Wf01 — Payout Reconciler (stripe + Shopify → Xero)

The workflow JSON

Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →

{
  "name": "WF01 \u2014 Payout Reconciler (Stripe + Shopify \u2192 Xero)",
  "nodes": [
    {
      "parameters": {
        "content": "## WF01: Payout Reconciler\n\n**Project 3, Xero Payment Processor Reconciliation**\n\nOne canvas, two ingestion shapes (Stripe webhook + Shopify cron poll), one shared decomposition and Xero-posting downstream. Decomposes each payout into balanced journal lines and posts to Xero as a Manual Journal.\n\n**Compliance posture**: signature verification (structural in test, HMAC-deferred), idempotency on (processor, payout_id), database-level append-only audit, strict balance validation, retry on every external call.\n\nRead this canvas left to right: section headers (purple) explain each band.\n\nBuild status: Stripe path tested, Shopify path tested, all 6 test paths run.",
        "height": 280,
        "width": 1200,
        "color": 7
      },
      "type": "n8n-nodes-base.stickyNote",
      "typeVersion": 1,
      "position": [
        6912,
        3248
      ],
      "id": "28c8c5ca-f45f-4f95-aef6-5474440ba3d5",
      "name": "Header"
    },
    {
      "parameters": {
        "content": "## 1. Dual Ingestion (webhook + cron)\n\n**Top branch (Stripe webhook)**: Stripe pushes `payout.paid` or `payout.updated` to the webhook. Signature verification (structural, see ASSUMPTIONS.md for HMAC defer rationale), filter to genuine paid-payout events, tag run context.\n\n**Bottom branch (Shopify cron)**: Shopify Payments has no payout webhook, so this branch polls `GET /shopify_payments/payouts.json?status=paid` daily with a 3-day lookback. Split Out iterates the array, each payout tagged with run context.",
        "height": 864,
        "width": 976
      },
      "type": "n8n-nodes-base.stickyNote",
      "typeVersion": 1,
      "position": [
        6848,
        3600
      ],
      "id": "a60c2fd4-85b9-427f-930d-4d3d5de9bbf7",
      "name": "Section 1: Dual Ingestion"
    },
    {
      "parameters": {
        "content": "## 2. Merge & Idempotency\n\nBoth processors converge here. Single LEFT JOIN query against `payment_recon.payouts` (unique on `processor, payout_id`) determines:\n\n- NEW: continue to processor branch\n- POSTED: return original JournalID with idempotent: true\n- PENDING: return 409 Conflict\n\nFAILED rows allow reprocess so a Xero retry can proceed after credential fixes.",
        "height": 864,
        "width": 834,
        "color": 2
      },
      "type": "n8n-nodes-base.stickyNote",
      "typeVersion": 1,
      "position": [
        7840,
        3600
      ],
      "id": "062fb511-fcbd-4359-b6f1-9cb752bd89b1",
      "name": "Section 2: Merge & Idempotency"
    },
    {
      "parameters": {
        "content": "## 3. Dual Branch (fetch + decompose)\n\n**Top branch (Stripe)**: fetch payout detail, paginate balance transactions (starting_after), fetch live account_map, decompose. Maps charge/payment, refund/payment_refund, stripe_fee, adjustment/transfer, payout. Integer minor units throughout.\n\n**Bottom branch (Shopify)**: same shape. Decomposer constructs `adjustment_<reason>` lookup keys for Shopify's adjustment subtypes. Defensive amount parsing handles string-or-numeric major units. Manually unwraps the `{transactions: [...]}` envelope (Stripe's `{data: [...]}` is auto-unwrapped by n8n; Shopify's is not).\n\nThrows on unknown types; first real run surfaces gaps loudly.",
        "height": 892,
        "width": 1102,
        "color": 5
      },
      "type": "n8n-nodes-base.stickyNote",
      "typeVersion": 1,
      "position": [
        8704,
        3600
      ],
      "id": "0b20e92f-b783-4ec9-a580-f2c45849cfa1",
      "name": "Section 3: Dual Branches"
    },
    {
      "parameters": {
        "content": "## 4. Shared Validation & Xero Posting\n\nBoth branches merge into this shared chain. PENDING audit row, balance validation, build Xero ManualJournal, POST to Xero, update POSTED with JournalID.\n\n**Strict-fail validation**: debits must equal credits to the cent. No rounding plug in v1. Any imbalance is signal (missing type, wrong map, sign bug), not noise.\n\n**Why account 855 (Clearing) for payout, not 090 (Bank)**: Xero refuses Manual Journals against BANK-type accounts. The clearing account holds the net payout; bank reconciliation handles the clearing\u2192bank movement when the deposit lands. This is the standard accountant-approved pattern.",
        "height": 1068,
        "width": 1916,
        "color": 4
      },
      "type": "n8n-nodes-base.stickyNote",
      "typeVersion": 1,
      "position": [
        9824,
        3600
      ],
      "id": "bc68912d-66ce-4132-86ec-22b75a06e1ba",
      "name": "Section 4: Validate & Post"
    },
    {
      "parameters": {
        "content": "## 5. Error Paths & Terminal\n\nFour failure envelopes (Decomposition, Validation, Xero 4xx, Xero 5xx) converge through Update Payouts FAILED \u2192 Write FAILED event \u2192 Persist FAILED envelope \u2192 terminal IF.\n\n**Dual response by source_trigger**: webhook path emits HTTP response (Respond to Webhook); cron path emits no response (NoOp loop continue). The IF on `source_trigger` is the gate that distinguishes them.\n\n**Network failures route to 5xx**: Branch Xero Error 4xx vs 5xx defaults missing httpCode to 0, fails both bounds, lands in 502 envelope. Connection drops, timeouts, retry-exhausted failures are never silently treated as success.",
        "height": 924,
        "width": 1800,
        "color": 3
      },
      "type": "n8n-nodes-base.stickyNote",
      "typeVersion": 1,
      "position": [
        11792,
        3728
      ],
      "id": "78dde573-2035-4920-b131-6a64bb48a86f",
      "name": "Section 5: Error & Terminal"
    },
    {
      "parameters": {
        "httpMethod": "POST",
        "path": "stripe-payout-paid",
        "responseMode": "responseNode",
        "options": {
          "rawBody": true
        }
      },
      "id": "e790c8a6-8c07-42eb-8039-98d88f6fcdda",
      "name": "Stripe Webhook Trigger1",
      "type": "n8n-nodes-base.webhook",
      "typeVersion": 2.1,
      "position": [
        6912,
        3920
      ],
      "notes": "Stripe webhook endpoint. responseMode=responseNode lets the terminal Respond node carry the dynamic envelope. rawBody=true exposes the unparsed body for HMAC verification."
