This workflow follows the Google Drive → HTTP Request recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "Cross-Platform Knowledge Search Tool",
"nodes": [
{
"parameters": {
"httpMethod": "POST",
"path": "cross-platform-search",
"responseMode": "responseNode",
"options": {}
},
"id": "cross-platform-search-webhook",
"name": "Cross-Platform Search Webhook",
"type": "n8n-nodes-base.webhook",
"typeVersion": 2,
"position": [
200,
400
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "search-query",
"name": "searchQuery",
"value": "={{ $json.body.query || $json.body.searchTerm || '' }}",
"type": "string"
},
{
"id": "target-platforms",
"name": "targetPlatforms",
"value": "={{ $json.body.platforms || ['appflowy', 'affine', 'google_drive', 'vector_db'] }}",
"type": "array"
},
{
"id": "search-mode",
"name": "searchMode",
"value": "={{ $json.body.mode || 'comprehensive' }}",
"type": "string"
},
{
"id": "result-limit-cross",
"name": "resultLimit",
"value": "={{ $json.body.limit || 20 }}",
"type": "number"
},
{
"id": "enable-deduplication",
"name": "enableDeduplication",
"value": "={{ $json.body.enableDeduplication || true }}",
"type": "boolean"
},
{
"id": "priority-sources",
"name": "prioritySources",
"value": "={{ $json.body.prioritySources || [] }}",
"type": "array"
},
{
"id": "search-timestamp",
"name": "timestamp",
"value": "={{ $now }}",
"type": "string"
},
{
"id": "enable-analytics",
"name": "enableAnalytics",
"value": "={{ $json.body.enableAnalytics || true }}",
"type": "boolean"
}
]
},
"options": {}
},
"id": "process-cross-platform-query",
"name": "Process Cross-Platform Query",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
450,
400
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "appflowy-enabled",
"leftValue": "={{ $json.targetPlatforms.includes('appflowy') }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-appflowy-enabled",
"name": "Check AppFlowy Enabled",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
700,
200
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "affine-enabled",
"leftValue": "={{ $json.targetPlatforms.includes('affine') }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-affine-enabled",
"name": "Check Affine Enabled",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
700,
300
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "vector-db-enabled",
"leftValue": "={{ $json.targetPlatforms.includes('vector_db') }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-vector-db-enabled",
"name": "Check Vector DB Enabled",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
700,
400
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "google-drive-enabled",
"leftValue": "={{ $json.targetPlatforms.includes('google_drive') }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-google-drive-enabled",
"name": "Check Google Drive Enabled",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
700,
500
]
},
{
"parameters": {
"url": "https://n8n.{{ $vars.domain_name }}/webhook/appflowy-query-tool",
"options": {
"timeout": 30000
},
"sendBody": true,
"contentType": "json",
"body": {
"query": "={{ $('Process Cross-Platform Query').item.json.searchQuery }}",
"queryType": "semantic_search",
"limit": "={{ Math.ceil($('Process Cross-Platform Query').item.json.resultLimit / 4) }}",
"includeMetadata": true
}
},
"id": "query-appflowy",
"name": "Query AppFlowy",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
950,
150
]
},
{
"parameters": {
"url": "https://n8n.{{ $vars.domain_name }}/webhook/affine-query-tool",
"options": {
"timeout": 30000
},
"sendBody": true,
"contentType": "json",
"body": {
"query": "={{ $('Process Cross-Platform Query').item.json.searchQuery }}",
"queryType": "semantic_search",
"limit": "={{ Math.ceil($('Process Cross-Platform Query').item.json.resultLimit / 4) }}",
"includeMetadata": true
}
},
"id": "query-affine",
