Marián Današ
This workflow corresponds to n8n.io template #14491 — we link there as the canonical source.
This workflow follows the Form Trigger → Gmail recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"id": "Ajt6puMLs0M0Ae05",
"meta": {
"templateCredsSetupCompleted": true
},
"name": "Event registration system with waitlist and multi-tier PDFs (PDF Generator API)",
"tags": [],
"nodes": [
{
"id": "9afefbd2-6a98-446d-91ce-553352cd2fcf",
"name": "\ud83d\udccb Setup Instructions",
"type": "n8n-nodes-base.stickyNote",
"position": [
0,
0
],
"parameters": {
"width": 952,
"height": 736,
"content": "## \ud83c\udfab Event Registration System with Waitlist & Multi-Tier PDFs\n### Powered by PDF Generator API\n\nAutomate end-to-end event registration: check capacity, generate tier-specific PDF tickets with QR codes, email attendees, and manage a waitlist with automatic promotion when a spot opens.\n\n## How it works\n\n**Flow A \u2014 New Registration**\n1. Attendee submits the registration form (name, email, event details, ticket tier)\n2. Current registrations are read from Google Sheets to check remaining capacity\n3. **Spots available \u2192** routes by tier (General / VIP / Backstage), generates a PDF ticket via PDF Generator API, emails it, logs to Sheets, and sends a Slack alert to the organizer\n4. **Event full \u2192** adds the attendee to the Waitlist tab and sends a waitlist confirmation email\n\n**Flow B \u2014 Cancellation & Promotion**\n1. A POST request hits the Cancellation Webhook with `{ \"ticket_id\": \"TKT-XXXXXXXX\" }`\n2. Ticket ID is validated and the registration is marked `CANCELED` in Sheets\n3. **Waitlist has entries \u2192** the first person is promoted: PDF ticket generated, emailed, logged in Registrations, and a Slack alert sent\n4. **Waitlist is empty \u2192** cancellation-only Slack alert is sent to the organizer\n\n---\n\n## Set up steps\n1. **PDF Generator API** \u2014 Create 3 ticket templates (General, VIP, Backstage) at [pdfgeneratorapi.com](https://pdfgeneratorapi.com). Use variables: `ticket_id`, `attendee_name`, `event_name`, `venue`, `event_date`, `seat_number`, `ticket_tier`, `issued_date`. Add a **QR Code** component bound to `{{ ticket_id }}`\n2. **Template IDs + Capacity** \u2014 In **\"Check Capacity & Prepare Data\"** (Flow A) and **\"Promote from Waitlist\"** (Flow B), replace the 3 placeholder template IDs and set `MAX_CAPACITY`\n3. **Google Sheets** \u2014 Create a spreadsheet with two tabs: **Registrations** and **Waitlist** (see the Sheets setup note on the right). Update the Spreadsheet ID in all Google Sheets nodes\n4. **Gmail** \u2014 Connect your Gmail (OAuth2) account in the 3 email nodes: Send Ticket, Send Waitlist Email, Send Promotion Email\n5. **Slack** \u2014 Connect your Slack account and update the recipient ID in all 3 Slack nodes\n6. **Cancellation** \u2014 Wire the Cancellation Webhook URL into your site with POST body: `{ \"ticket_id\": \"TKT-XXXXXXXX\" }`"
},
"typeVersion": 1
},
{
"id": "55f6eb83-1590-444b-8ac0-209b0126cd51",
"name": "\ud83d\udcca Google Sheets Setup",
"type": "n8n-nodes-base.stickyNote",
"position": [
992,
0
],
"parameters": {
"color": 3,
"width": 400,
"height": 360,
"content": "### \ud83d\udcca Google Sheets Setup\n\nCreate one spreadsheet with **two tabs**:\n\n**Tab 1: Registrations**\nColumns: `Ticket ID` \u00b7 `Name` \u00b7 `Email` \u00b7 `Event` \u00b7 `Venue` \u00b7 `Date` \u00b7 `Seat` \u00b7 `Tier` \u00b7 `PDF URL` \u00b7 `Registered At`\n\n**Tab 2: Waitlist**\nColumns: `Position` \u00b7 `Name` \u00b7 `Email` \u00b7 `Event` \u00b7 `Venue` \u00b7 `Date` \u00b7 `Seat` \u00b7 `Tier` \u00b7 `Waitlisted At`\n\nConnect your Google Sheets account in all Sheets nodes and set the Spreadsheet ID.\n\n\ud83d\udca1 The **Position** column in Waitlist is auto-assigned. The first person added gets position 1, and promotion always picks the lowest position."
},
"typeVersion": 1
},
{
"id": "777015dc-4829-45fc-86c8-8b4a899f6f73",
"name": "\ud83d\udd32 QR Code & Templates",
"type": "n8n-nodes-base.stickyNote",
"position": [
1440,
0
],
"parameters": {
"color": 4,
"width": 420,
"height": 400,
"content": "### \ud83d\udd32 QR Code & Multi-Tier Templates\n\nThe QR code is a **native component** inside your PDF Generator API templates \u2014 not generated externally by this workflow.\n\n**Setup per template (General, VIP, Backstage):**\n1. Open the template in the PDF Generator API editor\n2. Add a **QR Code** component\n3. Set its data source to `{{ ticket_id }}`\n\n**Why 3 templates?**\nEach tier can have a unique design, colour scheme, and perks section while sharing the same data variables. The Switch node routes to the correct template ID automatically.\n\n---\n**Output format:** `URL` \u2014 returns a hosted PDF link (valid 30 days).\nChange to `File` in the PDF Generator API nodes to attach the PDF directly to the email instead."
