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
-60,
300
]
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/webhooks/instagram",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
},
{
"name": "X-Hub-Signature-256",
"value": "={{ $json.signature }}"
},
{
"name": "X-Workflow-Code",
"value": "WF-02"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify($json.body) }}",
"options": {
"timeout": 15000,
"response": {
"response": {
"fullResponse": false,
"neverError": false
}
}
}
},
"id": "wf02-ingest",
"name": "Normalize & Store (FastAPI)",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
180,
200
],
"retryOnFail": true,
"maxTries": 3,
"waitBetweenTries": 2000,
"onError": "continueErrorOutput",
"notes": "The backend verifies the signature itself, normalizes via InstagramAdapter, de-duplicates on (org, platform, external_message_id), and returns the stored message plus its conversation."
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/ai/route",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ message_id: $json.message_id, conversation_id: $json.conversation_id, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 45000
}
},
"id": "wf02-router",
"name": "AI Router",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
400,
200
],
"retryOnFail": true,
"maxTries": 2,
"waitBetweenTries": 3000,
"onError": "continueErrorOutput",
"notes": "Returns { intent, confidence, action, lead_score, needs_human }."
},
{
"parameters": {
"rules": {
"values": [
{
"conditions": {
"options": {
"version": 2
},
"conditions": [
{
"leftValue": "={{ $json.needs_human }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"renameOutput": true,
"outputKey": "Human"
},
{
"conditions": {
"options": {
"version": 2
},
"conditions": [
{
"leftValue": "={{ $json.action }}",
"rightValue": "qualify",
"operator": {
"type": "string",
"operation": "equals"
}
}
],
"combinator": "and"
},
"renameOutput": true,
"outputKey": "Sales"
},
{
"conditions": {
"options": {
"version": 2
},
"conditions": [
{
"leftValue": "={{ $json.action }}",
"rightValue": "answer",
"operator": {
"type": "string",
"operation": "equals"
}
}
],
"combinator": "and"
},
"renameOutput": true,
"outputKey": "Support"
}
]
},
"options": {
"fallbackOutput": 0
}
},
"id": "wf02-switch",
"name": "Route by Decision",
"type": "n8n-nodes-base.switch",
"typeVersion": 3,
"position": [
620,
200
],
"notes": "Fallback output is Human. When the router is unsure about its own output, a person sees it."
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/approvals",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ subject_type: 'message', conversation_id: $json.conversation_id, reason: $json.escalation_reason ?? 'Low confidence or sensitive intent', confidence: $json.confidence, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 15000
}
},
"id": "wf02-human",
"name": "Queue for Human",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
860,
60
],
"onError": "continueErrorOutput"
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/ai/sales",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ conversation_id: $json.conversation_id, message_id: $json.message_id, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 45000
}
},
"id": "wf02-sales",
"name": "Sales Agent \u00b7 Qualify",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
860,
200
],
"retryOnFail": true,
"maxTries": 2,
"onError": "continueErrorOutput"
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/ai/support",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ conversation_id: $json.conversation_id, message_id: $json.message_id, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 45000
}
},
"id": "wf02-support",
"name": "Support Agent \u00b7 RAG Answer",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
860,
340
],
"retryOnFail": true,
"maxTries": 2,
"onError": "continueErrorOutput"
},
{
"parameters": {
"conditions": {
"options": {
"version": 2
},
"conditions": [
{
"leftValue": "={{ $json.needs_human }}",
"rightValue": false,
"operator": {
"type": "boolean",
"operation": "false",
"singleValue": true
}
},
{
"leftValue": "={{ $json.answer }}",
"rightValue": "",
"operator": {
"type": "string",
"operation": "notEmpty",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "wf02-safe-to-send",
"name": "Safe to Send?",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
1080,
340
],
"notes": "Second gate. The agent may downgrade its own confidence after searching the knowledge base, so the check happens again here."
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/messages/send",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ conversation_id: $json.conversation_id, text: $json.answer, sender_type: 'ai', ai_run_id: $json.ai_run_id, confidence: $json.confidence, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 30000
}
},
"id": "wf02-send",
"name": "Send via Instagram API",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1300,
280
],
"retryOnFail": true,
"maxTries": 3,
"waitBetweenTries": 5000,
"onError": "continueErrorOutput",
"notes": "The backend owns the credential and picks the live or mock adapter. n8n never holds a platform token."