    },
    {
      "parameters": {
        "conditions": {
          "options": {
            "caseSensitive": true,
            "leftValue": "",
            "typeValidation": "strict",
            "version": 1
          },
          "conditions": [
            {
              "id": "c1",
              "leftValue": "={{ $json.data.object.object }}",
              "rightValue": "payout",
              "operator": {
                "type": "string",
                "operation": "equals"
              }
            },
            {
              "id": "c2",
              "leftValue": "={{ $json.data.object.status }}",
              "rightValue": "paid",
              "operator": {
                "type": "string",
                "operation": "equals"
              }
            }
          ],
          "combinator": "and"
        },
        "options": {}
      },
      "id": "b9478dd0-1844-46db-864b-3763dc8eb2bf",
      "name": "Filter to Paid Payout1",
      "type": "n8n-nodes-base.if",
      "typeVersion": 2,
      "position": [
        7440,
        3904
      ],
      "notes": "Proceed only on a payout that is now paid. payout.created (status=pending) and unrelated payout.updated events fall through the false branch to Set 200 IGNORED."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "a1",
              "name": "workflow_run_id",
              "value": "={{ \"xxxxxxxx-xxxx-4xxx-yxxx-xxxxxxxxxxxx\".replace(/[xy]/g, c => { const r = Math.random()*16|0, v = c===\"x\"?r:(r&0x3|0x8); return v.toString(16); }) }}",
              "type": "string"
            },
            {
              "id": "a2",
              "name": "processor",
              "value": "stripe",
              "type": "string"
            },
            {
              "id": "a3",
              "name": "payout_id",
              "value": "={{ $json.data.object.id }}",
              "type": "string"
            },
            {
              "id": "a4",
              "name": "payout_date",
              "value": "={{ new Date($json.data.object.arrival_date * 1000).toISOString().split(\"T\")[0] }}",
              "type": "string"
            },
            {
              "id": "a5",
              "name": "received_at",
              "value": "={{ $now.toISO() }}",
              "type": "string"
            },
            {
              "id": "a6",
              "name": "source_trigger",
              "value": "webhook",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "5249a666-2824-4eef-9649-ad1a045789d9",
      "name": "Set Stripe Run Context1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        7664,
        3904
      ],
      "notes": "Establishes run context. workflow_run_id is a fresh UUID v4; payout_date converts Stripe unix arrival_date to YYYY-MM-DD."
    },
    {
      "parameters": {
        "rule": {
          "interval": [
            {
              "field": "cronExpression",
              "expression": "0 6 * * *"
            }
          ]
        }
      },
      "id": "7af823de-a9ae-4fcb-8462-642f4bd49e59",
      "name": "Schedule Trigger1",
      "type": "n8n-nodes-base.scheduleTrigger",
      "typeVersion": 1.2,
      "position": [
        6992,
        4304
      ],
      "notes": "Daily 06:00 UTC poll of Shopify payouts. Can also be triggered manually for testing."
    },
    {
      "parameters": {
        "url": "=https://clancy-pqkyawsh.myshopify.com/admin/api/2026-04/shopify_payments/payouts.json",
        "authentication": "predefinedCredentialType",
        "nodeCredentialType": "shopifyOAuth2Api",
        "sendQuery": true,
        "queryParameters": {
          "parameters": [
            {
              "name": "status",
              "value": "paid"
            },
            {
              "name": "date_min",
              "value": "={{ $now.minus({days: 3}).toISODate() }}"
            }
          ]
        },
        "options": {}
      },
      "id": "324eb3f2-f9f9-4b77-8744-c4cb34200196",
      "name": "Fetch Shopify Payouts List1",
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.2,
      "position": [
        7216,
        4304
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "oAuth2Api": {
          "name": "<your credential>"
        },
        "shopifyOAuth2Api": {
          "name": "<your credential>"
        }
      },
      "notes": "Lists payouts with status=paid in the last 3 days. 3-day lookback covers weekend gaps; idempotency dedupes anything already processed."
    },
    {
      "parameters": {
        "fieldToSplitOut": "payouts",
        "options": {}
      },
      "id": "cdd8a5eb-22eb-40e4-9aed-63e99fae42ab",
      "name": "Split Out Payouts1",
      "type": "n8n-nodes-base.splitOut",
      "typeVersion": 1,
      "position": [
        7440,
        4304
      ],
      "notes": "Splits response.payouts[] into one item per payout. Empty list terminates cleanly."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "a1",
              "name": "workflow_run_id",
              "value": "={{ \"xxxxxxxx-xxxx-4xxx-yxxx-xxxxxxxxxxxx\".replace(/[xy]/g, c => { const r = Math.random()*16|0, v = c===\"x\"?r:(r&0x3|0x8); return v.toString(16); }) }}",
              "type": "string"
            },
            {
              "id": "a2",
              "name": "processor",
              "value": "shopify",
              "type": "string"
            },
            {
              "id": "a3",
              "name": "payout_id",
              "value": "={{ String($json.id) }}",
              "type": "string"
            },
            {
              "id": "a4",
              "name": "payout_date",
              "value": "={{ $json.date }}",
              "type": "string"
            },
            {
              "id": "a5",
              "name": "received_at",
              "value": "={{ $now.toISO() }}",
              "type": "string"
            },
            {
              "id": "a6",
              "name": "source_trigger",
              "value": "cron",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "6ef393fd-072e-4370-be4c-32aa7abe89d5",
      "name": "Set Shopify Run Context1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        7664,
        4304
      ],
      "notes": "Run context per payout. Shopify payout.date already arrives as YYYY-MM-DD so no conversion needed."
