This workflow follows the Chainllm → OpenAI Chat recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "VY4TXYGmqth57Een",
"meta": {
"templateCredsSetupCompleted": true
},
"name": "Docsify example",
"tags": [],
"nodes": [
{
"id": "f41906c3-ee4c-4333-bfd5-426f82ba4bd9",
"name": "CONFIG",
"type": "n8n-nodes-base.set",
"position": [
660,
60
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "b48986ec-f58d-4a7f-afba-677edcb28d31",
"name": "project_path",
"type": "string",
"value": "./.n8n/test_docs"
},
{
"id": "cf632419-f839-4045-922c-03784bb3ae07",
"name": "instance_url",
"type": "string",
"value": "={{$env[\"N8N_PROTOCOL\"]}}://{{$env[\"N8N_HOST\"]}}"
},
{
"id": "7a7c70a6-1853-4ca7-b5b1-e36bb0e190d0",
"name": "HTML_headers",
"type": "string",
"value": "= <meta http-equiv=\"X-UA-Compatible\" content=\"IE=edge,chrome=1\" />\n <meta name=\"viewport\" content=\"width=device-width,initial-scale=1\" />\n <meta charset=\"UTF-8\" />\n <link rel=\"stylesheet\" href=\"//cdn.jsdelivr.net/npm/docsify@4/themes/vue.css\" />\n <script src=\"https://cdn.jsdelivr.net/npm/mermaid/dist/mermaid.min.js\"></script>"
},
{
"id": "1e785afe-f05f-4e51-a164-f341da81ccac",
"name": "HTML_styles_editor",
"type": "string",
"value": "= <style>\n body {\n margin: 0;\n padding: 0;\n overflow: hidden;\n }\n \n .container {\n display: flex;\n flex-direction: column;\n height: 100vh;\n margin: 0;\n }\n\n .button-container {\n display: flex;\n justify-content: center;\n gap: 10px;\n padding: 10px;\n background: #f8f8f8;\n border-bottom: 1px solid #eee;\n width: 50%;\n }\n\n .button {\n padding: 8px 16px;\n border: none;\n border-radius: 4px;\n cursor: pointer;\n font-size: 14px;\n }\n\n .save-button {\n background: #42b983;\n color: white;\n }\n\n .cancel-button {\n background: #666;\n color: white;\n }\n\n .editor-preview-container {\n display: flex;\n flex: 1;\n overflow: hidden;\n }\n \n #editor {\n width: 50%;\n height: 100%;\n resize: none;\n padding: 20px;\n box-sizing: border-box;\n font-family: monospace;\n border: none;\n border-right: 1px solid #eee;\n }\n \n .preview-container {\n width: 50%;\n height: 100%;\n overflow-y: auto;\n }\n\n /* Remove width from main */\n main {\n width: auto !important;\n }\n\n /* Fix code block wrapping */\n .markdown-section pre > code {\n white-space: pre-wrap !important;\n }\n </style>"
},
{
"id": "37e22865-7b6b-438d-83a0-dc680d4775cc",
"name": "HTML_docsify_include",
"type": "string",
"value": "= <script src=\"//cdn.jsdelivr.net/npm/docsify@4\"></script>"
}
]
},
"includeOtherFields": true
},
"typeVersion": 3.4
},
{
"id": "75cdf7fc-3dfa-49c1-bdbf-01d8be08aaa4",
"name": "Convert to File",
"type": "n8n-nodes-base.convertToFile",
"position": [
4020,
1600
],
"parameters": {
"options": {},
"operation": "toText",
"sourceProperty": "workflowdata"
},
"typeVersion": 1.1
},
{
"id": "3868011e-8374-496a-b3f5-4cbf7bde4e56",
"name": "HasFile?",
"type": "n8n-nodes-base.if",
"position": [
2400,
880
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "2d9feb22-49d1-4354-9b0b-b82da2b20678",
"operator": {
"type": "number",
"operation": "gt"
},
"leftValue": "={{ Object.keys($json).length }}",
"rightValue": 0
}
]
}
},
"typeVersion": 2.2
},
{
"id": "0bf2317b-2534-4022-9a16-395d4b44680c",
"name": "Extract from File",
"type": "n8n-nodes-base.extractFromFile",
"position": [
2660,
860
],
"parameters": {
"options": {},
"operation": "text",
"destinationKey": "workflowdata"
},
"typeVersion": 1
},
{
"id": "4b44a7f3-09bf-46a8-9520-247993af654b",
"name": "Main Page",
"type": "n8n-nodes-base.html",
"position": [
4660,
-100
],
"parameters": {
"html": "<!DOCTYPE html>\n<html>\n <head>\n{{ $('CONFIG').first().json.HTML_headers }}\n <body>\n <div data-app id=\"main\">Please wait...</div>\n <script>\n \n mermaid.initialize({\n startOnLoad: false,\n });\n let svgCounter = 0;\n\n window.$docsify = {\n el: '#main',\n auto2top: true,\n loadSidebar: 'summary.md',\n basePath: '{{ $json.webhookUrl.split($json.webhookUrl.extractDomain())[1] }}/',\n name: 'All Workflows',\n markdown: {\n renderer: {\n code(code, lang) {\n if (lang === \"mermaid\") {\n const svgName = `mermaid-svg-${svgCounter++}`;\n const MERMAID_CONTAINER_ID = `${svgName}-container`;\n mermaid.render(svgName, code).then(({ svg }) => {\n const containerElement = document.querySelector(\n `#${MERMAID_CONTAINER_ID}`\n );\n if (containerElement) {\n containerElement.innerHTML = svg;\n } else {\n console.error(`Error: #${MERMAID_CONTAINER_ID} not found`);\n }\n });\n return `<div class=\"mermaid\" id=\"${MERMAID_CONTAINER_ID}\"></div>`;\n }\n return this.origin.code.apply(this, arguments);\n },\n },\n }, \n plugins: [\n function(hook, vm) {\n hook.ready(function() {\n // Check if URL doesn't end with slash but also isn't a file path\n if (!window.location.pathname.endsWith('/') && !window.location.pathname.includes('.')) {\n // Use history.replaceState to avoid adding to browser history\n const newUrl = window.location.pathname + '/' + window.location.hash;\n window.history.replaceState(null, null, newUrl);\n }\n });\n }\n ], \n };\n </script>\n{{ $('CONFIG').first().json.HTML_docsify_include }}\n </body>\n</html>"
},
"typeVersion": 1.2
},
{
"id": "28c29cec-7efd-4f05-bf53-ac08cc3834a1",
