This workflow corresponds to n8n.io template #14721 — we link there as the canonical source.
This workflow follows the Google Sheets → HTTP Request recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "xxxxxxxxx",
"meta": {
"templateCredsSetupCompleted": true
},
"name": "Meta Ads Insights to Google Sheets (Backfill & Weekly Sync ETL)",
"tags": [],
"nodes": [
{
"id": "a0e731a9-5868-4143-a057-134d5815f13e",
"name": "Manual Trigger (Historical Backfill)",
"type": "n8n-nodes-base.manualTrigger",
"position": [
-1312,
5728
],
"parameters": {},
"typeVersion": 1
},
{
"id": "43c27e49-8444-493a-8bcb-c8f720e613b2",
"name": "Append to Log Sheet (Account B)",
"type": "n8n-nodes-base.googleSheets",
"position": [
496,
6016
],
"parameters": {
"columns": {
"value": {
"since": "={{ $json.since }}",
"until": "={{ $json.until }}",
"reason": "={{ $json.reason }}",
"status": "={{ $json.status }}",
"account": "={{ $json.account }}",
"timestamp": "={{ $json.timestamp }}",
"execution_id": "={{ $json.execution_id }}"
},
"schema": [
{
"id": "status",
"type": "string",
"display": true,
"required": false,
"displayName": "status",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "reason",
"type": "string",
"display": true,
"required": false,
"displayName": "reason",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "account",
"type": "string",
"display": true,
"required": false,
"displayName": "account",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "since",
"type": "string",
"display": true,
"required": false,
"displayName": "since",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "until",
"type": "string",
"display": true,
"required": false,
"displayName": "until",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "execution_id",
"type": "string",
"display": true,
"required": false,
"displayName": "execution_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "timestamp",
"type": "string",
"display": true,
"required": false,
"displayName": "timestamp",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "name",
"value": "Account_B_Log"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "YOUR_SPREADSHEET_ID",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/YOUR_SPREADSHEET_ID/edit",
"cachedResultName": "Meta Ads Report"
}
},
"typeVersion": 4.7
},
{
"id": "a76c2362-6495-4c2b-91d6-92bc08f99159",
"name": "Workflow Overview",
"type": "n8n-nodes-base.stickyNote",
"position": [
-2560,
5008
],
"parameters": {
"color": 7,
"width": 1100,
"height": 516,
"content": "## Meta Ads Insights to Google Sheets (Backfill & Weekly Sync ETL)\n\nThis workflow extracts Meta Ads performance data and loads it into Google Sheets for reporting or use as a BI source such as Looker Studio. It supports two operating modes in a single workflow.\n\n---\n\n### Two Paths, One Workflow\n\n**Path 1 \u2014 Historical Backfill (Manual Trigger)** \nRun once to populate past data. Set `start_date` and `end_date` in the *Set Date Range* node. The *Generate Weekly Periods* node splits the range into 7-day chunks and processes them one by one to reduce the chance of API throttling.\n\n**Path 2 \u2014 Incremental Sync (Schedule Trigger, every 7 days)** \nRuns automatically and pulls the last 7 days. The date range is calculated dynamically, so no manual input is needed.\n\n---\n\n### Granularity Per Account\n- **Account A** \u2014 `level=campaign`, weekly\n- **Account B** \u2014 `level=ad` + `time_increment=1`, daily per ad\n\n---\n\n### Known Limitation\nThis template uses append-only writes. Re-running over the same date range will produce duplicate rows. Manual deduplication or a cleanup step may be needed.\n\n---\n\n### Setup\na) **Meta credential** \u2014 Configure an HTTP Header Auth credential with a long-lived Meta User Access Token that has `ads_read` permission. \nb) **Ad Account IDs** \u2014 Replace `act_XXXXXXXXXXXXXXXXX` in both HTTP Request nodes. \nc) **Google Sheets** \u2014 Configure a Google Sheets OAuth2 credential and prepare tabs `Account_A`, `Account_B`, `Account_A_Log`, and `Account_B_Log`. \nd) **Historical range** \u2014 Update `start_date` and `end_date` in *Set Date Range* before running the Manual Trigger."