    },
    {
      "parameters": {},
      "id": "acdaf4b2-dbf0-4968-afcc-67d2f607b89b",
      "name": "Merge Ingestion1",
      "type": "n8n-nodes-base.merge",
      "typeVersion": 3,
      "position": [
        7872,
        4112
      ],
      "notes": "Combines both ingestion paths. From here, both processors share the same downstream."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "SELECT\n  p.id,\n  p.status,\n  p.xero_journal_id,\n  (p.id IS NOT NULL) AS row_exists\nFROM (SELECT 1) AS dummy\nLEFT JOIN payment_recon.payouts p\n  ON p.processor = $1 AND p.payout_id = $2",
        "options": {
          "queryReplacement": "={{ $json.processor }},={{ $json.payout_id }}"
        }
      },
      "id": "8e6a6070-c94d-4c2a-a136-36df701e1025",
      "name": "Idempotency Check1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        8096,
        4112
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "Looks up existing payouts row by (processor, payout_id). Returns 0 or 1 row; Resolve Idempotency Code materialises the decision."
    },
    {
      "parameters": {
        "jsCode": "// Merges the Postgres lookup result with the upstream run context.\n// Produces a single item per input with idem_decision in {NEW, POSTED, PENDING}.\nconst ctx = $('Merge Ingestion1').first().json;\nconst pgItems = $input.all();\n\nlet existing = null;\nif (pgItems.length > 0 && pgItems[0].json && pgItems[0].json.id) {\n  existing = pgItems[0].json;\n}\n\nlet idem_decision = 'NEW';\nif (existing) {\n  if (existing.status === 'POSTED') idem_decision = 'POSTED';\n  else if (existing.status === 'PENDING') idem_decision = 'PENDING';\n  // FAILED falls through to NEW (allow reprocess)\n}\n\nreturn [{\n  json: {\n    ...ctx,\n    idem_decision,\n    existing_payout_uuid: existing ? existing.id : null,\n    existing_xero_journal_id: existing ? existing.xero_journal_id : null,\n  }\n}];"
      },
      "id": "181e367e-e310-40eb-9080-89126ab01e6c",
      "name": "Resolve Idempotency1",
      "type": "n8n-nodes-base.code",
      "typeVersion": 2,
      "position": [
        8320,
        4112
      ],
      "notes": "Pivot point: combines Postgres lookup + run context. Sets idem_decision so the downstream Switch is a simple equals check."
    },
    {
      "parameters": {
        "rules": {
          "values": [
            {
              "conditions": {
                "options": {
                  "caseSensitive": true,
                  "leftValue": "",
                  "typeValidation": "strict",
                  "version": 2
                },
                "conditions": [
                  {
                    "id": "r0",
                    "leftValue": "={{ $json.idem_decision }}",
                    "rightValue": "POSTED",
                    "operator": {
                      "type": "string",
                      "operation": "equals"
                    }
                  }
                ],
                "combinator": "and"
              },
              "renameOutput": true,
              "outputKey": "Idempotent"
            },
            {
              "conditions": {
                "options": {
                  "caseSensitive": true,
                  "leftValue": "",
                  "typeValidation": "strict",
                  "version": 2
                },
                "conditions": [
                  {
                    "id": "r1",
                    "leftValue": "={{ $json.idem_decision }}",
                    "rightValue": "PENDING",
                    "operator": {
                      "type": "string",
                      "operation": "equals"
                    }
                  }
                ],
                "combinator": "and"
              },
              "renameOutput": true,
              "outputKey": "Conflict"
            },
            {
              "conditions": {
                "options": {
                  "caseSensitive": true,
                  "leftValue": "",
                  "typeValidation": "strict",
                  "version": 2
                },
                "conditions": [
                  {
                    "id": "r2",
                    "leftValue": "={{ $json.idem_decision }}",
                    "rightValue": "NEW",
                    "operator": {
                      "type": "string",
                      "operation": "equals"
                    }
                  }
                ],
                "combinator": "and"
              },
              "renameOutput": true,
              "outputKey": "New"
            }
          ]
        },
        "options": {}
      },
      "id": "a6727751-0c96-497e-a472-75e09c149a47",
      "name": "Idempotency Decision1",
      "type": "n8n-nodes-base.switch",
      "typeVersion": 3.2,
      "position": [
        8544,
        4144
      ],
      "notes": "Routes by idem_decision. POSTED -> idempotent envelope, PENDING -> conflict envelope, NEW -> continue to Route by Processor."
    },
    {
      "parameters": {
        "rules": {
          "values": [
            {
              "conditions": {
                "options": {
                  "caseSensitive": true,
                  "leftValue": "",
                  "typeValidation": "strict",
                  "version": 2
                },
                "conditions": [
                  {
                    "id": "r0",
                    "leftValue": "={{ $json.processor }}",
                    "rightValue": "stripe",
                    "operator": {
                      "type": "string",
                      "operation": "equals"
                    }
                  }
                ],
                "combinator": "and"
              },
              "renameOutput": true,
              "outputKey": "Stripe"
            },
            {
              "conditions": {
                "options": {
                  "caseSensitive": true,
                  "leftValue": "",
                  "typeValidation": "strict",
                  "version": 2
                },
                "conditions": [
                  {
                    "id": "r1",
                    "leftValue": "={{ $json.processor }}",
                    "rightValue": "shopify",
                    "operator": {
                      "type": "string",
                      "operation": "equals"
                    }
                  }
                ],
                "combinator": "and"
              },
              "renameOutput": true,
              "outputKey": "Shopify"
            }
          ]
        },
        "options": {}
      },
      "id": "0b4299b1-15b5-439c-ba27-3f20ebf6fa75",
      "name": "Route to Processor Branch1",
      "type": "n8n-nodes-base.switch",
      "typeVersion": 3.2,
      "position": [
        8752,
        4112
      ],
      "notes": "Routes to processor-specific fetch + decompose branch."
    },
    {
      "parameters": {
        "url": "=https://api.stripe.com/v1/payouts/{{ $json.payout_id }}",
        "authentication": "predefinedCredentialType",
        "nodeCredentialType": "stripeApi",
        "options": {}
      },
      "id": "7c86f8d1-ea9f-4100-b1aa-1d41661400e2",
      "name": "Fetch Stripe Payout1",
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.2,
      "position": [
        8976,
        3968
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "oAuth2Api": {
          "name": "<your credential>"
        },
        "stripeApi": {
          "name": "<your credential>"
        }
      },
      "notes": "GET /v1/payouts/{id} for authoritative payout amount."