"name": "Query Affine",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
950,
250
]
},
{
"parameters": {
"code": {
"execute": {
"code": "const { QdrantVectorStore } = require(\"@langchain/qdrant\");\nconst { OllamaEmbeddings } = require(\"@langchain/community/embeddings/ollama\");\n\nconst embeddings = new OllamaEmbeddings({\n model: \"nomic-embed-text\",\n baseUrl: \"http://ollama:11434\"\n});\n\nconst vectorStore = await QdrantVectorStore.fromExistingCollection(\n embeddings,\n {\n url: \"http://qdrant:6333\",\n collectionName: \"knowledge_base\",\n }\n);\n\nconst queryText = this.getInputData()[0].json.searchQuery;\nconst resultLimit = Math.ceil(this.getInputData()[0].json.resultLimit / 4) || 5;\n\n// Comprehensive search across all sources in vector DB\nconst results = await vectorStore.similaritySearch(queryText, resultLimit);\n\n// Format results with enhanced metadata\nconst formattedResults = results.map((doc, index) => ({\n id: `vector_${index}`,\n content: doc.pageContent,\n metadata: {\n ...doc.metadata,\n searchSource: 'vector_database',\n queryMatched: queryText\n },\n source: 'vector_database',\n relevanceScore: doc.score || 0,\n platform: doc.metadata?.source || 'unknown'\n}));\n\nreturn [{ json: { results: formattedResults, searchType: 'vector_search', totalResults: formattedResults.length } }];"
}
},
"inputs": {
"input": [
{
"type": "main",
"required": true
}
]
},
"outputs": {
"output": [
{
"type": "main"
}
]
}
},
"id": "query-vector-database",
"name": "Query Vector Database",
"type": "@n8n/n8n-nodes-langchain.code",
"typeVersion": 1,
"position": [
950,
350
]
},
{
"parameters": {
"authentication": "oAuth2",
"resource": "file",
"operation": "search",
"q": "={{ $('Process Cross-Platform Query').item.json.searchQuery }}",
"options": {
"fields": [
"id",
"name",
"mimeType",
"createdTime",
"modifiedTime",
"size",
"webViewLink"
]
}
},
"id": "query-google-drive",
"name": "Query Google Drive",
"type": "n8n-nodes-base.googleDrive",
"typeVersion": 3,
"position": [
950,
450
],
"credentials": {
"googleDriveOAuth2Api": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "format-google-drive-results",
"name": "formattedResults",
"value": "={{ $json.files?.map((file, index) => ({\n id: `gdrive_${file.id}`,\n content: `${file.name}\\n\\nFile Type: ${file.mimeType}\\nCreated: ${file.createdTime}\\nModified: ${file.modifiedTime}\\nSize: ${file.size || 'Unknown'} bytes`,\n metadata: {\n source: 'google_drive',\n type: 'file',\n file_id: file.id,\n file_name: file.name,\n mime_type: file.mimeType,\n created_time: file.createdTime,\n modified_time: file.modifiedTime,\n web_view_link: file.webViewLink,\n searchSource: 'google_drive_api'\n },\n source: 'google_drive',\n relevanceScore: 0.8, // Base relevance for Google Drive matches\n platform: 'google_drive'\n})) || [] }}",
"type": "array"
}
]
},
"options": {}
},
"id": "format-google-drive-results",
"name": "Format Google Drive Results",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
1200,
450
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "aggregate-all-results",
"name": "allResults",
"value": "={{ [\n ...($('Query AppFlowy').all().flatMap(item => item.rankedResults || [])),\n ...($('Query Affine').all().flatMap(item => item.rankedResults || [])),\n ...($('Query Vector Database').all().flatMap(item => item.results || [])),\n ...($('Format Google Drive Results').all().flatMap(item => item.formattedResults || []))\n] }}",
"type": "array"
},
{
"id": "platform-summary",
"name": "platformSummary",
"value": "={{ {\n appflowy: ($('Query AppFlowy').all().flatMap(item => item.rankedResults || [])).length,\n affine: ($('Query Affine').all().flatMap(item => item.rankedResults || [])).length,\n vector_database: ($('Query Vector Database').all().flatMap(item => item.results || [])).length,\n google_drive: ($('Format Google Drive Results').all().flatMap(item => item.formattedResults || [])).length\n} }}",
