This workflow corresponds to n8n.io template #3912 — we link there as the canonical source.
This workflow follows the Gmail → Google Sheets recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "QO4Mg23JvVfNCICy",
"meta": {
"templateCredsSetupCompleted": true
},
"name": "Build a Phone Agent to qualify outbound leads and inbound calls with RetellAI -vide",
"tags": [
{
"id": "12w64ydbjEKDaM0B",
"name": "inbound",
"createdAt": "2025-05-06T20:31:43.427Z",
"updatedAt": "2025-05-06T20:31:43.427Z"
},
{
"id": "xSqaFWDcbJCRECKZ",
"name": "outbound",
"createdAt": "2025-05-06T20:31:38.072Z",
"updatedAt": "2025-05-06T20:31:38.072Z"
}
],
"nodes": [
{
"id": "78f39980-c9f8-49b6-93bb-a1f61d347ac3",
"name": "Sticky Note",
"type": "n8n-nodes-base.stickyNote",
"position": [
-240,
0
],
"parameters": {
"width": 1260,
"height": 320,
"content": "# Outbound lead qualification call workflow"
},
"typeVersion": 1
},
{
"id": "661006b9-dac7-4ac0-882a-2e0cba9dbae1",
"name": "Sticky Note4",
"type": "n8n-nodes-base.stickyNote",
"position": [
-240,
360
],
"parameters": {
"color": 5,
"width": 1260,
"height": 320,
"content": "# Inbound call appointment scheduler workflow"
},
"typeVersion": 1
},
{
"id": "96a278b9-8d2e-4f85-9f6a-2997932a7ca4",
"name": "Sticky Note2",
"type": "n8n-nodes-base.stickyNote",
"position": [
1060,
-420
],
"parameters": {
"color": 4,
"width": 1400,
"height": 1100,
"content": "# Post-call workflow\n## Triggers when a new lead is added in Google Sheets:\n\n### 1 -Sends SMS to remind rep to call in 5 min\n### 2- (Optional delay step)\n### 3- Triggers RetellAI to place an automated call to the lead\n\n## \ud83d\udca1 Requires phone numbers to be formatted in E.164"
},
"typeVersion": 1
},
{
"id": "d082f904-f185-4615-b0d8-9438c731786f",
"name": "Detect new lead in Google Sheets",
"type": "n8n-nodes-base.googleSheetsTrigger",
"position": [
-160,
100
],
"parameters": {
"event": "rowAdded",
"options": {},
"pollTimes": {
"item": [
{
"mode": "everyHour"
}
]
},
"sheetName": {
"__rl": true,
"mode": "id",
"value": "="
},
"documentId": {
"__rl": true,
"mode": "id",
"value": "="
}
},
"credentials": {
"googleSheetsTriggerOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "c61172c2-7795-47be-acaa-d4824ca69680",
"name": "Send SMS reminder to call lead in 5 minutes",
"type": "n8n-nodes-base.twilio",
"position": [
140,
100
],
"parameters": {
"to": "={{ $json['Phone Number'] }}",
"from": "+1234567890",
"message": "Hello, thanks for your interest in our roofing services. We'll be calling you shortly to ask about your project!",
"options": {},
"resource": "call"
},
"credentials": {
"twilioApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "d88573d4-ec99-40e4-8603-f1e910d034d1",
"name": "Wait 5 minutes before making call",
"type": "n8n-nodes-base.wait",
"position": [
460,
100
],
"parameters": {
"unit": "minutes",
"amount": 1
},
"typeVersion": 1.1
},
{
"id": "d6778895-90dd-471e-9d9d-c48a35154291",
"name": "Call new lead using RetellAI",
"type": "n8n-nodes-base.httpRequest",
"position": [
760,
100
],
"parameters": {
"url": "https://api.retellai.com/v2/create-phone-call",
"method": "POST",
"options": {},
"jsonBody": "={\n \"from_number\": \"+33600000000\",\n \"to_number\": \"{{ $json['Phone Number'] }}\",\n \"retell_llm_dynamic_variables\": {\n \"uuid\": \"{{ $('Detect new lead in Google Sheets').item.json.UUID }}\"\n }\n}",
"sendBody": true,
"sendHeaders": true,
"specifyBody": "json",
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "Bearer YOUR_TOKEN_HERE"
},
{
"name": "Content-Type",
"value": "application/json"
}
]
}
},
"typeVersion": 4.2
},
{
"id": "8e7e7c0c-2600-4b20-ba30-b855d456d302",
"name": "Receive inbound call from RetellAI (webhook)",
"type": "n8n-nodes-base.webhook",
"position": [
-160,
460
],
"parameters": {
"path": "ebd11c9b-129c-4b59-8c27-9a4b567305f7",
"options": {},
"httpMethod": "POST",
"responseMode": "responseNode"
},
"typeVersion": 2
},
{
"id": "36bf25b0-d39d-4127-b005-5e3619069744",
"name": "Check if phone number exists in Google Sheets",
"type": "n8n-nodes-base.googleSheets",
"position": [
300,
460
],
"parameters": {
"options": {},
"filtersUI": {
"values": [
{
"lookupValue": "={{ $json.body.call_inbound.from_number }}",
"lookupColumn": "Phone Number"
}
]
},
"sheetName": {
"__rl": true,
"mode": "id",
"value": "="
},
"documentId": {
"__rl": true,
"mode": "id",
"value": "="
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.5
},
{
"id": "0b2dc7b9-84c1-488b-9d02-47cf6ee460c7",
"name": "Send response to inbound webhook call",
"type": "n8n-nodes-base.respondToWebhook",