    },
    {
      "parameters": {
        "url": "https://api.stripe.com/v1/balance_transactions",
        "authentication": "predefinedCredentialType",
        "nodeCredentialType": "stripeApi",
        "sendQuery": true,
        "queryParameters": {
          "parameters": [
            {
              "name": "payout",
              "value": "={{ $('Resolve Idempotency1').item.json.payout_id }}"
            },
            {
              "name": "limit",
              "value": "100"
            }
          ]
        },
        "options": {
          "pagination": {
            "pagination": {
              "parameters": {
                "parameters": [
                  {
                    "type": "query",
                    "name": "starting_after",
                    "value": "={{ $json.id }}"
                  }
                ]
              },
              "paginationCompleteWhen": "other",
              "completeExpression": "={{ $response.body.has_more === false }}"
            }
          }
        }
      },
      "id": "43afde57-21ae-4661-8ef1-ac6b3eb8e750",
      "name": "Fetch Stripe Balance Transactions1",
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.2,
      "position": [
        9200,
        3968
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "stripeApi": {
          "name": "<your credential>"
        }
      },
      "notes": "GET /v1/balance_transactions?payout={id}&limit=100, paginated via starting_after until has_more=false."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "SELECT transaction_type, xero_account_code, debit_or_credit, description_template FROM payment_recon.account_map WHERE processor = 'stripe' AND active = true;",
        "options": {}
      },
      "id": "689856f3-a3b9-4ce1-91ec-6551af5e13c7",
      "name": "Fetch Stripe Account Map1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        9424,
        3968
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "executeOnce": true,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "Fetches the live Stripe account map. Per Design Q2: per-branch fetch keeps DB calls at one per payout (only the active branch fires)."
    },
    {
      "parameters": {
        "jsCode": "// Decomposes a Stripe payout into journal lines using the account_map.\n// THROWS on any unknown BT type \u2014 first real run surfaces gaps loudly.\nconst ctx = $('Resolve Idempotency1').item.json;\nconst payout = $('Fetch Stripe Payout1').item.json;\nconst btItems = $('Fetch Stripe Balance Transactions1').all();\nconst mapRows = $('Fetch Stripe Account Map1').all();\n\nconst accountMap = {};\nfor (const row of mapRows) {\n  accountMap[row.json.transaction_type] = {\n    code: row.json.xero_account_code,\n    side: row.json.debit_or_credit,\n    tmpl: row.json.description_template,\n  };\n}\n\nif (btItems.length === 0) {\n  throw new Error(`Empty Stripe balance transactions for payout ${ctx.payout_id} (workflow_run_id=${ctx.workflow_run_id})`);\n}\n\nconst lines = [];\nlet gross = 0, fee = 0, refund = 0, adjustment = 0;\n\nfor (const item of btItems) {\n  const bt = item.json;\n  const map = accountMap[bt.type];\n  if (!map) {\n    throw new Error(`Unknown Stripe BT type: ${bt.type} (workflow_run_id=${ctx.workflow_run_id}, payout_id=${ctx.payout_id}, bt_id=${bt.id})`);\n  }\n\n  // Stripe amounts are signed integer minor units; absolute value goes into the line.\n  const amountMinor = Math.abs(bt.amount);\n\n  switch (bt.type) {\n    case 'charge':\n    case 'payment':\n      gross += amountMinor;\n      break;\n    case 'refund':\n    case 'payment_refund':\n      refund += amountMinor;\n      break;\n    case 'stripe_fee':\n      fee += amountMinor;\n      break;\n    case 'adjustment':\n    case 'transfer':\n      adjustment += amountMinor;\n      break;\n    case 'payout':\n      // The payout BT itself is the net deposit; no category counter.\n      break;\n  }\n\n  lines.push({\n    account_code: map.code,\n    debit_or_credit: map.side,\n    amount_minor: amountMinor,\n    description: map.tmpl.replace('{payout_id}', ctx.payout_id),\n    transaction_type: bt.type,\n    bt_id: bt.id,\n  });\n}\n\nconst netAmountMinor = Math.abs(payout.amount);\n\nreturn [{\n  json: {\n    processor: 'stripe',\n    payout_id: ctx.payout_id,\n    workflow_run_id: ctx.workflow_run_id,\n    payout_date: ctx.payout_date,\n    source_trigger: ctx.source_trigger,\n    received_at: ctx.received_at,\n    lines,\n    line_count: lines.length,\n    gross_amount_minor: gross,\n    net_amount_minor: netAmountMinor,\n    fee_amount_minor: fee,\n    refund_amount_minor: refund,\n    adjustment_amount_minor: adjustment,\n  }\n}];"
      },
      "id": "70eefe4b-a5bd-42ba-ace8-00da9fbbec5c",
      "name": "Decompose Stripe1",
      "type": "n8n-nodes-base.code",
      "typeVersion": 2,
      "position": [
        9632,
        3968
      ],
      "onError": "continueErrorOutput",
      "notes": "Stripe decomposer. Handles charge/refund (Charges-era) AND payment/payment_refund (PaymentIntents-era). Throws on unknown type or empty basket."
    },
    {
      "parameters": {
        "url": "=https://clancy-pqkyawsh.myshopify.com/admin/api/2026-04/shopify_payments/payouts/{{ $json.payout_id }}.json",
        "authentication": "predefinedCredentialType",
        "nodeCredentialType": "shopifyOAuth2Api",
        "options": {}
      },
      "id": "1791c2fd-084b-4ec2-8a44-002cf9bd8127",
      "name": "Fetch Shopify Payout Detail1",
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.2,
      "position": [
        8976,
        4256
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "shopifyOAuth2Api": {
          "name": "<your credential>"
        }
      },
      "notes": "Confirms authoritative payout amount before posting (list summary alone is not trusted)."
    },
    {
      "parameters": {
        "url": "=https://clancy-pqkyawsh.myshopify.com/admin/api/2026-04/shopify_payments/balance/transactions.json",
        "authentication": "predefinedCredentialType",
        "nodeCredentialType": "shopifyOAuth2Api",
        "sendQuery": true,
        "queryParameters": {
          "parameters": [
            {
              "name": "payout_id",
              "value": "={{ $('Resolve Idempotency1').item.json.payout_id }}"
            },
            {
              "name": "limit",
              "value": "250"
            }
          ]
        },
        "options": {
          "pagination": {
            "pagination": {
              "paginationMode": "responseContainsNextURL",
              "nextURL": "={{ ($response.headers.link || '').match(/<([^>]+)>;\\s*rel=\"next\"/) ? ($response.headers.link.match(/<([^>]+)>;\\s*rel=\"next\"/)[1]) : '' }}"
            }
          }
        }
      },
      "id": "e0b7b87c-1df4-4223-b4c3-82fd0d0f9815",
      "name": "Fetch Shopify Balance Transactions1",
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.2,
      "position": [
        9200,
        4256
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "shopifyOAuth2Api": {
          "name": "<your credential>"
        }
      },
      "notes": "GET balance/transactions.json?payout_id=... Shopify cursor pagination via Link header rel=next."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "SELECT transaction_type, xero_account_code, debit_or_credit, description_template FROM payment_recon.account_map WHERE processor = 'shopify' AND active = true;",
        "options": {}
      },
      "id": "777e592c-7391-43ba-b68d-df02557b71b0",
      "name": "Fetch Shopify Account Map1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        9424,
        4256
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "Per-branch Shopify account map fetch."