"name": "Instance overview",
"type": "n8n-nodes-base.html",
"position": [
4660,
160
],
"parameters": {
"html": "# Your n8n instance workflows:\n\n| Workflow | Status | Docs | Created | Updated | Nodes | Triggers |\n|----------|:------:|------|---------|---------|-------|----------|\n{{ $jmespath($input.all(),'[].json.content').join('\\n') }}"
},
"executeOnce": true,
"typeVersion": 1.2
},
{
"id": "3e8eb52e-8d35-4aa3-a485-6674d67720dc",
"name": "Sort-workflows",
"type": "n8n-nodes-base.sort",
"position": [
2080,
160
],
"parameters": {
"options": {},
"sortFieldsUi": {
"sortField": [
{
"order": "descending",
"fieldName": "updatedAt"
}
]
}
},
"typeVersion": 1
},
{
"id": "2178e1cf-90b8-4779-9b5c-3d6180823c95",
"name": "doc action",
"type": "n8n-nodes-base.switch",
"position": [
1740,
1080
],
"parameters": {
"rules": {
"values": [
{
"outputKey": "view",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "ee386c7d-1abe-4864-bb3a-a19d3816c906",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.query.action }}",
"rightValue": "view"
}
]
},
"renameOutput": true
},
{
"outputKey": "edit",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "aa1a33ee-ac38-4ea4-9a4c-d355e7de1312",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.query.action }}",
"rightValue": "edit"
}
]
},
"renameOutput": true
},
{
"outputKey": "recreate",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "676c36e1-4c88-4314-9317-abc877ff3d17",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.query.action }}",
"rightValue": "recreate"
}
]
},
"renameOutput": true
},
{
"outputKey": "save",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "164314cf-7d99-4716-9949-b9196ce47959",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.query.action }}",
"rightValue": "save"
}
]
},
"renameOutput": true
}
]
},
"options": {
"fallbackOutput": "extra"
}
},
"typeVersion": 3.2
},
{
"id": "7f4aab9b-b7e8-4920-98e8-af8f504a1333",
"name": "Empty Set",
"type": "n8n-nodes-base.set",
"position": [
2000,
960
],
"parameters": {
"options": {}
},
"typeVersion": 3.4
},
{
"id": "1f35bc3e-29d7-47a2-a1c7-cf6052d99993",
"name": "Load Doc File",
"type": "n8n-nodes-base.readWriteFile",
"position": [
1900,
860
],
"parameters": {
"options": {},
"fileSelector": "={{ $('CONFIG').first().json.project_path }}/{{ $json.params.file }}"
},
"typeVersion": 1,
"alwaysOutputData": true
},
{
"id": "c0805f50-8f8c-49ba-b0c7-6768bf89798c",
"name": "Respond with markdown",
"type": "n8n-nodes-base.respondToWebhook",
"position": [
4920,
1040
],
"parameters": {
"options": {
"responseCode": 200,
"responseHeaders": {
"entries": [
{
"name": "Content-Type",
"value": "text/markdown"
}
]
}
},
"respondWith": "text",
"responseBody": "={{ $json.html }}"
},
"typeVersion": 1.1
},
{
"id": "9c7a18b9-a081-4162-94f4-e125d666cbcc",
"name": "Respond with HTML",
"type": "n8n-nodes-base.respondToWebhook",
"position": [
4920,
860
],
"parameters": {
"options": {
"responseCode": 200,
"responseHeaders": {
"entries": [
{
"name": "Content-Type",
"value": "text/html"
}
]
}
},
"respondWith": "text",
"responseBody": "={{ $json.html }}"
},
"typeVersion": 1.1
},
{
"id": "50944148-eb7c-4c28-99c5-478ddb2596f2",
"name": "Save New Doc File",
"type": "n8n-nodes-base.readWriteFile",
"position": [
4180,
1600
],
"parameters": {
"options": {},
"fileName": "={{ $('CONFIG').first().json.project_path }}/{{ $('CONFIG').first().json.params.file }}",
"operation": "write"
},
"typeVersion": 1,
"alwaysOutputData": true
},
{
"id": "6d7e0dcf-d12b-4428-9c5e-ef7fb2c6be28",
"name": "Blank Doc File",
"type": "n8n-nodes-base.set",
"position": [
4000,
1080
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "b168d9b1-1a13-4915-b59b-8a17258fd9cc",
"name": "workflowdata",
"type": "string",
"value": "=# {{ $json.name }}\n\n## Workflow Description\n!> Please write what is this workflow doing\n\n## Workflow schematic\n\n```mermaid\n{{ $json.mermaidChart }}\n```\n\n## Any further information\n\n> You can also add tables like this:\n\n| Parameter | Value |\n|-----------|-------|\n| Created | {{ $json.createdAt }} |\n| Last updated | {{ $json.updatedAt }} |\n| Author | {{ $json.shared[0].project.name }} |\n\n"
}
]
},
"includeOtherFields": true
},
"typeVersion": 3.4
},
{
"id": "778a97eb-f7a2-4537-81fc-979dc6c674a2",
"name": "Fetch Single Workflow1",
"type": "n8n-nodes-base.n8n",
"position": [
2820,
1200
],
"parameters": {
"operation": "get",
"workflowId": {
"__rl": true,
"mode": "id",
"value": "={{ $('CONFIG').first().json.params.file.replaceAll('docs_','').split('.md')[0] }}"
},
"requestOptions": {}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "092b8c67-77f9-4d4b-aa26-8f0e3ea3ed29",
"name": "Fill Workflow Table",
"type": "n8n-nodes-base.set",
"position": [
2280,
160
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "3bed44f3-7fa6-4d28-8a6e-7074ca354cd6",
"name": "content",
"type": "string",