},
"typeVersion": 1
},
{
"id": "e961643f-78b9-4a2a-90fa-33ec5b37aa0a",
"name": "Sticky Note3",
"type": "n8n-nodes-base.stickyNote",
"position": [
-544,
4928
],
"parameters": {
"color": 3,
"width": 1332,
"height": 604,
"content": "## Ad Account A \u2014 Campaign Level\n\nFetches weekly campaign-level insights from the Meta Ads API.\n\n**Setup:**\n- Replace `act_XXXXXXXXXXXXXXXXX` in the HTTP node URL with your Meta Ad Account ID.\n- Target sheet tab: **Account_A**\n- Granularity: `level=campaign` (one row per campaign per week)."
},
"typeVersion": 1
},
{
"id": "31355294-6709-4e6a-8b1a-8eb48dd9ccf4",
"name": "Sticky Note4",
"type": "n8n-nodes-base.stickyNote",
"position": [
-544,
5648
],
"parameters": {
"color": 6,
"width": 1332,
"height": 604,
"content": "## Ad Account B \u2014 Ad Level (Daily Breakdown)\n\nFetches weekly ad-level insights with a daily breakdown from the Meta Ads API.\n\n**Setup:**\n- Replace `act_XXXXXXXXXXXXXXXXX` in the HTTP node URL with your Meta Ad Account ID.\n- Target sheet tab: **Account_B**\n- Granularity: `level=ad` + `time_increment=1` (one row per ad per day)."
},
"typeVersion": 1
},
{
"id": "5bbd4115-daba-4bba-84a6-d7439d628b14",
"name": "Split API Response (Account A)",
"type": "n8n-nodes-base.code",
"position": [
256,
5088
],
"parameters": {
"jsCode": "return items.flatMap(item => {\n const rows = item.json.data || [];\n\n return rows.map(row => ({\n json: {\n date_start: row.date_start,\n date_stop: row.date_stop,\n account_id: row.account_id,\n account_name: row.account_name,\n campaign_id: row.campaign_id,\n campaign_name: row.campaign_name,\n adset_id: row.adset_id,\n adset_name: row.adset_name,\n ad_id: row.ad_id,\n ad_name: row.ad_name,\n objective: row.objective,\n buying_type: row.buying_type,\n\n spend: Number(row.spend || 0),\n impressions: Number(row.impressions || 0),\n reach: Number(row.reach || 0),\n frequency: Number(row.frequency || 0),\n clicks: Number(row.clicks || 0),\n unique_clicks: Number(row.unique_clicks || 0),\n ctr: Number(row.ctr || 0),\n cpc: Number(row.cpc || 0),\n cpm: Number(row.cpm || 0),\n\n actions: row.actions || [],\n cost_per_action_type: row.cost_per_action_type || [],\n action_values: row.action_values || [],\n quality_ranking: row.quality_ranking || '',\n engagement_rate_ranking: row.engagement_rate_ranking || '',\n conversion_rate_ranking: row.conversion_rate_ranking || ''\n }\n }));\n});"
},
"typeVersion": 2
},
{
"id": "6956d380-dfdd-4caa-81f2-b1b4b0ef1734",
"name": "Append to Sheet (Account A)",
"type": "n8n-nodes-base.googleSheets",
"position": [
640,
5088
],
"parameters": {
"columns": {
"value": {
"cpc": "={{ $json.cpc }}",
"cpm": "={{ $json.cpm }}",
"ctr": "={{ $json.ctr }}",
"ad_id": "={{ $json.ad_id }}",
"reach": "={{ $json.reach }}",
"spend": "={{ $json.spend }}",
"clicks": "={{ $json.clicks }}",
"actions": "={{ $json.actions }}",
"ad_name": "={{ $json.ad_name }}",
"adset_id": "={{ $json.adset_id }}",
"date_stop": "={{ $json.date_stop }}",
"frequency": "={{ $json.frequency }}",
"objective": "={{ $json.objective }}",
"account_id": "={{ $json.account_id }}",
"adset_name": "={{ $json.adset_name }}",
"date_start": "={{ $json.date_start }}",
"buying_type": "={{ $json.buying_type }}",
"campaign_id": "={{ $json.campaign_id }}",
"impressions": "={{ $json.impressions }}",
"account_name": "={{ $json.account_name }}",
"action_values": "={{ $json.action_values }}",
"campaign_name": "={{ $json.campaign_name }}",
"unique_clicks": "={{ $json.unique_clicks }}",
"quality_ranking": "={{ $json.quality_ranking }}",
"cost_per_action_type": "={{ $json.cost_per_action_type }}",
"conversion_rate_ranking": "={{ $json.conversion_rate_ranking }}",
"engagement_rate_ranking": "={{ $json.engagement_rate_ranking }}"
},
"schema": [
{
"id": "date_start",
"type": "string",
"display": true,
"required": false,
"displayName": "date_start",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "date_stop",
"type": "string",
"display": true,
"required": false,
"displayName": "date_stop",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "account_id",
"type": "string",
"display": true,
"required": false,