},
"typeVersion": 1
},
{
"id": "42f4c5db-e16f-43e5-aa33-574c99ae5c22",
"name": "\ud83c\udd70\ufe0f Flow A",
"type": "n8n-nodes-base.stickyNote",
"position": [
432,
1008
],
"parameters": {
"width": 360,
"height": 200,
"content": "### \ud83c\udd70\ufe0f Flow A \u2014 New Registration\n\nTriggered by the **Event Registration Form**.\n\n1. **Check Capacity** \u2014 reads current Registrations from Sheets and compares the row count to `MAX_CAPACITY`\n2. **Event Full? (IF)** \u2014 True \u2192 Waitlist branch; False \u2192 ticket generation branch\n3. **Route by Tier (Switch)** \u2014 sends to the General, VIP, or Backstage path to attach the correct tier perks\n4. **Generate PDF** \u2014 calls PDF Generator API with the tier's template ID; returns a hosted PDF URL (valid 30 days)\n5. **Build & Send Email** \u2014 constructs an HTML email with event details and a download button; sends via Gmail\n6. **Log & Notify** \u2014 appends the registration to the Sheets Registrations tab; posts a Slack alert to the organizer\n7. **Waitlist path** \u2014 if full: appends to Waitlist tab and sends a waitlist confirmation email"
},
"typeVersion": 1
},
{
"id": "bfba4f60-06e1-4062-a3e5-42894746540a",
"name": "\ud83c\udd71\ufe0f Flow B",
"type": "n8n-nodes-base.stickyNote",
"position": [
384,
1488
],
"parameters": {
"width": 416,
"height": 332,
"content": "### \ud83c\udd71\ufe0f Flow B \u2014 Cancellation & Waitlist Promotion\n\nTriggered by a **POST webhook**. Send:\n`POST <webhook-url>` with `{ \"ticket_id\": \"TKT-XXXXXXXX\" }`\n\n1. **Validate** \u2014 checks that `ticket_id` exists and matches the `TKT-XXXXXXXX` format; throws an error if invalid\n2. **Remove Registration** \u2014 updates the matching row in Sheets to `Status: CANCELED`\n3. **Check Waitlist (IF)** \u2014 if Waitlist tab is empty \u2192 sends a cancellation-only Slack alert and ends\n4. **Promote** \u2014 picks the first waitlisted attendee (lowest row), generates their ticket PDF, emails the promotion, logs to Registrations, marks as `PROMOTED` in Waitlist, and sends a Slack alert"
},
"typeVersion": 1
},
{
"id": "ec1295a9-4714-4ea1-a3ee-5d10ba5c33e7",
"name": "\ud83d\udd14 Slack Setup",
"type": "n8n-nodes-base.stickyNote",
"position": [
1920,
0
],
"parameters": {
"color": 7,
"width": 360,
"height": 280,
"content": "### \ud83d\udd14 Slack Notifications\n\nThe workflow sends three types of Slack alerts:\n\n1. **New Registration** \u2014 when a ticket is issued\n2. **Waitlist Promotion** \u2014 when a waitlisted attendee gets promoted\n3. **Cancellation Only** \u2014 when someone cancels and the waitlist is empty\n\n**Setup:** Connect Slack in each notification node and choose your channel (e.g. `#event-tickets`). Remove all Slack nodes if you don't use Slack."
},
"typeVersion": 1
},
{
"id": "c7d8e9f0-a1b2-4c3d-8e5f-6a7b8c9d0e1f",
"name": "\u2699\ufe0f Event Config",
"type": "n8n-nodes-base.stickyNote",
"position": [
2336,
0
],
"parameters": {
"color": 6,
"width": 492,
"height": 340,
"content": "### \u2699\ufe0f Required: Edit Before Running\n\nTwo **Code nodes** contain placeholder template IDs that must be replaced before the workflow will work:\n\n**\"Check Capacity & Prepare Data\"** (Flow A)\n**\"Promote from Waitlist\"** (Flow B)\n\nIn each node, update the `TEMPLATES` object:\n- `'General Admission': YOUR_TEMPLATE_ID`\n- `'VIP': YOUR_TEMPLATE_ID`\n- `'Backstage Pass': YOUR_TEMPLATE_ID`\n\nAlso set `MAX_CAPACITY` to your event size\n(currently `3` \u2014 demo only)."
},
"typeVersion": 1
},
{
"id": "a1b1c1d1-e1f1-1111-a1b1-c1d1e1f11111",
"name": "cluster-form-capacity",
"type": "n8n-nodes-base.stickyNote",
"position": [
864,
1024
],
"parameters": {
"color": 4,
"width": 700,
"height": 220,
"content": "## Form & Capacity Check"
},
"typeVersion": 1
},
{
"id": "a2b2c2d2-e2f2-2222-a2b2-c2d2e2f22222",
"name": "cluster-tier-routing",
"type": "n8n-nodes-base.stickyNote",
"position": [
1664,
768
],
"parameters": {
"color": 5,
"width": 872,
"height": 536,
"content": "## Ticket Tier Routing\nEvent full \u2192 Waitlist. Has spots \u2192 route by tier (General / VIP / Backstage) and attach tier perks."
},
"typeVersion": 1
},
{
"id": "a3b3c3d3-e3f3-3333-a3b3-c3d3e3f33333",
"name": "cluster-pdf-delivery",
"type": "n8n-nodes-base.stickyNote",
"position": [
2672,
912
],
"parameters": {
"color": 3,
"width": 1320,
"height": 252,
"content": "## PDF Generation & Delivery"
},
"typeVersion": 1
},
{
"id": "a4b4c4d4-e4f4-4444-a4b4-c4d4e4f44444",
"name": "cluster-waitlist-reg",
"type": "n8n-nodes-base.stickyNote",
"position": [
2032,
1328
],
"parameters": {
"color": 7,
"width": 764,
"height": 264,
"content": "## Waitlist Registration"
},
"typeVersion": 1
},
{
"id": "a5b5c5d5-e5f5-5555-a5b5-c5d5e5f55555",
"name": "cluster-cancel-validate",
"type": "n8n-nodes-base.stickyNote",
"position": [
816,
1728
],
"parameters": {
"width": 800,
"height": 280,
"content": "## Cancellation & Validation"
},
"typeVersion": 1
},
{
"id": "a6b6c6d6-e6f6-6666-a6b6-c6d6e6f66666",
"name": "cluster-waitlist-check",
"type": "n8n-nodes-base.stickyNote",
"position": [
1664,
1792
],
"parameters": {
"color": 2,
"width": 480,
"height": 216,
"content": "## Waitlist Check"
},
"typeVersion": 1
},
{
"id": "a7b7c7d7-e7f7-7777-a7b7-c7d7e7f77777",
"name": "cluster-promotion",
"type": "n8n-nodes-base.stickyNote",
"position": [
2192,
1696
],
"parameters": {
"color": 6,
"width": 1820,
"height": 444,
"content": "## Waitlist Promotion\nPromotes the first queued attendee: PDF ticket generated, emailed, logged, and removed from waitlist. Waitlist empty \u2192 cancellation-only Slack alert."
