This workflow follows the HTTP Request → Notion recipe pattern — see all workflows that pair these two integrations.
The workflow JSON
Copy or download the full n8n JSON below. Paste it into a new n8n workflow, add your credentials, activate. Full import guide →
{
"name": "WorkFlow 11",
"nodes": [
{
"parameters": {
"httpMethod": "POST",
"path": "{{WEBHOOK_PATH_WF11}}",
"options": {
"responseData": ""
}
},
"type": "n8n-nodes-base.webhook",
"typeVersion": 2.1,
"position": [
-176,
-16
],
"id": "d31418f4-d61b-4169-920d-8ec950d7df9c",
"name": "Documentation"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "a91b73e3-5366-498a-98f2-967593ea01fd",
"name": "New.Id",
"value": "={{ $json.body.data.id }}",
"type": "string"
},
{
"id": "5a181939-7d89-4c9f-b60b-56a4b2916022",
"name": "New.Code",
"value": "={{ $json.body.data.properties[\"Code \"].title[0].text.content }}",
"type": "string"
},
{
"id": "f6af742b-e899-4325-a3e2-8da4b0710684",
"name": "New.Version",
"value": "={{ $json.body.data.properties[\"Version d'usage\"].rich_text[0].text.content }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
48,
-16
],
"id": "493386e0-da76-4754-87ff-080f3bf15949",
"name": "New Doc"
},
{
"parameters": {
"resource": "databasePage",
"operation": "getAll",
"databaseId": {
"__rl": true,
"value": "{{NOTION_DB_ID_MASTER_DOCUMENTATIONS_ENTREPRISE}}",
"mode": "list",
"cachedResultName": "Master Documentations Entreprise",
"cachedResultUrl": "https://www.notion.so/{{NOTION_DB_ID_MASTER_DOCUMENTATIONS_ENTREPRISE}}"
},
"filterType": "manual",
"filters": {
"conditions": [
{
"key": "Mise \u00e0 jours|checkbox",
"condition": "equals",
"checkboxValue": true
}
]
},
"options": {}
},
"type": "n8n-nodes-base.notion",
"typeVersion": 2.2,
"position": [
288,
-32
],
"id": "68a76823-76e5-4c14-bc4f-2c2327c219e4",
"name": "Get Document",
"retryOnFail": true,
"credentials": {
"notionApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"conditions": {
"options": {
"caseSensitive": true,
"leftValue": "",
"typeValidation": "strict",
"version": 2
},
"conditions": [
{
"id": "82216235-7c9a-4202-9a72-dae33b04ec0c",
"leftValue": "={{ $json.property_code }}",
"rightValue": "={{ $('New Doc').item.json.New.Code }}",
"operator": {
"type": "string",
"operation": "equals"
}
}
],
"combinator": "and"
},
"options": {}
},
"type": "n8n-nodes-base.if",
"typeVersion": 2.2,
"position": [
528,
-32
],
"id": "afd6a66b-f593-4a6f-8b98-f44435344d71",
"name": "If"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "2083ac49-eee1-4750-94ce-fca0a723528b",
"name": "Last.id",
"value": "={{ $json.id }}",
"type": "string"
},
{
"id": "cacb4dee-94cb-407b-90f3-a2cec996700b",
"name": "Last.TypeCode",
"value": "={{ $json.property_type_code }}",
"type": "string"
},
{
"id": "447617a9-0437-4276-9fd4-3beb79f114f1",
"name": "Last.Shape",
"value": "={{ $json.property_shape }}",
"type": "array"
},
{
"id": "3f8cba94-7997-4681-b485-6730335c6b30",
"name": "Last.niveau",
"value": "={{ $json.property_niveau }}",
"type": "string"
},
{
"id": "c4c3e9af-6483-48da-bf2d-d8f9bc239d07",
"name": "Last.VersionUsage",
"value": "={{ $json.property_version_d_usage }}",
"type": "string"
},
{
"id": "881bd715-a5b2-4d6f-9d07-1eafe6071e7e",
"name": "Last.Document",
"value": "={{ $json.property_documents }}",
"type": "string"