"displayName": "account_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "account_name",
"type": "string",
"display": true,
"required": false,
"displayName": "account_name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "campaign_id",
"type": "string",
"display": true,
"required": false,
"displayName": "campaign_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "campaign_name",
"type": "string",
"display": true,
"required": false,
"displayName": "campaign_name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "adset_id",
"type": "string",
"display": true,
"required": false,
"displayName": "adset_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "adset_name",
"type": "string",
"display": true,
"required": false,
"displayName": "adset_name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ad_id",
"type": "string",
"display": true,
"required": false,
"displayName": "ad_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ad_name",
"type": "string",
"display": true,
"required": false,
"displayName": "ad_name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "objective",
"type": "string",
"display": true,
"required": false,
"displayName": "objective",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "buying_type",
"type": "string",
"display": true,
"required": false,
"displayName": "buying_type",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "spend",
"type": "string",
"display": true,
"required": false,
"displayName": "spend",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "impressions",
"type": "string",
"display": true,
"required": false,
"displayName": "impressions",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "reach",
"type": "string",
"display": true,
"required": false,
"displayName": "reach",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "frequency",
"type": "string",
"display": true,
"required": false,
"displayName": "frequency",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "clicks",
"type": "string",
"display": true,
"required": false,
"displayName": "clicks",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "unique_clicks",
"type": "string",
"display": true,
"required": false,
"displayName": "unique_clicks",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ctr",
"type": "string",
"display": true,
"required": false,
"displayName": "ctr",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "cpc",
"type": "string",
"display": true,
"required": false,
"displayName": "cpc",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "cpm",
"type": "string",
"display": true,
"required": false,
"displayName": "cpm",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "actions",
"type": "string",
"display": true,
"required": false,
"displayName": "actions",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "cost_per_action_type",
"type": "string",
"display": true,
"required": false,
"displayName": "cost_per_action_type",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "action_values",
"type": "string",
"display": true,
"required": false,
"displayName": "action_values",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "quality_ranking",
"type": "string",
"display": true,
"required": false,
"displayName": "quality_ranking",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "engagement_rate_ranking",
"type": "string",
"display": true,
"required": false,
"displayName": "engagement_rate_ranking",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "conversion_rate_ranking",
"type": "string",
"display": true,
"required": false,
"displayName": "conversion_rate_ranking",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/YOUR_SPREADSHEET_ID/edit#gid=0",
"cachedResultName": "Account_A"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "YOUR_SPREADSHEET_ID",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/YOUR_SPREADSHEET_ID/edit",
"cachedResultName": "Meta Ads Report"
}
},
"typeVersion": 4.7
},
{
"id": "a7e0dc63-3014-4ba6-b2a3-ebb8231f2560",
"name": "Fetch Meta Insights (Account A)",
"type": "n8n-nodes-base.httpRequest",
"maxTries": 5,
"position": [
-224,
5168
],
"parameters": {
"url": "https://graph.facebook.com/v24.0/act_XXXXXXXXXXXXXXXXX/insights",
"options": {
"response": {