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/webhooks/instagram/status",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify($json.body) }}",
"options": {
"timeout": 15000
}
},
"id": "wf02-status",
"name": "Record Delivery Status",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
180,
420
],
"onError": "continueRegularOutput"
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/workflow-runs",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ workflow_code: 'WF-02', n8n_execution_id: $execution.id, status: 'failed', platform: 'instagram', error: JSON.stringify($json.error ?? $json), input_payload: $json }) }}",
"options": {
"timeout": 15000
}
},
"id": "wf02-deadletter",
"name": "Dead Letter \u00b7 Manual Review",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1300,
540
],
"onError": "continueRegularOutput",
"notes": "Every error output converges here. The run shows up on the Workflows page as a failure needing attention."
}
],
"connections": {
"Webhook \u00b7 Instagram": {
"main": [
[
{
"node": "Ack 200 Immediately",
"type": "main",
"index": 0
}
]
]
},
"Ack 200 Immediately": {
"main": [
[
{
"node": "Classify Payload",
"type": "main",
"index": 0
}
]
]
},
"Classify Payload": {
"main": [
[
{
"node": "Contains a Message?",
"type": "main",
"index": 0
}
]
]
},
"Contains a Message?": {
"main": [
[
{
"node": "Normalize & Store (FastAPI)",
"type": "main",
"index": 0
}
],
[
{
"node": "Record Delivery Status",
"type": "main",
"index": 0
}
]
]
},
"Normalize & Store (FastAPI)": {
"main": [
[
{
"node": "AI Router",
"type": "main",
"index": 0
}
],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"AI Router": {
"main": [
[
{
"node": "Route by Decision",
"type": "main",
"index": 0
}
],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"Route by Decision": {
"main": [
[
{
"node": "Queue for Human",
"type": "main",
"index": 0
}
],
[
{
"node": "Sales Agent \u00b7 Qualify",
"type": "main",
"index": 0
}
],
[
{
"node": "Support Agent \u00b7 RAG Answer",
"type": "main",
"index": 0
}
]
]
},
"Sales Agent \u00b7 Qualify": {
"main": [
[
{
"node": "Send via Instagram API",
"type": "main",
"index": 0
}
],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"Support Agent \u00b7 RAG Answer": {
"main": [
[
{
"node": "Safe to Send?",
"type": "main",
"index": 0
}
],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"Safe to Send?": {
"main": [
[
{
"node": "Send via Instagram API",
"type": "main",
"index": 0
}
],
[
{
"node": "Queue for Human",
"type": "main",
"index": 0
}
]
]
},
"Send via Instagram API": {
"main": [
[],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"Queue for Human": {
"main": [
[],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
}
},
"settings": {
"executionOrder": "v1",
"saveDataErrorExecution": "all",
"saveDataSuccessExecution": "all",
"saveExecutionProgress": true,
"errorWorkflow": "WF-90"
},
"tags": [
{
"name": "incoming"
},
{
"name": "instagram"
}
],
"meta": {
"description": "Inbound Instagram: same architecture as WF-02. The only differences are the webhook path, the adapter the backend selects, and the delivery-status branch."
}
}
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
WF-02 · Instagram Incoming. Uses httpRequest. Webhook trigger; 14 nodes.
Source: https://github.com/hamza01055/omni-ai-automation/blob/main/n8n/workflows/incoming/WF-02-instagram-incoming.json — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
Instagram - Fluxo de mensagens. Uses rabbitmq, rabbitmqTrigger, googleSheets, httpRequest. Webhook trigger; 74 nodes.
Rabbitmq, Rabbitmq Trigger, Google Sheets +1
This workflow receives a webhook request, uses AtlasCloud (GPT Image 2 and HappyHorse) to turn a profile image into a short vertical video, then publishes the reel to TikTok and Instagram via Blotato.
HTTP Request, @Blotato/N8N Nodes Blotato, Stop And Error
Automated n8n workflow: Receives videos via form, dubs/translates them to the selected languages, and—upon completion—uploads them to multiple social media channels and cloud drives, including Box, Dr
HTTP Request, Telegram, Box +3
Automate your post-event Instagram carousel using a fan-out and merge pattern. One Code node splits the photos array into individual n8n items. Every photo then flows through HTTP Fetch, Upload to URL
HTTP Request, N8N Nodes Uploadtourl, Airtable +1
My workflow 3. Uses httpRequest, youTube. Webhook trigger; 17 nodes.
HTTP Request, YouTube
