This workflow follows the HTTP Request → Postgres recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "Affine Direct Query Tool",
"nodes": [
{
"parameters": {
"httpMethod": "POST",
"path": "affine-query-tool",
"responseMode": "responseNode",
"options": {}
},
"id": "affine-query-webhook",
"name": "Affine Query Webhook",
"type": "n8n-nodes-base.webhook",
"typeVersion": 2,
"position": [
200,
400
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "query-text-affine",
"name": "queryText",
"value": "={{ $json.body.query || $json.body.searchTerm || '' }}",
"type": "string"
},
{
"id": "query-type-affine",
"name": "queryType",
"value": "={{ $json.body.queryType || 'semantic_search' }}",
"type": "string"
},
{
"id": "workspace-filter-affine",
"name": "workspaceFilter",
"value": "={{ $json.body.workspaceFilter || $vars.affine_workspace_id }}",
"type": "string"
},
{
"id": "doc-type-filter",
"name": "docTypeFilter",
"value": "={{ $json.body.docTypeFilter || ['document', 'whiteboard', 'database'] }}",
"type": "array"
},
{
"id": "result-limit-affine",
"name": "resultLimit",
"value": "={{ $json.body.limit || 10 }}",
"type": "number"
},
{
"id": "include-metadata-affine",
"name": "includeMetadata",
"value": "={{ $json.body.includeMetadata || true }}",
"type": "boolean"
},
{
"id": "search-timestamp",
"name": "timestamp",
"value": "={{ $now }}",
"type": "string"
}
]
},
"options": {}
},
"id": "process-affine-query",
"name": "Process Affine Query",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
450,
400
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "semantic-search-condition-affine",
"leftValue": "={{ $json.queryType }}",
"rightValue": "semantic_search",
"operator": {
"type": "string",
"operation": "equals"
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-affine-query-type",
"name": "Check Affine Query Type",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
700,
400
]
},
{
"parameters": {
"code": {
"execute": {
"code": "const { QdrantVectorStore } = require(\"@langchain/qdrant\");\nconst { OllamaEmbeddings } = require(\"@langchain/community/embeddings/ollama\");\n\nconst embeddings = new OllamaEmbeddings({\n model: \"nomic-embed-text\",\n baseUrl: \"http://ollama:11434\"\n});\n\nconst vectorStore = await QdrantVectorStore.fromExistingCollection(\n embeddings,\n {\n url: \"http://qdrant:6333\",\n collectionName: \"knowledge_base\",\n }\n);\n\nconst queryText = this.getInputData()[0].json.queryText;\nconst resultLimit = this.getInputData()[0].json.resultLimit || 10;\n\n// Create filter for Affine content only\nconst filter = {\n must: [\n {\n key: \"metadata.source\",\n match: {\n value: \"affine\",\n },\n },\n ],\n};\n\n// Perform semantic search\nconst results = await vectorStore.similaritySearch(queryText, resultLimit, filter);\n\n// Format results\nconst formattedResults = results.map((doc, index) => ({\n id: index,\n content: doc.pageContent,\n metadata: doc.metadata,\n source: 'vector_search',\n relevanceScore: doc.score || 0\n}));\n\nreturn [{ json: { results: formattedResults, queryType: 'semantic_search', totalResults: formattedResults.length } }];"
}
},
"inputs": {
"input": [
{
"type": "main",
"required": true
}
]
},
"outputs": {
"output": [
{
"type": "main"
}
]
}
},
"id": "perform-affine-semantic-search",
"name": "Perform Affine Semantic Search",
"type": "@n8n/n8n-nodes-langchain.code",
"typeVersion": 1,
"position": [
950,
300
]
},
{
"parameters": {
"url": "http://affine:3010/graphql",
"options": {
"timeout": 30000
},
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Content-Type",
"value": "application/json"
},
{
"name": "Authorization",
"value": "Bearer {{ $vars.affine_api_token }}"
}
]
},
"sendBody": true,
"contentType": "json",
"body": {
"query": "query SearchWorkspace($workspaceId: String!, $searchTerm: String!) { workspace(id: $workspaceId) { id name docs { id title content updatedAt createdAt type } } }",
"variables": {
"workspaceId": "={{ $('Process Affine Query').item.json.workspaceFilter }}",