"response": {
"neverError": true
}
},
"pagination": {
"pagination": {
"nextURL": "={{ $response.body.paging.next }}",
"paginationMode": "responseContainsNextURL",
"requestInterval": 3000,
"completeExpression": "={{ !$response.body.paging?.next }}",
"paginationCompleteWhen": "other"
}
}
},
"sendQuery": true,
"authentication": "genericCredentialType",
"genericAuthType": "httpHeaderAuth",
"queryParameters": {
"parameters": [
{
"name": "fields",
"value": "date_start,date_stop,account_id,account_name,campaign_id,campaign_name,adset_id,adset_name,ad_id,ad_name,objective,buying_type,spend,impressions,reach,frequency,clicks,unique_clicks,ctr,cpc,cpm,actions,cost_per_action_type,action_values,quality_ranking,engagement_rate_ranking,conversion_rate_ranking"
},
{
"name": "level",
"value": "campaign"
},
{
"name": "time_range[since]",
"value": "={{ $json.since }}"
},
{
"name": "time_range[until]",
"value": "={{ $json.until }}"
}
]
}
},
"retryOnFail": true,
"typeVersion": 4.3,
"continueOnFail": true,
"waitBetweenTries": 3000
},
{
"id": "b511f5f0-2958-4587-83df-8f3def77e9d0",
"name": "Loop Over Periods (Account A)",
"type": "n8n-nodes-base.splitInBatches",
"position": [
-464,
5168
],
"parameters": {
"options": {}
},
"typeVersion": 3,
"alwaysOutputData": false
},
{
"id": "0cc3675f-73a2-42ba-b28b-36eb70862328",
"name": "Valid Response? (Account A)",
"type": "n8n-nodes-base.if",
"position": [
16,
5168
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 1,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "0433ddac-c3db-4463-a06d-c0a4ecb09210",
"operator": {
"type": "boolean",
"operation": "equals"
},
"leftValue": "={{ Array.isArray($json.data) && $json.data.length > 0 }}",
"rightValue": true
}
]
}
},
"typeVersion": 2
},
{
"id": "cf7c2e06-7e5f-42c3-a0e8-ea9e903b2fe7",
"name": "Log Skipped Period (Account A)",
"type": "n8n-nodes-base.set",
"position": [
256,
5296
],
"parameters": {
"mode": "raw",
"options": {},
"jsonOutput": "{\n \"status\": \"skipped\",\n \"reason\": \"Meta API returned no data or an error for this period\",\n \"account\": \"Account A\",\n \"since\": \"={{ $('Loop Over Periods (Account A)').item.json.since }}\",\n \"until\": \"={{ $('Loop Over Periods (Account A)').item.json.until }}\",\n \"execution_id\": \"={{ $execution.id }}\",\n \"timestamp\": \"={{ new Date().toISOString() }}\"\n}"
},
"typeVersion": 3.4
},
{
"id": "db2400d2-3ac1-405b-bdd0-cf7768b0be4a",
"name": "Append to Log Sheet (Account A)",
"type": "n8n-nodes-base.googleSheets",
"position": [
496,
5296
],
"parameters": {
"columns": {
"value": {
"since": "={{ $json.since }}",
"until": "={{ $json.until }}",
"reason": "={{ $json.reason }}",
"status": "={{ $json.status }}",
"account": "={{ $json.account }}",
"timestamp": "={{ $json.timestamp }}",
"execution_id": "={{ $json.execution_id }}"
},
"schema": [
{
"id": "status",
"type": "string",
"display": true,
"required": false,
"displayName": "status",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "reason",
"type": "string",
"display": true,
"required": false,
"displayName": "reason",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "account",
"type": "string",
"display": true,
"required": false,
"displayName": "account",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "since",
"type": "string",
"display": true,
"required": false,
"displayName": "since",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "until",
"type": "string",
"display": true,
"required": false,
"displayName": "until",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "execution_id",
"type": "string",
"display": true,
"required": false,
"displayName": "execution_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "timestamp",
"type": "string",
"display": true,
"required": false,
"displayName": "timestamp",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "name",
"value": "Account_A_Log"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "YOUR_SPREADSHEET_ID",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/YOUR_SPREADSHEET_ID/edit",
"cachedResultName": "Meta Ads Report"
}
},
"typeVersion": 4.7
},
{
"id": "73bb5e27-b475-429b-8cdd-a6db1dae3900",
"name": "Loop Over Periods (Account B)",