"type": "object"
}
]
},
"options": {}
},
"id": "aggregate-platform-results",
"name": "Aggregate Platform Results",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
1450,
400
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "deduplication-enabled",
"leftValue": "={{ $('Process Cross-Platform Query').item.json.enableDeduplication }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-deduplication-enabled",
"name": "Check Deduplication Enabled",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
1700,
400
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "deduplicated-results",
"name": "deduplicatedResults",
"value": "={{ (() => {\n const results = $json.allResults;\n const seen = new Set();\n const deduplicated = [];\n \n for (const result of results) {\n // Create a content fingerprint for deduplication\n const contentFingerprint = result.content?.substring(0, 100).toLowerCase().replace(/\\s+/g, ' ').trim();\n const titleFingerprint = result.metadata?.title?.toLowerCase();\n const fingerprint = titleFingerprint || contentFingerprint;\n \n if (fingerprint && !seen.has(fingerprint)) {\n seen.add(fingerprint);\n deduplicated.push({\n ...result,\n deduplicationFingerprint: fingerprint\n });\n }\n }\n \n return deduplicated;\n})() }}",
"type": "array"
}
]
},
"options": {}
},
"id": "perform-deduplication",
"name": "Perform Deduplication",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
1950,
300
]
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "final-ranked-results",
"name": "finalResults",
"value": "={{ (() => {\n const results = $('Perform Deduplication').all().length > 0 \n ? $('Perform Deduplication').item.json.deduplicatedResults \n : $json.allResults;\n \n const prioritySources = $('Process Cross-Platform Query').item.json.prioritySources;\n const resultLimit = $('Process Cross-Platform Query').item.json.resultLimit;\n \n // Apply priority boosting\n const boostedResults = results.map(result => ({\n ...result,\n finalScore: result.relevanceScore + (prioritySources.includes(result.platform) ? 0.2 : 0)\n }));\n \n // Sort by final score and limit results\n return boostedResults\n .sort((a, b) => b.finalScore - a.finalScore)\n .slice(0, resultLimit);\n})() }}",
"type": "array"
},
{
"id": "search-analytics",
"name": "searchAnalytics",
"value": "={{ {\n queryText: $('Process Cross-Platform Query').item.json.searchQuery,\n searchMode: $('Process Cross-Platform Query').item.json.searchMode,\n platformsSearched: $('Process Cross-Platform Query').item.json.targetPlatforms,\n totalResultsFound: $json.finalResults.length,\n platformBreakdown: $('Aggregate Platform Results').item.json.platformSummary,\n deduplicationEnabled: $('Process Cross-Platform Query').item.json.enableDeduplication,\n prioritySourcesUsed: $('Process Cross-Platform Query').item.json.prioritySources,\n searchTimestamp: $('Process Cross-Platform Query').item.json.timestamp,\n processingTimeMs: $now - $('Process Cross-Platform Query').item.json.timestamp\n} }}",
"type": "object"
}
]
},
"options": {}
},
"id": "finalize-cross-platform-results",
"name": "Finalize Cross-Platform Results",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
2200,
400
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict"
},
"conditions": [
{
"id": "analytics-enabled",
"leftValue": "={{ $('Process Cross-Platform Query').item.json.enableAnalytics }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "check-analytics-enabled",
"name": "Check Analytics Enabled",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
2450,
400
]
},
{
"parameters": {
"operation": "insert",
"table": {
"__rl": true,
"value": "cross_platform_search_analytics",
"mode": "list"
},
"data": {
"insert": [
{
"column": "query_text",
"value": "={{ $('Finalize Cross-Platform Results').item.json.searchAnalytics.queryText }}"