    },
    {
      "parameters": {
        "jsCode": "// Decomposes a Shopify payout into journal lines. Throws on unknown type or unmapped adjustment_reason.\nconst ctx = $('Resolve Idempotency1').item.json;\nconst payoutDetail = $('Fetch Shopify Payout Detail1').item.json.payout || $('Fetch Shopify Payout Detail1').item.json;\n// Unwrap the response envelope. The HTTP node may return either:\n// - one item with .json = {transactions: [...]} (envelope mode)\n// - many items each with .json = a single transaction (auto-unwrapped mode)\nconst rawItems = $('Fetch Shopify Balance Transactions1').all();\nlet txItems;\nif (rawItems.length === 1 && Array.isArray(rawItems[0].json.transactions)) {\n  // Envelope mode: unwrap manually\n  txItems = rawItems[0].json.transactions.map(t => ({ json: t }));\n} else {\n  // Already a list of transactions\n  txItems = rawItems;\n}\nconst mapRows = $('Fetch Shopify Account Map1').all();\n\nconst accountMap = {};\nfor (const row of mapRows) {\n  accountMap[row.json.transaction_type] = {\n    code: row.json.xero_account_code,\n    side: row.json.debit_or_credit,\n    tmpl: row.json.description_template,\n  };\n}\n\nif (txItems.length === 0) {\n  throw new Error(`Empty Shopify balance transactions for payout ${ctx.payout_id} (workflow_run_id=${ctx.workflow_run_id})`);\n}\n// Coerce string-or-numeric major units to integer minor units.\nfunction toMinor(amount) {\n  if (amount === null || amount === undefined) return 0;\n  const n = typeof amount === 'number' ? amount : parseFloat(amount);\n  if (Number.isNaN(n)) throw new Error(`Non-numeric Shopify amount: ${JSON.stringify(amount)}`);\n  return Math.round(n * 100);\n}\n\nconst lines = [];\nlet gross = 0, fee = 0, refund = 0, adjustment = 0;\n\nfor (const item of txItems) {\n  const tx = item.json;\n  // Adjustments carry an adjustment_reason; build the lookup key as adjustment_<reason>.\n  const lookupKey = tx.type === 'adjustment' ? `adjustment_${tx.adjustment_reason}` : tx.type;\n  const map = accountMap[lookupKey];\n  if (!map) {\n    throw new Error(`Unknown Shopify transaction key: ${lookupKey} (workflow_run_id=${ctx.workflow_run_id}, payout_id=${ctx.payout_id}, tx_id=${tx.id})`);\n  }\n\n  const amountMinor = Math.abs(toMinor(tx.amount));\n\n  switch (tx.type) {\n    case 'charge':\n      gross += amountMinor;\n      break;\n    case 'refund':\n      refund += amountMinor;\n      break;\n    case 'fee':\n      fee += amountMinor;\n      break;\n    case 'adjustment':\n      adjustment += amountMinor;\n      break;\n    case 'payout':\n      // Payout BT itself is the net deposit\n      break;\n  }\n\n  lines.push({\n    account_code: map.code,\n    debit_or_credit: map.side,\n    amount_minor: amountMinor,\n    description: map.tmpl.replace('{payout_id}', ctx.payout_id),\n    transaction_type: lookupKey,\n    tx_id: tx.id,\n  });\n}\n\nconst netAmountMinor = Math.abs(toMinor(payoutDetail.amount));\n\nreturn [{\n  json: {\n    processor: 'shopify',\n    payout_id: ctx.payout_id,\n    workflow_run_id: ctx.workflow_run_id,\n    payout_date: ctx.payout_date,\n    source_trigger: ctx.source_trigger,\n    received_at: ctx.received_at,\n    lines,\n    line_count: lines.length,\n    gross_amount_minor: gross,\n    net_amount_minor: netAmountMinor,\n    fee_amount_minor: fee,\n    refund_amount_minor: refund,\n    adjustment_amount_minor: adjustment,\n  }\n}];"
      },
      "id": "d28e0d77-961a-4113-8469-8551eca2ae95",
      "name": "Decompose Shopify1",
      "type": "n8n-nodes-base.code",
      "typeVersion": 2,
      "position": [
        9632,
        4256
      ],
      "onError": "continueErrorOutput",
      "notes": "Shopify decomposer. Defensively handles string-or-numeric amount in major units. Throws on unknown type / adjustment_reason."