"value": "=| [{{ `${$json.name.replace(/[|\\\\[\\]`_*{}()<>#+-]/g, '\\\\$&')}` }}]({{ `${$('CONFIG').first().json.instance_url}/workflow/${$json.id}` }} \"Click to open workflow in n8n\") | {{ $json.active ? '[:green_circle:](# \"Active\")' : '[:white_circle:](# \"Inactive\")' }} | <nobr>[:book:]({{ `docs_${$json.id}?action=view` }} \"View docs\") [:memo:]({{ `docs_${$json.id}.md?action=edit` }} \":ignore Edit\") [:arrows_counterclockwise:]({{ `docs_${$json.id}?action=recreate` }} \"Recreate docs\")</nobr> | <nobr>{{ `${new Date($json.createdAt).toISOString().replace('T', ' ').slice(0, 16)}` }}</nobr> | <nobr>{{ `${new Date($json.updatedAt).toISOString().replace('T', ' ').slice(0, 16)}` }}</nobr> | {{ $json.nodes.length }} | {{ $json.nodes.filter(n => n.type.includes('Trigger')).length }} |"
}
]
}
},
"executeOnce": false,
"typeVersion": 3.4
},
{
"id": "18c58a09-0dfe-4cb4-ae7f-503957eabadb",
"name": "Basic LLM Chain",
"type": "@n8n/n8n-nodes-langchain.chainLlm",
"onError": "continueRegularOutput",
"position": [
3480,
1200
],
"parameters": {
"text": "=Here's the workflow data:\n{{Object.assign(\n Object.fromEntries(Object.entries($json).filter(([key]) => !['staticData', 'pinData'].includes(key))),\n {nodes: $json.nodes.map(node => Object.fromEntries(Object.entries(node).filter(([key]) => !['id', 'position'].includes(key))))}\n).toJsonString() }}",
"messages": {
"messageValues": [
{
"message": "=Your task is to generate simple workflow documentation for the n8n workflows. The user will provide a JSON structure. Reply \nin JSON format in 2 sections: workflow_desription and nodes_settings. Important! Each json key should be a simple markdown text without any additional comments or remarks from your end.\n\nInstruction for `workflow_desription`:\n```\n## Section header with H2\n\\n\n> subline with who created workflow and when, when it was last edited and the status (active / inactive as the green / grey round emoji). Also, when the documentation was generated. Now is: {{ $now }}.\n\\n\\n\nShould contain a description of the workflow. in a couple of paragraphs. Use direct voice without the fluff\n```\n\nInstruction for `nodes_settings`:\n```\n## Section header with H2.\n\\n\n### Node 1 name as H3 title\n - For each node make a bullet list with the main node configs. Ignore irrelevant configs. Enclose each config value in code backticks (`). Look:\n - Parameter 1 name: `Parameter 1 value`\n - Parameter 2 name: `Parameter 2 value`\n\\n\\n\n### Node 2 name as H3 title\n - For each node make a bullet list with the main node configs. Ignore irrelevant configs. Enclose each config value in code backticks (`). Look:\n - Parameter 1 name: `Parameter 1 value`\n - Parameter 2 name: `Parameter 2 value`\n\\n\\n\n```"
}
]
},
"promptType": "define",
"hasOutputParser": true
},
"typeVersion": 1.4,
"alwaysOutputData": false
},
{
"id": "9bc58cd3-a55e-4cda-95b5-7fa8dc0e7076",
"name": "OpenAI Chat Model",
"type": "@n8n/n8n-nodes-langchain.lmChatOpenAi",
"position": [
3480,
1360
],
"parameters": {
"model": "gpt-4-turbo",
"options": {
"timeout": 120000,
"temperature": 0.2
}
},
"credentials": {
"openAiApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "38fb6192-b8ce-4241-a9fe-aebda09aa8d5",
"name": "Structured Output Parser",
"type": "@n8n/n8n-nodes-langchain.outputParserStructured",
"position": [
3820,
1360
],
"parameters": {
"jsonSchemaExample": "{\n\t\"workflow_description\": \"## Workflow overview\\n\\n>some additiona info\\n\\nWorkflow desctiption\",\n\t\"nodes_settings\": \"## Nodes settings\\n\\n###Node name 1\\n\\n- Setting 1\\n- Setting 2###Node name 2\\n\\n- Setting 1\\n- Setting 2\"\n}"
},
"typeVersion": 1.2
},
{
"id": "29261bbb-dbbb-44df-b99d-bb084df7d846",
"name": "Auto-fixing Output Parser",
"type": "@n8n/n8n-nodes-langchain.outputParserAutofixing",
"position": [
3580,
1360
],
"parameters": {
"options": {}
},
"typeVersion": 1
},
{
"id": "086a57cf-a2b4-4f32-8ca6-38546e4856c1",
"name": "Respond with main page HTML",
"type": "n8n-nodes-base.respondToWebhook",
"position": [
4920,
-100
],
"parameters": {
"options": {
"responseCode": 200,
"responseHeaders": {
"entries": [
{
"name": "Content-Type",
"value": "text/html"
}
]
}
},
"respondWith": "text",
"responseBody": "={{ $json.html }}"
},
"typeVersion": 1.1
},
{
"id": "fdbfe60b-e677-4897-ab1a-9a9f506bba27",
"name": "Workflow Tags",
"type": "n8n-nodes-base.html",
"position": [
4660,
500
],
"parameters": {
"html": "- **Click to filter by tag:**\n{{ [...new Set($jmespath($input.all(),'[].json.tags[].name'))].map(tag => `- [${tag}](tag-${encodeURIComponent(tag)})`).join('\\n') }}"
},
"executeOnce": true,
"typeVersion": 1.2
},
{
"id": "94a258ed-c07c-42d4-8d37-3395fad205b0",
"name": "No Operation, do nothing",
"type": "n8n-nodes-base.noOp",
"position": [
1740,
1880
],
"parameters": {},
"typeVersion": 1
},
{
"id": "c35ca075-52e7-4c2f-9891-f709afe36e52",
"name": "Merge",
"type": "n8n-nodes-base.merge",
"position": [
3140,
1100
],
"parameters": {
"mode": "combine",
"options": {},
"combineBy": "combineByPosition",
"numberInputs": 3
},
"typeVersion": 3
},
{
"id": "55a1e32f-b20c-4b1f-9d6f-9bc4ec221fab",
"name": "Fallback file name",
"type": "n8n-nodes-base.html",
"position": [
4660,
1900
],
"parameters": {
"html": "> File: {{ $json.params.file }}"
},
"typeVersion": 1.2
},
{
"id": "3eef159b-99ad-4c9a-82f4-13bf16972521",
"name": "mkdir",
"type": "n8n-nodes-base.executeCommand",
"position": [
2100,
1060
],
"parameters": {
"command": "=mkdir -p {{$('CONFIG').first().json.project_path}}"
},
"typeVersion": 1
},
{
"id": "15fda233-925b-4a4d-964e-1916c0cd39a2",