"position": [
760,
460
],
"parameters": {
"options": {},
"respondWith": "json",
"responseBody": "={\n \"call_inbound\": {\n \"dynamic_variables\": {\n \"name\": \"{{ $json.Name }}\"\n }\n }\n}"
},
"typeVersion": 1.1
},
{
"id": "063a4a31-429f-4cf0-b248-869131e92633",
"name": "Receive post-call data from RetellAI (webhook)",
"type": "n8n-nodes-base.webhook",
"position": [
1180,
80
],
"parameters": {
"path": "f8878b78-43ea-4caa-b16c-cde9aaf2e9b1",
"options": {},
"httpMethod": "POST"
},
"typeVersion": 2
},
{
"id": "215e2031-983a-4785-b46d-026f64c115e4",
"name": "Filter for analyzed calls only",
"type": "n8n-nodes-base.filter",
"position": [
1400,
80
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "a0e40476-0054-43ec-b7a7-e872d1c6061a",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.body.event }}",
"rightValue": "call_analyzed"
}
]
}
},
"typeVersion": 2.2
},
{
"id": "f8cae0c3-1b5d-47e6-b7fd-b47558c30d3f",
"name": "Check if call was outbound",
"type": "n8n-nodes-base.if",
"position": [
1620,
80
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "46590184-4e33-48fd-a9f4-c63b13f88c1f",
"operator": {
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.body.call.direction }}",
"rightValue": "outbound"
}
]
}
},
"typeVersion": 2.2
},
{
"id": "8997d5ec-bfb9-4ce9-9e13-6035f02b634e",
"name": "Update lead record in Google Sheets",
"type": "n8n-nodes-base.googleSheets",
"position": [
1860,
-40
],
"parameters": {
"columns": {
"value": {
"UUID": "={{ $json.body.call.retell_llm_dynamic_variables.uuid }}",
"Qualification": "={{ $json.body.call.call_analysis.custom_analysis_data.qualification }}"
},
"schema": [
{
"id": "UUID",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "UUID",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Name",
"type": "string",
"display": true,
"required": false,
"displayName": "Name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Phone Number",
"type": "string",
"display": true,
"required": false,
"displayName": "Phone Number",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Datetime Called",
"type": "string",
"display": true,
"required": false,
"displayName": "Datetime Called",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Qualification",
"type": "string",
"display": true,
"required": false,
"displayName": "Qualification",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "row_number",
"type": "string",
"display": true,
"removed": true,
"readOnly": true,
"required": false,
"displayName": "row_number",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [
"UUID"
],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "update",
"sheetName": {
"__rl": true,
"mode": "id",
"value": "="
},
"documentId": {
"__rl": true,
"mode": "id",
"value": "="
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.5
},
{
"id": "20757ff8-6604-4c80-96ec-32bfac983ed7",
"name": "Send call summary email",
"type": "n8n-nodes-base.gmail",
"position": [
2220,
-40
],
"parameters": {
"sendTo": "user@example.com",
"message": "=Name:\n{{ $json.body.call.call_analysis.custom_analysis_data.first_name }}\n\nNumber:\n{{ $json.body.call.call_analysis.custom_analysis_data.phone_number }}\n\nQualification:\n{{ $json.body.call.call_analysis.custom_analysis_data.qualification }}\n\n\nCall Summary:\n{{ $json.body.call.call_analysis.custom_analysis_data.call_summary }}",
"options": {},
"subject": "=New Lead - Call Summary",
"emailType": "text"
},
"credentials": {
"gmailOAuth2": {
"name": "<your credential>"
}
},
"typeVersion": 2.1
},
{
"id": "753bd92d-b95b-4710-bf49-6da89a43223f",
"name": "Generate call summary with OpenAI",
"type": "@n8n/n8n-nodes-langchain.openAi",
"position": [
1860,
180
],
"parameters": {
"modelId": {
"__rl": true,
"mode": "list",
"value": "gpt-4.1",
"cachedResultName": "GPT-4.1"
},
"options": {},
"messages": {
"values": [
{
"content": "=Analyze this call transcript to identify how the call went and identify possible improvements to the voice prompt:\n\n{{ $json.body.call.transcript }}"
}
]
}
},
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
},
"typeVersion": 1.8
},
{
"id": "cf600277-bb07-4f7a-a9b7-3e20017f716d",
"name": "Send confirmation email to lead",
"type": "n8n-nodes-base.gmail",
"position": [
2220,
180
],
"parameters": {
"sendTo": "user@example.com",