    },
    {
      "parameters": {},
      "id": "85a2140d-1280-4c75-b57c-cc425b3312ed",
      "name": "Merge Decomposed1",
      "type": "n8n-nodes-base.merge",
      "typeVersion": 3,
      "position": [
        9856,
        4112
      ],
      "notes": "Joins both decomposer outputs into a single stream for shared validation + posting."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "INSERT INTO payment_recon.payouts (workflow_run_id, processor, payout_id, status, currency_code, gross_amount_minor, net_amount_minor, fee_amount_minor, refund_amount_minor, adjustment_amount_minor, line_count, lines_json) VALUES ($1, $2, $3, 'PENDING', 'USD', $4, $5, $6, $7, $8, $9, $10::jsonb) ON CONFLICT (processor, payout_id) DO UPDATE SET status = 'PENDING', failed_check = NULL, gross_amount_minor = EXCLUDED.gross_amount_minor, net_amount_minor = EXCLUDED.net_amount_minor, fee_amount_minor = EXCLUDED.fee_amount_minor, refund_amount_minor = EXCLUDED.refund_amount_minor, adjustment_amount_minor = EXCLUDED.adjustment_amount_minor, line_count = EXCLUDED.line_count, lines_json = EXCLUDED.lines_json, updated_at = now() RETURNING id AS payout_uuid;",
        "options": {
          "queryReplacement": "={{ $json.workflow_run_id }},={{ $json.processor }},={{ $json.payout_id }},={{ $json.gross_amount_minor }},={{ $json.net_amount_minor }},={{ $json.fee_amount_minor }},={{ $json.refund_amount_minor }},={{ $json.adjustment_amount_minor }},={{ $json.line_count }},={{ JSON.stringify($json.lines) }}"
        }
      },
      "id": "0c410a9d-29be-43f7-974f-96b6fefb0e53",
      "name": "Insert PENDING1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        10080,
        4112
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "INSERT ON CONFLICT DO UPDATE: handles FAILED -> reprocess. Identity field triggers protect immutable columns."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "INSERT INTO payment_recon.posting_events (payout_uuid, workflow_run_id, event_type, event_data) VALUES ($1, $2, 'RECEIVED', $3::jsonb);",
        "options": {
          "queryReplacement": "={{ $json.payout_uuid }},={{ $('Merge Decomposed1').item.json.workflow_run_id }},={{ JSON.stringify({ processor: $('Merge Decomposed1').item.json.processor, payout_id: $('Merge Decomposed1').item.json.payout_id, source_trigger: $('Merge Decomposed1').item.json.source_trigger, received_at: $('Merge Decomposed1').item.json.received_at }) }}"
        }
      },
      "id": "f7b13aa3-b9ec-4344-869c-4b0eba5c2b6e",
      "name": "Write RECEIVED event1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        10304,
        4112
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "Append-only posting_event for RECEIVED. event_data captures source_trigger so audit can distinguish webhook vs cron."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "INSERT INTO payment_recon.posting_events (payout_uuid, workflow_run_id, event_type, event_data) VALUES ($1, $2, 'DECOMPOSED', $3::jsonb);",
        "options": {
          "queryReplacement": "={{ $('Insert PENDING1').item.json.payout_uuid }},={{ $('Merge Decomposed1').item.json.workflow_run_id }},={{ JSON.stringify({ line_count: $('Merge Decomposed1').item.json.line_count, gross: $('Merge Decomposed1').item.json.gross_amount_minor, net: $('Merge Decomposed1').item.json.net_amount_minor, fee: $('Merge Decomposed1').item.json.fee_amount_minor, refund: $('Merge Decomposed1').item.json.refund_amount_minor, adjustment: $('Merge Decomposed1').item.json.adjustment_amount_minor }) }}"
        }
      },
      "id": "829a4218-760f-41e9-b2b3-3bfb7a69b302",
      "name": "Write DECOMPOSED event1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        10512,
        4112
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "DECOMPOSED event with totals summary."
    },
    {
      "parameters": {
        "jsCode": "// Strict-fail validation. No rounding plug (Design Q3).\nconst data = $('Merge Decomposed1').item.json;\nconst lines = data.lines || [];\n\nlet totalDebits = 0, totalCredits = 0;\nfor (const line of lines) {\n  if (line.debit_or_credit === 'debit') totalDebits += line.amount_minor;\n  else if (line.debit_or_credit === 'credit') totalCredits += line.amount_minor;\n  else throw new Error(`Line has invalid debit_or_credit: ${line.debit_or_credit} (workflow_run_id=${data.workflow_run_id}, payout_id=${data.payout_id})`);\n}\n\nif (totalDebits !== totalCredits) {\n  const diff = totalDebits - totalCredits;\n  throw new Error(JSON.stringify({\n    check: 'unbalanced',\n    expected: totalDebits,\n    actual: totalCredits,\n    diff,\n    workflow_run_id: data.workflow_run_id,\n    payout_id: data.payout_id,\n    processor: data.processor,\n  }));\n}\n\n// Forward input plus payout_uuid from Insert PENDING.\nreturn [{\n  json: {\n    ...data,\n    payout_uuid: $('Insert PENDING1').item.json.payout_uuid,\n    validated: true,\n    total_debits_minor: totalDebits,\n    total_credits_minor: totalCredits,\n  }\n}];"
      },
      "id": "c44c7334-e2d0-4020-b364-a9a4ed6dfe36",
      "name": "Validate Balance1",
      "type": "n8n-nodes-base.code",
      "typeVersion": 2,
      "position": [
        10736,
        4112
      ],
      "onError": "continueErrorOutput",
      "notes": "Strict debit=credit check. Throws to error output on imbalance; envelope routes to Set 422 Validation."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "INSERT INTO payment_recon.posting_events (payout_uuid, workflow_run_id, event_type, event_data) VALUES ($1, $2, 'VALIDATED', $3::jsonb);",
        "options": {
          "queryReplacement": "={{ $json.payout_uuid }},={{ $json.workflow_run_id }},={{ JSON.stringify({ total_debits_minor: $json.total_debits_minor, total_credits_minor: $json.total_credits_minor }) }}"
        }
      },
      "id": "4e8fd2c7-24ed-425d-a1b3-bf9a97b11165",
      "name": "Write VALIDATED event1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        10960,
        4112
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "VALIDATED event records balanced totals."
    },
    {
      "parameters": {
        "jsCode": "// Build the Xero ManualJournal request body.\nconst data = $('Set Xero Tenant Id1').first().json;\nconst processorLabel = data.processor === 'stripe' ? 'Stripe' : 'Shopify';\n\nconst journalLines = data.lines.map(line => {\n  const major = parseFloat((line.amount_minor / 100).toFixed(2));\n  const signed = line.debit_or_credit === 'debit' ? major : -major;\n  return {\n    LineAmount: signed,\n    AccountCode: line.account_code,\n    Description: line.description,\n  };\n});\n\nconst journal = {\n  Narration: `${processorLabel} payout ${data.payout_id} reconciliation`,\n  Date: data.payout_date,\n  Status: 'POSTED',\n  JournalLines: journalLines,\n};\n\nreturn [{\n  json: {\n    ...data,\n    xero_request_body: { ManualJournals: [journal] },\n  }\n}];"
      },
      "id": "4b012354-3142-4bf7-9b72-d899f74c0758",
      "name": "Build Xero Manual Journal1",
      "type": "n8n-nodes-base.code",
      "typeVersion": 2,
      "position": [
        11392,
        4112
      ],
      "notes": "Positive LineAmount = debit, negative = credit. Integer minor -> signed major USD."