},
{
"column": "search_mode",
"value": "={{ $('Finalize Cross-Platform Results').item.json.searchAnalytics.searchMode }}"
},
{
"column": "platforms_searched",
"value": "={{ $('Finalize Cross-Platform Results').item.json.searchAnalytics.platformsSearched }}"
},
{
"column": "total_results",
"value": "={{ $('Finalize Cross-Platform Results').item.json.searchAnalytics.totalResultsFound }}"
},
{
"column": "platform_breakdown",
"value": "={{ $('Finalize Cross-Platform Results').item.json.searchAnalytics.platformBreakdown }}"
},
{
"column": "processing_time_ms",
"value": "={{ $('Finalize Cross-Platform Results').item.json.searchAnalytics.processingTimeMs }}"
},
{
"column": "deduplication_enabled",
"value": "={{ $('Finalize Cross-Platform Results').item.json.searchAnalytics.deduplicationEnabled }}"
},
{
"column": "created_at",
"value": "={{ $now }}"
}
]
},
"options": {}
},
"id": "log-cross-platform-analytics",
"name": "Log Cross-Platform Analytics",
"type": "n8n-nodes-base.postgres",
"typeVersion": 2.5,
"position": [
2700,
300
],
"credentials": {
"postgres": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "api-response",
"name": "response",
"value": "={{ {\n results: $('Finalize Cross-Platform Results').item.json.finalResults,\n analytics: $('Finalize Cross-Platform Results').item.json.searchAnalytics,\n metadata: {\n queryProcessed: $('Process Cross-Platform Query').item.json.searchQuery,\n totalPlatforms: $('Process Cross-Platform Query').item.json.targetPlatforms.length,\n resultsReturned: $('Finalize Cross-Platform Results').item.json.finalResults.length,\n timestamp: $now\n }\n} }}",
"type": "object"
}
]
},
"options": {}
},
"id": "prepare-api-response",
"name": "Prepare API Response",
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
2950,
400
]
},
{
"parameters": {
"options": {}
},
"id": "respond-to-cross-platform-search",
"name": "Respond to Cross-Platform Search",
"type": "n8n-nodes-base.respondToWebhook",
"typeVersion": 1.1,
"position": [
3200,
400
]
},
{
"parameters": {
"content": "## Cross-Platform Knowledge Search Tool\n\n**Purpose:** Unified search interface across all knowledge management platforms with intelligent result aggregation and deduplication.\n\n**Supported Platforms:**\n- **AppFlowy**: Database rows, pages, and documents\n- **Affine**: Documents, whiteboards, and databases\n- **Vector Database**: Semantic search across all ingested content\n- **Google Drive**: Files, documents, and folders\n\n**Key Features:**\n- **Multi-Platform Search**: Simultaneous search across all enabled platforms\n- **Intelligent Deduplication**: Remove duplicate content across platforms\n- **Priority Sources**: Boost results from specified platforms\n- **Relevance Ranking**: Smart scoring and result prioritization\n- **Analytics**: Comprehensive search performance tracking\n- **Flexible Configuration**: Enable/disable platforms per search\n\n**Search Modes:**\n- `comprehensive`: Search all enabled platforms (default)\n- `semantic_only`: Vector database semantic search only\n- `direct_only`: Platform-specific direct queries only\n- `hybrid`: Combination approach with relevance scoring\n\n**API Parameters:**\n- `query`: Search text/question\n- `platforms`: Array of platforms to search\n- `mode`: Search mode to use\n- `limit`: Maximum total results\n- `enableDeduplication`: Remove duplicate content\n- `prioritySources`: Platforms to prioritize in results\n- `enableAnalytics`: Track search performance\n\n**Response Format:**\n```json\n{\n \"results\": [...],\n \"analytics\": {...},\n \"metadata\": {...}\n}\n```",
"height": 700,
"width": 800,
"color": 6
},
"id": "cross-platform-search-documentation",
"name": "Cross-Platform Search Documentation",
"type": "n8n-nodes-base.stickyNote",
"typeVersion": 1,
"position": [
100,
100
]
}
],
"connections": {