},
{
"id": "0e8039d9-028a-4be6-a06b-bb15de69ee1a",
"name": "Last.Type",
"value": "={{ $json.property_type }}",
"type": "string"
},
{
"id": "faa1253f-1be3-44d6-a924-1a7f7a4a14ea",
"name": "Last.Secteur",
"value": "={{ $json.property_secteur }}",
"type": "string"
},
{
"id": "9d3998e5-510d-4a30-b02d-72ecf5791234",
"name": "Last.Titre",
"value": "={{ $json.property_titre }}",
"type": "string"
},
{
"id": "227ad996-9d2d-4be2-b0aa-85d2ea323d85",
"name": "Last.fichiers_parents",
"value": "={{ $json.property_fichiers_parents }}",
"type": "boolean"
},
{
"id": "2bbd7a16-8ad1-4273-b834-ca9cbb377fd9",
"name": "Last.Fournisseurs",
"value": "={{ $json.property_fournisseurs }}",
"type": "string"
},
{
"id": "e7553f3e-46ef-4b7c-a47a-42804001f882",
"name": "property_alliages_sp_cifiques",
"value": "={{ $json.property_alliages_sp_cifiques }}",
"type": "array"
},
{
"id": "0f8bd8dc-8339-4400-9663-c9e453532200",
"name": "Last.ICon",
"value": "={{ $json.property_icon }}",
"type": "string"
},
{
"id": "5bb57d2b-27fb-466a-8ef7-dda953b0f098",
"name": "Last.Metaux",
"value": "={{ $json.property_m_taux }}",
"type": "array"
},
{
"id": "8e4528c8-12a8-4830-bf4c-4aa13a3b4dcc",
"name": "Last.date_de_cr_ation",
"value": "={{ $json.property_date_de_cr_ation }}",
"type": "object"
},
{
"id": "ef8a7d65-2a13-4312-b402-0a38741c7bf8",
"name": "New.Version",
"value": "={{ $('New Doc').item.json.New.Version }}",
"type": "string"
},
{
"id": "c970cfa3-037a-4760-81f6-e584055dbbcd",
"name": "New.Id",
"value": "={{ $('New Doc').item.json.New.Id }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
288,
192
],
"id": "8e9d18ab-ee45-4625-8333-8904f12c1b8c",
"name": "Last Doc"
},
{
"parameters": {
"assignments": {
"assignments": [
{
"id": "5132da66-4593-44d0-8004-70b1bc2d1cc1",
"name": "ID_Typedeproc\u00e9d\u00e9",
"value": "={{ $json.properties[\"Types de proc\u00e9d\u00e9\"].id }}",
"type": "string"
},
{
"id": "30ceb869-aa9b-4065-9a11-04fd98669469",
"name": "ID_Groupe Fichiers",
"value": "={{ $json.properties[\"Groupe Fichiers\"].id }}",
"type": "string"
},
{
"id": "61485a59-d938-4892-9f42-14917e8ea882",
"name": "Identifiant_Responsable",
"value": "={{ $json.properties.Responsable.id }}",
"type": "string"
},
{
"id": "7fe7aa40-03e2-4e21-903d-fb9f44056217",
"name": "ID_New",
"value": "={{ $('New Doc').item.json.New.Id }}",
"type": "string"
},
{
"id": "e2a5cc2a-a13f-4f98-9dc6-9c05c38ee636",
"name": "Groupe_Fichiers",
"value": "={{ $('Get Document').item.json.property_groupe_fichiers.join(\", \") }}",
"type": "string"
},
{
"id": "49a2c38b-4a48-459d-9553-d525f201f3ea",
"name": "types_de_process",
"value": "={{ $('Get Document').item.json.property_types_de_proc_d.join(\", \") }}",
"type": "string"
},
{
"id": "ee01039b-5bfa-4b51-8382-43c68cbf8b12",
"name": "Responsable",
"value": "={{ $('Get Document').item.json.property_responsable[0] }}",
"type": "string"
},
{
"id": "70a7a12e-5eb1-40cc-8852-17d8719fb520",
"name": "Accr\u00e9ditations_ID",
"value": "={{ $json.properties[\"Accr\u00e9ditations\"].id }}",
"type": "string"
},
{
"id": "275a169e-f952-47db-99a4-120ad72e51cf",
"name": "Accr\u00e9ditation",
"value": "={{ $('Get Document').item.json.property_accr_ditations.join(\", \") }}",
"type": "string"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.set",
"typeVersion": 3.4,