"searchTerm": "={{ $('Process Affine Query').item.json.queryText }}"
}
}
},
"id": "fetch-affine-workspace-docs",
"name": "Fetch Affine Workspace Docs",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
950,
500
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "all-docs",
"name": "allDocs",
"value": "={{ $json.data?.workspace?.docs || [] }}",
"type": "array"
},
{
"id": "workspace-info",
"name": "workspaceInfo",
"value": "={{ { id: $json.data?.workspace?.id, name: $json.data?.workspace?.name } }}",
"type": "object"
}
]
},
"options": {}
},
"id": "extract-affine-docs",
"name": "Extract Affine Docs",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
1200,
500
]
},
{
"parameters": {
"fieldsToSplitOut": "allDocs",
"options": {}
},
"id": "split-affine-docs",
"name": "Split Affine Docs",
"type": "n8n-nodes-base.splitInBatches",
"typeVersion": 3,
"position": [
1450,
500
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "filter-matching-docs",
"name": "matchesQuery",
"value": "={{ (() => {\n const queryText = $('Process Affine Query').item.json.queryText.toLowerCase();\n const docText = (($json.title || '') + ' ' + ($json.content || '')).toLowerCase();\n return docText.includes(queryText);\n})() }}",
"type": "boolean"
},
{
"id": "doc-type-matches",
"name": "typeMatches",
"value": "={{ $('Process Affine Query').item.json.docTypeFilter.includes($json.type || 'document') }}",
"type": "boolean"
}
]
},
"options": {}
},
"id": "check-doc-relevance",
"name": "Check Doc Relevance",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
1700,
500
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "doc-matches-condition",
"leftValue": "={{ $json.matchesQuery }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
},
{
"id": "type-matches-condition",
"leftValue": "={{ $json.typeMatches }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "filter-relevant-docs",
"name": "Filter Relevant Docs",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
1950,
500
]
},
{
"parameters": {
"url": "http://affine:3010/graphql",
"options": {
"timeout": 15000
},
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Content-Type",
"value": "application/json"
},
{
"name": "Authorization",
"value": "Bearer {{ $vars.affine_api_token }}"
}
]
},
"sendBody": true,
"contentType": "json",
"body": {
"query": "query GetDocumentDetails($workspaceId: String!, $docId: String!) { workspace(id: $workspaceId) { doc(id: $docId) { id title content updatedAt createdAt type blocks { id type content properties } } } }",
"variables": {
"workspaceId": "={{ $('Extract Affine Docs').item.json.workspaceInfo.id }}",
"docId": "={{ $json.id }}"
}
}
},
"id": "get-detailed-doc-content",
"name": "Get Detailed Doc Content",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
2200,
400
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "format-affine-result",
"name": "formattedResult",
"value": "={{ {\n id: $json.data.workspace.doc.id,\n content: ($json.data.workspace.doc.title || '') + '\\n\\n' + ($json.data.workspace.doc.content || '') + (($json.data.workspace.doc.blocks || []).length > 0 ? '\\n\\nBlocks:\\n' + $json.data.workspace.doc.blocks.map(block => `${block.type}: ${block.content || ''}`).join('\\n') : ''),\n metadata: {\n source: 'affine',\n type: $json.data.workspace.doc.type || 'document',\n doc_id: $json.data.workspace.doc.id,\n workspace_id: $('Extract Affine Docs').item.json.workspaceInfo.id,\n workspace_name: $('Extract Affine Docs').item.json.workspaceInfo.name,\n title: $json.data.workspace.doc.title,\n created_at: $json.data.workspace.doc.createdAt,\n updated_at: $json.data.workspace.doc.updatedAt,\n block_count: ($json.data.workspace.doc.blocks || []).length\n },\n source: 'direct_query',\n relevanceScore: (() => {\n const queryText = $('Process Affine Query').item.json.queryText.toLowerCase();\n const docText = (($json.data.workspace.doc.title || '') + ' ' + ($json.data.workspace.doc.content || '')).toLowerCase();\n const matches = (docText.match(new RegExp(queryText, 'g')) || []).length;\n return Math.min(matches / 10, 1.0); // Normalize to 0-1 range\n })()\n} }}",