},
"typeVersion": 1
},
{
"id": "58926685-e1d2-47a6-b2c4-fdca4e1cfd32",
"name": "Event Registration Form",
"type": "n8n-nodes-base.formTrigger",
"position": [
944,
1104
],
"parameters": {
"path": "ev-reg-+1234567890",
"options": {},
"formTitle": "\ud83c\udfab Event Registration",
"formFields": {
"values": [
{
"fieldLabel": "Full Name",
"placeholder": "Jane Smith",
"requiredField": true
},
{
"fieldType": "email",
"fieldLabel": "Email Address",
"placeholder": "user@example.com",
"requiredField": true
},
{
"fieldLabel": "Event Name",
"placeholder": "Summer Rock Festival 2025",
"requiredField": true
},
{
"fieldLabel": "Venue",
"placeholder": "Madison Square Garden, New York",
"requiredField": true
},
{
"fieldLabel": "Event Date",
"placeholder": "Saturday, July 5, 2025",
"requiredField": true
},
{
"fieldLabel": "Seat Preference",
"placeholder": "Section A, Row 3, Seat 12",
"requiredField": true
},
{
"fieldType": "dropdown",
"fieldLabel": "Ticket Tier",
"fieldOptions": {
"values": [
{
"option": "General Admission"
},
{
"option": "VIP"
},
{
"option": "Backstage Pass"
}
]
},
"requiredField": true
}
]
},
"formDescription": "Register for the event. If the event is at capacity, you'll be added to the waitlist and automatically promoted when a spot opens."
},
"typeVersion": 2.1
},
{
"id": "d296e533-fb0a-406e-96c4-6c67f50846d9",
"name": "Get Current Registrations",
"type": "n8n-nodes-base.googleSheets",
"onError": "continueRegularOutput",
"position": [
1200,
1104
],
"parameters": {
"options": {},
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit#gid=0",
"cachedResultName": "Registrations"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit?usp=drivesdk",
"cachedResultName": "Event Registration System"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.7,
"alwaysOutputData": true
},
{
"id": "9c624c4c-d866-4cbd-88b7-ee2b8ed4a96b",
"name": "Check Capacity & Prepare Data",
"type": "n8n-nodes-base.code",
"onError": "continueRegularOutput",
"position": [
1472,
1104
],
"parameters": {
"jsCode": "// \u2500\u2500\u2500 CONFIG \u2500\u2500\u2500\n// \u26a0\ufe0f Replace these template IDs with your own from PDF Generator API.\nconst TEMPLATES = {\n 'General Admission': 1615251,\n 'VIP': 1615251,\n 'Backstage Pass': 1615251\n};\nconst MAX_CAPACITY = 3; // Set your event capacity here\n\n// \u2500\u2500\u2500 Count current registrations \u2500\u2500\u2500\nconst registrations = $('Get Current Registrations').all();\nconst currentCount = registrations.length;\nconst spotsLeft = MAX_CAPACITY - currentCount;\nconst isFull = spotsLeft <= 0;\n\n// \u2500\u2500\u2500 Form data \u2500\u2500\u2500\nconst form = $('Event Registration Form').item.json;\n\n// \u2500\u2500\u2500 Generate unique ticket ID \u2500\u2500\u2500\nconst chars = 'ABCDEFGHJKLMNPQRSTUVWXYZ23456789';\nlet suffix = '';\nfor (let i = 0; i < 8; i++) {\n suffix += chars[Math.floor(Math.random() * chars.length)];\n}\nconst ticketId = 'TKT-' + suffix;\n\nconst now = new Date();\nconst issuedDate = now.toLocaleDateString('en-US', {\n year: 'numeric', month: 'long', day: 'numeric'\n});\nconst isoTimestamp = now.toISOString();\n\nconst ticketTier = form['Ticket Tier'] || 'General Admission';\nconst tierBadge = ticketTier === 'VIP' ? 'VIP'\n : ticketTier === 'Backstage Pass' ? 'BACKSTAGE'\n : 'GENERAL';\nconst tierColor = ticketTier === 'VIP' ? '#7B2FBE'\n : ticketTier === 'Backstage Pass' ? '#C0392B'\n : '#0f3460';\n\nconst templateId = TEMPLATES[ticketTier] || TEMPLATES['General Admission'];\n\nreturn [{\n json: {\n isFull,\n currentCount,\n spotsLeft,\n maxCapacity: MAX_CAPACITY,\n ticketId,\n attendeeName: form['Full Name'],\n attendeeEmail: form['Email Address'],\n eventName: form['Event Name'],\n venue: form['Venue'],\n eventDate: form['Event Date'],\n seatNumber: form['Seat Preference'],\n ticketTier,\n tierBadge,\n tierColor,\n templateId,\n issuedDate,\n isoTimestamp,\n outputName: `event-ticket-${ticketId}`,\n templateData: {\n ticket_id: ticketId,\n attendee_name: form['Full Name'],\n event_name: form['Event Name'],\n venue: form['Venue'],\n event_date: form['Event Date'],\n seat_number: form['Seat Preference'],\n ticket_tier: tierBadge,\n issued_date: issuedDate\n }\n }\n}];"
},
"typeVersion": 2
},
{
"id": "2127188f-826d-40b7-a025-b61ff40ed508",
"name": "Event Full?",
"type": "n8n-nodes-base.if",
"position": [
1728,
1104
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "condition-full",
"operator": {
"name": "filter.operator.equals",
"type": "boolean",
"operation": "equals"
},
"leftValue": "={{ $json.isFull }}",
"rightValue": true
}
]
}
},
"typeVersion": 2.3
},
{
"id": "a3480aef-d04f-43fb-89bb-e3d5bc7e23d6",
"name": "Route by Ticket Tier",
"type": "n8n-nodes-base.switch",
"position": [
1984,
944
],
"parameters": {
"rules": {
"values": [
{
"outputKey": "General",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "d1e9b926-3756-40f2-86cb-40d79841b542",
"operator": {
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.ticketTier }}",
"rightValue": "General Admission"
}
]
},
"renameOutput": true
},
{
"outputKey": "VIP",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "76777430-fa18-4455-aa6b-2b216666b0fc",
"operator": {
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.ticketTier }}",
"rightValue": "VIP"
}
]
},
"renameOutput": true
},
{
"outputKey": "Backstage",
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "119722f9-a20b-4dd3-a4ef-bc96da6463c0",
"operator": {
"type": "string",
"operation": "equals"
},
"leftValue": "={{ $json.ticketTier }}",
"rightValue": "Backstage Pass"
}
]
},
"renameOutput": true
}
]
},
"options": {}
},
"typeVersion": 3.4
},
{
"id": "03ae8b1b-458a-4f81-9976-8a02bc2752ef",
"name": "General Admission Config",
"type": "n8n-nodes-base.set",
"position": [
2240,
832
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "set-perks-general",
"name": "tierPerks",
"type": "string",
"value": "Access to the main stage area and food court. Doors open 1 hour before showtime."