"position": [
1024,
-16
],
"id": "427709ee-8380-48e6-a5a0-9918b224b245",
"name": "ID Properties"
},
{
"parameters": {
"resource": "databasePage",
"operation": "get",
"pageId": {
"__rl": true,
"value": "={{ $json.id }}",
"mode": "id"
},
"simple": false
},
"type": "n8n-nodes-base.notion",
"typeVersion": 2.2,
"position": [
800,
-16
],
"id": "09f88889-b64b-4d04-8864-148bd03c4be5",
"name": "Get Last Doc",
"executeOnce": true,
"retryOnFail": true,
"credentials": {
"notionApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {},
"type": "n8n-nodes-base.merge",
"typeVersion": 3.2,
"position": [
48,
192
],
"id": "68ab4318-7de8-452f-8f56-7003c7018287",
"name": "Merge"
},
{
"parameters": {
"method": "PATCH",
"url": "=https://api.notion.com/v1/pages/{{ $json.ID_New }}",
"authentication": "predefinedCredentialType",
"nodeCredentialType": "notionApi",
"sendBody": true,
"specifyBody": "json",
"jsonBody": "={{ \n JSON.stringify((() => {\n // Pr\u00e9parer les relations (null si vide)\n const Responsable = $json.Responsable && $json.Responsable !== \"\"\n ? [{ id: $json.Responsable }]\n : null;\n \n const Fichier = $json.Groupe_Fichiers && $json.Groupe_Fichiers !== \"\"\n ? ($json.Groupe_Fichiers.includes(\",\")\n ? $json.Groupe_Fichiers.split(\", \").map(id => ({ id: id.trim() }))\n : [{ id: $json.Groupe_Fichiers }])\n : null;\n \n const Process = $json.types_de_process && $json.types_de_process !== \"\"\n ? ($json.types_de_process.includes(\",\")\n ? $json.types_de_process.split(\", \").map(id => ({ id: id.trim() }))\n : [{ id: $json.types_de_process }])\n : null;\n \n const Accreditation = $json.Accr\u00e9ditation && $json.Accr\u00e9ditation !== \"\"\n ? ($json.Accr\u00e9ditation.includes(\",\")\n ? $json.Accr\u00e9ditation.split(\", \").map(id => ({ id: id.trim() }))\n : [{ id: $json.Accr\u00e9ditation }])\n : null;\n \n // Construire le payload dynamiquement\n const properties = {};\n \n if (Responsable !== null) {\n properties['b[xj'] = { relation: Responsable };\n }\n \n if (Process !== null) {\n properties['%3Cqu%3A'] = { relation: Process };\n }\n \n if (Fichier !== null) {\n properties['NymW'] = { relation: Fichier };\n }\n \n if (Accreditation !== null) {\n properties['iQxB'] = { relation: Accreditation };\n }\n \n return { properties };\n })())\n}}",
"options": {
"batching": {
"batch": {
"batchSize": 1
}
}
}
},
"type": "n8n-nodes-base.httpRequest",
"typeVersion": 4.2,
"position": [
1216,
-16
],
"id": "de2c45ee-9398-4c7d-b69b-1d0dfc57e26e",
"name": "Mise \u00e0 jours",
"retryOnFail": true,
"credentials": {
"notionApi": {
"name": "<your credential>"
}
},
"onError": "continueErrorOutput",
"notes": "{{NOTION_ID_GENERIC_03}}\nResponsable : b[xj\nGroupe fichier : NymW\nType de proc\u00e9d\u00e9 : '%3Cqu%3A'"
},
{
"parameters": {
"resource": "databasePage",
"operation": "update",
"pageId": {
"__rl": true,
"value": "={{ $json.New.Id }}",
"mode": "id"
},
"propertiesUi": {
"propertyValues": [
{
"key": "Type Code|select",
"selectValue": "={{ $json.Last.TypeCode }}"
},
{
"key": "Shape|multi_select",
"multiSelectValue": "={{ $json.Last.Shape }}"
},
{
"key": "Niveau|select",
"selectValue": "={{ $json.Last.niveau }}"
},
{
"key": "Derni\u00e8re Version|rich_text",
"textContent": "={{ $json.New.Version }}"
},
{
"key": "Documents|select",