"type": "object"
}
]
},
"options": {}
},
"id": "format-affine-query-result",
"name": "Format Affine Query Result",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
2450,
400
]
},
{
"parameters": {
"fieldsToAggregate": {
"fieldToAggregate": [
{
"fieldToAggregate": "formattedResult"
}
]
},
"options": {}
},
"id": "aggregate-affine-results",
"name": "Aggregate Affine Results",
"type": "n8n-nodes-base.aggregate",
"typeVersion": 1,
"position": [
2700,
400
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "combine-affine-results",
"name": "allResults",
"value": "={{ [...($('Perform Affine Semantic Search').all().flatMap(item => item.results || [])), ...($('Aggregate Affine Results').all().flatMap(item => item.formattedResult || []))] }}",
"type": "array"
},
{
"id": "affine-query-summary",
"name": "querySummary",
"value": "={{ {\n queryText: $('Process Affine Query').item.json.queryText,\n queryType: $('Process Affine Query').item.json.queryType,\n workspaceId: $('Process Affine Query').item.json.workspaceFilter,\n totalResults: $json.allResults.length,\n semanticResults: ($('Perform Affine Semantic Search').all().flatMap(item => item.results || [])).length,\n directResults: ($('Aggregate Affine Results').all().flatMap(item => item.formattedResult || [])).length,\n timestamp: $now\n} }}",
"type": "object"
}
]
},
"options": {}
},
"id": "combine-affine-results",
"name": "Combine Affine Results",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
2950,
400
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "ranked-affine-results",
"name": "rankedResults",
"value": "={{ $json.allResults.sort((a, b) => b.relevanceScore - a.relevanceScore).slice(0, $('Process Affine Query').item.json.resultLimit) }}",
"type": "array"
},
{
"id": "affine-response-metadata",
"name": "responseMetadata",
"value": "={{ {\n queryProcessed: $json.querySummary.queryText,\n resultsFound: $json.rankedResults.length,\n queryType: $json.querySummary.queryType,\n workspaceSearched: $json.querySummary.workspaceId,\n includeMetadata: $('Process Affine Query').item.json.includeMetadata,\n docTypesFiltered: $('Process Affine Query').item.json.docTypeFilter,\n timestamp: $now\n} }}",
"type": "object"
}
]
},
"options": {}
},
"id": "rank-affine-results",
"name": "Rank Affine Results",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
3200,
400
]
},
{
"parameters": {
"operation": "insert",
"table": {
"__rl": true,
"value": "query_analytics",
"mode": "list"
},
"data": {
"insert": [
{
"column": "query_text",
"value": "={{ $('Process Affine Query').item.json.queryText }}"
},
{
"column": "query_type",
"value": "affine_direct"
},
{
"column": "results_count",
"value": "={{ $json.rankedResults.length }}"
},
{
"column": "response_time_ms",
"value": "={{ $now - $('Process Affine Query').item.json.timestamp }}"
},
{
"column": "query_metadata",
"value": "={{ $json.responseMetadata }}"
},
{
"column": "created_at",
"value": "={{ $now }}"
}
]
},
"options": {}
},
"id": "log-affine-query-analytics",
"name": "Log Affine Query Analytics",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
3450,
600
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"options": {}
},
"id": "respond-to-affine-query",
"name": "Respond to Affine Query",
"type": "n8n-nodes-base.respondToWebhook",
"typeVersion": 1.1,
"position": [
3450,
400
]
},
{
"parameters": {