    },
    {
      "parameters": {
        "method": "POST",
        "url": "https://api.xero.com/api.xro/2.0/ManualJournals",
        "authentication": "genericCredentialType",
        "genericAuthType": "oAuth2Api",
        "sendHeaders": true,
        "headerParameters": {
          "parameters": [
            {
              "name": "Xero-tenant-id",
              "value": "={{ $('Set Xero Tenant Id1').item.json.tenantId }}"
            },
            {
              "name": "Content-Type",
              "value": "application/json"
            },
            {
              "name": "Accept",
              "value": "application/json"
            }
          ]
        },
        "sendBody": true,
        "specifyBody": "json",
        "jsonBody": "={{ JSON.stringify($json.xero_request_body) }}",
        "options": {}
      },
      "id": "97134988-97e1-4578-9332-1d84f50a11a7",
      "name": "POST Xero Manual Journal1",
      "type": "n8n-nodes-base.httpRequest",
      "typeVersion": 4.2,
      "position": [
        11616,
        4112
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "oAuth2Api": {
          "name": "<your credential>"
        }
      },
      "onError": "continueErrorOutput",
      "notes": "POST /api.xro/2.0/ManualJournals. onError=continueErrorOutput so 4xx/5xx/network failures route to the IF Branch downstream rather than aborting."
    },
    {
      "parameters": {
        "conditions": {
          "options": {
            "caseSensitive": true,
            "leftValue": "",
            "typeValidation": "strict",
            "version": 1
          },
          "conditions": [
            {
              "id": "c1",
              "leftValue": "={{ $json.error && $json.error.httpCode ? Number($json.error.httpCode) : 0 }}",
              "rightValue": 500,
              "operator": {
                "type": "number",
                "operation": "lt"
              }
            },
            {
              "id": "c2",
              "leftValue": "={{ $json.error && $json.error.httpCode ? Number($json.error.httpCode) : 0 }}",
              "rightValue": 400,
              "operator": {
                "type": "number",
                "operation": "gte"
              }
            }
          ],
          "combinator": "and"
        },
        "options": {}
      },
      "id": "a0ce8cb2-c594-485e-9741-df71981b48c1",
      "name": "Branch Xero Error 4xx vs 5xx1",
      "type": "n8n-nodes-base.if",
      "typeVersion": 2,
      "position": [
        11840,
        4304
      ],
      "notes": "TRUE = httpCode in [400, 500) -> 4xx envelope. FALSE = 5xx, missing httpCode (timeout/DNS/connection reset), or post-retry exhaustion -> 5xx envelope. Network failures are NOT treated as success."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "UPDATE payment_recon.payouts SET status = 'POSTED', xero_journal_id = $1, updated_at = now() WHERE id = $2 RETURNING id AS payout_uuid;",
        "options": {
          "queryReplacement": "={{ $json.ManualJournals[0].ManualJournalID }},={{ $('Validate Balance1').item.json.payout_uuid }}"
        }
      },
      "id": "e6a28f5d-54b9-4f70-8adb-188264d53a04",
      "name": "Update Payouts POSTED1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        12176,
        3968
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "Marks payout POSTED with Xero JournalID. Identity-field trigger blocks the other immutable columns."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "INSERT INTO payment_recon.posting_events (payout_uuid, workflow_run_id, event_type, event_data) VALUES ($1, $2, 'POSTED', $3::jsonb);",
        "options": {
          "queryReplacement": "={{ $json.payout_uuid }},={{ $('Validate Balance1').item.json.workflow_run_id }},={{ JSON.stringify({ xero_journal_id: $('POST Xero Manual Journal1').item.json.ManualJournals[0].ManualJournalID, line_count: $('Validate Balance1').item.json.line_count }) }}"
        }
      },
      "id": "b95e85d7-d236-4829-ab2f-a8e6375ab280",
      "name": "Write POSTED event1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        12400,
        3968
      ],
      "retryOnFail": true,
      "maxTries": 3,
      "waitBetweenTries": 2000,
      "credentials": {
        "postgres": {
          "name": "<your credential>"
        }
      },
      "notes": "POSTED event with Xero JournalID for audit + reversal traceability."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 200,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'POSTED', payout_id: $('Validate Balance1').item.json.payout_id, xero_journal_id: $('POST Xero Manual Journal1').item.json.ManualJournals[0].ManualJournalID, line_count: $('Validate Balance1').item.json.line_count }) }}",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "source_trigger",
              "value": "={{ $('Validate Balance1').item.json.source_trigger }}",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "32eac9f7-8e7c-47ec-9331-9e84b7c02cd6",
      "name": "Set \"Success 200\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        12608,
        3968
      ],
      "notes": "Terminal success envelope."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 401,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'UNAUTHORIZED', message: 'Invalid Stripe signature' }) }}",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "source_trigger",
              "value": "webhook",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "1fed1ca2-7ec2-4cea-a64b-f398107b7143",
      "name": "Set \"401 UNAUTHORIZED\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        7216,
        4096
      ],
      "notes": "Stripe-only. Sig Verify error output lands here. Shopify has no inbound signature."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 200,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'IGNORED', reason: 'not_a_paid_transition' }) }}",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "source_trigger",
              "value": "webhook",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "43c05bf5-ee92-458a-bbd1-2e22c9471d3d",
      "name": "Set \"200 IGNORED\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        7440,
        4096
      ],
      "notes": "Filter to Paid Payout false branch. Stripe sends many non-paid lifecycle events; we 200 them so Stripe doesn't retry."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 200,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'POSTED', payout_id: $json.payout_id, xero_journal_id: $json.existing_xero_journal_id, idempotent: true }) }}",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "source_trigger",
              "value": "={{ $json.source_trigger }}",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "e4c56f7a-3765-4703-bb33-a01532973f6e",
      "name": "Set \"200 Idempotent\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        8752,
        3904
      ],
      "notes": "Existing POSTED row. Returns original JournalID."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 409,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'CONFLICT_PENDING', payout_id: $json.payout_id }) }}",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "source_trigger",
              "value": "={{ $json.source_trigger }}",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "68b0402e-a2a9-4836-829f-8c21aff9c158",
      "name": "Set \"409 Conflict\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        8752,
        4304
      ],
      "notes": "Existing PENDING row. Concurrent run in progress."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 422,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "failed_check",