"selectValue": "={{ $json.Last.Document }}"
},
{
"key": "Type|select",
"selectValue": "={{ $json.Last.Type }}"
},
{
"key": "Secteur|select",
"selectValue": "={{ $json.Last.Secteur }}"
},
{
"key": "Titre|rich_text",
"textContent": "={{ $json.Last.Titre }}"
},
{
"key": "=M\u00e9taux|multi_select",
"multiSelectValue": "={{ $json.Last.Metaux }}"
},
{
"key": "Alliages sp\u00e9cifiques|multi_select",
"multiSelectValue": "={{ $json.property_alliages_sp_cifiques }}"
},
{
"key": "Fournisseurs|select",
"selectValue": "={{ $json.Last.Fournisseurs }}"
},
{
"key": "Fichiers Parents|checkbox",
"checkboxValue": "={{ $json.Last.fichiers_parents }}"
},
{
"key": "Mise \u00e0 jours|checkbox"
},
{
"key": "Date de cr\u00e9ation|date",
"includeTime": false,
"date": "={{ $json.Last.date_de_cr_ation.start }}"
}
]
},
"options": {
"icon": "={{ $json.Last.ICon }}"
}
},
"type": "n8n-nodes-base.notion",
"typeVersion": 2.2,
"position": [
528,
192
],
"id": "05eeebdc-432a-4b3e-b62e-56cd786e5a3b",
"name": "Fill my new page",
"executeOnce": true,
"retryOnFail": true,
"credentials": {
"notionApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"resource": "databasePage",
"operation": "update",
"pageId": {
"__rl": true,
"value": "={{ $('Get Last Doc').item.json.id }}",
"mode": "id"
},
"propertiesUi": {
"propertyValues": [
{
"key": "Archiver ?|checkbox",
"checkboxValue": true
},
{
"key": "Mise \u00e0 jours|checkbox"
}
]
},
"options": {}
},
"type": "n8n-nodes-base.notion",
"typeVersion": 2.2,
"position": [
1024,
176
],
"id": "f4ecee12-07f3-4cdf-b4b2-c69244388279",
"name": "Update Archivage Last Doc",
"retryOnFail": true,
"executeOnce": true,
"credentials": {
"notionApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"operation": "archive",
"pageId": {
"__rl": true,
"value": "={{ $json.id }}",
"mode": "id"
}
},
"type": "n8n-nodes-base.notion",
"typeVersion": 2.2,
"position": [
1216,
176
],
"id": "223cc1ad-b4ee-414e-8ce1-a9c27b418fd4",
"name": "Archive Last Doc",
"credentials": {
"notionApi": {
"name": "<your credential>"
}
}
},
{
"parameters": {
"content": "## Webhook Notion de la base de donn\u00e9e Master documentation entreprise et settings\n**Double click** to edit me. [Guide](https://docs.n8n.io/workflows/sticky-notes/)",
"height": 240,
"width": 448,
"color": 6
},
"type": "n8n-nodes-base.stickyNote",
"position": [
-256,
-112
],
"typeVersion": 1,
"id": "4f16d80b-eaf9-439b-95c0-4686a8bc2fc7",
"name": "Sticky Note"
},
{
"parameters": {
"content": "## Scan du document et agr\u00e9gation des donn\u00e9es\n**Double click** to edit me. [Guide](https://docs.n8n.io/workflows/sticky-notes/)",
"height": 240,
"width": 752,
"color": 5
},
"type": "n8n-nodes-base.stickyNote",
"position": [
192,
-112
],
"typeVersion": 1,
"id": "a0d604c1-2ebc-4dea-85f5-798510880f60",
"name": "Sticky Note1"
},
{
"parameters": {
"content": "## Mise \u00e0 jours du nouveau document\n**Double click** to edit me. [Guide](https://docs.n8n.io/workflows/sticky-notes/)",
"height": 240,
"width": 976,
"color": 4
},
"type": "n8n-nodes-base.stickyNote",
"position": [
-32,
128
],
"typeVersion": 1,
"id": "1319e039-65e3-458f-8a21-4d53afe35391",
"name": "Sticky Note2"
},
{
"parameters": {
"content": "## Mise \u00e0 jours du nouveau document\n**Double click** to edit me. [Guide](https://docs.n8n.io/workflows/sticky-notes/)",