}
]
},
"includeOtherFields": true
},
"typeVersion": 3.4
},
{
"id": "78d823e6-ca15-4920-87a4-9fe50eef904b",
"name": "VIP Config",
"type": "n8n-nodes-base.set",
"position": [
2240,
992
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "set-perks-vip",
"name": "tierPerks",
"type": "string",
"value": "Priority entry, VIP lounge access, complimentary drinks, and premium viewing area."
}
]
},
"includeOtherFields": true
},
"typeVersion": 3.4
},
{
"id": "d53de589-4c58-4c8b-a619-9a472c1d7893",
"name": "Backstage Pass Config",
"type": "n8n-nodes-base.set",
"position": [
2240,
1152
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "set-perks-backstage",
"name": "tierPerks",
"type": "string",
"value": "All VIP perks plus backstage meet & greet, soundcheck access, and exclusive merchandise."
}
]
},
"includeOtherFields": true
},
"typeVersion": 3.4
},
{
"id": "62ccd0d9-9ae9-468d-863b-ebdc03959344",
"name": "Generate Ticket PDF",
"type": "@pdfgeneratorapi/n8n-nodes-pdf-generator-api.pdfGeneratorApi",
"position": [
2768,
992
],
"parameters": {
"data": "={{ JSON.stringify($json.templateData) }}",
"templateId": {
"__rl": true,
"mode": "id",
"value": "={{ $json.templateId }}"
},
"documentOutput": "url",
"additionalFields": {
"outputName": "={{ $json.outputName }}"
}
},
"credentials": {
"pdfGeneratorApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "7a23c615-f9fe-435c-9432-9c2af341fb41",
"name": "Build Confirmation Email",
"type": "n8n-nodes-base.code",
"position": [
3024,
992
],
"parameters": {
"jsCode": "const pdfData = $input.first().json;\nconst t = $('Check Capacity & Prepare Data').first().json;\nconst TIER_PERKS = {\n 'General Admission': 'Access to the main stage area and food court...',\n 'VIP': 'Priority entry, VIP lounge access...',\n 'Backstage Pass': 'All VIP perks plus backstage meet & greet...'\n};\nconst tierPerks = TIER_PERKS[t.ticketTier] || '';\n\nconst pdfUrl = pdfData.response || '';\nconst headerColor = t.tierColor || '#0f3460';\n\nconst emailHtml = ''\n + '<!DOCTYPE html><html><body style=\"margin:0;padding:0;background:#f4f4f8;font-family:Arial,sans-serif\">'\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\" style=\"padding:24px 0\"><tr><td align=\"center\">'\n + '<table width=\"600\" cellpadding=\"0\" cellspacing=\"0\" style=\"background:#fff;border-radius:12px;overflow:hidden;box-shadow:0 4px 24px rgba(0,0,0,0.12)\">'\n\n // Header\n + '<tr><td style=\"background:' + headerColor + ';padding:36px 30px;text-align:center\">'\n + '<div style=\"font-size:44px;line-height:1\">\ud83c\udfab</div>'\n + '<h1 style=\"color:#fff;margin:10px 0 4px;font-size:24px;font-weight:700\">Registration Confirmed!</h1>'\n + '<span style=\"display:inline-block;background:rgba(255,255,255,0.2);color:#fff;padding:4px 18px;border-radius:20px;font-size:11px;letter-spacing:2px;font-weight:700;margin-top:6px\">'\n + t.tierBadge + '</span>'\n + '</td></tr>'\n\n // Body\n + '<tr><td style=\"padding:32px 40px\">'\n + '<p style=\"font-size:16px;color:#333;margin:0 0 10px\">Hi <strong>' + t.attendeeName + '</strong>,</p>'\n + '<p style=\"color:#555;line-height:1.7;margin:0 0 20px\">Your <strong>' + t.ticketTier + '</strong> registration is confirmed! Your personalized PDF ticket with a unique QR code for entry is ready.</p>'\n\n // Perks box\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\" style=\"background:#f9f9f9;border-left:4px solid ' + headerColor + ';border-radius:6px;margin-bottom:20px\"><tr><td style=\"padding:16px 20px\">'\n + '<p style=\"margin:0 0 4px;font-weight:700;color:' + headerColor + ';font-size:13px\">YOUR ' + t.tierBadge + ' PERKS</p>'\n + '<p style=\"margin:0;color:#555;font-size:14px;line-height:1.6\">' + tierPerks + '</p>'\n + '</td></tr></table>'\n\n // Event details card\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\" style=\"border:2px dashed ' + headerColor + ';border-radius:10px;margin-bottom:24px\"><tr><td style=\"padding:22px\">'\n + '<h2 style=\"color:' + headerColor + ';margin:0 0 14px;font-size:19px\">\ud83c\udfb8 ' + t.eventName + '</h2>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83d\udccd <strong>Venue:</strong> ' + t.venue + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83d\udcc5 <strong>Date:</strong> ' + t.eventDate + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83d\udcba <strong>Seat:</strong> ' + t.seatNumber + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83c\udfab <strong>Ticket ID:</strong> <code style=\"background:#f0f0f0;padding:2px 7px;border-radius:4px;font-size:13px\">' + t.ticketId + '</code></p>'\n + '<p style=\"margin:6px 0;color:#999;font-size:12px\">\ud83d\udcca Spots remaining: ' + (t.spotsLeft - 1) + ' / ' + t.maxCapacity + '</p>'\n + '</td></tr></table>'\n\n // Download button\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\"><tr><td align=\"center\" style=\"padding-bottom:24px\">'\n + '<a href=\"' + pdfUrl + '\" style=\"background:' + headerColor + ';color:#fff;padding:14px 44px;border-radius:8px;text-decoration:none;font-size:15px;font-weight:700;display:inline-block\">\ud83d\udcc4 Download Your Ticket</a>'\n + '</td></tr></table>'\n\n + '<p style=\"color:#999;font-size:12px;text-align:center;margin:0 0 4px\">Your PDF contains a unique QR code for venue entry.</p>'\n + '<p style=\"color:#bbb;font-size:11px;text-align:center;margin:0\">Please have it ready \u2014 printed or on your phone.</p>'\n + '</td></tr>'\n\n // Footer\n + '<tr><td style=\"background:#f8f8f8;padding:16px 30px;text-align:center;border-top:1px solid #eee\">'\n + '<p style=\"color:#bbb;font-size:11px;margin:0\">Ticket generated with <a href=\"https://pdfgeneratorapi.com\" style=\"color:' + headerColor + ';text-decoration:none\">PDF Generator API</a> \u00b7 Automated by <a href=\"https://n8n.io\" style=\"color:' + headerColor + ';text-decoration:none\">n8n</a></p>'\n + '</td></tr>'\n + '</table></td></tr></table></body></html>';\n\nreturn [{\n json: {\n attendeeEmail: t.attendeeEmail,\n emailSubject: `\ud83c\udfab Registration Confirmed: ${t.ticketTier} \u2014 ${t.eventName} (${t.ticketId})`,\n emailHtml,\n pdfUrl,\n ticketId: t.ticketId,\n attendeeName: t.attendeeName,\n eventName: t.eventName,\n venue: t.venue,\n eventDate: t.eventDate,\n seatNumber: t.seatNumber,\n ticketTier: t.ticketTier,\n tierBadge: t.tierBadge,\n isoTimestamp: t.isoTimestamp\n }\n}];"