"content": "## Affine Direct Query Tool\n\n**Purpose:** Direct querying interface for Affine workspaces with GraphQL API integration and semantic search capabilities.\n\n**Features:**\n- **Semantic Search**: Vector-based similarity search using embeddings\n- **GraphQL Query**: Direct workspace and document querying\n- **Document Type Filtering**: Support for documents, whiteboards, databases\n- **Block-level Search**: Content analysis including Affine blocks\n- **Result Ranking**: Relevance scoring based on query matches\n- **Analytics**: Query performance tracking and usage analytics\n\n**Query Types:**\n- `semantic_search`: Vector similarity search (default)\n- `direct_query`: GraphQL-based workspace search\n- `hybrid`: Combination of both approaches\n\n**Supported Document Types:**\n- `document`: Regular text documents\n- `whiteboard`: Visual collaboration boards\n- `database`: Structured data tables\n\n**API Parameters:**\n- `query`: Search text/question\n- `queryType`: Type of search to perform\n- `workspaceFilter`: Target workspace ID\n- `docTypeFilter`: Document types to include\n- `limit`: Maximum results to return\n- `includeMetadata`: Include detailed metadata\n\n**Response Format:**\n```json\n{\n \"rankedResults\": [...],\n \"responseMetadata\": {...}\n}\n```",
"height": 650,
"width": 700,
"color": 5
},
"id": "affine-query-documentation",
"name": "Affine Query Documentation",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
100,
100
]
}
],
"connections": {
"Affine Query Webhook": {
"main": [
[
{
"node": "Process Affine Query",
"type": "main",
"index": 0
}
]
]
},
"Process Affine Query": {
"main": [
[
{
"node": "Check Affine Query Type",
"type": "main",
"index": 0
}
]
]
},
"Check Affine Query Type": {
"main": [
[
{
"node": "Perform Affine Semantic Search",
"type": "main",
"index": 0
}
],
[
{
"node": "Fetch Affine Workspace Docs",
"type": "main",
"index": 0
}
]
]
},
"Perform Affine Semantic Search": {
"main": [
[
{
"node": "Combine Affine Results",
"type": "main",
"index": 0
}
]
]
},
"Fetch Affine Workspace Docs": {
"main": [
[
{
"node": "Extract Affine Docs",
"type": "main",
"index": 0
}
]
]
},
"Extract Affine Docs": {
"main": [
[
{
"node": "Split Affine Docs",
"type": "main",
"index": 0
}
]
]
},
"Split Affine Docs": {
"main": [
[
{
"node": "Check Doc Relevance",
"type": "main",
"index": 0
}
]
]
},
"Check Doc Relevance": {
"main": [
[
{
"node": "Filter Relevant Docs",
"type": "main",
"index": 0
}
]
]
},
"Filter Relevant Docs": {
"main": [
[
{
"node": "Get Detailed Doc Content",
"type": "main",
"index": 0
}
]
]
},
"Get Detailed Doc Content": {
"main": [
[
{
"node": "Format Affine Query Result",
"type": "main",
"index": 0
}
]
]
},
"Format Affine Query Result": {
"main": [
[
{
"node": "Aggregate Affine Results",
"type": "main",
"index": 0
}
]
]
},
"Aggregate Affine Results": {
"main": [
[
{
"node": "Combine Affine Results",
"type": "main",
"index": 0
}
]
]
},
"Combine Affine Results": {
"main": [
[
{
"node": "Rank Affine Results",
"type": "main",
"index": 0
}
]
]
},
"Rank Affine Results": {
"main": [
[
{
"node": "Respond to Affine Query",
"type": "main",
"index": 0
},
{
"node": "Log Affine Query Analytics",
"type": "main",
"index": 0
}
]
]
}
},
"active": true,
"settings": {
"executionOrder": "v1"
},
"versionId": "affine-query-v1",
"meta": {
"templateCredsSetupCompleted": true
},
"id": "AffineQueryTool",
"tags": [
"affine",
"query",
"search",
"tool",
"semantic",
"graphql"
]
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
postgres
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
Affine Direct Query Tool. Uses httpRequest, postgres. Webhook trigger; 17 nodes.
Source: https://github.com/161sam/n8n-installer/blob/main/modularium/ai-workspace/Affine-Query-Tool.json — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
Cross-Platform Knowledge Search Tool. Uses httpRequest, googleDrive, postgres. Webhook trigger; 20 nodes.
HTTP Request, Google Drive, Postgres
Postgres. Uses openAi, postgres, postgresTool, httpRequest. Webhook trigger; 19 nodes.
OpenAI, Postgres, Postgres Tool +2
Crop Planning. Uses postgres, httpRequest, respondToWebhook, googleGemini. Webhook trigger; 11 nodes.
Postgres, HTTP Request, Google Gemini +1
OTTO - Épico 1: Resolução Determinística de Identidade. Uses openAi, postgres, httpRequest. Webhook trigger; 11 nodes.
OpenAI, Postgres, HTTP Request
OTTO - Épico 2: Funil de Hipótese (IA Sugere, Sistema Julga). Uses openAi, postgres, httpRequest. Webhook trigger; 10 nodes.
OpenAI, Postgres, HTTP Request