"Cross-Platform Search Webhook": {
"main": [
[
{
"node": "Process Cross-Platform Query",
"type": "main",
"index": 0
}
]
]
},
"Process Cross-Platform Query": {
"main": [
[
{
"node": "Check AppFlowy Enabled",
"type": "main",
"index": 0
},
{
"node": "Check Affine Enabled",
"type": "main",
"index": 0
},
{
"node": "Check Vector DB Enabled",
"type": "main",
"index": 0
},
{
"node": "Check Google Drive Enabled",
"type": "main",
"index": 0
}
]
]
},
"Check AppFlowy Enabled": {
"main": [
[
{
"node": "Query AppFlowy",
"type": "main",
"index": 0
}
]
]
},
"Check Affine Enabled": {
"main": [
[
{
"node": "Query Affine",
"type": "main",
"index": 0
}
]
]
},
"Check Vector DB Enabled": {
"main": [
[
{
"node": "Query Vector Database",
"type": "main",
"index": 0
}
]
]
},
"Check Google Drive Enabled": {
"main": [
[
{
"node": "Query Google Drive",
"type": "main",
"index": 0
}
]
]
},
"Query Google Drive": {
"main": [
[
{
"node": "Format Google Drive Results",
"type": "main",
"index": 0
}
]
]
},
"Format Google Drive Results": {
"main": [
[
{
"node": "Aggregate Platform Results",
"type": "main",
"index": 0
}
]
]
},
"Query AppFlowy": {
"main": [
[
{
"node": "Aggregate Platform Results",
"type": "main",
"index": 0
}
]
]
},
"Query Affine": {
"main": [
[
{
"node": "Aggregate Platform Results",
"type": "main",
"index": 0
}
]
]
},
"Query Vector Database": {
"main": [
[
{
"node": "Aggregate Platform Results",
"type": "main",
"index": 0
}
]
]
},
"Aggregate Platform Results": {
"main": [
[
{
"node": "Check Deduplication Enabled",
"type": "main",
"index": 0
}
]
]
},
"Check Deduplication Enabled": {
"main": [
[
{
"node": "Perform Deduplication",
"type": "main",
"index": 0
}
],
[
{
"node": "Finalize Cross-Platform Results",
"type": "main",
"index": 0
}
]
]
},
"Perform Deduplication": {
"main": [
[
{
"node": "Finalize Cross-Platform Results",
"type": "main",
"index": 0
}
]
]
},
"Finalize Cross-Platform Results": {
"main": [
[
{
"node": "Check Analytics Enabled",
"type": "main",
"index": 0
}
]
]
},
"Check Analytics Enabled": {
"main": [
[
{
"node": "Log Cross-Platform Analytics",
"type": "main",
"index": 0
}
],
[
{
"node": "Prepare API Response",
"type": "main",
"index": 0
}
]
]
},
"Log Cross-Platform Analytics": {
"main": [
[
{
"node": "Prepare API Response",
"type": "main",
"index": 0
}
]
]
},
"Prepare API Response": {
"main": [
[
{
"node": "Respond to Cross-Platform Search",
"type": "main",
"index": 0
}
]
]
}
},
"active": true,
"settings": {
"executionOrder": "v1"
},
"versionId": "cross-platform-search-v1",
"meta": {
"templateCredsSetupCompleted": true
},
"id": "CrossPlatformSearch",
"tags": [
"cross-platform",
"search",
"aggregation",
"deduplication",
"knowledge-management"
]
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
googleDriveOAuth2Apipostgres
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
Cross-Platform Knowledge Search Tool. Uses httpRequest, googleDrive, postgres. Webhook trigger; 20 nodes.
Source: https://github.com/161sam/n8n-installer/blob/main/modularium/ai-workspace/Cross-Platform-Search.json — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
This n8n workflow automates the transformation of spreadsheet data into professional charts and graphs using AI-driven analysis. Triggered via Slack, it processes uploaded files (Excel, CSV, Google Sh
Agent, Postgres, HTTP Request +8
Postgres. Uses openAi, postgres, postgresTool, httpRequest. Webhook trigger; 19 nodes.
OpenAI, Postgres, Postgres Tool +2
Affine Direct Query Tool. Uses httpRequest, postgres. Webhook trigger; 17 nodes.
HTTP Request, Postgres
Crop Planning. Uses postgres, httpRequest, respondToWebhook, googleGemini. Webhook trigger; 11 nodes.
Postgres, HTTP Request, Google Gemini +1
OTTO - Épico 1: Resolução Determinística de Identidade. Uses openAi, postgres, httpRequest. Webhook trigger; 11 nodes.
OpenAI, Postgres, HTTP Request