},
"typeVersion": 2
},
{
"id": "7d90331a-18e2-4525-bf3d-9b60965f69a0",
"name": "Send Ticket to Attendee",
"type": "n8n-nodes-base.gmail",
"position": [
3280,
992
],
"parameters": {
"sendTo": "={{ $json.attendeeEmail }}",
"message": "={{ $json.emailHtml }}",
"options": {},
"subject": "={{ $json.emailSubject }}"
},
"credentials": {
"gmailOAuth2": {
"name": "<your credential>"
}
},
"typeVersion": 2.2
},
{
"id": "a7bf80c6-dae5-4f75-8054-8626b8f31437",
"name": "Log Registration",
"type": "n8n-nodes-base.googleSheets",
"position": [
3552,
992
],
"parameters": {
"columns": {
"value": {
"Tier": "={{ $('Build Confirmation Email').item.json.ticketTier }}",
"ticketID": "={{ $('Build Confirmation Email').item.json.ticketId }}",
"eventName": "={{ $('Build Confirmation Email').item.json.eventName }}",
"atendeeName": "={{ $('Build Confirmation Email').item.json.attendeeName }}"
},
"schema": [
{
"id": "atendeeName",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "atendeeName",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ticketID",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "ticketID",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "eventName",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "eventName",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Tier",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Tier",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Status",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Status",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [
"id"
],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit#gid=0",
"cachedResultName": "Registrations"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit?usp=drivesdk",
"cachedResultName": "Event Registration System"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.7
},
{
"id": "d2588cb2-f8a6-4f4b-a043-f7be01e97eb1",
"name": "Notify: New Registration",
"type": "n8n-nodes-base.slack",
"position": [
3808,
992
],
"parameters": {
"text": "={{ '\ud83c\udfab *New Registration*\\n*' + $('Build Confirmation Email').item.json.tierBadge + '* \u2014 ' + $('Build Confirmation Email').item.json.eventName + '\\n\\n\ud83d\udc64 ' + $('Build Confirmation Email').item.json.attendeeName + '\\n\ud83d\udce7 ' + $('Build Confirmation Email').item.json.attendeeEmail + '\\n\ud83d\udcba ' + $('Build Confirmation Email').item.json.seatNumber + '\\n\ud83c\udf9f `' + $('Build Confirmation Email').item.json.ticketId + '`\\n\ud83d\udcc4 ' + $('Build Confirmation Email').item.json.pdfUrl }}",
"user": {
"__rl": true,
"mode": "id",
"value": "U02P47JDS0J"
},
"select": "user",
"otherOptions": {}
},
"credentials": {
"slackApi": {
"name": "<your credential>"
}
},
"typeVersion": 2.4
},
{
"id": "6bdfc2fe-1ccc-4ea3-99a1-cfb919656a3d",
"name": "Add to Waitlist",
"type": "n8n-nodes-base.googleSheets",
"position": [
2080,
1408
],
"parameters": {
"columns": {
"value": {
"Name": "={{ $json.attendeeName }}",
"TicketID": "={{ $json.ticketId }}",
"atendeeEmail": "={{ $json.attendeeEmail }}"
},
"schema": [
{
"id": "Name",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "TicketID",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "TicketID",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "atendeeEmail",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "atendeeEmail",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "list",
"value": 101672691,
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit#gid=101672691",
"cachedResultName": "Waitlist"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit?usp=drivesdk",
"cachedResultName": "Event Registration System"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.7
},
{
"id": "9bdcebcd-8ab0-4c7e-ad8c-8d6a837ebf19",
"name": "Build Waitlist Email",
"type": "n8n-nodes-base.code",
"position": [
2336,
1408
],
"parameters": {
"jsCode": "const t = $('Check Capacity & Prepare Data').item.json;\nconst headerColor = '#6c757d';\n\nconst emailHtml = ''\n + '<!DOCTYPE html><html><body style=\"margin:0;padding:0;background:#f4f4f8;font-family:Arial,sans-serif\">'\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\" style=\"padding:24px 0\"><tr><td align=\"center\">'\n + '<table width=\"600\" cellpadding=\"0\" cellspacing=\"0\" style=\"background:#fff;border-radius:12px;overflow:hidden;box-shadow:0 4px 24px rgba(0,0,0,0.12)\">'\n\n + '<tr><td style=\"background:' + headerColor + ';padding:36px 30px;text-align:center\">'\n + '<div style=\"font-size:44px;line-height:1\">\u23f3</div>'\n + '<h1 style=\"color:#fff;margin:10px 0 4px;font-size:24px;font-weight:700\">You\\'re on the Waitlist</h1>'\n + '</td></tr>'\n\n + '<tr><td style=\"padding:32px 40px\">'\n + '<p style=\"font-size:16px;color:#333;margin:0 0 10px\">Hi <strong>' + t.attendeeName + '</strong>,</p>'\n + '<p style=\"color:#555;line-height:1.7;margin:0 0 20px\">Unfortunately, <strong>' + t.eventName + '</strong> is currently at full capacity. But don\\'t worry \u2014 you\\'ve been added to the waitlist!