              "value": "decomposition",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'FAILED', payout_id: $('Resolve Idempotency1').item.json.payout_id, failed_check: 'decomposition', message: ($json.error && $json.error.message) || 'Decomposition error' }) }}",
              "type": "string"
            },
            {
              "id": "e4",
              "name": "source_trigger",
              "value": "={{ $('Resolve Idempotency1').item.json.source_trigger }}",
              "type": "string"
            },
            {
              "id": "e5",
              "name": "processor",
              "value": "={{ $('Resolve Idempotency1').item.json.processor }}",
              "type": "string"
            },
            {
              "id": "e6",
              "name": "payout_id",
              "value": "={{ $('Resolve Idempotency1').item.json.payout_id }}",
              "type": "string"
            },
            {
              "id": "e7",
              "name": "workflow_run_id",
              "value": "={{ $('Resolve Idempotency1').item.json.workflow_run_id }}",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "a34405ae-7935-485b-9d1a-c587476c6697",
      "name": "Set \"422 Decomposition\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        9856,
        4512
      ],
      "notes": "Receives error output from both Decompose Stripe and Decompose Shopify. Multi-parent input is intentional."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 422,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "failed_check",
              "value": "unbalanced",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'FAILED', payout_id: $('Merge Decomposed1').item.json.payout_id, failed_check: 'unbalanced', message: ($json.error && $json.error.message) || 'Validation error' }) }}",
              "type": "string"
            },
            {
              "id": "e4",
              "name": "source_trigger",
              "value": "={{ $('Merge Decomposed1').item.json.source_trigger }}",
              "type": "string"
            },
            {
              "id": "e5",
              "name": "processor",
              "value": "={{ $('Merge Decomposed1').item.json.processor }}",
              "type": "string"
            },
            {
              "id": "e6",
              "name": "payout_id",
              "value": "={{ $('Merge Decomposed1').item.json.payout_id }}",
              "type": "string"
            },
            {
              "id": "e7",
              "name": "workflow_run_id",
              "value": "={{ $('Merge Decomposed1').item.json.workflow_run_id }}",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "4045c4ec-cd62-4403-8eb9-536b7ca592a1",
      "name": "Set \"422 Validation\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        10736,
        4512
      ],
      "notes": "Validate Balance error output lands here."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 422,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "failed_check",
              "value": "xero_4xx",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'FAILED', payout_id: $('Validate Balance1').item.json.payout_id, failed_check: 'xero_4xx', message: ($json.error && $json.error.message) || 'Xero 4xx', http_code: ($json.error && $json.error.httpCode) || null }) }}",
              "type": "string"
            },
            {
              "id": "e4",
              "name": "source_trigger",
              "value": "={{ $('Validate Balance1').item.json.source_trigger }}",
              "type": "string"
            },
            {
              "id": "e5",
              "name": "processor",
              "value": "={{ $('Validate Balance1').item.json.processor }}",
              "type": "string"
            },
            {
              "id": "e6",
              "name": "payout_id",
              "value": "={{ $('Validate Balance1').item.json.payout_id }}",
              "type": "string"
            },
            {
              "id": "e7",
              "name": "workflow_run_id",
              "value": "={{ $('Validate Balance1').item.json.workflow_run_id }}",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "a57c8475-8dd7-424b-9848-8ae64bf64928",
      "name": "Set \"422 Xero 4xx\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        12160,
        4208
      ],
      "notes": "Branch Xero Error true branch (httpCode in [400, 500))."
    },
    {
      "parameters": {
        "assignments": {
          "assignments": [
            {
              "id": "e1",
              "name": "http_code",
              "value": 502,
              "type": "number"
            },
            {
              "id": "e2",
              "name": "failed_check",
              "value": "xero_5xx",
              "type": "string"
            },
            {
              "id": "e3",
              "name": "result_body_json",
              "value": "={{ JSON.stringify({ result: 'FAILED', payout_id: $('Validate Balance1').item.json.payout_id, failed_check: 'xero_5xx', message: ($json.error && $json.error.message) || 'Xero 5xx or network failure', http_code: ($json.error && $json.error.httpCode) || null }) }}",
              "type": "string"
            },
            {
              "id": "e4",
              "name": "source_trigger",
              "value": "={{ $('Validate Balance1').item.json.source_trigger }}",
              "type": "string"
            },
            {
              "id": "e5",
              "name": "processor",
              "value": "={{ $('Validate Balance1').item.json.processor }}",
              "type": "string"
            },
            {
              "id": "e6",
              "name": "payout_id",
              "value": "={{ $('Validate Balance1').item.json.payout_id }}",
              "type": "string"
            },
            {
              "id": "e7",
              "name": "workflow_run_id",
              "value": "={{ $('Validate Balance1').item.json.workflow_run_id }}",
              "type": "string"
            }
          ]
        },
        "options": {}
      },
      "id": "30fcd2fa-a668-4422-ae99-9bb52f8042fe",
      "name": "Set \"502 Xero 5xx\" envelope1",
      "type": "n8n-nodes-base.set",
      "typeVersion": 3.4,
      "position": [
        12112,
        4416
      ],
      "notes": "Branch Xero Error false branch. Catches 5xx, missing httpCode (timeouts, DNS, connection failures), and post-retry exhaustion. Confirmed: NOT treated as success."
    },
    {
      "parameters": {
        "operation": "executeQuery",
        "query": "INSERT INTO payment_recon.payouts (workflow_run_id, processor, payout_id, status, failed_check, currency_code) VALUES ($1, $2, $3, 'FAILED', $4, 'USD') ON CONFLICT (processor, payout_id) DO UPDATE SET status = 'FAILED', failed_check = EXCLUDED.failed_check, updated_at = now() RETURNING id AS payout_uuid;",
        "options": {
          "queryReplacement": "={{ $json.workflow_run_id }},={{ $json.processor }},={{ $json.payout_id }},={{ $json.failed_check }}"
        }
      },
      "id": "178c2be6-625c-45ee-9884-afeb5e2f9268",
      "name": "Update Payouts FAILED1",
      "type": "n8n-nodes-base.postgres",
      "typeVersion": 2.6,
      "position": [
        12496,
        4416
      ],
      "r

Credentials you'll need

Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.

• oAuth2Api
• postgres
• shopifyOAuth2Api
• stripeApi

About this workflow

WF01 — Payout Reconciler (Stripe + Shopify → Xero). Uses httpRequest, postgres. Webhook trigger; 54 nodes.

Source: https://github.com/tabii-dev/accounting-automation-portfolio/blob/main/xero-payment-processor-reconciliation/workflows/01-payout-reconciler.json — original creator credit. Request a take-down →

More E-commerce workflows → · Browse all categories →

Related workflows

Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