"type": "n8n-nodes-base.splitInBatches",
"position": [
-464,
5888
],
"parameters": {
"options": {}
},
"typeVersion": 3,
"alwaysOutputData": false
},
{
"id": "e9473c81-f8b9-4ab6-8fef-2835df2a1f42",
"name": "Fetch Meta Insights (Account B)",
"type": "n8n-nodes-base.httpRequest",
"maxTries": 5,
"position": [
-224,
5888
],
"parameters": {
"url": "https://graph.facebook.com/v24.0/act_XXXXXXXXXXXXXXXXX/insights",
"options": {
"response": {
"response": {
"neverError": true
}
},
"pagination": {
"pagination": {
"nextURL": "={{ $response.body.paging.next }}",
"paginationMode": "responseContainsNextURL",
"requestInterval": 3000,
"completeExpression": "={{ !$response.body.paging?.next }}",
"paginationCompleteWhen": "other"
}
}
},
"sendQuery": true,
"authentication": "genericCredentialType",
"genericAuthType": "httpHeaderAuth",
"queryParameters": {
"parameters": [
{
"name": "fields",
"value": "date_start,date_stop,account_id,account_name,campaign_id,campaign_name,adset_id,adset_name,ad_id,ad_name,objective,buying_type,spend,impressions,reach,frequency,clicks,unique_clicks,ctr,cpc,cpm,actions,cost_per_action_type,action_values,quality_ranking,engagement_rate_ranking,conversion_rate_ranking"
},
{
"name": "level",
"value": "ad"
},
{
"name": "time_range[since]",
"value": "={{ $json.since }}"
},
{
"name": "time_increment",
"value": "1"
},
{
"name": "time_range[until]",
"value": "={{ $json.until }}"
}
]
}
},
"retryOnFail": true,
"typeVersion": 4.3,
"continueOnFail": true,
"waitBetweenTries": 3000
},
{
"id": "fa27b4f8-139a-4d31-bcef-204e70e3f7b6",
"name": "Valid Response? (Account B)",
"type": "n8n-nodes-base.if",
"position": [
16,
5888
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 1,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "df38f124-c4f4-4a0b-a375-858436180d5b",
"operator": {
"type": "boolean",
"operation": "equals"
},
"leftValue": "={{ Array.isArray($json.data) && $json.data.length > 0 }}",
"rightValue": true
}
]
}
},
"typeVersion": 2
},
{
"id": "558675fc-af90-4ef3-b567-d835b650d5d2",
"name": "Split API Response (Account B)",
"type": "n8n-nodes-base.code",
"position": [
256,
5808
],
"parameters": {
"jsCode": "return items.flatMap(item => {\n const rows = item.json.data || [];\n\n return rows.map(row => ({\n json: {\n date_start: row.date_start,\n date_stop: row.date_stop,\n account_id: row.account_id,\n account_name: row.account_name,\n campaign_id: row.campaign_id,\n campaign_name: row.campaign_name,\n adset_id: row.adset_id,\n adset_name: row.adset_name,\n ad_id: row.ad_id,\n ad_name: row.ad_name,\n objective: row.objective,\n buying_type: row.buying_type,\n\n spend: Number(row.spend || 0),\n impressions: Number(row.impressions || 0),\n reach: Number(row.reach || 0),\n frequency: Number(row.frequency || 0),\n clicks: Number(row.clicks || 0),\n unique_clicks: Number(row.unique_clicks || 0),\n ctr: Number(row.ctr || 0),\n cpc: Number(row.cpc || 0),\n cpm: Number(row.cpm || 0),\n\n actions: row.actions || [],\n cost_per_action_type: row.cost_per_action_type || [],\n action_values: row.action_values || [],\n quality_ranking: row.quality_ranking || '',\n engagement_rate_ranking: row.engagement_rate_ranking || '',\n conversion_rate_ranking: row.conversion_rate_ranking || ''\n }\n }));\n});"
},
"typeVersion": 2
},
{
"id": "46f44c50-d25d-44bb-9215-5fbeab7165a8",
"name": "Append to Sheet (Account B)",
"type": "n8n-nodes-base.googleSheets",
"position": [
608,
5808
],
"parameters": {
"columns": {
"value": {
"cpc": "={{ $json.cpc }}",
"cpm": "={{ $json.cpm }}",
"ctr": "={{ $json.ctr }}",
"ad_id": "={{ $json.ad_id }}",
"reach": "={{ $json.reach }}",
"spend": "={{ $json.spend }}",
"clicks": "={{ $json.clicks }}",
"actions": "={{ $json.actions }}",
"ad_name": "={{ $json.ad_name }}",
"adset_id": "={{ $json.adset_id }}",
"date_stop": "={{ $json.date_stop }}",
"frequency": "={{ $json.frequency }}",
"objective": "={{ $json.objective }}",
"account_id": "={{ $json.account_id }}",
"adset_name": "={{ $json.adset_name }}",
"date_start": "={{ $json.date_start }}",
"buying_type": "={{ $json.buying_type }}",
"campaign_id": "={{ $json.campaign_id }}",
"impressions": "={{ $json.impressions }}",