"message": "=New roofing appointment:\n\nClient Name:\n{{ $('Check if call was outbound').item.json.body.call.call_analysis.custom_analysis_data.first_name }}\n\nClient Number:\n{{ $('Check if call was outbound').item.json.body.call.call_analysis.custom_analysis_data.phone_number }}\n\nAvailabilities:\n{{ $('Check if call was outbound').item.json.body.call.call_analysis.custom_analysis_data.availabilities }}\n\n\nCall Summary:\n{{ $('Check if call was outbound').item.json.body.call.call_analysis.call_summary }}\n\n\nChatGPT analysis of how the call went and suggestions for improving the voice prompt:\n{{ $json.message.content }}",
"options": {},
"subject": "=Roofing Appointment Scheduled",
"emailType": "text"
},
"credentials": {
"gmailOAuth2": {
"name": "<your credential>"
}
},
"typeVersion": 2.1
},
{
"id": "f75763b6-0867-4625-89e1-cafa3c9e6e44",
"name": "Sticky Note1",
"type": "n8n-nodes-base.stickyNote",
"position": [
-240,
-420
],
"parameters": {
"width": 1260,
"height": 400,
"content": "# \u2705 General Workflow Explanation\n## This workflow automates outbound and inbound lead calls with RetellAI, Google Sheets, OpenAI, and Gmail. It handles:\n\nScheduling and reminding outbound qualification calls\nHandling inbound appointment calls\nAutomatically updating records and sending summaries post-call\n\n## \ud83d\udc49 Dependencies:\n\nActive RetellAI API key\nGoogle Sheet set up with lead data\nGmail API credentials configured"
},
"typeVersion": 1
}
],
"active": false,
"settings": {
"executionOrder": "v1"
},
"versionId": "879f8e4d-91d7-41fc-825d-08f2ef283c25",
"connections": {
"Check if call was outbound": {
"main": [
[
{
"node": "Update lead record in Google Sheets",
"type": "main",
"index": 0
}
],
[
{
"node": "Generate call summary with OpenAI",
"type": "main",
"index": 0
}
]
]
},
"Filter for analyzed calls only": {
"main": [
[
{
"node": "Check if call was outbound",
"type": "main",
"index": 0
}
]
]
},
"Detect new lead in Google Sheets": {
"main": [
[
{
"node": "Send SMS reminder to call lead in 5 minutes",
"type": "main",
"index": 0
}
]
]
},
"Generate call summary with OpenAI": {
"main": [
[
{
"node": "Send confirmation email to lead",
"type": "main",
"index": 0
}
]
]
},
"Wait 5 minutes before making call": {
"main": [
[
{
"node": "Call new lead using RetellAI",
"type": "main",
"index": 0
}
]
]
},
"Update lead record in Google Sheets": {
"main": [
[
{
"node": "Send call summary email",
"type": "main",
"index": 0
}
]
]
},
"Send SMS reminder to call lead in 5 minutes": {
"main": [
[
{
"node": "Wait 5 minutes before making call",
"type": "main",
"index": 0
}
]
]
},
"Receive inbound call from RetellAI (webhook)": {
"main": [
[
{
"node": "Check if phone number exists in Google Sheets",
"type": "main",
"index": 0
}
]
]
},
"Check if phone number exists in Google Sheets": {
"main": [
[
{
"node": "Send response to inbound webhook call",
"type": "main",
"index": 0
}
]
]
},
"Receive post-call data from RetellAI (webhook)": {
"main": [
[
{
"node": "Filter for analyzed calls only",
"type": "main",
"index": 0
}
]
]
}
}
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
gmailOAuth2googleSheetsOAuth2ApigoogleSheetsTriggerOAuth2ApiopenAiApitwilioApi
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
This workflow is designed for sales teams, call centers, and businesses handling both outbound and inbound lead calls who want to automate their qualification, follow-up, and call documentation process without manual intervention. It’s ideal for teams using Google Sheets,…
Source: https://n8n.io/workflows/3912/ — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
Build a Phone Agent to qualify outbound leads and inbound calls with RetellAI -vide. Uses googleSheetsTrigger, twilio, httpRequest, googleSheets. Event-driven trigger; 18 nodes.
Google Sheets Trigger, Twilio, HTTP Request +3
The workflow is triggered when a new lead is added to your data source (such as a new row in Google Sheets, using the “Google Sheets Trigger” node). The trigger node captures essential lead informatio
Google Sheets Trigger, OpenAI, Google Sheets +2
This workflow automates the creation, rendering, approval, and posting of TikTok-style POV (Point of View) videos to Instagram, with cross-posting to Facebook and YouTube. It eliminates manual video p
OpenAI Chat, Output Parser Item List, HTTP Request +10
This automation is designed to help you generate AI-powered music tracks, cover art, and fully rendered music videos — all triggered from a simple Telegram chat and managed via Google Sheets.
OpenAI Chat, Memory Buffer Window, Output Parser Structured +11
This workflow automates the process of generating, reviewing, and publishing blog posts across multiple platforms, now enhanced with support for RSS Feeds as a content source. It streamlines the manag
HTTP Request, Html Extract, RSS Feed Read +9