"height": 240,
"width": 512,
"color": 4
},
"type": "n8n-nodes-base.stickyNote",
"position": [
944,
-112
],
"typeVersion": 1,
"id": "7d960b1a-7eab-429c-95ca-d6122f458c3f",
"name": "Sticky Note3"
},
{
"parameters": {
"content": "## Destruction de l'ancien document\n**Double click** to edit me. [Guide](https://docs.n8n.io/workflows/sticky-notes/)",
"height": 240,
"width": 512,
"color": 3
},
"type": "n8n-nodes-base.stickyNote",
"position": [
944,
128
],
"typeVersion": 1,
"id": "7694ff14-bca5-4036-bc34-a3df8d49dd57",
"name": "Sticky Note4"
}
],
"connections": {
"Documentation": {
"main": [
[
{
"node": "New Doc",
"type": "main",
"index": 0
}
]
]
},
"New Doc": {
"main": [
[
{
"node": "Get Document",
"type": "main",
"index": 0
},
{
"node": "Merge",
"type": "main",
"index": 1
}
]
]
},
"Get Document": {
"main": [
[
{
"node": "If",
"type": "main",
"index": 0
}
]
]
},
"If": {
"main": [
[],
[
{
"node": "Get Last Doc",
"type": "main",
"index": 0
},
{
"node": "Merge",
"type": "main",
"index": 0
}
]
]
},
"Last Doc": {
"main": [
[
{
"node": "Fill my new page",
"type": "main",
"index": 0
}
]
]
},
"ID Properties": {
"main": [
[
{
"node": "Mise \u00e0 jours",
"type": "main",
"index": 0
}
]
]
},
"Get Last Doc": {
"main": [
[
{
"node": "ID Properties",
"type": "main",
"index": 0
},
{
"node": "Update Archivage Last Doc",
"type": "main",
"index": 0
}
]
]
},
"Merge": {
"main": [
[
{
"node": "Last Doc",
"type": "main",
"index": 0
}
]
]
},
"Fill my new page": {
"main": [
[]
]
},
"Mise \u00e0 jours": {
"main": [
[]
]
},
"Update Archivage Last Doc": {
"main": [
[
{
"node": "Archive Last Doc",
"type": "main",
"index": 0
}
]
]
}
},
"active": true,
"settings": {
"executionOrder": "v1"
},
"versionId": "3ba86595-b0ac-41fa-9e22-c7320c712c77",
"meta": {
"templateCredsSetupCompleted": true
},
"id": "P47d8FI4GwMMuPLr",
"tags": [
{
"updatedAt": "2025-10-07T22:35:26.042Z",
"createdAt": "2025-10-07T22:35:26.042Z",
"id": "RquBntK103e9IXsC",
"name": "Documentation"
},
{
"updatedAt": "2025-10-07T22:35:30.605Z",
"createdAt": "2025-10-07T22:35:30.605Z",
"id": "E4NU5T8v7Wxa8N7i",
"name": "Mise \u00e0 jours"
}
]
}
Credentials you'll need
Each integration node will prompt for credentials when you import. We strip credential IDs before publishing — you'll add your own.
notionApi
Pro
For the full experience including quality scoring and batch install features for each workflow upgrade to Pro
About this workflow
WorkFlow 11. Uses notion, httpRequest. Webhook trigger; 17 nodes.
Source: https://github.com/WealthFinPilot/notion-qms-platform/blob/main/exports/workflows/wf-11-mise-a-jour-documentation.json — original creator credit. Request a take-down →
Related workflows
Workflows that share integrations, category, or trigger type with this one. All free to copy and import.
This workflow automates the entire lifecycle of a service-based client, combining four distinct business flows into a single view: Intake Leads: Receives a webhook from your form builder, validates th
Airtable, Notion, Google Calendar +3
This solution enables you to manage all your Notion and Todoist tasks from different workspaces as well as your calendar events in a single place. This is 2 way sync with partial support for recurring
Redis, HTTP Request, Notion