"name": "Merge1",
"type": "n8n-nodes-base.merge",
"position": [
2240,
880
],
"parameters": {
"mode": "chooseBranch"
},
"typeVersion": 3
},
{
"id": "3e6c9243-d5f7-4f04-8231-9994963df36d",
"name": "Edit Page",
"type": "n8n-nodes-base.html",
"position": [
4660,
860
],
"parameters": {
"html": "<!DOCTYPE html>\n<html>\n <head>\n{{ $('CONFIG').first().json.HTML_headers }}\n{{ $('CONFIG').first().json.HTML_styles_editor }}\n </head>\n <body>\n <div class=\"container\">\n <div class=\"button-container\">\n <button class=\"button save-button\" onclick=\"saveContent()\">Save</button>\n <button class=\"button cancel-button\" onclick=\"closeWindow()\">Cancel</button>\n </div>\n <div class=\"editor-preview-container\">\n <textarea id=\"editor\">{{ $json.workflowdata }}</textarea>\n <div class=\"preview-container\">\n <div id=\"preview\"></div>\n </div>\n </div>\n </div>\n \n<script>\n const editor = document.getElementById('editor');\n let vm;\n\n mermaid.initialize({\n startOnLoad: false,\n });\n\n let svgCounter = 0;\n\n // Function to save content\n async function saveContent() {\n try {\n const response = await fetch(window.location.pathname + '?action=save', {\n method: 'POST',\n headers: {\n 'Content-Type': 'application/json',\n },\n body: JSON.stringify({\n content: editor.value\n })\n });\n \n if (response.ok) {\n alert('Successfully saved!');\n } else {\n alert('Failed to save content');\n }\n } catch (error) {\n console.error('Error saving content:', error);\n alert('Error saving content');\n }\n }\n \n // Function to close window\n function closeWindow() {\n window.close();\n }\n \n window.$docsify = {\n el: '#preview',\n loadSidebar: false,\n loadNavbar: false,\n basePath: '/',\n hideSidebar: true,\n markdown: {\n renderer: {\n code(code, lang) {\n if (lang === \"mermaid\") {\n const svgName = `mermaid-svg-${svgCounter++}`;\n const MERMAID_CONTAINER_ID = `${svgName}-container`;\n mermaid.render(svgName, code).then(({ svg }) => {\n const containerElement = document.querySelector(\n `#${MERMAID_CONTAINER_ID}`\n );\n if (containerElement) {\n containerElement.innerHTML = svg;\n } else {\n console.error(`Error: #${MERMAID_CONTAINER_ID} not found`);\n }\n });\n return `<div class=\"mermaid\" id=\"${MERMAID_CONTAINER_ID}\"></div>`;\n }\n return this.origin.code.apply(this, arguments);\n },\n },\n },\n plugins: [\n function(hook, _vm) {\n vm = _vm;\n \n hook.beforeEach(function(content) {\n return editor.value;\n });\n }\n ]\n };\n \nlet timeout;\nfunction updatePreview() {\n clearTimeout(timeout);\n timeout = setTimeout(() => {\n if (vm) {\n const markdownSection = document.querySelector('.markdown-section');\n if (markdownSection) {\n const compiler = new window.DocsifyCompiler({\n basePath: '/',\n relativePath: false,\n fallbackLanguages: [],\n nameLink: '/',\n routerMode: 'hash'\n }, vm.router);\n \n const html = compiler.compile(editor.value);\n markdownSection.innerHTML = html;\n window.Prism.highlightAll();\n\n // Re-render all mermaid diagrams\n const mermaidDivs = markdownSection.querySelectorAll('pre[data-lang=\"mermaid\"] code');\n mermaidDivs.forEach((div, index) => {\n const code = div.textContent;\n const svgName = `mermaid-svg-${svgCounter++}`;\n const MERMAID_CONTAINER_ID = `${svgName}-container`;\n \n // Replace the <pre> element with our container\n const container = document.createElement('div');\n container.className = 'mermaid';\n container.id = MERMAID_CONTAINER_ID;\n div.parentElement.replaceWith(container);\n \n // Render the diagram\n mermaid.render(svgName, code).then(({ svg }) => {\n const containerElement = document.getElementById(MERMAID_CONTAINER_ID);\n if (containerElement) {\n containerElement.innerHTML = svg;\n }\n });\n });\n }\n }\n }, 500);\n};\n \n editor.addEventListener('input', updatePreview);\n</script>\n{{ $('CONFIG').first().json.HTML_docsify_include }}\n </body>\n</html>"
},
"typeVersion": 1.2
},
{
"id": "71e136d5-bb5b-4eab-8cab-bfc50ea2a5a5",
"name": "Workflow md content",
"type": "n8n-nodes-base.html",
"position": [
4660,
1040
],
"parameters": {
"html": "{{ $json.workflowdata }}"
},
"executeOnce": true,
"typeVersion": 1.2
},
{
"id": "6cb6f3b8-de65-43a5-9df3-48299ba7fcce",
"name": "Is Action Edit?1",
"type": "n8n-nodes-base.if",
"position": [
3300,
1100
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "856cdb3b-a187-4db5-b77b-43ee086780ee",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.query.action }}",
"rightValue": "edit"
}
]
}
},
"typeVersion": 2.2
},
{
"id": "aff9ed71-bb49-4170-9ae3-5f05f89bab05",
"name": "Is Action Edit?2",
"type": "n8n-nodes-base.if",
"position": [
4180,
880
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "e3648023-8cb7-4b82-bd35-1ba196458327",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.query.action }}",
"rightValue": "edit"
}
]
}
},
"typeVersion": 2.2
},
{
"id": "7b3d31a9-ee01-4bce-bc5b-78161536999d",
"name": "Generate Mermaid Chart",
"type": "n8n-nodes-base.code",
"position": [
3000,
1260
],
"parameters": {
