The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "WF-01 \u00b7 WhatsApp Incoming",
"nodes": [
{
"parameters": {
"httpMethod": "POST",
"path": "whatsapp",
"responseMode": "responseNode",
"options": {
"rawBody": true
}
},
"id": "wf01-webhook",
"name": "Webhook \u00b7 WhatsApp",
"type": "n8n-nodes-base.webhook",
"typeVersion": 2,
"position": [
-720,
300
],
"notes": "Meta posts here. Point the WhatsApp app's Callback URL at this path."
},
{
"parameters": {
"respondWith": "text",
"responseBody": "EVENT_RECEIVED",
"options": {
"responseCode": 200
}
},
"id": "wf01-ack",
"name": "Ack 200 Immediately",
"type": "n8n-nodes-base.respondToWebhook",
"typeVersion": 1,
"position": [
-500,
300
],
"notes": "Meta retries for ~24h on any non-200. Acknowledge first, then process \u2014 never make the platform wait on the AI call."
},
{
"parameters": {
"jsCode": "// Guard clause: only forward payloads that actually contain messages.\n// Status-only callbacks (delivered/read) go down the status branch instead.\nconst items = [];\nfor (const item of $input.all()) {\n const body = item.json.body ?? item.json;\n const entries = body.entry ?? [];\n let hasMessages = false;\n let hasStatuses = false;\n for (const entry of entries) {\n for (const change of entry.changes ?? []) {\n const value = change.value ?? {};\n if ((value.messages ?? []).length) hasMessages = true;\n if ((value.statuses ?? []).length) hasStatuses = true;\n }\n }\n items.push({\n json: {\n body,\n signature: item.json.headers?.['x-hub-signature-256'] ?? null,\n hasMessages,\n hasStatuses,\n },\n });\n}\nreturn items;"
},
"id": "wf01-classify",
"name": "Classify Payload",
"type": "n8n-nodes-base.code",
"typeVersion": 2,
"position": [
-280,
300
]
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"version": 2
},
"conditions": [
{
"id": "has-messages",
"leftValue": "={{ $json.hasMessages }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "wf01-is-message",
"name": "Contains a Message?",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
-60,
300
]
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/webhooks/whatsapp",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
},
{
"name": "X-Hub-Signature-256",
"value": "={{ $json.signature }}"
},
{
"name": "X-Workflow-Code",
"value": "WF-01"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify($json.body) }}",
"options": {
"timeout": 15000,
"response": {
"response": {
"fullResponse": false,
"neverError": false
}
}
}
},
"id": "wf01-ingest",
"name": "Normalize & Store (FastAPI)",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
180,
200
],
"retryOnFail": true,
"maxTries": 3,
"waitBetweenTries": 2000,
"onError": "continueErrorOutput",
"notes": "The backend verifies the signature itself, normalizes via WhatsAppAdapter, de-duplicates on (org, platform, external_message_id), and returns the stored message plus its conversation."
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/ai/route",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ message_id: $json.message_id, conversation_id: $json.conversation_id, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 45000
}
},
"id": "wf01-router",
"name": "AI Router",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
400,
200
],
"retryOnFail": true,
"maxTries": 2,
"waitBetweenTries": 3000,
"onError": "continueErrorOutput",
"notes": "Returns { intent, confidence, action, lead_score, needs_human }."