</p>'\n + '<p style=\"color:#555;line-height:1.7;margin:0 0 20px\">If a spot opens up, we\\'ll <strong>automatically generate your ticket</strong> and email it to you. No action needed on your end.</p>'\n\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\" style=\"border:2px dashed ' + headerColor + ';border-radius:10px;margin-bottom:24px\"><tr><td style=\"padding:22px\">'\n + '<h2 style=\"color:' + headerColor + ';margin:0 0 14px;font-size:19px\">\ud83d\udccb Your Waitlist Details</h2>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83c\udfb8 <strong>Event:</strong> ' + t.eventName + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83d\udccd <strong>Venue:</strong> ' + t.venue + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83d\udcc5 <strong>Date:</strong> ' + t.eventDate + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83c\udfab <strong>Requested Tier:</strong> ' + t.ticketTier + '</p>'\n + '</td></tr></table>'\n\n + '</td></tr>'\n\n + '<tr><td style=\"background:#f8f8f8;padding:16px 30px;text-align:center;border-top:1px solid #eee\">'\n + '<p style=\"color:#bbb;font-size:11px;margin:0\">Powered by <a href=\"https://pdfgeneratorapi.com\" style=\"color:' + headerColor + ';text-decoration:none\">PDF Generator API</a> \u00b7 <a href=\"https://n8n.io\" style=\"color:' + headerColor + ';text-decoration:none\">n8n</a></p>'\n + '</td></tr>'\n + '</table></td></tr></table></body></html>';\n\nreturn [{\n json: {\n attendeeEmail: t.attendeeEmail,\n emailSubject: `\u23f3 Waitlisted: ${t.eventName} \u2014 We'll notify you when a spot opens`,\n emailHtml\n }\n}];"
},
"typeVersion": 2
},
{
"id": "4b5bc3fa-974d-410a-a911-ac8fc58668fd",
"name": "Send Waitlist Email",
"type": "n8n-nodes-base.gmail",
"position": [
2608,
1408
],
"parameters": {
"sendTo": "={{ $json.attendeeEmail }}",
"message": "={{ $json.emailHtml }}",
"options": {},
"subject": "={{ $json.emailSubject }}"
},
"credentials": {
"gmailOAuth2": {
"name": "<your credential>"
}
},
"typeVersion": 2.2
},
{
"id": "3d4f4409-b987-4a7b-81b3-2cd8d6449b55",
"name": "Cancellation Webhook",
"type": "n8n-nodes-base.webhook",
"position": [
944,
1856
],
"parameters": {
"path": "ev-cancel-+1234567890",
"options": {},
"httpMethod": "POST"
},
"typeVersion": 2.1
},
{
"id": "eaa3024b-9b66-41aa-ba11-f8d70f8addbe",
"name": "Validate Cancellation",
"type": "n8n-nodes-base.code",
"position": [
1200,
1856
],
"parameters": {
"jsCode": "const input = $input.item.json;\nconst ticketId = (input.body && input.body.ticket_id) || input.ticket_id || '';\n\nif (!ticketId || !ticketId.startsWith('TKT-')) {\n throw new Error(`Invalid or missing ticket_id: \"${ticketId}\". Expected format: TKT-XXXXXXXX`);\n}\n\nreturn [{\n json: {\n ticketId\n }\n}];"
},
"typeVersion": 2
},
{
"id": "346ff3fe-3a60-4bc2-bf4e-71d381e43bc3",
"name": "Remove Registration",
"type": "n8n-nodes-base.googleSheets",
"position": [
1472,
1856
],
"parameters": {
"columns": {
"value": {
"Status": "CANCELED",
"ticketID": "={{ $json.ticketId }}"
},
"schema": [
{
"id": "atendeeName",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "atendeeName",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ticketID",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "ticketID",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "eventName",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "eventName",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Tier",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Tier",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Status",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Status",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "row_number",
"type": "number",
"display": true,
"removed": true,
"readOnly": true,
"required": false,
"displayName": "row_number",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [
"ticketID"
],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "update",
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit#gid=0",
"cachedResultName": "Registrations"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit?usp=drivesdk",
"cachedResultName": "Event Registration System"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.7
},
{
"id": "d9dd07c5-f6ff-4723-a340-6b9cf0f70ea1",
"name": "Get Waitlist",
"type": "n8n-nodes-base.googleSheets",
"position": [
1728,
1856
],
"parameters": {
"options": {},
"sheetName": {
"__rl": true,
"mode": "list",
"value": 101672691,
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit#gid=101672691",
"cachedResultName": "Waitlist"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit?usp=drivesdk",
"cachedResultName": "Event Registration System"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.7
},
{
"id": "0340e22d-0ab7-49f3-84fd-d25a58afbf28",
"name": "Waitlist Not Empty?",
"type": "n8n-nodes-base.if",
"position": [
1984,
1856
],
"parameters": {
"options": {},
"conditions": {
"options": {
"version": 2,
"leftValue": "",
"caseSensitive": true,
"typeValidation": "strict"
},
"combinator": "and",
"conditions": [
{
"id": "condition-waitlist",
"operator": {
"name": "filter.operator.gt",
"type": "number",
"operation": "gt"
},
"leftValue": "={{ $input.all().length }}",
"rightValue": 0
}
]
}
},
"typeVersion": 2.3
},
{
"id": "372dd21b-0412-4667-bb30-acabfb284fd1",
"name": "Promote from Waitlist",
"type": "n8n-nodes-base.code",
"position": [
2240,
1776
],
"parameters": {