"jsCode": "const workflow = $input.first().json;\n\n// Extract nodes from the workflow\nconst nodes = workflow.nodes || [];\n\n// Node types to exclude\nconst excludedNodeTypes = ['n8n-nodes-base.stickyNote'];\n\n// Define shapes and their corresponding brackets\n// https://mermaid.js.org/syntax/flowchart.html\nconst shapes = {\n 'rect': ['[', ']'],\n 'rhombus': ['{', '}'],\n 'circle': ['((', '))'],\n 'hexagon': ['{{', '}}'],\n 'subroutine': ['[[', ']]'],\n 'parallelogram': ['[\\/', '\\/]'],\n 'wait': ['(', ')']\n // Add more shapes here as needed\n};\n\n// Define special shapes for specific node types\nconst specialShapes = {\n 'n8n-nodes-base.if': 'rhombus',\n 'n8n-nodes-base.switch': 'rhombus',\n 'n8n-nodes-base.code': 'subroutine',\n 'n8n-nodes-base.executeWorkflow': 'subroutine',\n 'n8n-nodes-base.httpRequest':'parallelogram',\n 'n8n-nodes-base.wait':'wait'\n // List more special node types\n};\n\n// Function to get the shape for a node type\nfunction getNodeShape(nodeType) {\n return specialShapes[nodeType] || 'rect';\n}\n\n// Create a map of node names to their \"EL<N>\" identifiers, disabled status, and shape\nconst nodeMap = {};\nlet nodeCounter = 1;\nnodes.forEach((node) => {\n if (!excludedNodeTypes.includes(node.type)) {\n const shape = getNodeShape(node.type);\n nodeMap[node.name] = {\n id: `EL${nodeCounter}`,\n disabled: node.disabled || false,\n shape: shape,\n brackets: shapes[shape] || shapes['rect'] // Default to rect if shape not found\n };\n nodeCounter++;\n }\n});\n\n// Function to convert special characters to HTML entities\nfunction convertToHTMLEntities(str) {\n return str.replaceAll('\"',\"'\").replace(/[^\\w\\s-]/g, function(char) {\n return '&#' + char.charCodeAt(0) + ';';\n });\n}\n\n// Function to format node text (with strike-through if disabled)\nfunction formatNodeText(nodeName, isDisabled) {\n const escapedName = convertToHTMLEntities(nodeName);\n return isDisabled ? `<s>${escapedName}</s>` : escapedName;\n}\n\n// Generate connections and isolated nodes\nconst connections = [];\nconst isolatedNodes = new Set(Object.keys(nodeMap));\n\nif (workflow.connections) {\n Object.entries(workflow.connections).forEach(([sourceName, targetConnections]) => {\n Object.entries(targetConnections).forEach(([connectionType, targets]) => {\n targets.forEach(targetArray => {\n targetArray.forEach(target => {\n const sourceNode = nodeMap[sourceName];\n const targetNode = nodeMap[target.node];\n if (sourceNode && targetNode) {\n let connectionLine = ` ${sourceNode.id}${sourceNode.brackets[0]}${formatNodeText(sourceName, sourceNode.disabled)}${sourceNode.brackets[1]}`;\n if (connectionType === 'main') {\n connectionLine += ` -->`;\n } else {\n connectionLine += ` -.- |${connectionType}|`;\n }\n connectionLine += ` ${targetNode.id}${targetNode.brackets[0]}${formatNodeText(target.node, targetNode.disabled)}${targetNode.brackets[1]}`;\n connections.push(connectionLine);\n isolatedNodes.delete(sourceName);\n isolatedNodes.delete(target.node);\n }\n });\n });\n });\n });\n}\n\n// Add isolated nodes to the connections array\nisolatedNodes.forEach(nodeName => {\n const node = nodeMap[nodeName];\n connections.push(` ${node.id}${node.brackets[0]}${formatNodeText(nodeName, node.disabled)}${node.brackets[1]}`);\n});\n\n// Generate the Mermaid flowchart string\nconst mermaidChart = `---\nconfig:\n look: neo\n theme: default\n---\nflowchart LR\n${connections.join('\\n')}`;\n\n// Output the result\nreturn {\n json: {\n mermaidChart: mermaidChart\n }\n};"
},
"typeVersion": 2
},
{
"id": "77a35cd5-cb8f-4ac5-a699-dff5e65cda09",
"name": "Merge2",
"type": "n8n-nodes-base.merge",
"position": [
3840,
1140
],
"parameters": {
"mode": "combine",
"options": {},
"combineBy": "combineByPosition"
},
"typeVersion": 3
},
{
"id": "f8119590-e9d7-4513-9da4-fa911165baff",
"name": "Generated Doc",
"type": "n8n-nodes-base.set",
"position": [
4000,
1240
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "7693348d-5129-4a07-809d-b0619b9fc44b",
"name": "workflowdata",
"type": "string",
"value": "=# {{ $json.name }}\n\n{{ $json?.output?.workflow_description || \"## <SORRY, COULD NOT GENERATE WORKFLOW DESCRIPTION>\" }}\n\n## Workflow schematic\n\n```mermaid\n{{ $json.mermaidChart }}\n```\n\n{{ $json?.output?.nodes_settings || \"## <SORRY, COULD NOT GENERATE DOCS FOR NODE SETTING>\" }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "92565206-6cf2-4243-9143-4f6def4b524d",
"name": "Passthrough",
"type": "n8n-nodes-base.noOp",
"position": [
2100,
1240
],
"parameters": {},
"typeVersion": 1
},
{
"id": "73081fc3-9554-4a12-b985-da02b356616f",
"name": "Merge3",
"type": "n8n-nodes-base.merge",
"position": [
3140,
880
],
"parameters": {
"mode": "combine",
"options": {},
"combineBy": "combineByPosition"
},
"typeVersion": 3
},
{
"id": "f50e72f8-9027-4ca7-9df7-700e828f48eb",
"name": "Merge4",
"type": "n8n-nodes-base.merge",
"position": [
960,
-100
],
"parameters": {
"mode": "combine",
"options": {},
"combineBy": "combineByPosition"
},
"typeVersion": 3
},
{
"id": "306820ac-7c87-45c2-b76f-55d772ac7300",
"name": "Merge5",
"type": "n8n-nodes-base.merge",
"position": [
960,
240
],
"parameters": {
"mode": "combine",
"options": {},
"combineBy": "combineByPosition"
},
"typeVersion": 3
},
{
"id": "96fd7265-7920-453f-8309-bdbd10880d03",
"name": "Edit Fields",
"type": "n8n-nodes-base.set",
"position": [
2100,
1600
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "8bc55c5b-e09a-459b-bbb6-ed5f70d4f353",