},
{
"parameters": {
"rules": {
"values": [
{
"conditions": {
"options": {
"version": 2
},
"conditions": [
{
"leftValue": "={{ $json.needs_human }}",
"rightValue": true,
"operator": {
"type": "boolean",
"operation": "true",
"singleValue": true
}
}
],
"combinator": "and"
},
"renameOutput": true,
"outputKey": "Human"
},
{
"conditions": {
"options": {
"version": 2
},
"conditions": [
{
"leftValue": "={{ $json.action }}",
"rightValue": "qualify",
"operator": {
"type": "string",
"operation": "equals"
}
}
],
"combinator": "and"
},
"renameOutput": true,
"outputKey": "Sales"
},
{
"conditions": {
"options": {
"version": 2
},
"conditions": [
{
"leftValue": "={{ $json.action }}",
"rightValue": "answer",
"operator": {
"type": "string",
"operation": "equals"
}
}
],
"combinator": "and"
},
"renameOutput": true,
"outputKey": "Support"
}
]
},
"options": {
"fallbackOutput": 0
}
},
"id": "wf01-switch",
"name": "Route by Decision",
"type": "n8n-nodes-base.switch",
"typeVersion": 3,
"position": [
620,
200
],
"notes": "Fallback output is Human. When the router is unsure about its own output, a person sees it."
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/approvals",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ subject_type: 'message', conversation_id: $json.conversation_id, reason: $json.escalation_reason ?? 'Low confidence or sensitive intent', confidence: $json.confidence, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 15000
}
},
"id": "wf01-human",
"name": "Queue for Human",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
860,
60
],
"onError": "continueErrorOutput"
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/ai/sales",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ conversation_id: $json.conversation_id, message_id: $json.message_id, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 45000
}
},
"id": "wf01-sales",
"name": "Sales Agent \u00b7 Qualify",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
860,
200
],
"retryOnFail": true,
"maxTries": 2,
"onError": "continueErrorOutput"
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/ai/support",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ conversation_id: $json.conversation_id, message_id: $json.message_id, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 45000
}
},
"id": "wf01-support",
"name": "Support Agent \u00b7 RAG Answer",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
860,
340
],
"retryOnFail": true,
"maxTries": 2,
"onError": "continueErrorOutput"
},
{
"parameters": {
"conditions": {
"options": {
"version": 2
},
"conditions": [
{
"leftValue": "={{ $json.needs_human }}",
"rightValue": false,
"operator": {
"type": "boolean",
"operation": "false",
"singleValue": true
}
},
{
"leftValue": "={{ $json.answer }}",
"rightValue": "",
"operator": {
"type": "string",
"operation": "notEmpty",
"singleValue": true
}
}
],
"combinator": "and"
},
"options": {}
},
"id": "wf01-safe-to-send",
"name": "Safe to Send?",
"type": "n8n-nodes-base.if",
"typeVersion": 2,
"position": [
1080,
340
],
"notes": "Second gate. The agent may downgrade its own confidence after searching the knowledge base, so the check happens again here."
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/messages/send",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ conversation_id: $json.conversation_id, text: $json.answer, sender_type: 'ai', ai_run_id: $json.ai_run_id, confidence: $json.confidence, organization_id: $json.organization_id }) }}",
"options": {
"timeout": 30000
}
},
"id": "wf01-send",
"name": "Send via WhatsApp API",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1300,
280
],
"retryOnFail": true,
"maxTries": 3,
"waitBetweenTries": 5000,
"onError": "continueErrorOutput",
"notes": "The backend owns the credential and picks the live or mock adapter. n8n never holds a platform token."
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/webhooks/whatsapp/status",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify($json.body) }}",
"options": {
"timeout": 15000
}
},
"id": "wf01-status",
"name": "Record Delivery Status",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
180,
420
],
"onError": "continueRegularOutput"
},
{
"parameters": {
"method": "POST",
"url": "={{ $env.OMNI_BACKEND_URL }}/api/internal/workflow-runs",
"sendHeaders": true,
"headerParameters": {
"parameters": [
{
"name": "Authorization",
"value": "=Bearer {{ $env.OMNI_INTERNAL_TOKEN }}"
}
]
},
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ JSON.stringify({ workflow_code: 'WF-01', n8n_execution_id: $execution.id, status: 'failed', platform: 'whatsapp', error: JSON.stringify($json.error ?? $json), input_payload: $json }) }}",
"options": {
"timeout": 15000
}
},
"id": "wf01-deadletter",
"name": "Dead Letter \u00b7 Manual Review",
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1300,
540
],
"onError": "continueRegularOutput",
"notes": "Every error output converges here. The run shows up on the Workflows page as a failure needing attention."