"account_name": "={{ $json.account_name }}",
"action_values": "={{ $json.action_values }}",
"campaign_name": "={{ $json.campaign_name }}",
"unique_clicks": "={{ $json.unique_clicks }}",
"quality_ranking": "={{ $json.quality_ranking }}",
"cost_per_action_type": "={{ $json.cost_per_action_type }}",
"conversion_rate_ranking": "={{ $json.conversion_rate_ranking }}",
"engagement_rate_ranking": "={{ $json.engagement_rate_ranking }}"
},
"schema": [
{
"id": "date_start",
"type": "string",
"display": true,
"required": false,
"displayName": "date_start",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "date_stop",
"type": "string",
"display": true,
"required": false,
"displayName": "date_stop",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "account_id",
"type": "string",
"display": true,
"required": false,
"displayName": "account_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "account_name",
"type": "string",
"display": true,
"required": false,
"displayName": "account_name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "campaign_id",
"type": "string",
"display": true,
"required": false,
"displayName": "campaign_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "campaign_name",
"type": "string",
"display": true,
"required": false,
"displayName": "campaign_name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "adset_id",
"type": "string",
"display": true,
"required": false,
"displayName": "adset_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "adset_name",
"type": "string",
"display": true,
"required": false,
"displayName": "adset_name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ad_id",
"type": "string",
"display": true,
"required": false,
"displayName": "ad_id",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ad_name",
"type": "string",
"display": true,
"required": false,
"displayName": "ad_name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "objective",
"type": "string",
"display": true,
"required": false,
"displayName": "objective",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "buying_type",
"type": "string",
"display": true,
"required": false,
"displayName": "buying_type",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "spend",
"type": "string",
"display": true,
"required": false,
"displayName": "spend",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "impressions",
"type": "string",
"display": true,
"required": false,
"displayName": "impressions",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "reach",
"type": "string",
"display": true,
"required": false,
"displayName": "reach",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "frequency",
"type": "string",
"display": true,
"required": false,
"displayName": "frequency",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "clicks",
"type": "string",
"display": true,
"required": false,
"displayName": "clicks",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "unique_clicks",
"type": "string",
"display": true,
"required": false,
"displayName": "unique_clicks",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ctr",
"type": "string",
"display": true,
"required": false,
"displayName": "ctr",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "cpc",
"type": "string",
"display": true,
"required": false,
"displayName": "cpc",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "cpm",
"type": "string",
"display": true,
"required": false,
"displayName": "cpm",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "actions",
"type": "string",
"display": true,
"required": false,
"displayName": "actions",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "cost_per_action_type",
"type": "string",
"display": true,
"required": false,
"displayName": "cost_per_action_type",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "action_values",
"type": "string",
"display": true,
"required": false,
"displayName": "action_values",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "quality_ranking",
"type": "string",
"display": true,
"required": false,
"displayName": "quality_ranking",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "engagement_rate_ranking",
"type": "string",
"display": true,
"required": false,