"jsCode": "// \u2500\u2500\u2500 CONFIG (must match Flow A) \u2500\u2500\u2500\nconst TEMPLATES = {\n 'General Admission': 1615251,\n 'VIP': 1615251,\n 'Backstage Pass': 1615251\n};\n\n// \u2500\u2500\u2500 Get first waitlisted person (lowest row number) \u2500\u2500\u2500\nconst waitlist = $input.all().map(i => i.json);\nwaitlist.sort((a, b) => Number(a.row_number) - Number(b.row_number));\nconst first = waitlist[0];\n\n// \u2500\u2500\u2500 Generate ticket ID for promoted attendee \u2500\u2500\u2500\nconst chars = 'ABCDEFGHJKLMNPQRSTUVWXYZ23456789';\nlet suffix = '';\nfor (let i = 0; i < 8; i++) {\n suffix += chars[Math.floor(Math.random() * chars.length)];\n}\nconst ticketId = 'TKT-' + suffix;\n\nconst now = new Date();\nconst issuedDate = now.toLocaleDateString('en-US', {\n year: 'numeric', month: 'long', day: 'numeric'\n});\nconst isoTimestamp = now.toISOString();\n\n// \u2500\u2500\u2500 Read actual field names as stored in the Waitlist sheet \u2500\u2500\u2500\nconst ticketTier = first.ticketTier || 'General Admission';\nconst tierBadge = ticketTier === 'VIP' ? 'VIP'\n : ticketTier === 'Backstage Pass' ? 'BACKSTAGE'\n : 'GENERAL';\nconst tierColor = ticketTier === 'VIP' ? '#7B2FBE'\n : ticketTier === 'Backstage Pass' ? '#C0392B'\n : '#0f3460';\n\nconst templateId = TEMPLATES[ticketTier] || TEMPLATES['General Admission'];\n\nreturn [{\n json: {\n ticketId,\n attendeeName: first.attendeeName,\n attendeeEmail: first.attendeeEmail,\n eventName: first.eventName,\n venue: first.venue,\n eventDate: first.eventDate,\n seatNumber: first.seatNumber,\n ticketTier,\n tierBadge,\n tierColor,\n templateId,\n issuedDate,\n isoTimestamp,\n waitlistPosition: first.row_number,\n outputName: `event-ticket-promoted-${ticketId}`,\n templateData: {\n ticket_id: ticketId,\n attendee_name: first.attendeeName,\n event_name: first.eventName,\n venue: first.venue,\n event_date: first.eventDate,\n seat_number: first.seatNumber,\n ticket_tier: tierBadge,\n issued_date: issuedDate\n }\n }\n}];"
},
"typeVersion": 2
},
{
"id": "8f6bbf13-880f-4f39-bdca-189335b2c71c",
"name": "Generate Promoted Ticket PDF",
"type": "@pdfgeneratorapi/n8n-nodes-pdf-generator-api.pdfGeneratorApi",
"position": [
2512,
1776
],
"parameters": {
"data": "={{ JSON.stringify($json.templateData) }}",
"templateId": {
"__rl": true,
"mode": "id",
"value": "={{ $json.templateId }}"
},
"documentOutput": "url",
"additionalFields": {
"outputName": "={{ $json.outputName }}"
}
},
"credentials": {
"pdfGeneratorApi": {
"name": "<your credential>"
}
},
"typeVersion": 1
},
{
"id": "a124f738-5c7f-4b2c-b05a-8890fe873191",
"name": "Build Promotion Email",
"type": "n8n-nodes-base.code",
"position": [
2768,
1776
],
"parameters": {
"jsCode": "const pdfData = $input.first().json;\nconst t = $('Promote from Waitlist').first().json;\nconst pdfUrl = pdfData.response || '';\nconst headerColor = t.tierColor || '#0f3460';\n\nconst emailHtml = ''\n + '<!DOCTYPE html><html><body style=\"margin:0;padding:0;background:#f4f4f8;font-family:Arial,sans-serif\">'\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\" style=\"padding:24px 0\"><tr><td align=\"center\">'\n + '<table width=\"600\" cellpadding=\"0\" cellspacing=\"0\" style=\"background:#fff;border-radius:12px;overflow:hidden;box-shadow:0 4px 24px rgba(0,0,0,0.12)\">'\n\n + '<tr><td style=\"background:' + headerColor + ';padding:36px 30px;text-align:center\">'\n + '<div style=\"font-size:44px;line-height:1\">\ud83c\udf89</div>'\n + '<h1 style=\"color:#fff;margin:10px 0 4px;font-size:24px;font-weight:700\">Great News \u2014 You\\'re In!</h1>'\n + '<span style=\"display:inline-block;background:rgba(255,255,255,0.2);color:#fff;padding:4px 18px;border-radius:20px;font-size:11px;letter-spacing:2px;font-weight:700;margin-top:6px\">'\n + t.tierBadge + '</span>'\n + '</td></tr>'\n\n + '<tr><td style=\"padding:32px 40px\">'\n + '<p style=\"font-size:16px;color:#333;margin:0 0 10px\">Hi <strong>' + t.attendeeName + '</strong>,</p>'\n + '<p style=\"color:#555;line-height:1.7;margin:0 0 20px\">A spot just opened up at <strong>' + t.eventName + '</strong> and you\\'ve been promoted from the waitlist! Your <strong>' + t.ticketTier + '</strong> ticket is ready.</p>'\n\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\" style=\"border:2px dashed ' + headerColor + ';border-radius:10px;margin-bottom:24px\"><tr><td style=\"padding:22px\">'\n + '<h2 style=\"color:' + headerColor + ';margin:0 0 14px;font-size:19px\">\ud83c\udfb8 ' + t.eventName + '</h2>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83d\udccd <strong>Venue:</strong> ' + t.venue + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83d\udcc5 <strong>Date:</strong> ' + t.eventDate + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83d\udcba <strong>Seat:</strong> ' + t.seatNumber + '</p>'\n + '<p style=\"margin:6px 0;color:#555;font-size:14px\">\ud83c\udfab <strong>Ticket ID:</strong> <code style=\"background:#f0f0f0;padding:2px 7px;border-radius:4px;font-size:13px\">' + t.ticketId + '</code></p>'\n + '</td></tr></table>'\n\n + '<table width=\"100%\" cellpadding=\"0\" cellspacing=\"0\"><tr><td align=\"center\" style=\"padding-bottom:24px\">'\n + '<a href=\"' + pdfUrl + '\" style=\"background:' + headerColor + ';color:#fff;padding:14px 44px;border-radius:8px;text-decoration:none;font-size:15px;font-weight:700;display:inline-block\">\ud83d\udcc4 Download Your Ticket</a>'\n + '</td></tr></table>'\n\n + '<p style=\"color:#999;font-size:12px;text-align:center;margin:0\">Your PDF contains a unique QR code for venue entry.</p>'\n + '</td></tr>'\n\n + '<tr><td style=\"background:#f8f8f8;padding:16px 30px;text-align:center;border-top:1px solid #eee\">'\n + '<p style=\"color:#bbb;font-size:11px;margin:0\">Ticket generated with <a href=\"https://pdfgeneratorapi.com\" style=\"color:' + headerColor + ';text-decoration:none\">PDF Generator API</a> \u00b7 Automated by <a href=\"https://n8n.io\" style=\"color:' + headerColor + ';text-decoration:none\">n8n</a></p>'\n + '</td></tr>'\n + '</table></td></tr></table></body></html>';\n\nreturn [{\n json: {\n attendeeEmail: t.attendeeEmail,\n emailSubject: `\ud83c\udf89 You're in! ${t.ticketTier} ticket for ${t.eventName} (${t.ticketId})`,\n emailHtml,\n pdfUrl,\n ticketId: t.ticketId,\n attendeeName: t.attendeeName,\n eventName: t.eventName,\n venue: t.venue,\n eventDate: t.eventDate,\n seatNumber: t.seatNumber,\n ticketTier: t.ticketTier,\n tierBadge: t.tierBadge,\n isoTimestamp: t.isoTimestamp,\n waitlistPosition: t.waitlistPosition\n }\n}];"