}
],
"connections": {
"Webhook \u00b7 WhatsApp": {
"main": [
[
{
"node": "Ack 200 Immediately",
"type": "main",
"index": 0
}
]
]
},
"Ack 200 Immediately": {
"main": [
[
{
"node": "Classify Payload",
"type": "main",
"index": 0
}
]
]
},
"Classify Payload": {
"main": [
[
{
"node": "Contains a Message?",
"type": "main",
"index": 0
}
]
]
},
"Contains a Message?": {
"main": [
[
{
"node": "Normalize & Store (FastAPI)",
"type": "main",
"index": 0
}
],
[
{
"node": "Record Delivery Status",
"type": "main",
"index": 0
}
]
]
},
"Normalize & Store (FastAPI)": {
"main": [
[
{
"node": "AI Router",
"type": "main",
"index": 0
}
],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"AI Router": {
"main": [
[
{
"node": "Route by Decision",
"type": "main",
"index": 0
}
],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"Route by Decision": {
"main": [
[
{
"node": "Queue for Human",
"type": "main",
"index": 0
}
],
[
{
"node": "Sales Agent \u00b7 Qualify",
"type": "main",
"index": 0
}
],
[
{
"node": "Support Agent \u00b7 RAG Answer",
"type": "main",
"index": 0
}
]
]
},
"Sales Agent \u00b7 Qualify": {
"main": [
[
{
"node": "Send via WhatsApp API",
"type": "main",
"index": 0
}
],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"Support Agent \u00b7 RAG Answer": {
"main": [
[
{
"node": "Safe to Send?",
"type": "main",
"index": 0
}
],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"Safe to Send?": {
"main": [
[
{
"node": "Send via WhatsApp API",
"type": "main",
"index": 0
}
],
[
{
"node": "Queue for Human",
"type": "main",
"index": 0
}
]
]
},
"Send via WhatsApp API": {
"main": [
[],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
},
"Queue for Human": {
"main": [
[],
[
{
"node": "Dead Letter \u00b7 Manual Review",
"type": "main",
"index": 0
}
]
]
}
},
"settings": {
"executionOrder": "v1",
"saveDataErrorExecution": "all",
"saveDataSuccessExecution": "all",
"saveExecutionProgress": true,
"errorWorkflow": "WF-90"
},
"tags": [
{
"name": "incoming"
},
{
"name": "whatsapp"
}
],
"meta": {
"description": "Inbound WhatsApp: acknowledge, normalize through the backend, route with AI, then answer, qualify, or escalate. Every branch has an error output that lands in the dead-letter node."
}
}
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
WF-01 · WhatsApp Incoming. Uses httpRequest. Webhook trigger; 14 nodes.
Source: https://github.com/hamza01055/omni-ai-automation/blob/main/n8n/workflows/incoming/WF-01-whatsapp-incoming.json — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
Flujowhatsapp. Uses @aldinokemal2104/n8n-nodes-gowa, postgres, httpRequest. Webhook trigger; 65 nodes.
@Aldinokemal2104/N8N Nodes Gowa, Postgres, HTTP Request
HR teams, IT Operations, and System Administrators managing employee onboarding at scale. It’s perfect if you use Odoo 18 to trigger account requests and need Redmine + GitLab accounts created instant
HTTP Request, Slack
This workflow is a complete, production-ready solution for recovering abandoned carts in Shopify stores using a multi-channel, multi-touch approach. It automates personalized follow-ups via Email, SMS
HTTP Request, Shopify, SendGrid +5
WF_UNIFIED_LEGAL_AUTOMATION. Uses googleSheets, httpRequest, telegram, telegramTrigger. Webhook trigger; 53 nodes.
Google Sheets, HTTP Request, Telegram +1
Backbrief: transcripts (Zoom webhook -> Slack + vault). Uses httpRequest, slack. Webhook trigger; 52 nodes.
HTTP Request, Slack