"displayName": "engagement_rate_ranking",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "conversion_rate_ranking",
"type": "string",
"display": true,
"required": false,
"displayName": "conversion_rate_ranking",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=XXXXXXXXXX",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/YOUR_SPREADSHEET_ID/edit#gid=XXXXXXXXXX",
"cachedResultName": "Account_B"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "YOUR_SPREADSHEET_ID",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/YOUR_SPREADSHEET_ID/edit",
"cachedResultName": "Meta Ads Report"
}
},
"typeVersion": 4.7
},
{
"id": "2e9f737a-5e02-4b94-ad1b-fa5a3690790e",
"name": "If Spend not 0 (Account A)",
"type": "n8n-nodes-base.if",
"position": [
448,
5088
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "loose"
},
"combinator": "and",
"conditions": [
{
"id": "b51d8946-3d1d-4ec3-8c7d-75cb05824fb7",
"operator": {
"type": "number",
"operation": "notEquals"
},
"leftValue": "={{ $json.spend }}",
"rightValue": 0
}
]
},
"looseTypeValidation": true
},
"typeVersion": 2.2,
"alwaysOutputData": false
},
{
"id": "8cf7699d-cdbf-4895-8d46-8c7ddea3a274",
"name": "If Spend not 0 (Account B)",
"type": "n8n-nodes-base.if",
"position": [
432,
5808
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "loose"
},
"combinator": "and",
"conditions": [
{
"id": "b51d8946-3d1d-4ec3-8c7d-75cb05824fb7",
"operator": {
"type": "number",
"operation": "notEquals"
},
"leftValue": "={{ $json.spend }}",
"rightValue": 0
}
]
},
"looseTypeValidation": true
},
"typeVersion": 2.2,
"alwaysOutputData": false
},
{
"id": "dbe8e070-b975-4ff8-9186-01993d48219a",
"name": "Set Incremental Range (Last 7 Days)",
"type": "n8n-nodes-base.set",
"position": [
-1088,
5168
],
"parameters": {
"mode": "raw",
"options": {},
"jsonOutput": "{\n \"since\": \"={{ $now.minus(7, 'days').toISODate() }}\",\n \"until\": \"={{ $now.toISODate() }}\"\n}"
},
"typeVersion": 3.4
},
{
"id": "f3c9c2f9-626f-42fc-8308-def370158e13",
"name": "Schedule Trigger (Incremental)",
"type": "n8n-nodes-base.scheduleTrigger",
"position": [
-1312,
5168
],
"parameters": {
"rule": {
"interval": [
{
"daysInterval": 7
}
]
}
},
"typeVersion": 1.3
},
{
"id": "8509aa01-3574-459a-a965-fcd12804cd3b",
"name": "Generate Weekly Periods",
"type": "n8n-nodes-base.code",
"position": [
-928,
5728
],
"parameters": {
"jsCode": "let start = new Date($input.first().json.start_date);\nconst end = new Date($input.first().json.end_date);\n\nlet output = [];\n\nwhile (start <= end) {\n let until = new Date(start);\n until.setDate(until.getDate() + 6);\n\n // Fix: clamp until so last chunk never exceeds end_date\n if (until > end) until = new Date(end);\n\n output.push({\n since: start.toISOString().split(\"T\")[0],\n until: until.toISOString().split(\"T\")[0]\n });\n\n start.setDate(start.getDate() + 7);\n}\n\nreturn output.map(d => ({ json: d }));\n"
},
"typeVersion": 2
},
{
"id": "bd4e94e1-fba0-439d-b70f-cca3cec34d32",
"name": "Set Date Range (Historical Backfill)",
"type": "n8n-nodes-base.set",
"position": [
-1120,
5728
],
"parameters": {
"mode": "raw",
"options": {},
"jsonOutput": "{\n \"start_date\": \"2024-01-01\",\n \"end_date\": \"2024-12-31\"\n}"
},
"typeVersion": 3.4
},
{
"id": "49204618-70fc-415d-b1cc-5f87510e60d0",
"name": "Log Skipped Period (Account B)",
"type": "n8n-nodes-base.set",
"position": [
256,
6016
],
"parameters": {
"mode": "raw",
"options": {},
"jsonOutput": "{\n \"status\": \"skipped\",\n \"reason\": \"Meta API returned no data or an error for this period\",\n \"account\": \"Account B\",\n \"since\": \"={{ $('Loop Over Periods (Account B)').item.json.since }}\",\n \"until\": \"={{ $('Loop Over Periods (Account B)').item.json.until }}\",\n \"execution_id\": \"={{ $execution.id }}\",\n \"timestamp\": \"={{ new Date().toISOString() }}\"\n}"
},
"typeVersion": 3.4
}
],
"active": false,
"settings": {
"binaryMode": "separate",
"executionOrder": "v1"
},
"versionId": "a282ce38-448e-4fe4-ba6d-66d9d9a53739",
"connections": {
"Generate Weekly Periods": {
"main": [
[
{
"node": "Loop Over Periods (Account A)",
"type": "main",
"index": 0
},
{
"node": "Loop Over Periods (Account B)",