"name": "workflowdata",
"type": "string",
"value": "={{ $json.body.content }}"
}
]
},
"includeOtherFields": true
},
"typeVersion": 3.4
},
{
"id": "2fffb547-1c11-4663-aed5-29b9557e8738",
"name": "Is Action Save?",
"type": "n8n-nodes-base.if",
"position": [
4540,
1600
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "e3648023-8cb7-4b82-bd35-1ba196458327",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json?.query?.action }}",
"rightValue": "save"
},
{
"id": "a44c9cc5-5717-4c34-978b-e644219a9cc1",
"operator": {
"type": "string",
"operation": "exists",
"singleValue": true
},
"leftValue": "={{ $json?.query?.action }}",
"rightValue": ""
}
]
}
},
"typeVersion": 2.2
},
{
"id": "15825037-a8e2-4fbc-b529-2bf89810a116",
"name": "Merge6",
"type": "n8n-nodes-base.merge",
"position": [
4360,
1700
],
"parameters": {
"mode": "chooseBranch",
"useDataOfInput": 2
},
"typeVersion": 3
},
{
"id": "b47f18a4-9b59-4278-890d-b6f6c596c554",
"name": "Respond OK on Save",
"type": "n8n-nodes-base.respondToWebhook",
"position": [
4920,
1580
],
"parameters": {
"options": {
"responseCode": 200
},
"respondWith": "noData"
},
"typeVersion": 1.1
},
{
"id": "273dfd58-abef-49b7-8f12-5abc3d3515a6",
"name": "single workflow",
"type": "n8n-nodes-base.webhook",
"position": [
240,
240
],
"parameters": {
"path": "/:file",
"options": {},
"responseMode": "responseNode",
"multipleMethods": true
},
"typeVersion": 2
},
{
"id": "a7d7ee50-1420-475b-9028-0c80e1ae2241",
"name": "Sticky Note",
"type": "n8n-nodes-base.stickyNote",
"position": [
140,
-242.54375384615383
],
"parameters": {
"width": 296.5956923076922,
"height": 277.9529846153844,
"content": "## Main Docsify webhook\nIn response, n8n serves the main html page with the [Docsify JS library](https://docsify.js.org/)"
},
"typeVersion": 1
},
{
"id": "b7c4b82a-9722-48ae-ab6a-4335981356ad",
"name": "Sticky Note1",
"type": "n8n-nodes-base.stickyNote",
"position": [
-77.62340912473337,
108.96056004923076
],
"parameters": {
"width": 509.1040245093486,
"height": 287.9568584558579,
"content": "## Single page requests\n* Docsify may request default pages (i.e. `readme.md` or a `summary.md`)\n* GET request for the workflow documentation pages\n* POST request for saving manually edited doc page"
},
"typeVersion": 1
},
{
"id": "18e1f4c5-3652-4244-9a09-cd7a498a9310",
"name": "Sticky Note2",
"type": "n8n-nodes-base.stickyNote",
"position": [
460,
-240.54580345183416
],
"parameters": {
"color": 3,
"width": 489.50636350106504,
"height": 462.9720128227216,
"content": "## EDIT THIS!\n* `project_path` to link to a writable directory that is accessible to n8n\n* update `instance_url` when running in the cloud version. If using in self-hosted mode, make sure N8N_PROTOCOL and N8N_HOST .env variables are correct"
},
"typeVersion": 1
},
{
"id": "d505d2ec-33e9-4983-8265-ff55f0df3da8",
"name": "file types",
"type": "n8n-nodes-base.switch",
"position": [
1180,
240
],
"parameters": {
"rules": {
"values": [
{
"outputKey": ".md",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"operator": {
"type": "string",
"operation": "endsWith"
},
"leftValue": "={{ $json.params.file.toLowerCase() }}",
"rightValue": ".md"
}
]
},
"renameOutput": true
}
]
},
"options": {
"fallbackOutput": "extra",
"renameFallbackOutput": "unknown"
}
},
"typeVersion": 3.2
},
{
"id": "59362792-4a3e-4f97-95e2-d7b33b870e1d",
"name": "Sticky Note3",
"type": "n8n-nodes-base.stickyNote",
"position": [
4620,
-245.7696645512633
],
"parameters": {
"width": 446.67466982248516,
"height": 309.89805271694365,
"content": "## Construct main HTML page and send it back to the user\n* `HTML_headers` and `HTML_docsify_include` are stored in the CONFIG node for the page simplicity"
},
"typeVersion": 1
},
{
"id": "83189146-4d1f-454e-9591-bdbfda676683",
"name": "Get All Workflows",
"type": "n8n-nodes-base.n8n",
"position": [
1880,
160
],
"parameters": {
"filters": {
"tags": "={{ decodeURIComponent(($json.params.file?.match(/^tag-(.+)\\.md$/))?.[1] || '') }}"
},
"requestOptions": {}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1,
"alwaysOutputData": true
},
{
"id": "39aa6017-a0ef-4f05-81b8-cfc9bb2fcc20",
"name": "Sticky Note4",
"type": "n8n-nodes-base.stickyNote",
"position": [
1780,
20.913927466176517
],
"parameters": {
"width": 820.1843305645202,
"height": 307.51990359708003,
"content": "## Serve main Markdown table with the workflow overview\n*NOTE! Here we don't reply with HTML content. Only Markdown elements are sent back and processed by the JS library*\n* Create an overall table when `README.md` (the home page) is requested\n* Create a table with a subset of workflows when a tag from a navigation pane is selected"
},
"typeVersion": 1
},
{
"id": "2d087c25-b998-4abc-b0ce-ede8e62e28b4",
"name": "md files",
"type": "n8n-nodes-base.switch",
"position": [
1440,
180
],
"parameters": {
"rules": {
"values": [
{
"outputKey": "README.md",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"operator": {
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.params.file }}",
"rightValue": "README.md"
}
]
},
"renameOutput": true
},
{
"outputKey": "docs",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "c1c1aecc-8faa-47ea-b831-4674c3c0db61",