},
"typeVersion": 2
},
{
"id": "8d5cf466-0c85-4b91-a8af-2038e7b2d47e",
"name": "Send Promotion Email",
"type": "n8n-nodes-base.gmail",
"position": [
3024,
1776
],
"parameters": {
"sendTo": "={{ $('Get Waitlist').item.json.atendeeEmail }}",
"message": "={{ $json.emailHtml }}",
"options": {},
"subject": "={{ $json.emailSubject }}"
},
"credentials": {
"gmailOAuth2": {
"name": "<your credential>"
}
},
"typeVersion": 2.2
},
{
"id": "e0951b6e-c28c-45e9-a2df-07966546a441",
"name": "Log Promoted Registration",
"type": "n8n-nodes-base.googleSheets",
"position": [
3280,
1776
],
"parameters": {
"columns": {
"value": {
"ticketID": "={{ $('Get Waitlist').item.json.TicketID }}",
"atendeeName": "={{ $('Get Waitlist').item.json.Name }}"
},
"schema": [
{
"id": "atendeeName",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "atendeeName",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "ticketID",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "ticketID",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "eventName",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "eventName",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Tier",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Tier",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Status",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Status",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultName": "Registrations"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit?usp=drivesdk",
"cachedResultName": "Event Registration System"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.7
},
{
"id": "b81f9948-3596-4bb7-9ff6-b7e8e7cbba0f",
"name": "Remove from Waitlist",
"type": "n8n-nodes-base.googleSheets",
"position": [
3552,
1776
],
"parameters": {
"columns": {
"value": {
"Status": "PROMOTED",
"TicketID": "={{ $('Get Waitlist').item.json.TicketID }}"
},
"schema": [
{
"id": "Name",
"type": "string",
"display": true,
"required": false,
"displayName": "Name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "TicketID",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "TicketID",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "atendeeEmail",
"type": "string",
"display": true,
"required": false,
"displayName": "atendeeEmail",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Status",
"type": "string",
"display": true,
"required": false,
"displayName": "Status",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "row_number",
"type": "number",
"display": true,
"removed": true,
"readOnly": true,
"required": false,
"displayName": "row_number",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [
"TicketID"
],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {},
"operation": "update",
"sheetName": {
"__rl": true,
"mode": "list",
"value": 101672691,
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit#gid=101672691",
"cachedResultName": "Waitlist"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1L0FOdxFBRwviw24jf_HlYPkpv6W5_N0thJH1LJraR3s/edit?usp=drivesdk",
"cachedResultName": "Event Registration System"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"name": "<your credential>"
}
},
"typeVersion": 4.7,
"alwaysOutputData": true
},
{
"id": "6a1b00bb-fcbb-4253-92d9-b36ed4ab46e9",
"name": "Notify: Promotion",
"type": "n8n-nodes-base.slack",
"position": [
3808,
1776
],
"parameters": {
"text": "={{ '\ud83c\udf89 *Waitlist Promotion*\\n\\nA cancellation opened a spot. The following attendee has been pr
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
gmailOAuth2googleSheetsOAuth2ApipdfGeneratorApislackApi
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
Automate event registration with capacity management, a waitlist, and multi-tier PDF ticket generation using PDF Generator API. When attendees register, the workflow checks available spots, routes by tier (General / VIP / Backstage), generates a PDF ticket with a QR code, emails…
Source: https://n8n.io/workflows/14491/ — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
Generate personalized concert ticket PDFs with QR codes using PDF Generator API, then email them to attendees, log sales to Google Sheets, and notify organizers via Slack — all triggered from a simple
Form Trigger, @Pdfgeneratorapi/N8N Nodes Pdf Generator Api, Gmail +2
Stop chasing blurry receipts and manually typing expense data. This workflow creates an intelligent, "snap-and-submit" reimbursement pipeline that hosts photos via UploadToURL, extracts deep data via
Form Trigger, N8N Nodes Uploadtourl, HTTP Request +3
This template automates internal equipment and supply purchase requests for operations, HR, and IT teams. Requests are submitted via a built-in n8n form, automatically approved for small amounts, and
Form Trigger, Google Sheets, Slack +1
This workflow is triggered when the contact form is submitted.
Form Trigger, Slack, Google Sheets +2
n8n Recruitment. Uses gmailTrigger, openAi, googleSheets, gmail. Event-driven trigger; 20 nodes.
Gmail Trigger, OpenAI, Google Sheets +4