"type": "main",
"index": 0
}
]
]
},
"If Spend not 0 (Account A)": {
"main": [
[
{
"node": "Append to Sheet (Account A)",
"type": "main",
"index": 0
}
]
]
},
"If Spend not 0 (Account B)": {
"main": [
[
{
"node": "Append to Sheet (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Append to Sheet (Account A)": {
"main": [
[
{
"node": "Loop Over Periods (Account A)",
"type": "main",
"index": 0
}
]
]
},
"Append to Sheet (Account B)": {
"main": [
[
{
"node": "Loop Over Periods (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Valid Response? (Account A)": {
"main": [
[
{
"node": "Split API Response (Account A)",
"type": "main",
"index": 0
}
],
[
{
"node": "Log Skipped Period (Account A)",
"type": "main",
"index": 0
}
]
]
},
"Valid Response? (Account B)": {
"main": [
[
{
"node": "Split API Response (Account B)",
"type": "main",
"index": 0
}
],
[
{
"node": "Log Skipped Period (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Loop Over Periods (Account A)": {
"main": [
[],
[
{
"node": "Fetch Meta Insights (Account A)",
"type": "main",
"index": 0
}
]
]
},
"Loop Over Periods (Account B)": {
"main": [
[],
[
{
"node": "Fetch Meta Insights (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Log Skipped Period (Account A)": {
"main": [
[
{
"node": "Append to Log Sheet (Account A)",
"type": "main",
"index": 0
}
]
]
},
"Log Skipped Period (Account B)": {
"main": [
[
{
"node": "Append to Log Sheet (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Schedule Trigger (Incremental)": {
"main": [
[
{
"node": "Set Incremental Range (Last 7 Days)",
"type": "main",
"index": 0
}
]
]
},
"Split API Response (Account A)": {
"main": [
[
{
"node": "If Spend not 0 (Account A)",
"type": "main",
"index": 0
}
]
]
},
"Split API Response (Account B)": {
"main": [
[
{
"node": "If Spend not 0 (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Append to Log Sheet (Account A)": {
"main": [
[
{
"node": "Loop Over Periods (Account A)",
"type": "main",
"index": 0
}
]
]
},
"Append to Log Sheet (Account B)": {
"main": [
[
{
"node": "Loop Over Periods (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Fetch Meta Insights (Account A)": {
"main": [
[
{
"node": "Valid Response? (Account A)",
"type": "main",
"index": 0
}
]
]
},
"Fetch Meta Insights (Account B)": {
"main": [
[
{
"node": "Valid Response? (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Set Incremental Range (Last 7 Days)": {
"main": [
[
{
"node": "Loop Over Periods (Account A)",
"type": "main",
"index": 0
},
{
"node": "Loop Over Periods (Account B)",
"type": "main",
"index": 0
}
]
]
},
"Manual Trigger (Historical Backfill)": {
"main": [
[
{
"node": "Set Date Range (Historical Backfill)",
"type": "main",
"index": 0
}
]
]
},
"Set Date Range (Historical Backfill)": {
"main": [
[
{
"node": "Generate Weekly Periods",
"type": "main",
"index": 0
}
]
]
}
}
}
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
This workflow provides a structured way to extract Meta Ads performance data and store it in Google Sheets for reporting, dashboarding, or further analysis.
Source: https://n8n.io/workflows/14721/ — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
This workflow acts as a junior finance research analyst for a UK boutique M&A or corporate finance team. It listens for Slack messages, classifies the request, gathers company or market data, and prod
HTTP Request, Google Drive, Google Docs +5
This workflow syncs Toggl Track time entries to Google Sheets and creates monthly tabs automatically.
HTTP Request, Google Sheets
This template demonstrates how to build a low-code, AI-powered data analysis workflow in n8n. It enables you to connect to various data sources (such as MySQL, Google Sheets, or local files), process
MySQL, Google Sheets, Read Write File +2
AI Money Tracker Chatbot. Uses telegramTrigger, postgres, googleSheets, telegram. Event-driven trigger; 24 nodes.
Telegram Trigger, Postgres, Google Sheets +2
This n8n workflow retrieves AI agent chat memory logs stored in Postgres and pushes them to Google Sheets, creating one sheet per session. It’s useful for teams building chat-based products or agents
Postgres, HTTP Request, Google Sheets