"operator": {
"type": "string",
"operation": "contains"
},
"leftValue": "={{ $json.params.file }}",
"rightValue": "docs_"
}
]
},
"renameOutput": true
},
{
"outputKey": "summary.md",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "fde643c9-31cd-4cbd-b4de-99a8ad6202af",
"operator": {
"name": "filter.operator.equals",
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.params.file }}",
"rightValue": "summary.md"
}
]
},
"renameOutput": true
},
{
"outputKey": "tags",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "df4bc9f8-9285-49a6-b31c-d7173bf42901",
"operator": {
"type": "string",
"operation": "startsWith"
},
"leftValue": "={{ $json.params.file }}",
"rightValue": "tag-"
}
]
},
"renameOutput": true
}
]
},
"options": {
"fallbackOutput": "extra"
}
},
"typeVersion": 3.2
},
{
"id": "08524df2-d555-42ca-8440-57ca5a780b74",
"name": "Get Workflow tags",
"type": "n8n-nodes-base.n8n",
"position": [
1880,
500
],
"parameters": {
"filters": {},
"requestOptions": {}
},
"credentials": {
"n8nApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "06e383dc-b1ea-4c97-9ee4-c07084ffc4cc",
"name": "Sticky Note5",
"type": "n8n-nodes-base.stickyNote",
"position": [
1780,
360
],
"parameters": {
"width": 817.6163848212657,
"height": 288.20835077550953,
"content": "## Serve left pane content\n* Here all workflows are fetched again when `summary.md` file is requested.\n\nIt contains Markdown for the left navigation pane: a list of all tags"
},
"typeVersion": 1
},
{
"id": "c28ae282-7d83-42dd-8714-30d26b0f20af",
"name": "Sticky Note6",
"type": "n8n-nodes-base.stickyNote",
"position": [
1700,
1780
],
"parameters": {
"width": 367.8950651848079,
"height": 262.5093167050718,
"content": "## Handle missing pages\nServe the Markdown content with the requested file name for edge cases, i.e. any unexpected files"
},
"typeVersion": 1
},
{
"id": "6441cf8f-dace-45fb-984e-aa9e0589e495",
"name": "Sticky Note7",
"type": "n8n-nodes-base.stickyNote",
"position": [
1020,
729
],
"parameters": {
"color": 6,
"width": 4161.578473434268,
"height": 1142.0268674813442,
"content": "# Main functionality here\n\n## * View existing documentation\n## * Auto-generate doc page if no file available\n## * Re-created autodoc page\n## * Edit doc page: LIVE Markdown editor included!\n## * Save edited file. WARNING! No authentication"
},
"typeVersion": 1
},
{
"id": "9116a4eb-18c6-4ec2-84e8-9a0b920d5c19",
"name": "Sticky Note8",
"type": "n8n-nodes-base.stickyNote",
"position": [
4460,
751
],
"parameters": {
"width": 652.3100890494833,
"height": 268.0620091282372,
"content": "## Custom markdown editor\nThis is another HTML page for the live Markdown editor\n* `Mermaid.js` is supported\n* Docsify preview on edit\n* Save or Cancel buttons"
},
"typeVersion": 1
},
{
"id": "920c1edb-29ad-4952-9e30-9020146ed88a",
"name": "Sticky Note9",
"type": "n8n-nodes-base.stickyNote",
"position": [
4000,
1501
],
"parameters": {
"width": 522.870786668288,
"height": 348.0868581511653,
"content": "## Save new file\nOnce the doc page is generated or edited manually, a Markdown files is saved in the directory"
},
"typeVersion": 1
},
{
"id": "cff4d2be-f627-4c7d-9f7a-093f6f9b2c27",
"name": "Sticky Note10",
"type": "n8n-nodes-base.stickyNote",
"position": [
1887,
758
],
"parameters": {
"width": 639.8696984316115,
"height": 429.7891698152571,
"content": "## Load existing doc file\nCheck the existing file when the View or Edit button is pressed\n"
},
"typeVersion": 1
},
{
"id": "b7f01785-99c7-47b2-967a-b7456bb8f562",
"name": "Sticky Note11",
"type": "n8n-nodes-base.stickyNote",
"position": [
2786.9421822644376,
1023
],
"parameters": {
"width": 1369.2986733206085,
"height": 466.42237140646773,
"content": "## If the file is not available, then:\n* either auto-generate new doc\n* prepare a basic template for editing"
},
"typeVersion": 1
},
{
"id": "6953bf0c-3122-4d80-9e74-1c07a892bf31",
"name": "docsify",
"type": "n8n-nodes-base.webhook",
"position": [
240,
-100
],
"parameters": {
"path": "135bc21f-c7d0-4afe-be73-f984d444b43b",
"options": {},
"responseMode": "responseNode"
},
"typeVersion": 2
}
],
"active": true,
"settings": {
"callerPolicy": "workflowsFromSameOwner",
"executionOrder": "v1",
"executionTimeout": 120,
"saveManualExecutions": true,
"saveDataSuccessExecution": "all"
},
"versionId": "eee9144a-c7a0-4947-874b-728d9e8618b7",
"connections": {
"Merge": {
"main": [
[
{
"node": "Is Action Edit?1",
"type": "main",
"index": 0
}
]
]
},
"mkdir": {
"main": [
[
{
"node": "Merge1",
"type": "main",
"index": 1
}
]
]
},
"CONFIG": {
"main": [
[
{
"node": "Merge4",
"type": "main",
"index": 1
},
{
"node": "Merge5",
"type": "main",
"index": 0
}
]
]
},
"Merge1": {
"main": [
[
{
"node": "HasFile?",
"type": "main",
"index": 0
}
]
]
},
"Merge2": {
"main": [
[
{
"node": "Generated Doc",
"type": "main",
"index": 0
}
]
]
},
"Merge3": {
"main": [
[
{
"node": "Is Action Edit?2",
"type": "main",
"index": 0
}
]
]
},
"Merge4": {
"main": [
[
{
"node": "Main Page",
"type": "main",
"index": 0
}
]
]
},
"Merge5": {
"main": [
[
{
"node": "file types",
"type": "main",
"index": 0
}
]
]
},
"Merge6": {
"main": [
[
{
"node": "Is Action Save?",
"type": "main",
"index": 0
}
]
]
},
"docsify": {
"main": [
[
{
"node": "CONFIG",
"type": "main",
"index": 0
},
{
"node": "Merge4",
"type": "main",
"index": 0
}
]
]
},
"HasFile?": {
"main": [
[
{
"node": "Extract from File",
"type": "main",
"index": 0
}
],
[
{
"node": "Fetch Single Workflow1",
"type": "main",
"index": 0
}
]
]
},
"md files": {
"main": [
[
{
"node": "Get All Workflows",
"type": "main",
"index": 0
}
],
[
{
"node": "doc action",
"type": "main",
"index": 0
}
],
[
{
"node": "Get Workflow tags",
"type": "main",
"index": 0
}
],
[
{
"node": "Get All Workflows",
"type": "main",
"index": 0
}
],
[
{
"node": "No Operation, do nothing",
"type": "main",
"index": 0
}
]
]
},
"Edit Page": {
"main": [
[
{
"node": "Respond with HTML",
"type": "main",
"index": 0
}
]
]
},
"Empty Set": {
"main": [
[
{
"node": "Merge1",
"type": "main",
"index": 0
}
]
]
},
"Main Page": {
"main": [
[
{
"node": "Respond with main page HTML",
"type": "main",
"index": 0
}
]
]
},
"doc action": {
"main": [
[
{
"node": "mkdir",
"type": "main",
"index": 0
},
{
"node": "Load Doc File",
"type": "main",
"index": 0
},
{
"node": "Passthrough",
"type": "main",
"index": 0
}
],
[
{
"node": "mkdir",
"type": "main",
"index": 0
},
{
"node": "Load Doc File",
"type": "main",
"index": 0
},
{
"node": "Passthrough",
"type": "main",
"index": 0
}
],
[
{
"node": "mkdir",
"type": "main",
"index": 0
},
{
"node": "Empty Set",
"type": "main",
"index": 0
},
{
"node": "Passthrough",
"type": "main",
"index": 0
}
],
[
{
"node": "Edit Fields",
"type": "main",
"index": 0
}
]
]
},
"file types": {
"main": [
[
{
"node": "md files",
"type": "main",
"index": 0
}
]
]
},
"Edit Fields": {
"main": [
[
{
"node": "Convert to File",
"type": "main",
"index": 0
},
{
"node": "Merge6",
"type": "main",
"index": 1
}
]
]
},
"Passthrough": {
"main": [
[
{
"node": "Merge3",
"type": "main",
"index": 1
},
{
"node": "Merge",
"type": "main",
"index": 0
}
]
]
},
"Generated Doc": {
"main": [
[
{
"node": "Convert to File",
"type": "main",
"index": 0
},
{
"node": "Is Action Edit?2",
"type": "main",
"index": 0
}
]
]
},
"Load Doc File": {
"main": [
[
{
"node": "Merge1",
"type": "main",
"index": 0
}
]
]
},
"Workflow Tags": {
"main": [
[
{
"node": "Respond with markdown",
"type": "main",
"index": 0
}
]
]
},
"Blank Doc File": {
"main": [
[
{
"node": "Is Action Edit?2",
"type": "main",
"index": 0
}
]
]
},
"Sort-workflows": {
"main": [
[
{
"node": "Fill Workflow Table",
"type": "main",
"index": 0
}
]
]
},
"Basic LLM Chain": {
"main": [
[
{
"node": "Merge2",
"type": "main",
"index": 1
}
]
]
},
"Convert to File": {
"main": [
[
{
"node": "Save New Doc File",
"type": "main",
"index": 0
}
]
]
},
"Is Action Save?": {
"main": [
[
{
"node": "Respond OK on Save",
"type": "main",
"index": 0
}
]
]
},
"single workflow": {
"main": [
[
{
"node": "CONFIG",
"type": "main",
"index": 0
},
{
"node": "Merge5",
"type": "main",
"index": 1
}
],
[
{
"node": "CONFIG",
"type": "main",
"index": 0
},
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
n8nApiopenAiApi
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
How this works
This workflow automates the generation of a comprehensive documentation site for your n8n workflows, transforming raw configuration data into an interactive, searchable HTML structure using Docsify. It suits automation enthusiasts and teams managing complex n8n setups who need quick, up-to-date docs without manual effort, saving hours on maintenance. The key step involves extracting and sorting workflow details via the extractFromFile and sort nodes, then rendering them into polished pages with HTML operations, integrating seamlessly with n8n's readWriteFile for data handling.
Use this when you have a large n8n instance and want automated docs updated via webhook triggers after changes, especially for sharing overviews with non-technical stakeholders. Avoid it for tiny setups with fewer than ten workflows, where simple exports suffice, or if you prefer static tools like MkDocs over dynamic Docsify rendering. Common variations include adding OpenAI's lmChatOpenAi for summarising workflow purposes or customising the switch node for filtering specific doc actions like tutorials versus references.
About this workflow
Docsify example. Uses convertToFile, extractFromFile, html, sort. Webhook trigger; 60 nodes.
Source: https://github.com/Zie619/n8n-workflows — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
Sign PDF documents with legally-compliant digital signatures using X.509 certificates. Supports multiple PAdES signature levels (B, T, LT, LTA) with optional visible stamps.
Execute Command, HTTP Request, Read Write File +1
This workflow allows you to import any workflow from a file or another n8n instance and map the credentials easily. A multi-form setup guides you through the entire process At the beginning you have t
Execute Command, Read Write File, HTTP Request +3
Generating PDF. Uses readWriteFile, httpRequest, executeCommand. Webhook trigger; 10 nodes.
Read Write File, HTTP Request, Execute Command
JFCandia_Flujo. Uses executeCommand, emailSend, readWriteFile, httpRequest. Webhook trigger; 8 nodes.
Execute Command, Email Send, Read Write File +1
Docsify example. Uses convertToFile, extractFromFile, html, sort. Webhook trigger; 60 nodes.
Read Write File, n8n, Chain Llm +4
